TP-LINK Smart Switch TL-SL2218 is equipped with 16 10/100Mbps RJ45 ports, 2
10/100/1000Mbps RJ45 ports and 2 combo SFP slots. These switches provide high perfor-
mance, enterprise-level QoS, useful security strategies and rich layer 2 management
features.
TP-LINK smart switch TL-SL2218 is a cost-eective product solution for the small and
medium business. TL-SL2218 has useful security features. The Storm Control feature
protects against broadcast, multicast and unknown unicast storm. Quality of Service (QoS,
L2 to L4) provides enhanced trac management capabilities to move your data smoother
and faster. Anymore, the easy-to-use web management interfaces, along with CLI, SNMP
and RMON, mean faster setup and conguration with less downtime. For workgroup and
departments requiring cost-sensitive layer 2 switch and gigabit capability, TP-LINK Smart
Switch TL-SL2218 provides you the ideal access-edge solution.
Overview
Datasheet
www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
TL-SL2218
16-Port 10/100Mbps + 2-Port Gigabit
Smart Switch
TP-LINK
TL-SL2218
TP-LINK
16-Port 10/100Mbps + 2-Port Gigabit
Smart Switch
Advanced QoS Features
To integrate voice, data and video service on one network, the switch applies rich
QoS policies. Administrator can designate the priority of the trac based on a variety
of means including Port Priority, 802.1P Priority and DSCP Priority, to ensure that
voice and video are always clear, smooth and jitter free.
Abundant Layer 2 features
For more application of layer 2 switches, TL-SL2218 supports a complete lineup of
layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring,
STP/RSTP/MSTP, LACP and 802.3x Flow Control function. Any more, the switches
provide advanced features for network maintenance, such as Loop Back Detection,
Cable Diagnostics and IGMP Snooping. IGMP snooping ensures the switch intelli-
gently forward the multicast stream only to the appropriate subscribers while IGMP
throttling & ltering restrict each subscriber on a port level to prevent unauthorized
multicast access.
Enterprise Level Management Features
TL-SL2218 is easy to use and manage. It supports various user-friendly standard
management features, such as intuitive web-based Graphical User Interface(GUI).
SNMP (v1/v2c/v3) and RMON support enables the switch to be polled for valuable
status information and send traps on abnormal events.
Layer 2 Features
Link Aggregation Control
Protocol (LACP)
Static Link Aggregation
512 VLANs
Port Isolation
STP/RSTP/MSTP
IGMP Snooping
Quality of Service
4 priority queues
Support IEEE 802.1P
DSCP QoS
Rate limit feature
Security Strategies
Port Security
Access Control List(L2~L4 ACL)
Storm Control
SSL and SSH encryptions
DHCP Filtering
Management
Web-based GUI
Command Line Interface
SNMP v1/v2c/v3
RMON (1, 2, 3, 9 group)
Datasheet
www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
24 / 7
Global technical support
Details:http://www.tp-link.com/
support/Localesupport.asp
German/Austrian/Swiss users are
not included
www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
Specifications
Datasheet
TL-SL2218
16
2
2(Combo)
100-240VAC, 50/60Hz
0
CE, FCC
17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm), 19-inch Rack mount Steel Case, 1U Height
7.2Gbps
5.4Mpps
8k
2.5Mb
9KB
Product Picture
Model
Physical Features
Connector
Power Supply
FAN Quantity
Certications
Dimensions (W × D × H)
Environment
Performance
Swtich Capacity
Forwarding Rate
MAC Address Table
Package Buer Memory
Jumbo Frame
TL-SL2218
Hardware Features & Performance
Software Features
10/100Mbps
RJ45 Ports
10/100/1000Mbps
RJ45 Ports
Gigabit SFP
Slots
Operating Temperature: 0°C~40°C (32°F~104°F); Storage Temperature: -40°C~70°C (-40°F~158°F);
Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing
L2 Switching Features
Link Aggregation
– Support 802.3ad LACP
– Support static link aggregation
– Up to 6 aggregation groups, containing 4 ports per
group
Spanning Tree Protocol(STP)
– IEEE 802.1D Spanning Tree Protocol
– IEEE 802.1W Rapid Spanning Tree Protocol
– IEEE 802.1S Multiple Spanning Tree Protocol
– STP Security: Loop back detection, TC Protect, BPDU
Filter/Protect, Root Protect
Multicast
– Support IGMP Snooping v1/v2/v3, up to 256 groups
– Support multicast VLANs, IGMP Immediate Leave,
Unknown IGMP Throttling, IGMP Filtering, Static
Multicast IP
VLAN
– Support IEEE802.1Q with 512 VLANs simultaneously
(out of 4K VIDs)
IEEE 802.3x ow control for Full Duplex mode and
backpressure for Half Duplex mode
www.tp-link.com Copyright © 2013 TP-LINK Technologies Co., Ltd. All rights reserved.
Datasheet
Ordering Information
Quality of Service (QoS)
Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
Voice VLAN assure voice applications much smoother
performance
Advanced Security Strategies
Support Broadcast, Multicast and Unknown unicast Storm
Control
Static/Dynamic Port Security (MAC-based)
Access Control List (ACL)-L2~L4 package ltering based on
source and destination MAC address, IP address, TCP/UDP
ports
SSL and SSH encryptions
Management
Support Web-based GUI management mode
Support Command Line Interface(CLI) through telnet
management mode
SNMP v1/v2c/v3
RMON (1, 2, 3, 9 groups)
DHCP/BOOTP Client
CPU Monitoring
Port Mirroring (Many to One)
Cable Diagnostics feature
Ping/Tracert feature
System Log
Ethernet Protocols
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX/FX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-X
IEEE 802.3x Flow control
IEEE 802.1p QoS
IEEE 802.1q VLANs / VLAN tagging
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1W Rapid Spanning Tree (RSTP)
IEEE 802.1S Multiple Spanning Tree (MSTP)
MIBs
MIB II (RFC1213)
Interface MIB (RFC2233)
Ethernet Interface MIB (RFC1643)
Bridge MIB (RFC1493)
P/Q-Bridge MIB (RFC2674)
RMON MIB (RFC2819)
RMON2 MIB (RFC2021)
Remote Ping, Traceroute MIB (RFC2925)
Support TP-LINK private MIBs
Host Switch
Product Model
TL-SL2218
Router
Product Model
TL-ER6120
TL-ER5120
SFP Modules
Product Model
TL-SM311LS
TL-SM311LM
TL-SM321A
TL-SM321B
Media Converter
Product Model
MC210CS
MC200CM
MC220L
MC1400
Description
Description
SafeStream Gigabit Dual-WAN VPN Router
Gigabit Load Balance Broadband Router
Description
Gigabit SFP module, Single-mode, LC interface, Up to 10km distance
Gigabit SFP module, Multi-mode, LC interface, Up to 550m distance
Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1550nm/RX:1310nm, 10km
Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1310nm/RX:1550nm, 10km
Description
16-Port 10/100Mbps + 2-Port Gigabit Smart Switch
Gigabit single-mode SC SFP Transceiver, up to 15Km, chassis mountable
Gigabit multi-mode SC SFP Transceiver, up to 550m, chassis mountable
Gigabit SFP slot supporting mini-GBIC modules, chassis mountable
14-slot power supply chassis for TP-LINK Media Converter, 19-inch rack-mountable
