Trane Total Home Humidifiers

Properly humidified air for a perfectly

comfortable home.

72-1232-05_Home_Humidifiers.indd 1 1/5/11 7:13 AM

READ ONLY

Discover the difference a Trane humidifier can make.

Trane total home humidifiers add a whole new

element of comfort to your indoor environment.

Your air may be at the perfect temperature. It may

be clean. But without the proper humidity levels, it’s

not as comfortable as it could be.

During winter months, or in hot, dry climates, the air

in your home will lose most of its moisture. Dry air

can lead to bothersome static electricity, and over

time it can damage plants, furniture and valuables.

It can also dry out your skin, aggravate asthma and

trigger allergy attacks.

A Trane total home humidifier restores proper

moisture levels to the air in your home, increasing

your comfort while

protecting your belongings

and your family’s health.

THUMD500

Power Humidifier

For homes up to 4,200 square feet,

the Trane Power Humidifier provides

exceptional comfort and delivers up to

50% more moisture than competitive

models due to its ultra-quiet

independent blower motor.

THUMD300

Large Bypass Humidifier

Ideal for homes up to 4,000 square

feet, the Trane Large Bypass

Humidifier’s flow-through design

works with your furnace blower

to deliver substantial moisture

on demand.

THUMD200

Small Bypass Humidifier

Brings balanced moisture levels to

homes up to 3,000 square feet for

quiet, economical comfort.

There’s a Trane humidifier for every home.

Responsible comfort.

Since humidified air feels

warmer, you’ll be able to set your

thermostat to a lower setting,

saving energy in the process. It’s a small

change that can make a big difference.

1

2

3

4

5

6

Features and components may

vary by model and are shown

for illustration purposes only.

72-1232-05_Home_Humidifiers.indd 2 1/5/11 7:13 AM

READ ONLY

THUMD500 THUMD300 THUMD200

FLOW-THROUGH DESIGN

•••

CONTROLLED MOISTURE DISTRIBUTION

•••

REPLACEABLE PAD

•••

BUILT-IN FAN

•

DURABLE, RUST-RESISTANT HOUSING

•••

AUTOMATIC CONTROL

• •

OUTDOOR SENSOR OPTION

• •

BYPASS DAMPER

• •

MANUAL CONTROL

•

DURABLE CONSTRUCTION

•••

QUIET OPERATION

•••

EVAPORATIVE CAPACITY (GALLONS PER DAY) 18 16.8 12

5 YEAR LIMITED WARRANTY ON FUNCTIONAL PARTS WITH REGISTRATION*

•••

* Registered Limited Warranty terms are available when you register within 60 days of installation. You can register online at Trane.com or by phone at 800-554-6413,

otherwise Trane’s Base Limited Warranty terms will apply. Base Limited Warranty information on specific products can be found on Trane.com.

1 Flow-Through Design

Air flows directly through the humidifier and across

the pad where the proper amount of moisture is added

and circulated in the indoor air. This design helps limit

mineral build-up for worry-free operation.

2 Controlled Moisture Distribution

Introduces fresh moisture, as a vapor, into the air to

maintain the correct level of relative humidity in your home.

3 Replaceable Pad

Water flows through and moisture is evaporated into

the air. Can be easily accessed for annual replacement.

4 Built-In Fan (Power Humidifier)

Quietly moves heated air across the humidifier

pad efficiently and effectively, independent of

the furnace blower.

5 Durable, Rust-Resistant Housing

Resists rust and corrosion. It also protects key internal

components for years of reliable performance.

6 Automatic Control (Power & Large Bypass Humidifiers)

Makes maintaining comfort effortless by responding

to temperature changes throughout the day and

automatically adjusting the relative humidity — helping

reduce the chances of condensation forming on windows.

7 Outdoor Sensor Option (Power & Large Bypass Humidifiers)

Works with the automatic control by monitoring the

outdoor temperature and signaling when to add

the correct amount of humidity. (not shown)

8 Bypass Damper (Large & Small Bypass Humidifiers)

Lets less air flow through the humidifier in the summer

and more air pass through during winter, so the humidity

remains balanced. (not shown)

9 Manual Control (Small Bypass Humidifier)

Lets you make your own humidity adjustments

to suit your comfort level. (not shown)

Suggested indoor relative humidity*

Outdoor Temperature (°F) Indoor Relative Humidity

+40° 45%

+30° 40%

+20° 35%

+10° 30%

0° 25%

-10° 20%

-20° 15%

* Relative humidity settings are based on double-pane windows or single-pane

windows with storm windows. These settings reduce the likelihood of

condensation forming on the windows inside a home.

Understanding relative humidity.

Relative humidity is the actual percentage of moisture

in the air compared to the maximum moisture it can

hold. For example, if the air contains only half of the

moisture it can hold, it is at 50% relative humidity. The

chart below suggests the most comfortable, most

effective indoor relative humidity settings, which are

easily achieved with a Trane total home humidifier.

72-1232-05_Home_Humidifiers.indd 3 1/5/11 7:13 AM

READ ONLY

Ingersoll Rand Residential Solutions, a business comprised of well-known brands like Schlage and Trane, delivers safety, comfort and efficiency

to homeowners throughout North America. Our quality products, services and solutions include mechanical and electronic locks, heating

and air conditioning systems, indoor air quality solutions, advanced controls, portable security systems and remote home management.

For more information on these and other residential solutions please visit www.ingersollrand.com, www.schlage.com, or www.trane.com.

Pub. No. 72-1232-05 01/11

© 2011 Trane. All rights reserved.

trane.com

P.O. Box 9010 • Tyler, TX 75711-9010

Your independent Trane Dealer knows

his or her reputation is made at every

sale, and with every installation.

Therefore, they are as personally

invested in your comfort as you are,

and take great pride in creating your

perfect indoor environment.

Trane dealers are some of the most

highly-trained in the business, with

advanced technical skills to optimize

every installation and solve any issue.

Independent Trane Dealers value reliability as much as you do.

They have an extensive understanding

of the movement and conditioning

of air, and the expertise to create a

perfectly balanced, ultra-efficient

system for every home.

Trane dealers believe in doing the

job right, every time. Otherwise, they

wouldn’t be Trane dealers.

Trane Air: When everything comes together perfectly.

When you combine a Trane air conditioner or heat pump with a Trane furnace

or air handler, you get a balanced system designed to work hard, and work in

harmony, for your comfort. Add in a Trane humidifier, and the .1 micron filtration

of Trane CleanEffects, and you get a home environment that feels cleaner, fresher,

healthier and more comfortable than you’ve ever imagined. An environment

filled with air we call Trane Air, held at just the right temperature and free of up to

99.98% of airborne pollutants, allergens and irritants. It feels good on your skin. It

feels fresher in your lungs. And it’s only available through a matched Trane system.
