S

S

St

t

to

o

or

r

re

e

eJ

J

Je

e

et

t

t®

®

®

3

3

35

5

5

T

T

Tu

u

ur

r

rb

b

bo

o

o

SATA HDD Enclosure

Transcend Information Inc.

1

Description

This stylish, versatile, high-speed USB storage device

is the perfect data management system for uploading,

downloading, storing and transferring your vital data

and information. With its OneTouch auto-backup button

and TurboHDD USB mode*, the compact StoreJet®

35T is quick and easy way to store and back-up

essential files, folders, documents, photos, music and

videos. In addition, the StoreJet® 35T comes with very

useful software* that can increase your storage

productivity and security.

*Note: StoreJet® elite and TurboHDD USB software only work

in Windows®

System Requirements

• Desktop or notebook computers with USB port

• One of following operating systems:

Windows® 7/Vista/XP/2000, Mac® OS 9.0 or above

Linux® Kernel 2.4.2 or above

Placement

Features

• Hi-Speed USB 2.0 compliant and USB 1.1 backwards

compatible

• Space-saving upright design – no stand needed

• Easy Plug and Play installation – no drivers required

• Pre-formatted for extra convenience

• Power-Saving Auto Sleep Mode

• High transfer rate up to 480 Mbits per second

• Additional software pack: StoreJet® elite (helps you manage

your data)

• OneTouch Auto-Backup function

• Includes StoreJet® Elite backup and security software

• Extra-large storage capacity for backing-up files

• Two-color LED indicator

• Recommended operating temperature: 5°C ~ 55°C

Dimensions

Side Millimeters Inches

A 172.40 ± 1.00 67.87 ± 0.04

B 44.80 ± 1.00 17.64 ± 0.04

C 152.40 ± 1.00 60.00 ± 0.04

Ordering Information

Transcend P/N Capacity

TS1TSJ35T 1TB

TS15TSJ35T 1.5TB

TS2TSJ35T 2TB

S

S

St

t

to

o

or

r

re

e

eJ

J

Je

e

et

t

t®

®

®

3

3

35

5

5

T

T

Tu

u

ur

r

rb

b

bo

o

o

SATA HDD Enclosure

Transcend Information Inc.

2

Block Diagram

S

S

St

t

to

o

or

r

re

e

eJ

J

Je

e

et

t

t®

®

®

3

3

35

5

5

T

T

Tu

u

ur

r

rb

b

bo

o

o

SATA HDD Enclosure

Transcend Information Inc.

3

Pinouts

Pin No. Pin Name

01 VCC

02 USB-

03 USB+

04 VSS

Pin Identification

Symbol Function

USB- USB differential signal

USB+ The pairs are used to transmit

Data/Address/Command

VCC USB Cable Power Detector

VSS Ground

Specifications

Above technical information is based on industry standard data and tested to be reliable. However, Transcend makes no warranty, either expressed or

implied, as to its accuracy and assumes no liability in connection with the use of this product. Transcend reserves the right to make changes in

specifications at any time without prior notice.

Environment

Storage Media 3.5 inch SATA Hard Disk Drive

Temperature Operation 5 ℃ to 55 ℃

Storage

-20 ℃ to 60 ℃

Power Supply DC input: 12V/2A

Size (L x W x H) 152.40mm ×44.80mm ×172.40mm

Weight 1040g (Max.)

Certificates CE, FCC, BSMI
