Transcend Information A0082 Dashcam User Manual

Transcend Information Inc. Dashcam Users Manual

Users Manual

85-0300 V2.1
www.transcend-info.com
Printed in Taiwan
www.transcend-info.com
Quick Start Guide
85-4010 V1.0
Printed in Taiwan
DrivePro 110/130
DrivePro 110/130/150
Dashcam
2:43 PM
Wi-Fi ON
English 0605 English
English 08
07 English
English 04
03 English
Quick Start Guide
Safety Precautions
Getting Started
DrivePro 110/130 Overview
What’s in the Box
For your own safety, do not operate the DrivePro or use the App while driving.
Never place the DrivePro where the driver’s view or deployment of airbags
is obstructed.
Do not mount the DrivePro on a tinted window to prevent damage to the
tinted lm.
Mount the DrivePro within range of the windshield wipers to ensure clear
visibility in rain.
Make sure the wire of the car adapter is securely attached and installed to
ensure safety.
•
•
•
•
•
Adhesive Mount
or Suction Mount
Quick Start Guide Warranty Card
microSD Memory Card
Car AdapterDrivePro 110/130
Quick Start Guide
DrivePro 110/130
1
1
2
2
3 4
Connecting to the Mobile Devices (for DrivePro 130 only)
Search & download the DrivePro app from
App Store or Google Play.
DrivePro130
Secured with WEP/WPA/WPA2
Telecom
Secured with WPA/WPA2
HOME
Secured with WPA/WPA2
Turn on Wi-Fi.
Tap “DrivePro” App.
2:43 PM
Installing DrivePro Toolbox™ Software
The DrivePro Toolbox, developed for Windows, features a user-friendly
interface that allows you to select and play videos recorded on your
DrivePro, and see your driving paths of the recorded videos displayed on
maps without the need to install separate codecs.
The complete User’s Manual provides detailed instructions for operating
your Transcend product. All product User’s Manuals and Firmware
Updates are available for download at
www.transcend-info.com/downloads
Contact Transcend for more in-depth technical support at:
www.transcend-info.com/support/contact
Download the installation les from:
www.transcend-info.com/downloads
Install DrivePro Toolbox software on your desktop or laptop.
User’s Manual / Firmware Updates
Technical Support
We strongly recommend the use of MLC-based memory cards to
reach the optimal recording performance as dashcams require
extensive read/write. Using TLC-based memory cards on your
dashcam might result in unstable performance.
!
Besides the bundled microSD card, we recommend Transcend’s
High Endurance microSD card as an additional purchase to reach
the most stable recording performance.
!
microSD
Connect to “DrivePro130”
using the default password
“12345678”.
Function Buttons
USB Connector
Bracket Socket
Wide Angle Lens
Built-in Speaker
Memory Card Slot
Emergency Button
Reset Button
2.4” LCD Display
LED Indicator
Built-in Microphone
Insert a microSD card.
Insert the mount bracket into the top and
slide sideways until you hear a click.
Position the DrivePro mount on your
windshield.
33
Start your car engine and the DrivePro will start recording automatically.
Note: Please set up the date, time, and time zone before the rst use.
Connect the small end of the car
adapter to the DrivePro.
Plug the other end of the car adapter
in your car’s lighter socket.
5
4
2
1
REC 00:01
DrivePro 110/130/150 Overview
DrivePro 110/130/150
Specifications
Panel: 2.4" color LCD
Speaker / Microphone: 1.0 Watt / 0.5 mA (built-in)
Connect Interface: USB2.0
Storage Capacity:
Control buttons:
4 function buttons
1 emergency recording button
1 reset button
Dimensions: 70.2 mm (L) × 63.1mm (W)× 34.5mm (H)
Weight: 71g
Power Supply
(car charger):
Input DC12V~24V
Output DC5V / 1A
Operating Temperature: -20°C (-4°F) ~ 65°C (149°F)
Video Formats:
H.264 (MOV: up to 1920x1080 30fps)
Lens:
F/2.0, 130° wide angle (DrivePro 110/130)
F/2.0, 160° wide angle (DrivePro 150)
Resolution / Frame Rate
Full HD (1920 x 1080) 30fps
HD (1280 x 720) 30fps
WiFi 802.11b/g/n
Certification: CE, FCC, NCC, BSMI
Warranty: 2 years
Federal Communications Commission (FCC) Statement
This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference. (2) This device must accept any interference
received including interference that may cause undesired operation.
This Equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20cm
between the radiator and your body.
You are cautioned that changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment.
This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
