ROVR Key Fob
Check in and out with the touch of a button
Features
Allows multiple vehicle drivers
to be associated with a ROVR TC
equipped vehicle
Vehicle driver can easily check in
as the current driver, or check
out
Compact size, similar to a typical
vehicle door and alarm control
key fob
Each fob has a unique number
that is communicated to the
ROVR TC device during the
association process.
Information associated with
each driver is available for
reporting and viewing in ROVR
Central.
Visual indication of the check in
and check out process to ensure
accurate driver to vehicle
association
User replaceable battery
The ROVR Identification key fob is a compact device, similar in size to a typical vehicle door/
alarm control key fob, that allows multiple drivers to be associated with a single ROVR TC
equipped vehicle. A vehicle driver can check in or check out with the touch of a button. Visual
indicators on the fob ensure accurate driver to vehicle association. Each fob has a unique
identification number that is communicated to the ROVR TC device during the association
process. The fob is assigned to a driver, and the information associated with each driver is
available for reporting and viewing in ROVR Central.
Operation
The driver checks in with the ROVR TC device by pressing and holding the left button on the
fob. The yellow light emitting diode (LED) illuminates briefly. When the ROVR TC device
detects a check-in from the fob, it sends a message to the ROVR Central server indicating that
the owner of the fob is now the active driver of the vehicle and the green LED light illuminates
for a few seconds.
The driver checks out by pressing and holding the right button on the fob. The yellow LED
illuminates briefly. When the ROVR TC device detects a check out from the fob, it sends a
message to the ROVR Central server to indicate that the owner of the fob is no longer the
active driver of the vehicle and the green LED illuminates.
The ROVR key fob is an ideal solution for vehicle fleet applications and for households with
multiple drivers using the same vehicle.
TM
![](/img.php?id=2065796&img=bg2.png)
For more information:
Call 1.717.561.5807 (Sales Support) ● 1.800.278.4310 (Technical Support)
© 2013 TransCore License, Ltd. All rights reserved. TRANSCORE is a registered trademark and is used under license. ROVR is a trademark of TransCore
and Cartasite. All other trademarks are the property of their respective owners. Contents subject to change. Printed in the U.S.A.
COMMUNICATIONS
Frequency Range
Radio Link at 2450 MHz ISM Band, Frequency Hopping
PHYSICAL CHARACTERISTICS
Weight
0.04 lbs (18.14 g)
Dimensions
2.10 x 1.30 x 0.58 in. (53.34 x 33.02 x 14.73 mm)
Case
Snap together design, molded-in key ring
Color: Clear Gray
Buttons: Rubberized gray
Assembly includes base, case, button insert, and
rubber button keypad
Status LEDs
Yellow and Green LEDs indicate check in and check
out status.
POWER REQUIREMENTS
Power Source
User replaceable coin cell battery (CR2032)
Operating Voltage
3 VDC
ENVIRONMENTAL
Operating Temperature
-4°F to +140°F (-20°C to +60°C)
Storage Temperature
-4°F to +140°F (-20°C to +60°C)
Humidity
95% RH @+122°F (+50°C) non-condensing
RoHS
RoHS compliant
Lifetime
> 1 year
REGULATORY AND COMPLIANCE
This device has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15.249 of the FCC Rules.
This device complies with Industry Canada license-
exempt RSS standard(s).
Operation is subject to the following two condi-
tions:
(1)This device may not cause interference, and
(2) This device must accept any interference, includ-
ing interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Indus-
trie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux
conditions suivantes :
(1)l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouil-
lage est susceptible d'en compromettre le
fonctionnement.
Changes or modifications not expressly
approved by TransCore could void the user's
authority to operate the equipment.
600192 X4 - 09/13
