www.tp-link.com
Features：
150Mbps Wireless N ADSL2+
Modem Router
Description：
All-in-One: ADSL2+ modem, NAT router, 4-port switch and
wireless N access point in one device provides an one-stop
networking solution
Wireless N speed up to 150Mbps
Parental Control allows parents or administrators to establish
restricted access policy for children or sta
Bandwidth Control allows administrators to determine how much
bandwidth is allotted to each PC
Ethernet WAN (EWAN) oers another broadband connectivity
option for connecting to Cable, VDSL or Fiber modems
Easy Setup Assistant with multi-language support provides quick
& hassle-free installation1
Wi-Fi On/O button allows users to simply turn their wireless
radio on or o
WPS button allows users to easily set up a WPA encrypted secure
connection
6000V Lightning Protection helps your device to avoid the
damage of tough thunderstorms
Port VLAN binds specic LAN ports to PVCs for an enjoyable IPTV
experience
TD-W8950N
The TD-W8950N Wireless N ADSL2+ Modem Router is an All-in-One device that combines the functions of a high-speed DSL modem, a 4-Port
10/100Mbps NAT router and a wireless access point. It is designed to give you a one-stop solution to acquire and share high-speed Internet access
over a wired/wireless network. Supporting the latest ADSL standards, the TD-W8950N brings with it much higher speed than a dial-up connection
without tying up the phone line. Compiling with the IEEE 802.11n, users will get up to 15X the speed and 5X the range of conventional 11g products.
Now you can enjoy more kinds of bandwidth consuming applications like HD video streaming wirelessly, from anywhere in your entire home or even
the yard.
1The Easy Setup Assistant utility supports Windows 8/7/Vista/XP/2000 operating system at present.
www.tp-link.com
Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are
trademarks or registered trademarks of their respective holders. Copyright @ 2014 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
TD-W8950N
150Mbps Wireless N ADSL2+ Modem Router
Specifications：
External Power Supply
IEEE Standards
ADSL2 Standards
ADSL Standards
Antenna Type
Antenna Gain
Dimensions ( W x D x H )
ADSL2+ Standards
Button
Interface
1 10/100Mbps RJ45 WAN/LAN Port
3 10/100Mbps RJ45 LAN Ports
1 RJ11 Port
1 Power On/O Switch
1 WPS button
1 Wi-Fi On/O button
9VDC/0.85A
IEEE 802.3, 802.3u
Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT)
ITU-T G.992.2(G.Lite)
ITU-T G.994.1
ITU-T G.992.3 (G.dmt.bis)
ITU-T G.992.4 (G.lite.bis)
ITU-T G.992.5
7.1 x 4.9 x 1.4 in. (181 x 125 x 36mm)
Omni directional, Fixed
5dBi
EIRP
Wireless Functions
Wireless Security
Frequency
Wireless Standards
Wireless Speeds
ATM/PPP Protocols
Advanced Features
VPN Passthrough
Quality of Service QoS Remarking based on IPP/ToS, DSCP, 802.1p
ATM QoS, Trac Control (IP QoS)
PPTP, L2TP, IPSec Passthrough
ATM Forum UNI3.1/4.0,
PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516),
IPoA (RFC1577/2225),
MER\IPoE (RFC 1483 Routed),
Bridge (RFC1483 Bridge),
PVC - Up to 8 PVCs
Parental Control
Trac Shaping (ATM QoS), UBR, CBR, VBR-rt, VBR-nrt;
Dynamic Host Conguration Protocol (DHCP), DHCP Relay, DHCP Reservation;
Network Address Translation (NAT), Port Mapping (Grouping);
VLAN, Static Routing, RIP v1/v2 (optional);
DNS Relay, DDNS, IGMP Snooping V1/2, IGMP Multicast, UPnP
HARDWARE FEATURES
SOFTWARE FEATURES
IEEE 802.11n, 802.11g, 802.11b
Up to 150Mbps (dynamic)
2.4-2.4835GHz
<20dBm (EIRP)
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption
Wireless MAC Filtering
WIRELESS FEATURES
www.tp-link.com
Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are
trademarks or registered trademarks of their respective holders. Copyright @ 2014 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
TD-W8950N
150Mbps Wireless N ADSL2+ Modem Router
Security
IPv6
Certication
System Requirements
Environment
Management
IPv6 and IPv4 dual stack
NAT Firewall, SPI Firewall, MAC/IP/Packet/Application/URL Filtering, Denial of Service
(DoS), SYN Flooding, Ping of Death
Web-Based Conguration (HTTP), Remote Management, Telnet Management, Command
Line Interface,
SSL for TR-069, SNMP v1/2c, SNMP over EOC, Web-Based Firmware Upgrade, CWMP
(TR-069), Diagnostic Tools
CE, RoHS
Microsoft® Windows 8/7/Vista/XP, MAC® OS, NetWare®, UNIX® or Linux
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Diagram:
SOFTWARE FEATURES
OTHERS
Online Gaming
Video and Audio Streaming
Wi-Fi Phone
150Mbps Wireless N USB Adapter
TL-WN721N
150Mbps Wireless N PCI Adapter
TL-WN751N
150Mbps Wireless N
ADSL2+ Modem Router
TD-W8950N
150Mbps Wireless N
ADSL2+ Modem Router
TD-W8950N
www.tp-link.com
Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are
trademarks or registered trademarks of their respective holders. Copyright @ 2014 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
150Mbps Wireless N ADSL2+ Modem Router
TD-W8950N
Package: Related Products:
- 150Mbps Wireless N ADSL2+ Modem Router
TD-W8950N
- External Splitter
- RJ-11 Telephone Cable
- RJ-45 Ethernet Cable
- Quick Installation Guide
- Resource CD
- Power Adapter
-150Mbps Wireless N USB Adapter
TL-WN721N
- 150Mbps Mini Wireless N USB Adapter
TL-WN723N
-150Mbps Wireless N PCI Adapter
TL-WN751ND
