Traxxas LP SA10046 2.4GHz, Rx Transceiver Board User Manual RxRadioModuleUserManualRx

Traxxas LP 2.4GHz, Rx Transceiver Board RxRadioModuleUserManualRx

User Manual

Spectrum 2.4Ghz, RX Board User Manual
Version 1.0
2.4GHz Rx Transceiver Board Version: 1.0
User Manual Date: 8/1/2011 10:31:00 AM
Confidential © Traxxas 2009 Page 2 of 8
Revision History
Date Version Description Author
8/1/2011 1.0 Original. Chris S. Russell
2.4GHz Rx Transceiver Board Version: 1.0
User Manual Date: 8/1/2011 10:31:00 AM
Confidential © Traxxas 2009 Page 3 of 8
Table of Contents
1. INTRODUCTION ........................................................................................................................................5
2. USERS GUIDE INFORMATION................................................................................................................6
2.1 ANTENNA REGULATION ...........................................................................................................................6
2.2 EMISSIONS COMPLIANCE TESTING............................................................................................................6
2.3 WORKING WITH ADDITIONAL TRANSMITTERS...........................................................................................7
2.4 PRODUCT LABELING REQUIREMENTS........................................................................................................7
3. FCC RF EXPOSURE STATEMENT...........................................................................................................8
2.4GHz Rx Transceiver Board Version: 1.0
User Manual Date: 8/1/2011 10:31:00 AM
Confidential © Traxxas 2009 Page 4 of 8
2.4GHz Rx Transceiver Board Version: 1.0
User Manual Date: 8/1/2011 10:31:00 AM
Confidential © Traxxas 2009 Page 5 of 8
1. Introduction
The user manual contains information pertaining to output power, operating frequency, operating channels, data
rates, tuning range, intended use, general installation instructions, and antenna connector and gain information.
.
2.4GHz Rx Transceiver Board Version: 1.0
User Manual Date: 8/1/2011 10:31:00 AM
Confidential © Traxxas 2009 Page 6 of 8
2. Users Guide Information
It is required that Traxxas LLP place the text below in the product user guide along with all other pertinent
regulatory information.
We are only using the module on our own motherboard, and there is sufficient filtering on the module for the
supplied voltage supply.
The requirements for FCC Limited Modular Approval were released in March 2009 in the FCC’s Public
Notice: FCC Public Notice DA-08-672, Part 15 Unlicensed Modular Transmitter Approvals.
Design Criteria for Modular Approval
General Conditions:
The following conditions must be strictly adhered to for modular approval:
1. No modification to the module including the circuitry is permitted.
2. Design criteria to include antenna, interconnects, and local oscillator.
3. Testing of the final device configuration for Digital Emissions Compliance
The Spectrum 2.4GHz, Rx Transceiver Board may not be altered or modified in any manner by the OEM or
other entity. Additionally, no component may be added which could change the radio frequency (RF)
characteristics. These include, but are not limited to unintentional or spurious emissions, immunity, ESD
characteristics, or other items commonly associated with RF devices. This includes all components; passive and
active. Additionally, no RF components may be placed between the RF output of the module and the antenna.
2.1 Antenna Regulation
The antenna has been selected and specifically tested with the Spectrum 2.4GHz, Rx Transceiver Board, and
has been certified through the regulatory agencies in the US and European Union authorized use. Use of any
other antenna type used with this unit voids the LMA grant for the said module.
2.2 Emissions Compliance Testing
Notwithstanding the Modular Approval for the device with associated antenna, the end product configuration
must meet digital emissions compliance and must be tested in accordance with FCC Part 15 requirements
confirming radiated emissions are within specified limits.
Applicable FCC guidelines:
Part 15 Section 15.109 Sub-paragraph A, Class B Radiated Emission Limits.
2.4GHz Rx Transceiver Board Version: 1.0
User Manual Date: 8/1/2011 10:31:00 AM
Confidential © Traxxas 2009 Page 7 of 8
These emission tests can be conducted by the manufacturer or by contacting an approved test facility equipped
and certified accordingly. The results of these emissions tests are not required to be submitted to the FCC or
Traxxas, but should be kept on file by the OEM.
2.3 Working with Additional Transmitters
The Spectrum 2.4GHz, Rx Transceiver Board should not be operated with any other transmitter in the end
product. However, if such an application comes about, further regulatory compliance from the FCC must be
obtained.
2.4 Product Labeling Requirements
FCC product labeling requirements stipulate an FCC label, including specific text, be placed on the device
containing the module. The product label must include the following text and must be affixed to the exterior of
the final product. The text should be located beneath the FCC compliance logo.
This product contains the Spectrum 2.4GHz, Rx Transceiver Board
FCC ID: XVE-SA10046
In addition to the above text FCC Part 15.21 stipulates that the Digital Electronic Devices manufacturers must
also have the following statements printed in their user/operations manual and/or indicate this exact text on the
side of the final device.
“This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user’s authority to operate the equipment”
2.4GHz Rx Transceiver Board Version: 1.0
User Manual Date: 8/1/2011 10:31:00 AM
Confidential © Traxxas 2009 Page 8 of 8
3. FCC RF Exposure Statement
“This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End
users must follow the specified operating instructions for satisfying RF exposure compliance. The antenna used
for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must
not be co-located or operating in conjunction with any other antenna or transmitter.”
This document is provided “as is” with no warranties whatsoever including any warranty of merchantability,
non-infringement, fitness for any particular purpose, or any warranty otherwise arising out of any proposal,
specific or simple.
Traxxas LLP disclaims all liability, including liability for infringement of any proprietary rights, relating to use
of information in this document. No license, expressed or implied, by estoppel or otherwise, to any intellectual
property rights is granted herein.
