JetStream T2500G Series

L2 Managed Switches

MODEL: T2500G-10TS (TL-SG3210) Datasheet

-Gigabit Ethernet connections on all ports provide full speed of data transferring

-Selective RJ45 console port and Micro-USB console port

-Advanced security features include IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm

Control, DHCP Snooping, 802.1X and Radius Authentication

-L2/L3/L4 QoS and IGMP snooping optimize voice and video applications

-Web/CLI managed modes, SNMP, RMON and Dual Image bring abundant management features

Highlights

Overview

TP-Link’s JetStream T2500G series L2 managed switches are designed exclusively for the networking

needs of growing businesses, with an extensive suite of management features and security functions

available. These TP-Link products are cost-eective for small and medium-sized businesses, making

them ideal networking solutions.

Abundant L2 Features

T2500G series switches support a complete lineup of L2 features, including 802.1Q tag VLAN, QinQ,

Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol and 802.3x Flow Control function.

In addition, the switches provide advanced features for network maintenance, including LoopBack

Detection and Cable Diagnostics. IGMP Snooping ensures intelligent forwarding of the multicast

stream to only the appropriate subscribers, while IGMP throttling & ltering restricts each subscriber on

a port level to prevent unauthorized multicast access.

Secure Networking

The T2500G series switches provide IP-MAC-Port Binding, Port Security, Storm control and DHCP

Snooping which protect against broadcast storms, ARP attacks, etc. It integrates some typical DoS

attacks to select. You can protect these attacks more easily ever than before. In addition, the Access

Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying

packets based on source and destination MAC address, IP address, TCP/UDP ports and even VLAN ID.

Moreover, the switch supports 802.1X authentication, which is used in conjunction with a RADIUS

server to require some authentication information before access to the network is allowed. Guest

VLAN function supports to enable the non-802.1X clients to access the specic network resource.

To integrate voice, data and video service on one network, T2500G series switches apply rich QoS

policies. Administrator can designate the priority of the trac based on a variety of means including

Port Priority, 802.1p Priority and DSCP Priority, to ensure that voice and video are always clear, smooth

and jitter free. In conjunction with the Voice VLAN the switch supports, the voice applications will

operate with much smoother performance.

Advanced QoS Features

T2500G series switches are easy to use and manage. It supports various user-friendly standard man-

agement features, such as intuitive web-based Graphical User Interface (GUI) or industry-standard

Command Line Interface (CLI), either administration trac can be protected through SSL or SSH

encryptions. SNMP (v1/v2c/v3) and RMON support enables the switch to be polled for valuable status

information and send traps on abnormal events. And it also supports Dual Image, which provides

reduced down-time for the switches, when the image is being upgraded / downgraded.

Enterprise Level Management Features

Product Picture

Model T2500G-10TS (TL-SG3210)

General

Standard and Protocols

IEEE 802.3i 10BASE-T Ethernet

IEEE 802.3u 100BASE-TX/FX

IEEE 802.3ab 1000BASE-T

IEEE 802.3z 1000BASE-X

IEEE 802.3x Flow control

IEEE 802.3ad Link Aggregation

IEEE 802.1d Spanning Tree Protocol (STP)

IEEE 802.1s Rapid Spanning Tree (RSTP)

IEEE 802.1w Multiple Spanning Tree (MSTP)

IEEE 802.1q VLAN

IEEE 802.1x Port-based Network Access Control

IEEE 802.1p QoS

Network Media

100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum

100m)

1000BASE-X: MMF, SMF

Interface 8 10/100/1000Mbps RJ45 ports

2 Gigabit SFP Slots

Performance

Power Supply 20Gbps

Fan Quantity 14.9Mpps

MAC Address Table 8K

3DFNHW%XƬHU 4Mbit

Jumbo Frame 9KB

Physical &

Environment

Power Supply 100-240V AC, 50/60Hz

Maximum Power

Consumption (220V/50Hz) 8.38W

Dimensions (W × D × H) 11.6 × 7.1 × 1.7 in. (294 × 180 × 44 mm)

Fan Quantity Fanless

Operating Temperature 0°C~40°C (32°F~104°F)

Storage Temperature -40°C~70°C (-40°F~158°F)

Operating Humidity 10% ~ 90%RH, non-condensing

Storage Humidity 5%~90%RH, non-condensing

&HUWLƮFDWLRQ CE, FCC

Hardware Features & Performance

Specications

L2 Features

• Link Aggregation

- static link aggregation

- 802.3ad LACP

- Up to 8 aggregation groups, containing 8 ports

per group

• Spanning Tree Protocol

- 802.1D STP

- 802.1w RSTP

- 802.1s MSTP

- STP Security: Loop back detection, TC Protect,

BPDU Filter/Protect, Root Protect

• Loopback Detection

• Flow Control

- 802.3x Flow Control

- HOL Blocking Prevention

• Port Mirroring

- One-to-One

- Many-to-One

- Flow-Based

- Tx/Rx/Both

• LLDP, LLDP-MED

• DHCP VLAN Relay

• L2PT

L2 Multicast

• 256 IPv4,IPv6 shared IGMP groups

• IGMP Snooping

- IGMP v1/v2/v3 Snooping

- IGMP Fast Leave

- Multicast VLAN

- IGMP Snooping Querier

- Limited IP Multicast

- Static Multicast Forwarding

• MLD Snooping

- MLD v1/v2 Snooping

- MLD Snooping Querier

- Fast Leave

- Limited IP Multicast

- Static Multicast Forwarding

VLAN

• VLAN Group

- Max. 4K VLAN Groups

• 802.1Q tag VLAN

• MAC VLAN

• Protocol VLAN

• VLAN VPN (QinQ)

• GVRP

QoS

• 802.1p CoS/DSCP priority

• 4 priority queues

• Queue scheduling

- SP (Strict Priority)

- WRR (Weighted Round Robin)

- SP+WRR

• Bandwidth Control

- Port/Flow based Rating Limiting

• Smoother Performance

r$FWLRQVIRUưRZV

- Mirror (to supported interface)

- Redirect (to supported interface)

- Rate Limit

- QoS Remark

• Voice VLAN

ACL

• Supports up to 64 entries

• MAC ACL

- Source MAC

- Destination MAC

- VLAN ID

- User Priority

- EtherType

• Standard IP ACL

- Source IP

- Destination IP

• ACL apply to Port/VLAN

• Extended IP ACL

- Source IP

- Destination IP

- Fragment

- IP Protocol

- TCP Flag

- TCP/UDP Port

- DSCP/IP TOS

Software Features

Security

• AAA

• DHCP Snooping

• IP-MAC-Port Binding

• ARP Inspection

• Static/Dynamic Port Security

- Up to 64 MAC addresses per port

• Broadcast/Multicast/Unicast Storm Control

- kbps/ratio/pps control mode

• IP/Port/MAC based access control

• DoS Defend

• 802.1X

- Port based authentication

- MAC(Host) based authentication

- Guest VLAN

- Support Radius authentication and accountability

• Port Isolation

• Secure web management through HTTPS with

SSLv3/TLS1.0

• Secure Command Line Interface(CLI)

management with SSHv1/SSHv2

• PPPoE

Management

• Web-based GUI

• Command Line Interface(CLI) through console

port, telnet

• SNMPv1/v2c/v3

• SNMP Trap/Inform

• RMON (1,2,3,9 groups)

• DHCP Option82

• CPU Monitoring

• Cable Diagnostics

• Access Control

• SNTP

• System Log

• Dual Image

• IPv6 Management

MIBs

• MIB II (RFC1213)

• Interface MIB (RFC2233)

• Ethernet Interface MIB (RFC1643)

• Bridge MIB (RFC1493)

• P/Q-Bridge MIB (RFC2674)

• RMON MIB (RFC2819)

• RMON2 MIB (RFC2021)

• Radius Accounting Client MIB (RFC2620)

• Radius Authentication Client MIB (RFC2618)

• Remote Ping, Traceroute MIB (RFC2925)

• Support TP-Link private MIBs

www.tp-link.com

Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or

registered trademarks of their respective holders. Copyright @ 2016 TP-Link Technologies Co., Ltd. All rights reserved.
