300Mbps High Gain Wireless USB Adapter

7106506495 REV7.0.0

Quick

Installation

Guide

MODEL NO. TL-WN822N

Connect to a Computer

1 2 Install Driver and Utility

Insert the CD.

Browse the CD, go to TL-WN822N > Mac OS

X Driver, unzip the Mac OS X version.zip file

and run the Installer.

3Join a Wireless Network

For Mac OS X

uninstall.commandInstaller.pkg

SHELL

Follow the wizard to complete the installation.

b.

a.

c.

Note: You can also download the driver and utility at

http://www.tp-link.com.

Option 1: Via TP-LINK Utility Option 2: Via Wi-Fi Protected Setup (WPS)

a. Click (TP-LINK Wireless Configuration

Utility) on the menu bar.

b. Select your Wi-Fi network and enter the Wi-Fi

password when prompted.

a. Press the WPS button on your router.

b. In 2 minutes, press and hold the WPS button on

the adapter until the WPS Progress screen appears.

c. When you are prompted “WPS Protocol Finished!”,

click OK.

Fri 5:14 PM

TP-LINK_TEST_Device

TP-LINK_0903

TP-LINK_0001

TP-LINK_XXXX

Join Other Network

WPS

Open Wireless Utility

USB-WiFi: On

Turn USB-WiFi Off

Connect the adapter to a USB port on your

computer using the USB cable provided.

WPS

Connect to a Computer

1

For Windows

Note: In Windows XP, a Found New Hardware Wizard

window will appear when the adapter is detected.

Please click Cancel.

This USB Adapter can only be powered by computers that

comply with Limited Power Source (LPS).

2Install Driver and Utility

Insert the CD and run the Autorun.exe from

the pop-up Autoplay window.

Select TL-WN822N and click Install Driver,

then follow the InstallShield Wizard to

complete the installation.

Notes:

1. You can also download the driver and utility at

http://www.tp-link.com.

2. In some operating systems, the CD screen will pop up

automatically. Otherwise, run the CD manually.

a.

b.

3Join a Wireless Network

Option 2: Via TP-LINK Utility

Select your Wi-Fi network from the utility window

and click Connect. The symbol indicates a

successful connection.

Network Name(SSID)

Channel

Signal

Security

2 (2.4G)

5 (2.4G)

11 (2.4G)

None

WPA/WPA2-Personal

None

TP-LINK_0001

TP-LINK_0903

TP-LINK_TEST_Device

6 (2.4G)

TP-LINK_XXXX

Connect automatically

WPA/WPA2-Personal

Connect

Status WPS Profile AdvancedNetwork

TP-LINK_0001

Network Na

TP-LINK_XX

Connect the adapter to a USB port on your

computer using the USB cable provided.

Option 3: Via Wi-Fi Protected Setup (WPS)

a. Press the WPS button on your router.

c. When you are prompted “Successfully connected

to the network by WPS!”, click OK.

b. In 2 minutes, press and hold the WPS button on

the adapter until the configuring screen appears.

For more information, please visit our website

http://www.tp-link.com

©2016 TP-LINK

Click or (Network icon) on the task bar,

select your Wi-Fi network, and click Connect.

Note: In Windows XP, you need to close the TP-LINK Utility

before using the Windows Wireless Utility.

Option 1: Via Windows Wireless Utility

Networks

Connect automatically Connect

√

Wi-Fi

TP-LINK_XXXX

TP-LINK_TEST_Device

TP-LINK_0001

Note: During the installation, select TP-LINK Wireless

Configuration Utility and Driver if you want to use

TP-LINK Utility and WPS function.

Setup Wizard

Browse CD EXIT

TL-WN823N

TL-WN822N

Install Driver

User Guide

TL-WN821N
