Trane Air Handlers

Revolutionary technology.

Unprecedented comfort and efficiency.

READ ONLY

The Trane Hyperion™ air handler.

An advanced solution for your energy efficiency and your comfort.

*Independent 2012 HVAC Claim Study, Funded by Ingersoll Rand

When it comes to heating and cooling homes,

people view Trane equipment as the most reliable

and longest lasting in the industry.*

• Winner of the Dealer Design Award presented

by Air Conditioning, Heating & Refrigeration

NEWS, the industry’s leading trade publication,

for the fourth year in a row.

• Winner of Building Products magazine’s

2009 Green Product Award, the only HVAC

manufacturer to win the award that year.

• Winner of the David Weekley Homes’

prestigious Partners of Choice Award for

Service and Product Performance.

Every component of the Hyperion, from the

smallest screw to the revolutionary unique cabinet,

has been carefully designed to deliver Trane’s

legendary reliability, innovation and efficiency

with your complete comfort in mind.

Over a hundred years

ago, Reuben and James

Trane made the decision

to stand out from the

crowd. To build a comfort

system like no other,

using uncompromising

quality, innovation

and reliability. Today,

their legacy is found in

everything Trane makes,

from our premium

materials to our industry-

leading technology to

our extensive product

testing under the harshest

conditions. When you buy a Trane, you’re

buying a commitment from us, to you. A

commitment to your total comfort, and your

total peace of mind. Because that’s what

Reuben and James would have done.

Trane has a tradition of quality

lasting more than a century.

Trane Storefront

La Crosse, Wisconsin 1891

Courtesy of the La Crosse (Wisconsin)

Public Library Archives

READ ONLY

You’ll appreciate the energy savings from your

Trane air handler the day your dealer installs it,

and for many years to come.

When shopping for a new system, efficiency is one

of your most important considerations. An efficient

system will not only lower your energy costs, it will

also lower your impact on the environment.

System efficiency is measured in SEER, which stands

for Seasonal Energy Efficiency Ratio. Similar to miles

per gallon in a car, SEER is a measure of the overall

efficiency of a complete heating and cooling system

on a seasonal basis. The higher the SEER, the greater

the system’s energy efficiency, and the lower the

overall carbon footprint of your household.

The best efficiency comes from matched

systems — systems in which all components are

balanced to work together for optimized efficiency

and performance.

Your Trane air handler has been

carefully designed to work as part

of a Trane matched system

to reduce your household

energy use, and provide reliable

comfort year after year.

If your system is more than a few years old,

you may be using far more energy than you

need to stay comfortable.

* Minimum efficiency established by the Department of Energy. Potential energy savings may

vary depending on your personal lifestyle, system settings and usage, equipment

maintenance, local climate, actual construction and installation of equipment and duct system.

50%

60%

38%

47%

0%

43%

8 SEER 12 SEER 13 SEER 14 SEER 15 SEER 16 SEER 20 SEER

33%

Annual savings for cooling your home

based on the efficiency of a

matched system.

Like miles per gallon in a car, the higher the

system SEER rating, the more comfort you

will get from each energy dollar.

Responsibly cool.

The Trane Hyperion was designed for

your comfort, and our planet. With

significantly reduced air leakage and

an exclusive electronic expansion valve, the

Hyperion’s efficiency helps reduce your carbon footprint.

The outstanding durability of the all-aluminum coil means

fewer chances of refrigerant entering the atmosphere.

And the unique, fully enclosed foam insulation design

eliminates loose fiberglass insulation particles that can

break off and circulate in the air that you breathe.

READ ONLY

1 Unique Cabinet Design

INDUSTRY

EXCLUSIVE

Tough, double-wall construction with

enclosed foam insulation makes Hyperion

both lightweight and durable while virtually

eliminating sweating and condensation. The

Hyperion was designed so less moisture

and fewer dust particles are drawn in from

garages, attics or crawl spaces. The cabinet

interior is also easy to clean, helping improve

indoor air quality.

2 Fully Enclosed Insulation

INDUSTRY

EXCLUSIVE

While other air handlers use metal cabinets

insulated by loose fiberglass and foil,

Hyperion’s unique cabinet uses insulating

foam between the

cabinet walls much

like a refrigerator.

This prevents loose,

fibrous insulation

from breaking off

and entering the

air that your family

breathes.

3 All-Aluminum Coil

INDUSTRY

EXCLUSIVE

Substantially more durable than conventional

copper coils, for prolonged efficiency, longer

system life and less chance of refrigerant

leaking into the atmosphere.

Features and components applicable to Hyperion Series only,

may vary by model and are shown for illustration purposes only.

Trane Hyperion.

™ Designed from the ground up to be

the industry’s most advanced air handler.

Hyperion Air Handlers – There’s a revolution in air movement for every home.

Hyperion XL

(TAM7 and TAM8)

For the ultimate in

efficiency, the Hyperion

XL’s variable-speed blower

motor fine tunes airflow,

while its Comfort-R™

technology controls humidity.

Many models feature

communicating technology

to optimize the performance

and energy efficiency of

a matched system.

Hyperion XR

(TAM4 and GAM5)

Built with a multi-speed

blower for quieter

performance, the

Hyperion XR helps

your Trane matched

system deliver

impressive efficiency

all year long.

Hyperion XB

(GAF2/T2)

As part of a matched

system, the durable

Hyperion XB meets or

exceeds all standard

energy requirements,

and Trane’s high standards

for reliability.

Conventional

Air Handler Cabinet

Hyperion

Air Handler Cabinet

10

11

1

2

3

4

6

5

7

8

9

READ ONLY

4 Variable-Speed Motor with

Comfort-R™ Technology

By starting gradually instead

of suddenly, the Hyperion

reduces operating noise while

eliminating hot and cold spots.

Comfort-R™ allows the Hyperion to

carefully regulate humidity for your

comfort.

5 Vortica™ Blower

INDUSTRY

EXCLUSIVE

Designed for quiet, efficient

operation, the Vortica uses less

energy than conventional blowers

to deliver more air, while reducing

energy consumption, carbon

emissions and noise.

6 Modular Design

INDUSTRY

EXCLUSIVE

Its innovative modular construction

enhances installation flexibility,

allowing the Hyperion to be installed

in tight spaces, and without the need

for expensive structural modifications

to your home.

7 Control Board Pocket

INDUSTRY

EXCLUSIVE

The Hyperion’s design includes

a dedicated control board pocket

that provides easy access, and helps

the board last longer by shielding it

from airstream humidity.

8 Electronic Expansion

INDUSTRY

EXCLUSIVE

Valve Metering Device

Based on Trane’s rigorous testing, this

expansion valve is 400% more reliable

than the standard expansion valves

found in other air handlers. The valve

also regulates the flow of refrigerant and

provides compressor protection, both

of which contribute to greater overall

efficiency and system life.

9 “No Leak” Drain Pan

Made from rust-resistant composites

and built with a gradual slope, the drain

pan helps promote better indoor air

quality by eliminating standing water.

10 Heating Options

Hyperion is flexible enough to add

either hydronic or electric heat

without changing the cabinet. This

allows you to select the heating

method that is most energy

efficient for your climate.

11 Corrosion Resistant Finish

The tough, rugged coating on the

Hyperion protects it from scuffs

and damage, ensuring a uniform

appearance for years.

XB 4F Air Handlers – Trane durability at an affordable price.

XB 4FWC/H Series

Convertible Air Handler

The durable XB 4FWC and

4FWH air handlers meet or

exceed standard efficiency

requirements. They feature

all-aluminum coils, non-bleed

TXV and no rust polymer

drain pans.

XB 4FWM Series

Stud-Mount Upflow Air Handler

These affordable XB 4FWM

air handlers are stud-mounted

and feature all-aluminum

coils, non-bleed TXV and

no rust polymer drain pans.

Hyperion

XL

TAM7, TAM8

Hyperion

XR

TAM4, GAM5

Hyperion

XB

GAF2/T2

XB

4FWC/H

XB

4FWM

UNIQUE CABINET DESIGN

• • •

FULLY ENCLOSED INSULATION

• • •

ALL-ALUMINUM COIL

• • • • •

VORTICA™ BLOWER

• • •

MODULAR DESIGN

• •

Select Models

CONTROL BOARD POCKET

• • •

EEV METERING DEVICE

• •

Select Models

“NO LEAK” DRAIN PAN

• • •

HEATING OPTIONS

• • • • •

CORROSION RESISTANT FINISH

• • •

TEXTURED GALVANIZED CABINET

WITH PAINTED DOORS

• •

COMFORTLINK™ COMMUNICATING

TECHNOLOGY Select Models

HIGHLY EFFICIENT VARIABLE-SPEED

TECHNOLOGY Select Models

See your dealer for more product information and

availability or go to Trane.com/residential/products.

Drop-ceiling or furr-down applications also available.

READ ONLY

1

2

3

Maximize your comfort and efficiency by customizing

a perfectly matched Trane system around your air handler.

Basic outdoor equipment

Air Conditioner: Cools your home

on even the hottest days with quiet,

reliable efficiency.

— OR —

Heat Pump: Draws heat out of your

home in the summer, and into your

home during the fall and winter. Ideal

for all-electric homes, or homes in

milder climates. May also be used

in colder climates with an additional

heat source.

3

Thermostat: Programmable or

non-programmable, Trane

thermostats are precise, easy

to use and fit into any decor.

Basic indoor equipment

Air Handler: Works with an air

conditioner or heat pump to cool

or heat and quietly circulate air in

homes that are all electric.

A Trane air handler can make a

significant contribution to the overall

efficiency of your matched system.

The more efficient it is the less work

your outdoor unit has to do to keep

your home comfortable.

1

2

When you choose a Trane air handler, you’ll enjoy the

utmost in consistent comfort. You can achieve the best

cooling performance by customizing a Trane “matched

system” for your home and comfort needs. A matched

system includes individual Trane components,

each designed and engineered to work together

seamlessly to maximize overall performance and

deliver exceptional efficiency, reliability and comfort.

READ ONLY

Optional equipment to maximize your comfort and peace of mind:

Humidifiers: Add moisture to the

air to alleviate dry skin and reduce

static electricity.

UV Light Kit: An optional kit for

the Hyperion that improves coil

and drain pan cleanliness.

Hydronic or Electric Heat Kit:

An optional kit that can be added

to the Hyperion air handler with a

simple slide-in module containing

all necessary connections.

What is Trane Air™?

We’ve devoted years to producing air that has

been flawlessly conditioned and meticulously

cleaned. Air that feels fresh and crisp with each

breath. We call it Trane Air, and you can experience

it for yourself when you install the optional

industry-leading filtration of Trane CleanEffects.

™

Air that’s dirty and full of particulates can not

only feel uncomfortable, it can cause breathing

problems for family members and exacerbate

existing respiratory problems like asthma and

allergies. Fortunately, the exclusive .1 micron

filtration of an optional Trane CleanEffects removes

up to 99.98% of airborne pollutants from heated

and cooled air, providing the most technologically

advanced air filtration available. That’s welcome

relief for everyone in your home.

Typical In-room

Appliance

Standard

1-inch Filter

Typical Room

HEPA Appliance

Whole-House

5-inch Media

Filter

Whole-House

Electronic Air

Cleaner

TRANE

CleanEffects

Clean Air

Delivery Rate:

10

Clean Air

Delivery Rate:

12

Clean Air

Delivery Rate:

150

Clean Air

Delivery Rate:

240

Clean Air

Delivery Rate:

660

Clean Air

Delivery Rate:

1,200

Clean Air Delivery Rate

measures the effectiveness of

air cleaning appliances. The

higher the clean air delivery rate,

the more effective the unit is at

cleaning the room or home of

airborne particles and allergens.

Air Cleaners: Available in a variety

of models, from standard filters to

highly efficient air filtration systems.

Add a Trane CleanEffects™ system for

the ultimate air filtration available.

Energy Recovery Ventilators (ERVs):

Introduce fresh outdoor air while removing

stale indoor air. Efficiently transfer heat

and moisture from the exchanged air for

enhanced comfort and energy efficiency.

Nexia™ Home Intelligence: Adjust heating and

cooling in your home, unlock the front door, turn

on the lights, manage home security, even monitor

and control energy use. And you can do all this

from anywhere you happen to be, using your

smart phone or web-enabled tablet or computer.

READ ONLY

Your independent Trane dealer knows his

or her reputation is made at every sale,

and with every installation. Therefore, they

are as personally invested in your comfort

as you are, and take great pride in creating

your perfect indoor environment.

Trane dealers are some of the most

highly trained in the business, with

advanced technical skills to optimize

every installation and solve any issue.

Independent Trane dealers value reliability as much as you do.

They have an extensive understanding of

the movement and conditioning of air, and

the expertise to create a perfectly balanced,

ultra-efficient system for every home.

Trane dealers believe in doing the job right,

every time. Otherwise, they wouldn’t be

Trane dealers.

Ingersoll Rand (NYSE:IR) advances the quality of life by creating and sustaining safe, comfortable and efficient

environments. Our people and our family of brands—including Club Car®, Ingersoll Rand®, Schlage®, Thermo King® and

Trane®—work together to enhance the quality and comfort of air in homes and buildings, transport and protect food

and perishables, secure homes and commercial properties, and increase industrial productivity and efficiency. We are a

$14 billion global business committed to a world of sustainable progress and enduring results

We are committed to using environmentally conscious print practices.

trane.com

©2012 Ingersoll-Rand Company 72-2167-07 06/12

Reliability, warranties and your peace of mind.

All Trane air handlers have a 10 year parts

Limited Warranty with product registration;

otherwise the Base Limited Warranty terms

of 5 year parts will apply.

• Optional Extended Warranties are

available.

• An option to purchase transferability

of your Registered Limited Warranty is

available. For more information visit

Trane.com.

Registered Limited Warranty terms are

available if the product is registered within

60 days of installation. Product registration

can be completed either online at Trane.com

or by calling 800-554-6413. Ask your dealer for

full warranty information at time of purchase.

Warranties are for residential use only, some

exclusions may apply.

READ ONLY
