TransCore Location Monitoring Services Transmitter
User Manual
Trusted Transportation Solutions
PocketPass™
Installation Instructions
16-0042-001 Rev A2
PocketPass is designed for mounting to a vehicle's interior windshield surface using 3M™
Dual Lock™ strips. This mounting method provide for easy mounting and removal when
portability is needed.
General Installation Information
Metallized Windshields
Some vehicle windshields contain a metallic treatment that could prevent an interior windshield-mounted
device from working correctly. If you have a vehicle with a metalized windshield, contact your local
customer service center for more information. If your vehicle’s metalized windshield has a metal-free
zone, it is typically located near the rearview mirror.
Required Supplies
• PocketPass
• Commercial glass cleaner and paper towels
PocketPass Installation and Removal Procedures
Installing the PocketPass with Dual Lock Strips
1. Choose the location for your PocketPass (Figure 1). It should be mounted as close to the bottom
center of the windshield as possible; at least 3 inches away from the windshield frame or
dashboard, and not behind the windshield wipers.
Figure 1 –
Page 2
Installation Instructions
2. Clean and dry the interior windshield surface completely before axing the Dual Lock strips. The
windshield temperature must be at least 68ºF (20ºC) for optimum bonding.
3. Peel the backing o the Dual Lock strips (Figure 2). Leave both sides of the Dual Lock strips
pressed together to ensure the strips will align between the tag and windshield. Apply the
PocketPass to the windshield using moderate pressure.
Figure 2 –
Note: When installing the PocketPass using Dual Lock strips for the first time, leave it in
place for at least 24 hours to allow the adhesive to cure.
4. To remove a PocketPass mounted with Dual Lock strips from the windshield, grip the case at the
top and bottom sides. Gently lift the PocketPass away from the windshield on one end until the
tag is free from the windshield.
User Replaceable Batteries
Two AAA batteries are pre-installed in your PocketPass. TransCore recommends Energizer® Advanced
Lithium AAA batteries for use in the PocketPass.
To replace the batteries, remove the tag from the windshield as described in Step 4 on page 2.
1. Hold the tag with the LED side facing down. Locate the battery door. Press the indentation
located under the arrow and slide the door in the direction of the arrow to open the door.
Page 3
PocketPass
Figure 3 –
2. Remove the old batteries and replace them with AAA batteries according to the diagram on the
inside of the battery compartment.
Figure 4 –
3. Close the cover and slide it back into place. You should hear a soft snap when the cover is in the
correct position.
4. You will see a brief audio/visual sequence display as the tag powers up. If there is an ASTM V6 AV
code stored, the sequence will take up to 15 minutes to complete.
5. Reinstall the tag on the windshield.
Installation Instructions
Page 4
NO UNAUTHORIZED MODIFICATIONS STATEMENT
Caution: This equipment may not be modied, altered, or changed in any way
without permission from TransCore, LP. Unauthorized modication may void the
equipment authorization from the FCC and will void the TransCore warranty.
RADIO FREQUENCY INTERFERENCE STATEMENTS
Note: This device complies with Part 15 of the FCC Rules and the Industry
Canada Licence-Exempt RSS Standards. Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of this device.
Note: Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur del’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Page 5
PocketPass
For more information:
Sales Support
800.923.4824
Technical Support
505.856.8007
transcore.com
Trusted Transportation Solutions
© 2015 TransCore L.P. All rights reserved. TRANSCORE and TRANSSUITE are registered
trademarks, and are used under license. All other trademarks listed are the property of
their respective owners. Contents subject to change. Printed in the U.S.A.
