Use and Care

Central Air Conditioning

22-5200-01-0901 (EN)

© 2001 American Standard Inc. All Rights Reserved 2 22-5200-01-0901 (EN)

Contents

How It Works ........................................ 3

Maintenance ......................................... 3

Peak Performance ................................ 4

Problem Solver ..................................... 5

Extra Energy Tips ................................. 5

Service Information ............................... 6

Contents

Optional Extended Warranty

Optional Extended Warranties are

available from the Manufacturer. The

Extended Warranty can be purchased

from your dealer and is in effect when

you have received an Extended Warranty

Certificate from Trane. No additional

warranty, either written or implied,

is extended by the Manufacturer

without an Extended Warranty

Certificate from Trane. If you do not

receive your Extended Warranty

Certificate within 45 days of purchase,

please call 800-554-6413. For additional

information regarding the Extended

Warranty, see page 5.

LIMITED WARRANTY

TRANE CENTRAL AIR CONDITIONER

2TTB0 AND TTB

Models Less Than 20 Tons for Residential Use*

(Parts Only)

This limited warranty is extended by The Trane Company, a division of American Standard

Inc., to the original purchaser and to any succeeding owner of the real property to which the

Trane Central Air Conditioner is originally affixed, and applies to products purchased and

retained for use within the U.S.A. and Canada.

If any part of your Trane Central Air Conditioner fails because of a manufacturing defect within

five years from the date of original purchase, Trane will furnish without charge the required

replacement part. Any local transportation, related service labor, diagnosis calls, refrigerant

and related items are not included.

If the sealed motor-compressor fails or if the outdoor coil should become defective, either or

both events occurring because of a manufacturing defect within five years from the date of

original purchase, Trane will furnish without charge the required replacement compressor

and/or outdoor coil. Any local transportation, related service labor, diagnosis calls, refrigerant

and related items are not included.

This limited warranty does not cover failure of your Trane Central Air Conditioner if it is

damaged while in your possession, failure attributable or caused by unreasonable use of the

Trane Central Air Conditioner and/or failure to properly maintain the Trane Central Air Condi-

tioner as set forth in the Use and Care manual.

This limited warranty applies to product installed on or after 10/1/2001 where product is

manufactured after 1/1/2000. This limited warranty is not retroactive to any installations prior

to 10/1/2001 or on product produced prior to 2000.

THE LIMITED WARRANTY AND LIABILITY SET FORTH HEREIN ARE IN LIEU OF

ALL OTHER WARRANTIES AND LIABILITIES, WHETHER IN CONTRACT OR IN

NEGLIGENCE, EXPRESS OR IMPLIED, IN LAW OR IN FACT, INCLUDING BUT NOT

SPECIFICALLY LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND

FITNESS FOR PARTICULAR USE, AND IN NO EVENT SHALL WARRANTOR BE

LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states do not allow limitations on how long an implied limited warranty lasts or do not

allow the exclusion or limitation of incidental or consequential damages, so the above

limitation or exclusion may not apply to you. This limited warranty gives you specific legal

rights, and you may also have other rights which vary from state to state.

Parts will be provided by our factory organization through an authorized service organization

in your area listed in the yellow pages. If you wish further help or information concerning this

limited warranty, contact:

The Trane Company

A Division of American Standard Inc.

6200 Troup Highway, Tyler, TX 75707

Attention: Manager, After Sales Support

Or visit our web site: www.trane.com/residential

TW-355-4001

* This limited warranty is for residential usage of this equipment and not applicable when this equipment is used for a

commercial application. A commercial use is any application where the end purchaser uses the product for other

than personal, family or household purposes.

22-5200-01-0901 (EN) 3

How it works to

keep you comfortable

Congratulations on the purchase of your new Trane air

conditioner. Your air conditioner is designed to work with

a matched indoor unit creating a system that delivers

years of dependable service and performance.

Your air conditioning system cools, filters, and dehumidifies your home.

As the air conditioning system circulates the air, it also filters it. The air conditioning

system also extracts excess moisture from the air inside your home, thus helping

to control humidity in muggy summer months.

Acquaint yourself with your new system by spending just a few minutes with

this booklet. Learn about the operation of your system and the small amount of

maintenance it takes to keep it operating at peak efficiency.

A central air conditioner is not a house-

hold appliance. It’s a self-contained

system that requires professional

maintenance and repair.

That’s why attempts at “do-it-yourself”

repairs on an in-warranty unit may void

the remainder of your warranty.

Other than performing the simple main-

tenance recommended in this manual,

you should not attempt to make any

adjustments to your central air condi-

tioning system. Your dealer will be

able to take care of any questions or

problems you may have.

Help ensure top efficiency

by cleaning or replacing the

filter monthly.*

When the air conditioner circulates

and filters the air in your home, dust

and dirt particles build up on the filter.

Excessive accumulation can block the

airflow, forcing the unit to work harder

to maintain desired temperatures. And

the harder your unit works, the more

energy it uses.

Clean or replace your filter twice a

month during seasons when the unit

runs more often.

When replacing your filter(s), always

use the same size and type that was

originally supplied. Filters are available

from your dealer.

Where disposable filters are used, they

must be replaced every month with the

same size as originally supplied.

How to remove your filter.*

Ask your Trane dealer where the filter

is located in your system and how to

service it.

Just be sure to replace it with the arrows

pointing in the direction of the airflow.

Efficiency can be maintained by

keeping outdoor unit clear of

debris, leaves and shrubbery.

Efficient operation of your air conditioner

depends on the free flow of air over the

coil. Anything that blocks the airflow,

causes the compressor to work harder

to move the warm air out of your house.

To avoid overworking your unit, do

not plant flowers or shrubbery right

next to it. Also, make sure that nothing

is stacked against the sides of the unit

or draped over it.

Making sure your outdoor unit is kept

clear at all times helps it work at peak

efficiency.

* Before removing the filter, see the owners manual

furnished with the indoor unit.

Proper maintenance for

maximum efficiency

▲CAUTION

!

To prevent injury, death, or property damage, read

and follow all instructions and warnings, including

labels shipped with or attached to unit before

operating your new air conditioning system.

▲WARNING

!

Disconnect all electrical power to the indoor air

handler or furnace before removing access panels

to perform any maintenance. Disconnect power to

both the indoor and outdoor units. NOTE: There

may be more than one electrical disconnect

switch. Electric shock can cause personal injury

or death.

▲CAUTION

!

Although special care has been taken to minimize

sharp edges in the construction of your unit, be

extremely careful when handling parts or reaching

into the unit.

4 22-5200-01-0901 (EN)

Proper maintenance (cont.)

•Inspection and, if required, cleaning

of indoor and outdoor coils.

•Inspection of the indoor coil drain

pan, plus the primary and secondary

drain lines. If supplied, the auxiliary

drain pan and line should be inspected

at this time. Service should include

cleaning, if required.

•A check of all electrical wiring and

connections.

•A check for secure physical connec-

tions of individual components within

units.

•Operational check for the air condi-

tioning system to determine actual

working condition. Necessary repair

and/or adjustment should be per-

formed at this time.

•Your servicing dealer may offer an

economical service or preventative

maintenance agreement that covers

seasonal inspections. Ask your

dealer for further details.

Keep your air conditioner looking

new for years.

Clean the enamel finish of your air

conditioner with soap and water. For

stubborn grease spots, use a household

detergent. Do not use lacquer thinner or

other synthetic solvents as they may

damage the finish.

Call your dealer for additional

routine maintenance

Your air conditioning system should be

inspected regularly by a properly trained

service technician. The inspection

(preferably twice each year, but at

least once a year) should include

the following:

•Routine inspection of air filter(s).

Replacement or cleaning as required.

•Inspection and cleaning of the blower

wheel, housing, and motor as required.

How to operate your system

for peak performance

How to help reduce summer humidity.

In summer, your air conditioner does

more than cool the air — it helps

remove the excess moisture, that can

make the inside of your home feel

muggy. When removing this moisture

your system must work harder than

when simply cooling the air.

That’s why kitchens, bathrooms and

utility rooms should have vents and

exhaust fans. These devices help

prevent accumulation of moisture

throughout the rest of the house so

your air conditioner works less to keep

you comfortable.

Setting the temperature

Place the system switch on COOL, and

the fan switch on AUTO. Then set the

temperature by using the indicator on

the thermostat* control.

Now your system will cool your house

whenever the indoor temperature climbs

above the thermostat setting. It will shut

off when the desired room temperature

is reached.

In winter, it works the same way.

When the system switch is on HEAT, the

system will operate whenever the room

temperature falls below the temperature

setting. Once the desired temperature is

reached, the system will shut off.

Save energy with an electronic

programmable thermostat.*

Program the thermostat for the temp-

eratures that meet your comfort level.

The Trane electronic programmable

thermostat has up to four setup or

setback periods each day, plus week-

end and vacation programs.

Let the thermostat do its job.

Your system will perform most efficiently

when you let the thermostat control it.

Turning the system on and off manually

is usually much less efficient. So let the

thermostat do its job.

We recommend keeping the temper-

ature setting at 78°F for cooling, 68°F

for heating. However, you can select

the temperature that meets your

comfort level.

The point is, once you’ve set the

thermostat, keep subsequent

adjustments to a minimum.

When you’re going to be away from

home for a few days, or when outdoor

temperatures are moderate, don’t let

the air conditioner run unnecessarily.

Lower the thermostat to 55°F in the

winter. And raise it to 85°F in summer.

Then when you return, or when tempera-

ture conditions dictate, you can reset the

system and it will resume making your

home comfortable again.

Never stop the system by shutting off

the main power.

If the main power is ever disconnected

for more than three hours, turn off the

thermostat. Then wait for at least three

more hours after the power has been

restored before turning the thermostat

back on. Failure to follow this procedure

could result in damage to your system.

* Accessory, purchased separately. Carefully read the

accompanying thermostat manual for complete

operating instructions.

▲CAUTION

!

Condensate drains should be checked and cleaned

periodically to assure condensate can drain freely

from coil to drain. If condensate cannot drain freely,

water damage could occur.

▲

CAUTION

!

If heating system is not operational during the cold

weather months, provisions must be taken to

prevent freeze-up of all water pipes and water

receptacles. This is very important during times

of vacancy.

▲

WARNING

!

Improper installation, adjustment, alteration,

service, maintenance, or use can cause explosion,

fire, electrical shock, or other conditions which

may cause personal injury or property damage.

Consult a qualified installer or service agency for

information or assistance. The qualified installer

or agency must use factory-authorized kits or

accessories when modifying this product.

22-5200-01-0901 (EN) 5

The Problem Solver

Extra Energy Tips

Insulation

1. Make sure your home is properly

insulated. This is the single most

important step in conserving

energy. Thermal insulation should

be specified in terms of thermal

resistance (R-values). R-30 (10")

is recommended for ceilings, R-11

(3-1/2) for exterior walls and floors

over unheated areas. In colder

climates, consider additional

insulation.

2. Infiltration of humid outside air is

your heating and cooling system’s

worst enemy — it could account for

15 to 30% of air conditioning energy

requirements. Find the places where

air can sneak into the home and

plug them with caulking, weather-

stripping or plastic. Also, weather-

strip and caulk around all entrance

doors and windows.

3. Cut heat transfer through your

windows by 40 to 50% with double

glazing (two panes of glass separ-

ated by a sealed air space) and

low-e glass.

4. Use wood- or metal-frame storm

windows even if single-glazed

windows are high quality. The

extra layer of glass and the layer

of still air will cut heat transfer

considerably.

5. Install storm doors at all entrances

to your house.

6. Keep all windows and doors closed.

7. Remember that by increasing the

glass area, you increase the amount

of heat added in summer and lost

in winter.

8. Make sure fireplaces have tight-

fitting dampers which can be closed

when the fireplace is not in use.

9. Invest in a humidifier to conserve

energy in winter. The air in your

home won’t be as dry, so you stay

comfortable at a lower temperature

setting.

Heating

10. Locate the thermostat on an inside

wall away from windows and doors.

11. Set the thermostat as low as

comfort permits. Each degree over

68°F can add 3% to the amount of

energy needed for heating.

12. People generate heat. So lower the

thermostat a degree or two when

expecting a large group of guests.

Cooling

13. Set the thermostat as high as

comfort will permit.

14. Make sure attics are adequately

ventilated to relieve heat buildup.

If necessary, improve airflow by

adding or enlarging vents.

15. When building a new house or

renovating an old one, choose

light-colored roof shingles to reflect

more of the sun’s heat.

16. During moderate weather, don’t use

the air conditioner unnecessarily.

17. Draw blinds or drapes to block the

sunlight during the hottest part of

the day.

18. Install awnings over windows

exposed to direct sunlight.

19. In the cooling season, don’t run

kitchen and bath exhaust fans

longer than necessary.

20. Don’t place lamps, TV sets or other

heat producing devices beneath a

wall-mounted thermostat. Rising

heat from the equipment may

cause the air conditioner system

to over cool your house.

Reduce the burden of unexpected repair bills with

a Trane Extended Warranty.

Trane offers the finest quality products and manufacturer’s

warranties on the market. But, like all good things, the Trane-

provided limited warranty on your new comfort equipment

will come to an end. To keep you protected, Trane offers the

Extended Warranty Program. It picks up right where your

Trane limited warranty leaves off. And, it offers years and

years of reliable protection at a low cost. Ask your dealer

for program details.

The Trane Extended Warranty provides:

1. The opportunity to supplement your Limited Warranty

for five or ten years.

2. Coverage that may include parts only or parts and labor

for the duration of the agreement. Be certain you read the

Extended Warranty for complete details and exclusions.

3. Service work performed by servicers knowledgeable of

the operation of Trane equipment.

Before you call for service, check the following:

Problem Possible cause Remedy

Insufficient heating a. dirty filters a. clean or replace

or cooling b. air not circulating b. check supply registers and

freely return grills for blockage

c. blocked outdoor coil c. clear away leaves or other

debris

Failure to operate a. power off a. make sure main switch is

in ON position

b. open circuit breaker b. reset circuit breaker, or

or burned-out fuses replace burned-out fuses

c. improperly adjusted c. check setting, adjust

thermostat thermostat

No Heating or Blower door removed Close door securely to

Cooling – Blower or ajar restore power to blower

does not operate

Unusual Noise Call your local servicer

The Trane Company

An American Standard Company

www.trane.com

P.I. 10/01

Since The Trane Company has a policy of continuous product and product data improvement, it reserves the

right to change design and specifications without notice.

Important Service Information

It’s always a good idea to keep records — it will save you time and money. If it’s necessary to have your air conditioner repaired, the

serviceman will want to know if your unit is still under Warranty. Take a few minutes to record the following information here:

Outdoor Model Number ___________________________________________________________________________________

Indoor Model Number ____________________________________________________________________________________

Thermostat Model Number ________________________________________________________________________________

Date of Purchase ________________________________________________________________________________________

Dealer ________________________________________________________________________________________________

Service Information

Call your installing dealer if the unit is inoperative. Before you call, always check the following to be sure service is required:

a. Be sure the main switch that supplies power to the unit is in the ON position.

b. Replace any burned-out fuses or reset circuit breakers.

c. Be sure the thermostat is properly set.

Service Phone __________________________________________________________________________________________
