TL WR940N V6 Datasheet
2017-05-18
: Tp-Link Tl-Wr940N V6 Datasheet TL-WR940N_V6_Datasheet
Open the PDF directly: View PDF
.
Page Count: 5
450 Mbps, the Fastest
11N Router
450Mbps
Wireless N Router
TL-WR940N Multi-mode5dBi Antennas
450Mbps
Wireless Speed
Highlights
TP-Link 450Mbps Wireless N Router TL-WR940N
The Best Choice on 11N
Enjoy reliable Wi-Fi with the TL-WR940N. The Wireless N router creates
strong Wi-Fi connections for devices throughout your home. Its 3 x 3 MIMO
technology strengthens your wireless signal, and the fast Ethernet ports
create high-speed wired connections for lag-free gaming and streaming.
Wireless N Speed & Range
Complying with the IEEE 802.11n standard, TL-WR940N can establish a
wireless network and get up to 18X the speed and 6X the range of
conventional 11g products. Also, with transmission rates up to 450Mbps.
WAN Port
Connect to Internet
Wi-Fi/
WPS
Reset
Power Power
On/O
LAN Ports
Connect to Computers, TVs and Game Consoles
TabletSmartphone Laptop DesktopGame Console
LAN
Reliability
· Intuitive Web UI– Ensures quick and simple installation without
hassle
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android or iOS device
· Guest Network – Keep your main network secure by creating a
separate network for friends and visitors
· Access Control – Establish a whitelist or blacklist to allow or
block certain devices from accessing the internet
· Parental Controls – Manage when and how children devices can
access the internet
· Encryptions for Secure Network – WPA-PSK/WPA2- PSK
encryptions provide active protection against security threats
Ease of Use Security
· Wireless N Speed – 450Mbps Wi-Fi speed meets your daily
internet needs
· 802.11n – Backward compatible with 802.11b/g products
· Easy Bandwidth Management – Bandwidth Control allocates
necessary speed of each connected device to ensure quality
of multimedia streaming
Features
TP-Link 450Mbps Wireless N Router TL-WR940N
Hardware
· Ethernet Ports: 4 10/100Mbps LAN Ports, 1 10/100Mbps WAN Port
· Buttons: Power On/O Button, Reset Button, Wi-Fi/WPS Button
· Antennas: 3 xed Omni Directional Antennas
· External Power Supply: 9VDC / 0.6A
· Dimensions (W x D x H): 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
Wireless
· Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
· Frequency: 2.4-2.4835GHz
· Signal Rate:
11n: Up to 450Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
· Reception Sensitivity:
450M: -68dBm@10% PER
216M: -70dBm@10% PER
130M: -78dBm@10% PER
54M: -74dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -93dBm@8% PER
· Wireless Function: Enable/Disable Wireless Radio, WMM,
Wireless Statistics
· Wireless Security: WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Specications
TP-Link 450Mbps Wireless N Router TL-WR940N
WAN Port
Wi-Fi/
WPS
Power Power
On/O
Reset LAN Ports
Specications
· Certication
CE, FCC, RoHS, Wi-Fi
· System Requirements
Microsoft Windows 10/8.1/8/7/Vista/XP/2000/NT/98SE, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
· Environment
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
450Mbps Wireless N Router TL-WR940N
Power Adapter
RJ-45 Ethernet Cable
Quick Installation Guide
OthersSoftware
· Working Modes: Wireless Router, Range Extender, Access Point
· WAN Type: Dynamic IP, Static IP, PPPoE, PPTP(Dual Access), L2TP(Dual
Access), Bigpond
· DHCP: Server, DHCP Client List, Address Reservation
· Quality of Service: WMM, Bandwidth Control
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, Comexe, NO-IP
· Access Control: Parental Controls, Local Management Control, Host list,
Access Schedule, Rule Management
· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· Management: Access Control, Local Management, Remote Management
· Guest Network: 2.4GHz guest network
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2017 TP-Link Technologies Co., Ltd. All rights reserved.
TP-Link Technologies Co., Ltd.
Building 24 (oors 1, 3, 4, 5) and 28 (oors 1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China
www.tp-link.com
For more information, please visit
http://www.tp-link.com/en/products/details/TL-WR940N.html
or scan the QR code left
www.tp-link.com
TP-Link 450Mbps Wireless N Router TL-WR940N
