48-Port 10/100Mbps

Rackmount Switch

MODEL: TL-SF1048 Datasheet

-48 10/100Mbps RJ45 ports

-Innovative energy-ecient technology saves power

-Supports MAC address self-learning and auto MDI/MDIX

-Standard 19-inch rack-mountable steel case

Highlights

Overview

The TL-SF1048 10/100Mbps Switch is designed to meet the needs of the most demanding workgroup

and departmental connectivity requirements. All 48 ports support auto MDI/MDIX, no need to worry

about the cable type, simply plug and play. Moreover, with the innovative energy-ecient technology,

TL-SF1048 can save power consumption and 80% of the packaging material can be recycled, making

it an eco-friendly solution for your business network.

This new generation TL-SF1048 10/100Mbps Switch features the latest innovative energy-ecient

technologies that can greatly expand your network capacity with much less power. It automatically

adjusts power consumption according to the link status and cable length to limit the carbon footprint

of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials.

Besides, 80% of the packaging material can be recycled.

High Performance

Featuring non-blocking switching architecture，TL-SF1048 forwards and lters packets at full

wire-speed for maximum throughput. And IEEE 802.3x ow control for Full Duplex mode and

backpressure for Half Duplex mode alleviate the trac congestion and make TL-SF1048 work reliably.

Easy to Use

The auto features of this Fast Ethernet switch make installation plug and play and hassle-free. No

conguring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on

each port senses the link speed of a network device (10, 100Mbps) and intelligently adjusts for

compatibility and optimal performance.

TP-Link Green Technology

Product Picture

Model TL-SF1048

Standards IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

Forwarding Mode Store and Forward

Interface

48*10/100Mbps RJ45 ports

Auto Negotiation

Auto MDI/MDIX

Switch Capacity 9.6 Gbps

MAC Address Table 8 K

Packet Forwarding Rate 7.14Mpps

Advanced Features Green Technology

802.3x Flow Control

Max Power Consumption (220V/50Hz) 9.9W

LEDS Power, 100Mbps, Link/Act

Power Supply 100-240V, 50/60Hz

Dimensions 17.3*7.1*1.7 in. (440*180*44 mm)

&HUWLƮFDWLRQV CE, FCC, RoHS

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10% ~ 90%RH, non-condensing

Storage Humidity: 5%~90%RH, non-condensing

Product Model Description

TL-SF1048 48-Port 10/100Mbps Rackmount Switch

Features & Performance

Specications

Ordering Information
