TL WR1043ND(UN) 3.0

Tl-Wr1043Nd(Un) 3.0 TL-WR1043ND(UN)_3.0 TL-WR1043ND(UN)_3.0 doc down res static.tp-link.com 3:

2016-08-01

: Tp-Link Tl-Wr1043Nd(Un) 3.0 TL-WR1043ND(UN)_3.0 doc down_res

Open the PDF directly: View PDF PDF.
Page Count: 6

Highlights
 Fast Wi-Fi – Wireless N speed up to 450Mbps makes it ideal for video streaming,
online gaming and VoIP
 Gigabit ports–All Gigabit ports ensure ultimate transfer speeds
 USB Port – Easily shares printers, les or media with your friends or family locally or
over the Internet
 Easily setup – WPA encrypted secure connection at a push of the WPS button
 WDS – wireless bridge provides seamless bridging to expand your wireless network
 Bandwidth Control– IP based bandwidth control allows administrators to determine
how much bandwidth is allotted to each PC
450Mbps Wireless N
Gigabit Router
TL-WR1043ND
 Blazing Fast Wireless Speed – Wireless speeds up to
450Mbps
 Gigabit Wired Speed – All Gigabit ports ensure
ultrafast data transfer speeds
 Hardware NAT function – The NAT WAN to LAN
throughput can achieve up to 800Mbps+ allowing
users to unleash the gull potential of their networks
 Ultimate Range & Reliable Wi-Fi – High-powered
ampliers ensure continuous Wi-Fi signal to all your
devices while boosting widespread converage
throughout your very large home
 3 Omni Directional Antennas – 3 detachable antennas
provide maximum Omni-directional wireless
coverage
 IP QoS – Advanced QoS automatically recognizes &
prioritizes streaming & gaming applications
Speed Wi-Fi Range Reliability
Features
450Mbps Wireless N Gigabit Router
TL-WR1043ND
 USB Ports for Fast Sharing – With the USB port, you
can access and share a printer as well as your les
and media locally. Via the router’s FTP server, you can
also have access to your les & media with
networked devices remotely
 Built-in Print Server – Supports wireless printing from
multiple computers (works in conjunction with a USB
Printer)
 Built-in Media Server – Allows users to play music,
video and view photos
 3-Step Quick Installation – Easy Setup Assistant
supporting multiple languages provides a quick &
hassle free installation
 Fast Encryption – Easy one-touch WPA wireless
security encryption with the WPS button
 Power On/O – Convenient power saving
Easy Sharing Ease of Use Security
Features
 Easy Bandwidth Management – IP-based Bandwidth
Control makes it easier for you to manage the
bandwidth of connected devices
 VPN Support – Secure access to your home or oce
network from remote devices
 Encryptions for Secure Network – WPA-PSK/WPA2- PSK
encryptions provide active defense against security
threats for user networks
450Mbps Wireless N Gigabit Router
TL-WR1043ND
Hardware Wireless
Gigabit Ethernet
Connect to computers,
TVs and game consoles
Gigabit Ethernet
Connect to DSL, Fiber
or Cable modem
WPS/Reset
USB 2.0 Port
Power On/O
Power
 External Power Supply: 12VDC / 1.5A
 Antenna: 5dBi*3 Detachable Omni Directional (RP-SMA)
 Dimensions (W x D x H): 8.9 x 5.6 x 1.2in. (225 x 141 x 30mm)
 Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
 Frequency: 2.4-2.4835GHz
 Signal Rate: 11n: Up to 450Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
 EIRP: <20dBm(EIRP)
 Reception Sensitivity: 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
 Wireless Function: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless
Statistics
 Wireless Security: 64/128/152-bit WEP, WPA / WPA2,WPA-PSK / WPA2-PSK
· Guest Network: 2.4GHz guest network × 1
Specications
450Mbps Wireless N Gigabit Router
TL-WR1043ND
Package Contents
· 450Mbps Wireless N Gigabit Router
TL-WR1043ND
· 3 detachable Omni directional antennas
· Power Supply Unit
· Resource CD
· Quick Installation Guide
Related Products:·
· 300Mbps Wireless N USB Adapter
TL-WN821N
· 300Mbps Wireless N PCI Adapter
TL-WN951N
· ADSL2+ Modem Router
TD-8816
Software
 WAN Type: Dynamic IP/Static IP/PPPoE/
PPTP(Dual Access)/L2TP(Dual Access)/BigPond
 DHCP: Server, Client, DHCP Client List, Address Reservation
 Quality of Service: WMM, Bandwidth Control
 Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
 Dynamic DNS: DynDns, Comexe, NO-IP
 VPN Pass-Through: PPTP, L2TP, IPSec (ESP Head)
 Access Control: Parental Control, Local Management Control, Host List, Access
Scheule,Rule Management
 Firewall Security: DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
 USB Sharing: Support Storage Sharing, FTP Server, Media Server, Print Server
· Protocols: Supports IPv4 and IPv6
 Certication: CE, FCC, RoHS
 System Requirements: Microsoft Windows 8/7/Vista/XP/2000, MAC OS,
NetWare, UNIX or Linux.
 Environment: Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Others
Specications
450Mbps Wireless N Gigabit Router
TL-WR1043ND
Specications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies CO., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specications may be reproduced in any form or by any means or used to make any derivative such as translation,
transformation, or adaptation without permission from TP-LINK Technologies CO., Ltd.
For more information, please visit
http://www.tp-link.com/en/products/details/cat-9_TL-WR1043ND.html#overview
or scan the QR code left
