UH700

Description：

USB 3.0 7-Port Hub

Features：

USB 3.0 ports oer transfer speeds of up to 5Gbps, 10 times faster than USB 2.0

7 data transfer ports make switching between devices unnecessary

Supports hot plugging

No driver required

Plug and play

The UH700 USB Hub is a great choice to expand the USB ports of your computer for data transfer when you need to connect

USB drives, USB mice, printers or other devices simultaneously. Equipped with USB 3.0 ports, UH700 provides a data transfer

rate of up to 5Gbps, 10 times faster than USB 2.0.

www.tp-link.com

Typical Applications：

Dimensions 6.5 x 2.6 x 0.7 in. (165 x 65.5 x 17.5 mm)

Output Interface 7 USB 3.0 Standard A

Input Interface 1 USB 3.0 Micro B

Chipset VIA VL812 Chipset with Latest Firmware

Supported Systems Windows, Mac OS X and Linux systems

ANTENNA FEATURES

Specifications：

CE, FCC, RoHS

Package Contents

Certication

USB 3.0 7-Port Hub UH700

12V & 2.5A Power Adapter

1-Meter USB 3.0 Cable

Quick Installation Guide

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

UH700

USB 3.0 7-Port Hub

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names

are trademarks or registered trademarks of their respective holders. Copyright @ 2014 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.

USB Drive Printer Mouse

USB 3.0 Ports

Provides transfer rates of up to 5Gbps,

10 times faster than USB 2.0.

Power Adapter PC

Connect your PC to the USB Hub

using the included USB cable
