Model GL700 Series Laser Systems
Operator’s Manual
Single-Grade, Dual-Grade, Long-Range, and Steep-Grade Lasers
Introduction
Thank you for choosing one of the Spectra Precision Lasers from the
Trimble family of precision grade lasers. You’ve just made a wise investment
in field-proven products made by Trimble, the world’s largest manufacturer
of laser-based leveling, alignment, and grade-control systems.
The grade laser is an easy-to-use tool that allows you to take accurate
horizontal measurements with grade up to 2500 ft (750 m) away using a
receiver. The exclusive automatic alignment features allow for quick and easy
setup. The exclusive temperature and grade compensation systems are
designed for superior accuracy so that your grade laser can be used for ALL
machine-control, general construction, and surveying applications requiring
tight tolerances…under all environmental conditions.
Included in this manual is information about setting up, using, maintaining,
and troubleshooting the laser system. Use the manual now to learn basic
skills, and use it later for reference. For the best performance of your laser
system, follow the maintenance and care recommendations in this manual. Be
sure to keep this manual in a convenient place for easy referencing.
Your comments and suggestions are welcome; please call the Trimble
Engineering and Construction Division listed below for your local, authorized
Trimble office.
Trimble
5475 Kellenburger Road
Dayton, Ohio 45424-1099 U.S.A.
Phone: (937) 233-8921
(800) 538-7800
Fax: (937) 233-9441
Internet: www.trimble.com
Claim for Damage in Shipment
The grade laser system generally includes a laser, remote control, receiver,
general-purpose clamp, operator’s manual, laser safety kit, carrying case,
rechargeable batteries, and battery recharger. The components vary
depending on the system that you purchase.
You should inspect your laser system as soon as you receive it. It has been
packaged for safe delivery. If it is damaged in any way, immediately file a
claim with the carrier or, if insured separately, with the insurance company.
Owner’s Record
Be sure to record the serial number of each component in the space provided
below. Refer to these numbers if you need to contact your Trimble dealer
regarding any of these products.
Safety Information
Included in this manual are CAUTIONS and Notes. Each of these words
represents a level of danger or concern.
A CAUTION indicates a hazard or an unsafe practice that could result in
minor injury or property damage.
A Note indicates important information unrelated to safety.
Laser Safety
The IEC and the United States Government Center of Devices for Radiology
Health (CDRH) has classified this laser as a Class I laser product (standard
model) and Class II product (long-range model).
Operation
For detailed installation and operating instructions, follow the instructions
given in this manual for this laser. The maximum radiant power output of this
laser is less than 5 mW.
Controls
Controls are listed in the operation section of this manual.
CAUTION: Use of controls or adjustments performance of procedures other
than those specified herein may result in higher dosage of laser exposure.
This laser complies with all applicable portions of Title 21 of the code of
Federal Regulations, Department of Health and Human Services, Food and
Drug Administration (Federal Register, Volume 50, Number 161, August 20,
1985).
Protective Eyewear
This laser complies with OSHA Standards Act Section 1518.54 for use
without eye protection devices. Consequently, protective eyewear is neither
required nor recommended.
As with any visible laser device, the following safety rules should be
observed:
• Never look directly into a laser beam or point the beam into the eyes of
others. Set the laser at a height that prevents the beam from shining
directly into people’s eyes.
• Do not remove any warning signs from the laser.
• Use of this product by people other than those trained on this product
may result in exposure to hazardous laser light.
• If initial service is required, which results in the removal of the outer
protective cover, removal must only be performed by factory-trained
personnel.
Questions about laser safety should be addressed to:
Trimble Engineering and Construction Division
5475 Kellenburger Road
Dayton, OH U.S.A. 45424-1099
Attention: Quality Assurance Group, Laser Safety Officer
Labels required for this product:
• Certification and Identification:
• Caution Logotype:
Features and Functions
Laser
1. Power Button—turns the laser on/off.
2. Status LED—shows the status of various conditions including an
internal, electronic, or a mechanical error (solid red), low-battery
(flashing yellow), manual mode (flashing red), HI alert (fast flashing red),
and out-of-level (flashing green).
3. Manual Button—changes the laser from automatic self-leveling to manual
mode.
4. ∠ Axis Up and Down Buttons—change the grade for the ∠ axis.
5. Rotation-Control Button—changes the laser beam rotation speed (300,
600, and 900 rpm).
6. ∠ Axis Up and Down Buttons (dual-grade laser only)—change the grade
for the ∠ axis.
7. Axis-Alignment Buttons—rotates the grade axis
clockwise/counterclockwise. Rotating the grade axis simulates turning
the laser on its tripod, with fine adjustment capability.
8. Liquid Crystal Displays (LCDs)—show the percentage of grade,
approximate charge of the batteries, beam's rotation speed, and axis
alignment (if other than zero). The single-grade laser has one LCD.
9. Antenna (for radio remote-control lasers only)—sends and receives
signals to and from the remote control.
10. Sunshade—protects the lighthouse from the environment.
11. Lighthouse—is the 360° exit window for the laser beam. The lighthouse
is sealed and protects the internal components from the environment.
12. Rotor—contains the rotating laser beam.
13. Handle—allows you to carry the laser easily.
14. Battery Recharging Receptacle—is the 4-pin receptacle that the battery
recharger plugs into.
15. Battery Housing—holds six D-cell Ni-Cd, Ni-MH, or backup alkaline
batteries.
16. 5/8-11 Tripod Mount—allows the laser to be connected to a standard
5/8-11 tripod or column mount.
17. Sighting Guides—are used to visually align the laser with a directional
hub or grade stake.
18. Axis-Alignment Marks—correspond with both laser axes and are used
to align the laser in the correct grade direction.
One-Way and Two-Way Radio Remote Controls (for radio equipped laser
only)
1. Power/Standby Button—turns the remote control on/off and
activates/deactivates standby mode.
2. Manual Button—changes the laser from automatic self-leveling to manual
mode.
3. Mode Button—allows you to choose the laser’s operational mode,
which includes grade change, automatic axis alignment, grade matching,
PlaneLok, grade bump, grade reverse, manual, and beam rotation speed.
4. Up and Down Buttons—increase/decrease the grade for the ∠ and ∠
axes and increase/decrease the laser beam’s rotation speed. When the
laser is in manual mode, these buttons can also be used to
increase/decrease the slope of the laser beam.
5. Left and Right Buttons—increase/decrease the slope of the ∠ axis when
the laser is in manual mode.
6. Liquid Crystal Display (LCD)—shows the mode messages, beam’s
rotation speed, and percentage of grade (on two-way remote control
only).
7. Remote Port Contacts—transfer operation and elevation information
between the remote control and the receiver.
8. Antenna—transfers signals between the radio remote control and laser.
9. Enter Button—is a multifunctional button confirms the selection made
from the laser’s operational mode and activates the backlighting
function.
10. Mounting Clip—allows the remote control to be connected to a grade-
rod holster, belt, or a screw on a wall.
11. Battery Housing—holds two AA alkaline batteries.
Accessories
Connector Cable
1. Contacts—transfers grade-display signals between the hand-held
receiver and radio remote control.
2. Mounting Plate—connects to the back of a hand-held receiver so that
the radio remote control and hand-held receiver can transfer signals.
3. 12-ft (4-m) Cable—transfers signals between the radio remote control
and a hand-held receiver.
4. Clamp—connects to the radio remote control so signals can be
transferred between the hand-held receiver and radio remote control.
5. Mounting Guides—fit into the mounting channels on the back of a hand-
held receiver so that signals can be transferred between the radio remote
control and hand-held receiver. To install, first put the small key of the
clamp into the guide on the back of the remote control. Next clip the
top part of the clamp into the guide on the front of the remote.
Remote Holster
1. Mounting Slot—provides an opening for the radio remote control clip to
be slipped into.
2. Mounting Strap—allows the radio remote control to be connected to the
grade rod for automatic alignment functions. The holes in the strap
accommodate grade rods of varying sizes.
Battery Recharger
1. 4-Socket Plug w/ Retaining Collar—connects to the 4-pin receptacle on
the laser.
2. Grounded Receptacle—connects to the supplied grounded electrical
power cord.
External Power Cord
1. Alligator Clips (+ and –)—connect to the positive (+) and negative (–)
terminals on a 12 V dc battery.
2. 4-Socket Plug—connects to the 4-pin receptacle on the laser.
Quick-Disconnect Adapter
The quick-disconnect adapter allows you to quickly connect/disconnect the
laser from the tripod.
3 1/2-8 Adapter
The 3 1/2-8 adapter allows you to connect the laser, which has a 5/8-11
threaded mount, to a tripod or other mounting device that has a 3 1/2-8
threaded mount.
Steep-Grade Adapter
The steep-grade adapter allows the internal leveling mechanism of the steep-
grade laser to level the laser at grades greater than 25%.
Offset Plate
The offset plate mounts to the steep-grade adapter and eliminates offset
errors when the laser is being used for steep-grade applications by
maintaining the laser’s rotor position over the laser’s mounting threads. This
adapter HAS to be used when performing a steep-grade axis alignment that is
perpendicular to the steep-grade axis.
How to Use the Laser System
Laser
Powering the Laser
Batteries
Depending on the laser system configuration that you purchase, the laser is
shipped with either rechargeable nickel-cadmium (Ni-Cd) or nickel/metal-
hydride (Ni-MH) batteries. Even if you buy a laser that uses Ni-Cd batteries,
you can upgrade to Ni-MH batteries. The upgrade installation, however, must
be performed by an authorized service center.
Alkaline batteries can also be used as a backup; however, rechargeable
batteries should be reinstalled in the laser as soon as possible.
To let you know when the batteries are getting low, the status LED flashes.
When the status LED flashes yellow, the laser has less than one hour of
running time. When the status LED remains on solid yellow, the batteries
have less than five minutes running time.
After shipment, the batteries may not have enough power to operate the
system. Be sure to recharge the batteries before use. The intelligent recharger
maximizes battery life and reduces the time before battery replacement by
precisely controlling the recharging/discharging cycle and by not
overcharging the batteries. The maximum time to achieve a full charge is six
hours.
Recharging the Batteries
Note: Do not recharge alkaline batteries. Trying to recharge them does not
damage the laser but the batteries do not recharge.
1. Plug the 4-socket plug into the laser and tighten the retaining collar.
2. Plug the supplied grounded electrical power cord into the battery-
recharger.
3. Plug the grounded electrical power cord into an appropriate outlet.
Note: The recharging status is indicated on the recharger.
Left LED Right LED Recharging Status
Off Off No connection or no batteries
Off On Recharging is in progress
Flashing Off Recharging is complete
Flashing Flashing Recharging error
Note: The laser will not operate while the batteries are recharging.
Note: Some countries or local areas have regulations regarding the disposal
of rechargeable batteries. Please be sure to follow the regulation in your area.
Installing/Removing the Batteries
CAUTION: The batteries should be removed when storing the laser more
than 30 days.
1. Remove the four screws from the battery housing. Remove the battery-
housing compartment.
2. Install/remove the batteries.
Note: When installing the batteries, be sure to note the positive (+) and
negative (-) diagram inside of the housing.
Note: The laser has reverse polarity protection. If the batteries are put in
wrong, no damage occurs to the laser but it does not work. Allow it one
minute to recover after the batteries have been installed correctly.
3. Put the battery-housing compartment in place and reinstall the four
screws.
External Power Cable
The laser system also includes an external power cable so you can operate
the laser in case the internal batteries become discharged. The internal
batteries will not recharge, however, while you’re using the external power
cable.
Connecting/Disconnecting the External Power Cable
CAUTION: To avoid damaging the laser, make sure the laser is off before
connecting/disconnecting the external power cable to/from the laser.
1. Connect the alligator clips to a 12-V dc automotive or motorcycle
battery noting the correct polarity (red = positive, black = negative).
2. Plug the 4-socket plug into the laser and tighten the retaining collar.
3. To disconnect the external power cable from the laser, loosen the
retaining collar, unplug the 4-socket plug from the laser, and remove the
alligator clips from the battery.
Learning Basic Laser Functions
Turning On/Off the Laser
1. Press the power button to turn on the laser.
Note: The laser always powers up in the automatic self-leveling mode. If the
laser is out of its self-leveling range and remains out of it for more than 30
minutes, the laser shuts down completely.
Note: When the laser is initially turned on, the LCD shows the approximate
charge of the batteries, the laser beam’s rotation speed, and manual axis-
alignment position if it’s other than zero. After the LCD shows this
information, the last-entered grade immediately appears in the LCD. The
status LED flashes green to indicate that the laser is self-leveling. After the
laser has self-leveled at the indicated grade, the laser beam rotates and the
status LED stops flashing.
Note: After the laser has been level for more than 30 minutes, the HI alert
activates. If the laser is disturbed (tripod bumped, etc.) so that when it re-
levels the laser beam elevation changes by more than 1/8 in. (3.1 mm), the HI
alert shuts down the laser and rotor, and the status LED flashes red two times
per second (twice the manual-mode rate).
2. To turn off the laser, press and hold the power button for three seconds.
Selecting the Rotation Speed
The laser has three laser beam rotation speeds—300, 600, and 900 rpm. The
rotation speed can be changed at any time to meet your job-site conditions.
Use 600 rpm for held-held receivers and most machine-control systems.
1. Repeatedly press and release the rotation-control button until the desired
rotation speed appears in the LCD.
Note: The selected rotation speed briefly appears in the LCD. After a few
seconds, the selected percentage of grade appears in the LCD.
Changing the Grade Value
The grade value for both axes can be changed using two methods—standard
and quick-change. The standard method is used for entering small changes in
the grade value. The quick-change method is used for setting grade to zero
and entering large changes in the grade value.
Standard Method
Note: The grade value can be quickly set to 0.000% by simultaneously
pressing and releasing the up and down buttons for the axis you want to
change.
1. Press and hold the up or down button for the axis you want to change
until the correct grade value appears in the laser’s LCD.
Note: The speed of the grade value change increases with the amount of time
the button is held down.
Note: Grade values from -0.500 to 9.999% are displayed in thousandths of a
percents. Grade values greater than 10% are displayed in hundredths of a
percent.
Note: All changes to the axis-alignment rotation made prior to changing the
grade value using the standard method are retained.
Quick-Change Method
Note: The grade value can be quickly set to 0.000% by simultaneously
pressing and holding the up and down buttons for the axis you want to
change
1. Simultaneously press and hold the up and down buttons for the axis you
want to change to set the grade value to 0.000%.
Note: The grade value for the ∠ axis increases in 1.00% increments. The
grade value for the ∠ axis increases in 5.00% increments.
2. Continue pressing and holding the up and down buttons until the correct
grade value appears in the laser’s LCD.
Note: When the grade value for either axis reaches its highest amount, the
grade value switches to the lowest value for that axis. In the ∠ axis, for
example, the value switches from +10.00% to –10.00%. In the ∠ axis, the
value switches from 25.00% to -0.500%. For steep-grade lasers, the value
switches from 110.00% to -0.500%.
Note: All changes to the axis-alignment rotation made prior to changing the
grade value using the quick-change method are cancelled.
Activating/Deactivating Manual Mode
Manual mode bypasses the laser’s automatic self-leveling mode so you can
use the laser in vertical mode. Manual mode also allows you to tilt the laser
beyond its built-in sloping capability so you can perform steep-sloping
horizontal applications.
1. Make sure the laser is on and in the orientation appropriate for your
application needs (horizontal or vertical).
2. Press the manual mode button.
Note: When manual mode is activated, the status LED flashes red once per
second and scrolling horizontal segments appear in the LCD.
3. To resume automatic self-leveling mode, press the manual button again.
Rotating the Axis Alignment Manually
The axes-alignment buttons allow you to electronically rotate the laser so that
the grade of the laser beam properly aligns to the job-site grade.
1. To make coarse adjustments, look through the sighting guides on top of
the laser and turn the laser on the tripod until it is properly aligned.
2. To make fine adjustments, press and hold the axis-alignment button that
corresponds to the direction you want to rotate the laser’s axis until the
desired rotation has been reached.
Note: A vertical line in the LCD moves to the left or right to give you a rough
indication of the rotation position.
One-Way and Two-Way Radio Remote Controls (Available for Radio-
Equipped Lasers Only)
Powering the Radio Remote Control
Batteries
CAUTION: The batteries should be removed when storing the radio remote
control more than 30 days.
Installing/Removing the Batteries
1. Turn the battery-housing knob counterclockwise to release the battery-
housing door.
2. Install/remove the batteries.
Note: When installing the batteries, be sure to note the positive (+) and
negative (-) diagram inside of the housing.
Note: The radio remote control has reverse-polarity protection. If the
batteries are put in wrong, no damage occurs to the radio remote control but
it does not work. Allow it one minute to recover after the batteries have been
installed correctly.
3. Put the battery-housing door in place and turn the battery-housing knob
clockwise.
Learning Basic Radio Remote Control Functions
The radio remote control is a hand-held device that allows you to send
operational commands to the laser from a remote location. While using the
radio remote control, make sure its antenna is pointing skyward. For
example, if you’re holding the radio remote control in your hand and using it
in the horizontal orientation, the antenna should be at a 90º angle to the radio
remote control. If you’re connecting the radio remote control to a grade rod
and the radio remote control is oriented vertically, the antenna should be
sticking up from the top of the radio remote control.
Turning On/Off the Radio Remote Control
1. Press the power button to turn on the radio remote control.
Note: When the two-way radio remote control is initially turned on, the axes
symbols and last-entered grade for each axis briefly appear in the LCD.
2. To turn off the radio remote control, press and hold the power button for
3 seconds.
Selecting the Operational Mode
The mode button allows you to choose the laser’s operational mode, which
includes automatic axis alignment, grade matching, PlaneLok, grade bump,
grade reverse, manual, and beam rotation speed. A “hidden” button sequence
also allows you to calibrate the laser from the radio remote control (see the
“Calibration” section of this manual for more information.
1. Repeatedly press and release the mode button to cycle through the
operational mode menu. The menu selections appear in the radio remote
control’s LCD.
Confirming the Operational Mode
1. Press the mode button to select the operational mode appropriate for you
application needs.
2. Press the enter button to confirm your selection.
Activating/Deactivating the Backlighting Feature
1. Press and hold the enter button to activate backlighting.
Backlighting turns off automatically to save battery life.
Selecting the Rotation Speed
The laser has three laser beam rotation speeds—300, 600, and 900 rpm. The
rotation speed can be changed at any time to meet your job-site conditions.
Use 600 rpm for held-held receivers and most machine-control systems.
1. Select “Rotation Speed” from the operational mode menu using the
mode button.
2. Repeatedly press and release the radio remote control’s up or down
button until the desired rotation speed has been selected.
Note: The rotation speed appears in the two-way radio remote control’s
LCD. If you are using a one-way remote control, you must look at the laser’s
LCD for this information.
3. Press the enter button to confirm the selected rotation speed.
Changing the Grade Value
The grade value for both axes can be changed using two methods—standard
and quick-change. The standard method is used for entering small changes in
the grade value. The quick-change method is used for setting grade to zero
and entering large changes in the grade value.
Standard Method
Note: The last-entered grade value for each axis appears in the two-way radio
remote control’s LCD. If you are using a one-way remote control, you must
look at the laser’s LCD for this information.
Note: The grade value can be quickly set to 0.000% by simultaneously
pressing and releasing either the laser’s or the radio remote control’s up and
down buttons for the axis you want to change.
1. Select the desired grade axis (∠ or ∠) from the menu using the mode
button.
2. Press and hold the up or down button for the axis you want to change
until the desired grade value appears in the laser’s LCD. If you are using a
two-way radio remote control, this information appears in the radio
remote control’s LCD.
Note: The speed of the grade value change increases with the amount of time
the button is held down.
Note: Grade values on the radio remote control are displayed in thousandths
of a percents.
Note: All changes to the axis-alignment rotation made prior to changing the
grade value using the standard method will be retained.
Quick-Change Method
1. Select the desired grade axis (∠ or ∠) from the menu using the mode
button.
2. Simultaneously press and hold the up and down buttons for the axis you
want to change to set the grade value to 0.000%.
Note: The grade value for the ∠ axis increases in 1.00% increments. The
grade value for the ∠ axis increases in 5.00% increments.
3. Continue pressing and holding the up and down buttons until the desired
grade value appears in the laser’s LCD. If you are using a two-way radio
remote control, this information also appears in the radio remote control’s
LCD.
Note: When the grade value for either axis reaches its highest amount, the
grade values switches to the lowest value for that axis. In the ∠ axis, for
example, the value switches from +10.00% to –10.00%. In the ∠ axis, the
value switches from 25.00% to –0.500%. For steep-grade lasers than value
switches from 110.0% to –0.500%.
Note: All changes to the axis-alignment rotation made prior to changing the
grade value using the quick-change method will be cancelled out.
Activating/Deactivating Manual Mode
Manual mode bypasses the laser’s automatic self-leveling mode so you can
use the laser in vertical mode. Manual mode also allows you to tilt the laser
beyond its built-in sloping capability so you can perform steep-sloping
horizontal applications.
1. Press the manual mode button.
Note: When manual mode is activated, the laser’s status LED flashes red
once per second and scrolling horizontal segments appear in the laser’s
LCDs. If you are using a two-way radio remote control, “Manual Mode”
appears in the radio remote control’s LCD.
2. To resume automatic self-leveling mode, press the manual mode button
again.
Activating Automatic-Axis-Alignment, Grade-Matching, and PlaneLok
Modes
Note: For more detailed information about these modes, please see the
System Setup section of this manual.
1. Select the desired mode from the operational mode menu using the mode
button.
2. Select the axis (∠ or ∠) that you are aligning using the radio remote
control’s up or down buttons.
3. Press the enter button to confirm the selection.
Note: While the system is aligning, “Start” followed by “Wait” appears in the
radio remote control’s LCD.
4. When the alignment has been completed, “Complete” appears in the radio
remote control’s LCD.
Note: Alignment can take one to five minutes to complete.
Activating/Deactivating Standby Mode
Standby mode, which can only be activated by using a one-way or two-way
radio remote control, is a power-saving feature that conserves laser battery
life.
1. Quickly press and release the radio remote control’s power button again
to activate standby mode.
Note: When standby mode is activated, the laser beam, rotor, self-leveling
system, and LEDs shut down. So that you know that the laser is in standby
mode rather than being turned off, dashed lines appear in the laser’s LCD. In
the radio remote control’s LCD, the word “standby” appears.
2. To deactivate standby mode and restore full operation of the laser,
quickly press and release the radio remote control’s power button. The
laser and all other functions turn on again.
System Setup
General Setup Information
• Prior to beginning work, decide where to place the laser for optimum
coverage of the job site.
• Place the laser on the job site where it will be out of the way of traffic and
will not be obstructed by equipment with respect to the machine-mounted
receiver.
• Set the height of the tripod and laser so that the laser beam will strike the
receiver when it’s positioned correctly on a machine or grade rod.
• Adjust the laser’s alignment to the job site as needed.
• When using the radio remote control, make sure the radio remote
control’s antenna is pointing skyward and the laser’s antenna is flipped
up. An “R” appears in the right corner of the remote’s first display line
indicating a connection has been made and the power is on.
• When the radio remote control and laser are “linked,” a flashing bar
above the “T” (antenna icon) appears in the right corner of the radio
remote control LCD.
• The laser-beam operating radius for the standard laser models is 1,500
feet (460 m).
• The laser-beam operating radius for the long-range mode is 2,500 feet
(7600 m).
• The radio-remote-control operating radius for the standard operating
modes is 750 feet (230 m). The operating radius for the radio remote
control in automatic alignment modes is 500 feet (150 m).
Getting Connected
Laser
Connecting the Laser to a Tripod
All lasers have a 5/8-11 tripod mount on the bottom of the laser so you can
connect the laser to a standard tripod, column clamp, or other mounting
device. The laser can also be used without a tripod, but the laser must be set
on a stable surface.
In addition to using the laser in horizontal mode, you can use it in vertical
mode. To do so, however, an after-market vertical mounting bracket is
needed. For instruction on how to use the vertical mounting bracket, consult
the specific manufacturer’s instructions.
1. Insert the tripod’s 5/8-11 screw into the laser’s threaded 5/8-11 tripod
mount.
2. Turn the screw counterclockwise to hold the laser securely in place.
3. To detach the laser from the tripod, turn the screw clockwise.
Connecting the Laser to the Adapters
Depending on the laser system you purchase, additional mounting
accessories may be shipped with your laser. The long-range (agricultural)
laser system includes a quick-disconnect adapter and a 3 1/2-8 adapter. The
steep-grade laser system includes a steep-grade adapter and offset plate.
Quick-Disconnect and 3 1/2-8 Adapters
1. Thread the appropriate adapter into the 5/8-11 threaded mount on the
bottom of the laser.
Note: The carrying case is designed so the adapter can remain on the laser.
Steep-Grade Adapter and Offset Plate
1. Set up a tripod so that its mounting surface is as close to true level as
possible. Make sure that one of the tripod legs is aligned to the down-
grade side of the ∠ axis of the laser.
2. Connect the offset plate to the steep-grade adapter.
3. Connect the steep-grade adapter (with laser and offset plate connected) to
the tripod.
4. Adjust the slope knob on the steep-grade adapter to the desired grade.
Align the adapter to the desired steep-slope direction hub.
5. Thread the offset plate into the 5/8-11 threaded mount on the bottom of
the laser. Make sure the offset plate is connected at the mark that indicates
the desired grade.
Radio Remote Control
Connecting the Remote Holster to a Grade Rod
1. Wrap the mounting strap around the grade rod and fasten it securely in
place.
Connecting the Radio Remote Control to the Remote Holster
1. Slip the radio remote control mounting clip into the mounting slot of the
remote holster.
Setting Up the Laser System
Setting Up the Laser in Manual Mode
1. Press the manual mode button on the laser or radio remote control.
Note: When manual mode is activated, the laser’s status LED flashes red at a
1-Hz rate and scrolling horizontal segments appear in the laser’s LCDs. If
you are using a two-way radio remote control, this information also appears
in the radio remote control’s LCD.
2. To adjust the laser in the ∠ axis so that the laser beam matches the
desired slope, use the up and down buttons on the laser or radio remote
control.
3. To adjust the laser in the ∠ axis so that the laser beam matches the
desired slope, use the up and down buttons on the laser or the left and
right buttons on the radio remote control.
4. To resume automatic self-leveling mode, press the manual button on the
laser or radio remote control again.
Aligning the Axis Manually
The manual axis alignment buttons are primarily used on lasers that don’t
have radio remote control capability. These buttons rotate the grade axis
electronically (simulates turning the laser on its tripod, with fine adjustment
capability up to a maximum of ±40 degrees).
1. Set up the laser over a reference point. Make sure the laser is positioned
so that the ∠ and ∠ axes are pointing in the right direction.
2. Using the sighting guides as guide, rotate the laser on its tripod to align the
laser to the direction hub.
3. Connect a receiver to a grade rod and turn on the receiver. Make sure you
position the receiver so that it is at the correct elevation for the distance
(and grade) from the laser to the direction hub.
4. Set the grade rod on the direction hub.
Note: If only one person is manually aligning the laser, use a bipod
(commonly used with prism poles) to keep the grade rod plumb when
placing is on the direction hub.
5. Press the appropriate manual axis alignment button to align the laser plane
to the receiver. The clockwise axis alignment button rotates the laser
clockwise; the counterclockwise axis alignment button rotates the laser
counterclockwise.
6. Press and hold the axis alignment button until you get an on-grade reading
on the receiver.
Setting Up the Laser in Vertical Mode
1. Set up the laser on its side.
Note: If you’re using the laser with a tripod, an after-market vertical mounting
bracket is needed. For instruction on how to use the vertical mounting
bracket, consult the specific manufacturer’s instructions.
2. Press the manual button on the laser or radio remote control.
3. To adjust the laser beam for line direction, use the up and down buttons
on the laser or radio remote control until the laser beam matches the line
point.
4. To adjust the plumb position of the laser beam, use the up and down
buttons on the laser or the left and right buttons on the radio remote
control.
Establishing Control
Determining Height of Instrument (HI)
1. Set up the laser and turn it on.
2. Connect a receiver to a grade rod. Turn on the receiver.
3. Place the grade rod on a job-site benchmark (BM). Adjust the height of
the receiver until the receiver’s LCD shows an on-grade reading.
4. Add the grade-rod reading to the benchmark to determine the height of
instrument. Use the HI as a reference for all other elevation measurements.
Establishing Elevation Control Hubs
The elevation control hub can be used to re-establish the elevation of the
laser plane in case the laser setup gets disturbed.
1. Establish an elevation-control hub close to the laser and determine the HI.
Note: If you’re also going to establish a grade control hub, make sure the
elevation-control hub and grade -control hubs are on the same axis.
Establishing Grade Control Hubs
The slope control hub can be used to check the alignment of the laser on the
job site and to confirm the grade entered into the laser.
1. Check the grade on a minimum of three hubs on the job site. The hubs
should be in lines that are 90° from one another with one line containing
two hubs.
Note: Because the accuracy of this procedure is based on the known
elevation of the hubs, the exact elevation of the hubs is critical.
Note: If there isn’t enough space for the laser to be setup on the desired
centerline, the laser can be set up on a line parallel to the centerline (D1-D2).
Reversing the Grade
(One-Way and Two-Way Radio Remote Controls)
The sign of the ∠ axis can be changed using the one-way or two-way radio
remote control.
1. Set up the laser. Turn on the laser and flip its antenna up.
2. Turn on the radio remote control and make sure its antenna is pointing
skyward.
3. Select “Grade Reverse” from the menu using the mode button.
4. Press the enter button to confirm the selection.
Note: On a one-way radio remote control, “Reversing” appears in the radio
remote control’s LCD to indicate that the process is occurring and the sign
of the ∠ axis will be changed on the laser’s LCD.
Note: When grade reversing has been completed, “Grade Reversing
Complete” appears in the LCD. If “Grade Reversing Unconfirmed” appears
in the LCD, check the distance between the laser and radio remote control
and try reversing the grade again.
Note: On a two-way radio remote control, the sign of the ∠ grade value
reverses to indicate that grade reversing has been completed.
Automatic Alignment Modes Summary
The laser system has three automatic alignment modes:
• Axis Alignment
• Grade Matching
• PlaneLok
To use these modes, a radio remote control (one-way or two-way) and hand-
held receiver are required. The radio remote control and receiver are typically
mounted to a grade rod, which must be placed somewhere between 60 feet
(20 m) and 500 feet (150m) from the laser. Automatic axis alignment can take
from 1 to 5 minutes to complete.
Automatic Axis Alignment Mode
This automatic axis alignment function replaces the manual alignment scope
and vernier base traditionally used to align the desired grade axis to a hub.
When this mode is being used, the receiver and radio remote control are
mounted to a grade rod, the desired grade is dialed into the laser, and the
grade rod is placed on the hub that the grade axis is being aligned to. When
activated, automatic axis alignment mode adjusts the direction the desired
grade axis is pointing to by electronically simulating “rotating” the laser on its
mounting base. This mode is typically used for agriculture, road
construction, and steep-grade applications where precision alignment of the
grade axis is required.
Grade-Matching Mode
This automatic alignment function changes the grade of the desired axis to
automatically match an unknown grade.
When this mode is being used, the receiver and radio remote control are
mounted to a grade rod, the approximate grade (within 1.5% of the actual
grade) is dialed into the laser, and the grade rod is benchmarked to the laser-
beam elevation at a point within 3 feet (1 m) of the laser. Without changing
the receiver’s elevation on the rod, the grade rod is then placed anywhere a
grade reading is needed.
When activated, grade-matching mode automatically adjusts the grade up or
down to “search” for the receiver. When the center of the receiver is found,
the resultant grade is calculated and dialed into the laser, and displayed on the
two-way radio remote control (if being used).
When grade matching is complete, the receiver can be removed from the
alignment point and the calculated grade will remain in the laser. Both axes of
the laser can be grade matched in sequence. Grade-matching mode is used
for applications where the existing grade is not known, but will remain
relatively unchanged (such as installation of a sidewalk or driveway).
PlaneLok Mode
PlaneLok mode works like grade-matching mode, except the receiver is
permanently mounted to the desired elevation so that the laser can use the
receiver to continually monitor beam elevation. The laser ignores the internal
level vial for that axis, using the absolute elevation from the receiver for level
control.
PlaneLok Mode is used for applications where extreme precision of the laser-
beam elevation is required, such as runway applications.
Using Axis-Alignment and Grade-Reverse Modes
How Axis-Alignment Mode Works
Axis-alignment mode works by changing grade in the aligned-axis direction
and cross-axis directions then monitoring the elevation changes of the laser
beam at the receiver via the radio remote control. The desired axis-alignment
angle can then be calculated and the internal grade system “rotated”
electronically to align the simulated grade axis to the desired point.
Important Things to Know about Automatic Axis Alignment
Automatic Axis Alignment
• Replaces the alignment scope and vernier base traditionally used
• Can be done from any side of any axis of the laser, even if grade is dialed
into the opposite axis that’s being aligned
• Automatically adjusts the direction the grade axis is pointing to the
receiver/remote location
• Electronically simulates rotating the laser on its base to match the hub
For Proper Operation
• The desired grades must be entered into the laser
• The receiver must be at the correct alignment point
• The receiver must be between 60 feet (20 m) and 500 feet (150 m) from
the laser
For Best Accuracy
• Set up the laser to align to the elevation reference the farthest away (such
as the centerline of the road)
• If the hubs are equally distant, align to the hub with the smallest amount
of grade
Practical Application for Automatic Axis Alignment and Grade Reverse
Modes: Road Construction Setup
The main uses for the laser in road construction are for planar sections where
the road design calls for no vertical or super-elevated curves.
Automatic Axis Alignment Mode
1. Set up the laser over a point on the centerline of the road.
2. Using the sighting guide as a guide, rough align the laser with the
direction hub on the centerline.
Note: Because the laser can provide positive and negative slopes in the ∠
axis, make sure the laser’s handle is at a 90° angle to the centerline of the
road.
Note: If there isn’t enough space for the laser setup on the centerline, the
laser can be set up on a line parallel to the centerline of the road (D1=D2).
3. Enter the grade value for the axis that aligns with the centerline of the
road (∠).
4. Enter the grade value for the side of the road to be graded first into the
axis that is perpendicular to the centerline of the road (∠).
5. Connect a receiver and radio remote control to a grade rod.
6. Set the grade rod on the centerline direction hub.
7. Slide the receiver up/down the grade rod until the receiver’s LCD
shows an on-grade reading.
Note: The grade rod MUST be plumb.
8. Select “Axis Align” from the operational menu using the radio remote
control’s mode button.
9. Select the axis (∠ or ∠) that you are aligning using the up or down
buttons.
10. Press the enter button to confirm the selection. “Start” then “Wait”
appears on the LCD.
11. Hold the grade rod plumb and steady during automatic axis alignment.
Note: Alignment can take from 1 to 5 minutes to complete.
Note: When axis alignment has been completed, “Axis Alignment Complete”
appears in the LCD. If axis alignment fails, a failure message appears in the
LCD.
12. Check the laser’s alignment and grade values using previously
established elevation-control hubs and slope-control hubs as
references.
Note: If the alignment and grade values need small adjustments, they can be
changed using the radio remote control. See the “Correcting Slope/Height
Differences” section of this manual for more information.
13. Grade that side of the road
Grade Reverse Mode
Note: After you’ve finished grading one side of the road, you can reverse the
sign of the ∠ axis from the cab using the radio remote control.
1. Set the blade on a known elevation hub on the centerline of the road.
2. Select “Grade Reverse” from the operational menu using the radio
remote mode button.
3. Press the enter button to confirm the selection.
Note: On the one-way radio remote control, “Reversing” appears in the radio
remote control’s LCD to indicate that the process is occurring and the sign
of the axis will be changed.
Note: When grade reversing has been completed, “Grade Reversing
Complete” appears in the LCD. If “Grade Reversing Unconfirmed” appears
in the LCD, check the distance between the laser and radio remote control
and try reversing the grade again.
Note: On a two-way radio remote control, the sign of the grade display
reverses to indicate that grade reversing has been completed.
Practical Application for Axis Alignment Mode: Steep Grades Setup
(Embankments, Waste Dumps and Sea Walls)
1. Set up a tripod on an established offset from the baseline of the bank to
make sure that the laser beam will be at the required height above the
bank surface. Make sure that one of the tripod legs is aligned with the
down-grade side of the ∠ axis.
2. Connect the steep-grade adapter to the tripod.
3. Adjust the steep-grade adapter to the desired grade value.
4. Align the adapter with the direction hub on the top of the bank.
5. Connect the laser to the steep grade adapter making sure that the laser’s
handle is parallel with the baseline of the bank.
6. Make sure the desired slope and rotation speed are entered into the
laser.
7. Using the sighting guides as a guide, rough align the laser with the
direction hub.
8. Connect a receiver and radio remote control to a grade rod.
9. Set the grade rod on the direction hub.
10. Slide the receiver up/down the grade rod until the receiver’s LCD
shows an on-grade reading.
Note: The grade rod MUST be plumb.
11. Select “Axis Align” from the operational menu using the radio remote
control’s mode button.
12. Select the axis (∠ or ∠) that you are aligning using the up or down
buttons.
13. Press the enter button to confirm the selection. “Start” then “Wait”
appears on the LCD.
14. Hold the grade rod plumb and steady on the direction hub.
Note: Alignment can take 1 to 5 minutes to complete.
Note: When axis alignment has been completed, “Axis Alignment Complete”
appears in the LCD. If axis alignment fails, a failure message appears in the
LCD.
15. Check the laser’s alignment using previously established direction hub
and baseline hubs as references.
Note: If the alignment and grade values need small adjustments, they can be
changed using the radio remote control. See the “Correcting Slope/Height
Differences” section of this manual for more information.
Note: If the axis alignment should be done to the baseline hub #2
(perpendicular to the steep grade axis), attach the offset plate to the steep
grade adapter so that the rotor head of the laser is at the same axis as the
tripod mount. Follow the steps as described above with the only change that
the axis alignment using the grade rod has to be done at baseline hub #2
(steps 7, 9, and 14) instead of the direction hub.
Using Grade-Matching Mode
How Grade-Matching Mode Works
Grade-matching mode works by changing grade in the selected axis direction
then monitoring the elevation changes of the laser beam at the receiver via the
radio remote control. Once the laser “finds” the center of the receiver, the
resultant grade is calculated and stored in the laser and two-way remote
control.
Important Things to Know about Grade-Matching Mode
Grade-Matching Mode
• Automatically adjusts the grade of the selected axis to match an unknown
grade
• Searches for and finds “on-grade” of the mounted receiver within a 1.5%
grade range of the final grade (starting with the beam centered on the
receiver isn’t necessary)
• Stores and displays the resultant grade on the remote and laser
For Proper Operation
• The receiver can be removed after alignment, and the resultant grade
remains in the laser
• One or Both axes can be grade matched in sequence
• The initial grade MUST be within 1.5% of the final grade before starting
Practical Application for Grade-Matching Mode, One-Axis Setup: General
Construction Setup
If the ∠ axis is not at 0% grade, the laser has to be aligned in automatic axis
alignment mode with control hub #2 before the grade-matching mode can be
activated.
1. Set up the laser over the reference point.
2. Using the sighting guide as a guide, rough align the laser with slope-
control hub #2.
Note: The laser and control hub #1 must be on one axis, which is at 0%
grade.
3. Enter the approximate grade value for the ∠ axis and 0% for the ∠ axis.
Note: The automatic slope-searching range is ±1.5%. The approximated
grade should be within 1.5% of the final matched grade.
4. Connect a hand-held receiver and radio remote control to a grade rod.
5. Set the grade rod on control hub #1.
6. Slide the receiver up/down the grade rod until the receiver’s LCD
shows an on-grade reading.
Note: The grade rod MUST be plumb.
7. Go to slope-control hub #2 and set the grade rod on the hub. Make
sure you DON’T change the height of the receiver on the grade rod.
8. Select “Grade Match” from the operational menu using the mode
button.
9. Select the axis (∠ or ∠) that you are aligning using the up or down
buttons.
10. Press the enter button to confirm the selection. “Start” then “Wait”
appears in the radio remote control LCD.
11. Hold the grade rod plumb and steady on slope-control hub #2 during
grade matching.
Note: “Grade Matching Complete” appears in the radio remote control LCD
when grade matching has been completed. If grade matching fails, a failure
message appears in the radio remote control LCD. (See the
“Troubleshooting” section of this manual for more information.)
Note: The resultant grade appears in the laser LCD display and on the two-
way remote control LCD display (if used).
Note: Alignment can take 1 to 5 minutes to complete.
Grade-Matching Mode: Two Axes Setup
This function can only be done on one axis at a time. The laser needs to be
aligned with one of the slope-control hubs in automatic axis alignment mode
before dual axes grade-matching mode can be activated.
1. Set up the laser over a reference point.
2. Using the sighting guide as a guide, rough align the laser with the slope-
control hub #1.
Note: The two slope-control hubs must be in lines that are at a 90° angle
from one another.
Note: The laser and the elevation-control hub must be on one axis.
3. Enter the approximate grade value for the ∠ axis and the ∠ axis.
Note: The automatic slope searching range is ±1.5%. The approximated
grade should be within 1.5% of the final matched grade.
4. Connect a hand-held receiver and radio remote control to a grade rod.
5. Set the grade rod on the elevation-control hub.
6. Slide the receiver up/down the grade rod until the receiver’s LCD shows
an on-grade reading.
Note: The grade rod MUST be plumb.
7. Determine the HI by using the elevation-control hub as a reference.
8. Go to slope-control hub #1 and set the grade rod on the hub. Make sure
you DON’T change the height of the receiver on the grade rod.
9. Select “Grade Match” from the operational menu using the mode button.
10. Select the axis (∠ or ∠) that you are aligning using the up or down
buttons.
11. Press the enter button to confirm the selection. “Start” then “Wait”
appear in the LCD.
12. Hold the grade rod plumb and steady on slope-control hub #1 during
grade matching.
Note: “Grade Matching Complete” appears in the radio remote control LCD
when grade matching has been completed. If grade matching fails, a failure
message appears in the radio remote control LCD. (See the
“Troubleshooting” section of this manual for more information.)
Note: The matched grade value for the aligned axis appears in the laser’s and
two-way radio remote control’s LCDs.
Note: Alignment can take 1 to 5 minutes to complete.
13. Go to slope-control hub #2 and set the grade rod on the hub. Make sure
you DON’T change the height of the receiver on the grade rod.
14. Select “Grade Match” from the operational menu using the mode button.
15. Select the axis (∠ or ∠) that you are aligning using the up or down
buttons.
16. Press the enter button to confirm the selection.
17. Hold the grade rod plumb and steady on slope-control hub #2 during
grade matching.
Note: “Grade Matching Complete” appears in the radio remote control LCD
when grade matching has been completed. If grade matching fails, a failure
message appears in the radio remote control LCD. (See the
“Troubleshooting” section of this manual for more information.)
Note: The matched grade value for the aligned axis appears in the laser’s and
two-way radio remote control’s LCDs.
Note: Alignment can take 1 to 5 minutes to complete.
Using PlaneLok Mode
How PlaneLok Mode Works
PlaneLok mode works by changing grade in the selected axis direction then
monitoring the elevation changes of the laser beam at the receiver via the
radio remote control. Once the laser “finds” the center of the receiver, it
continues to monitor its position and makes small corrections to hold the
beam on-grade.
Important Things to Know about PlaneLok Mode
• Loss of receiver signal results in laser “out of level” mode (no laser beam
or rotation)
• The internal laser level vial for that axis is ignored (the receiver is used for
level control)
• The opposite axis levels to its internal level vial and grade
PlaneLok
• Works like grade match mode, except the receiver is permanently
mounted at the desired elevation to continually monitor beam elevation
• Is used for applications requiring extreme accuracy, such as in runway
applications
For proper operation
• The initial grade MUST be within 1.5% of the final grade before starting
Practical Application for PlaneLok Mode: Agricultural and Runway
Applications
Agriculture and runway applications can generally be handled using any of
the previously described processes. For extremely accurate agriculture or
runway applications whose work-time extends over several days or even
weeks, PlaneLok mode is recommended.
PlaneLok Mode Setup
1. Set up the laser over a reference point.
2. Using the sighting guide as a guide, rough align the laser with one of the
slope-control hubs.
Note: The two slope-control hubs must be in lines that are at a 90° angle
from one another.
3. Enter the approximate grade into the axis that needs to be aligned and
an exact grade value into the other axis.
Note: The automatic slope searching range is ±1.5%. The approximated
grade should be within 1.5% of the final matched grade.
4. Connect a receiver and radio remote control to a grade rod.
5. Set the grade rod on the elevation-control hub.
6. Slide the receiver up/down the grade rod until the receiver’s LCD
shows an on-grade reading.
Note: The grade rod MUST be plumb.
7. Go to the slope-control hub on the axis to be aligned and set the grade
rod on the hub. Make sure you DON’T change the height of the
receiver on the grade rod.
8. Select “PlaneLok” from the operational menu using the mode button.
9. Select the axis (∠ or ∠) that you are aligning using the up or down
buttons.
10. Press the enter button to confirm the selection. “Start” then “Wait”
appears in the LCD.
Note: Note: When the PlaneLok function has been completed, “PlaneLok
Complete” and a “Lock” icon (padlock symbol) appear in the radio remote
control LCD.
Note: Alignment can take 1 to 5 minutes to complete.
Note: If the PlaneLok function fails, the remote indicates the cause of failure.
See the ‘Troubleshooting” section of this manual for more information.
Note: The receiver should be permanently mounted at this location and at the
desired elevation. Use a bipod (commonly used with prism poles) to hold the
grade rod steady for the entire workday.
Note: The resultant grade on the locked axis is displayed in the remote LCD.
Note: The laser continues to servo to the receiver’s elevation signals. Any
loss of signal over an extended period of time (1 minute) causes the laser
beam to turn off and rotor to stop. The PlaneLok mode must be reactivated
when the laser experiences loss of signal over an extended period.
Using the Radio Remote Control to Correct Slope/Height Differences after
Setup
Sometimes, after performing any of the advanced alignment functions, the
alignment and grade values need small adjustments. These adjustments can
be made using a one-way or two-way radio remote control.
One-Way Remote
Checking Slope/Height Differences for the ∠ and ∠ Axes
1. Determine the height of the laser (HI) by setting the grade rod on
elevation-control hub #1.
2. Check the HI by setting the grade rod on elevation-control hub #2. Make
sure you DON’T change the height of the receiver on the grade rod.
Adjusting Slope/Height Differences for the ∠ and ∠ Axes
Small differences of the slope/height can be corrected using the up and down
buttons in 0.01% using “Grade Bump” mode.
1. Select “∠ Grade Bump” from the operational mode menu using the radio
remote control’s mode button.
2. Press the up or down button on the radio remote control until you get an
on-grade reading on the receiver. Each press of the up/down button
increases/decrease grade in .01% increments. To change the grade by
0.05%, for example, press and release the button five times.
3. Go to the elevation-control hub for the ∠ closed axis and set the grade
rod on the hub. Make sure you DON’T change the height of the receiver
on the grade rod.
4. Select “∠ Grade Bump” from the operational menu using the radio remote
control’s mode button.
5. Press the up or down button on the radio remote control until you get an
on-grade reading on the receiver. Each press of the up/down button
increases/decrease grade in .01% increments. To change the grade by
0.05%, for example, press and release the button five times.
Two-Way Remote
Checking Slope/Height Differences for the ∠ and ∠ Axes
1. Determine the height of the laser (HI) by setting the grade rod on
elevation-control hub #1.
2. Check the HI by setting the grade rod on elevation-control hub #2. Make
sure you DON’T change the height of the receiver on the grade rod.
Adjusting Slope/Height Differences on the ∠ Axis
1. Select “∠ Grade” from the operational mode menu using the radio
remote control’s mode button.
2. Press the up or down button on the radio remote control until you get
an on-grade reading on the receiver.
Note: The new grade value appears on the radio remote control’s LCD.
3. Go to the elevation-control hub for the ∠ axis and set the grade rod on
the hub. Make sure you DON’T change the height of the receiver on
the grade rod.
Adjusting Slope/Height Differences on the ∠ Axis
1. Select “∠ Grade” from the operational mode menu using the radio
remote control’s mode button.
2. Press the up or down button on the radio remote control until you get
an on-grade reading on the receiver.
Note: The new grade value appears on the two-way radio remote control’s
LCD.
Specifications
Laser
Accuracy Single, Dual, and Steep-Grade
Models:
Diameter: accurate for machine-
control and agricultural applications
to 3,000 ft (900 m)
Long-Range (Agricultural) Model:
Diameter: accurate for machine-
control and agricultural applications
to 5,000 ft (1,500 m) over the entire
operating-temperature range
0-0.5% ± 8 arc seconds
0.501-2.0% ± 10 arc seconds
2.01 to 3.0% ± 15 arc seconds
3.01 to 5.0% ± 25 arc seconds
5.01% to
10.0% ± 40 arc seconds
10.01 to
30.0% ± 60 arc seconds
Grade Accuracy
Above 30.01%
± 3% of indicated
grade
Laser Type/Classification 658 nm IEC Class I (standard) and,
IEC Class II (Long-Range models)
Laser Power Output Single, Dual, and Steep-Grade
Models: 1.5 mW
Long-Range (Agricultural) Models:
4.3 mW
Operating Temperature -4° to 122° F (-20° to 50° C)
Storage Temperature -40° to 140° F (-40° to 60° C)
Operating Range (Radius) Standard and Steep-Grade Models:
1,500 feet (460 m)
Long-Range (Agricultural) Models:
2,500 ft (760 m)
Grade Range (Single Slope Models) ∠-axis N/A
∠-axis –0.500 to 25%
∠-axis –10 to 10% Grade Range (Dual Slope Models)
∠-axis –0.500 to 25%
∠-axis –10 to 10% Grade Range (Steep Slope Models)
∠-axis –0.500 to 110%
Rotation Speeds 300, 600, 900 rpm
Self-Leveling Range The laser will self level up to 25%
grade
Power Source 6.0 AH Ni-Cd
8.5 AH Ni-MH
Battery Life 50 Hours (Ni-Cd)
60 Hours (Ni-MH)
30 Hours (Alkaline, emergency use
only)
Recharging Time 6 hours, maximum
Low Battery Operations 1 hour with Ni-Cd batteries
Automatic Shutoff 30 minute if unable to level
Tripod Screw 5/8-11 standard
3-1/2-8 and quick-disconnect
(optional)
Water Resistance Completely sealed and waterproof
Weight 18.5 lb (8.4 kg)
Size 11.75 x 10.0 x 7.75 in. (H x W x D)
30 x 25 x 20 cm (H x W x D)
One-Way and Two-Way Radio Remote Control
Size 5 x 3 x 1.5 in. (H x W x D)
13 x 8 x 4 cm (H x W x D)
Weight 1 lb (0.5 kg)
Operating Temperature -4° to 122° F (-20° to 50°C)
Storage Temperature -40° to 140°F (-40° to 60°C)
Frequency 2.4 gHz digital
Operating Range
(Standard Functions) Line of sight up to 750 ft (230 m)
Operating Range
(Automatic Alignment Functions) Line of sight up to 500 ft (150 m)
Angular Coverage 360º
User Interface 6 buttons and a LCD
Power Source 2 x AA alkaline
Battery Life 40 hours
Maintenance and Care
You will get years of service from the leveling system by following the
maintenance and care recommendations in this manual. Carry the laser in its
moisture-resistant, field-tested carrying case to safely move the laser from
one job to another.
However well the product is designed, mishaps do occur. The most common
problems associated with these are covered in the following areas.
Storage
CAUTION: Do not store the laser in a wet carrying case. If the case gets wet,
open it and let it dry before storing the laser.
CAUTION: Remove the batteries from the laser and receiver when storing
the equipment more than 30 days.
Battery Disposal
Some countries, states, and local areas have regulations regarding the
disposal of rechargeable batteries. Be sure that replaced batteries are
disposed of properly.
System Cleaning
Use only a good-quality glass cleaner and a soft cloth to clean all external
optical components. A dry cloth used on the laser’s/radio remote control’s
optical components or displays could scratch or damage these surfaces.
Blow off any loose debris before cleaning any surfaces to prevent scratching
of optical surfaces. Monthly, wipe off with a moist, clean cloth any dust or
dirt from the laser’s outer surface, inside the battery housing, and within the
leveling base. Clean all corroded battery contacts with a pencil eraser or
baking soda solution.
Troubleshooting
If none of the following techniques corrects the problem, take your system to
a local Trimble dealer or authorized service center for evaluation or repair.
Laser
Problem Solution
Laser will not turn on • Make sure the batteries have
sufficient power and are installed
correctly.
• Make sure the batteries contacts
are in proper working condition.
No signal is received at the receiver • Make sure the receiver is turned
on.
• Make sure the batteries have
sufficient power and are installed
correctly.
• Make sure the laser is sending out
a beam.
• Check for a laser signal with
another receiver.
No laser beam • Make sure the laser is on.
• Make sure the batteries have
sufficient power and are installed
correctly.
• Make sure that the laser is within
its self-leveling range (up to
25%).
• Switch the laser into manual
mode; the laser should come on.
The battery life is short • Make sure high-quality batteries
are being used.
• When recharging the batteries,
make sure the charger is plugged
into an appropriate ac outlet. The
batteries require a minimum
charge time of six hours.
Radio remote control is not working
with the laser • Make sure the antenna is upright.
• If the remote does not work with
the laser, the remote needs to be
“matched” to the laser for proper
operation. Return the laser to an
authorized service center for the
matching procedure to be
performed.
Laser beam not accurate • Check and adjust calibration as
needed.
• Return the laser to an authorized
service center for inspection.
Receiver
Problem Solution
Receiver does not receive a laser
signal • Make sure the laser receiver is on.
• Make sure the batteries have
sufficient power and are installed
correctly.
• Make sure the batteries contacts
are in proper working condition.
• Make sure the receiver is within
the operating range of the laser.
• Try receiving the laser beam with
another receiver. If the new
receiver detects the laser beam,
return the original receiver to an
authorized service center for
repair.
Receiver occasionally beeps when it
is not in the laser beam • Make sure the receiver is not near
radar or high-frequency radio
stations.
• Make sure the laser beam is not
bouncing off a highly reflective
surface.
Radio Remote Control
Problem Solution
Radio remote control not receiving or
sending any signal • Make sure the radio remote
control is on.
• Make sure the batteries have
sufficient power and are installed
correctly.
• Make sure the batteries contacts
are in proper working condition.
• Make sure you have a good
connection between the receiver
and radio remote control.
• Make sure the radio remote
control antenna is mounted
solidly on the radio remote
control.
Radio remote control is damaged
(may include loose or broken LCD) • Return the damaged remote as
described in the “Request for
Service and Parts” section.
Radio Remote Control Operating Messages
Operating Messages Meaning
Start/Wait Automatic alignment is started and in process
Standby The laser is on and in standby mode
∠ Grade Grade value for ∠ axis can be changed
∠ Grade Grade value for ∠ axis can be changed
Axis Align Automatic axis alignment can be selected
∠ Grade Bump (One-
Way Remote) Grade value for ∠ axis can be changed in 0.01%
steps
∠ Grade Bump (One-
Way Remote) Grade value for ∠ axis can be changed in 0.01%
steps
PlaneLok PlaneLok mode can be selected
Grade Match Grade match mode can be selected
Grade Reverse Grade reverse for the ∠ axis can be selected
Reversing The sign (+/-) of the cross axis is changing
RPM Rotor speed can be changed
Success Messages Meaning
Axis Align Complete Completion of automatic axis alignment
Grade Match Complete Completion of automatic grade matching
PlaneLok Complete Completion of automatic PlaneLok
Grade Reverse Complete
Completion of grade reverse
300, 600, 900 Shows the selected rotation speed
Radio Remote Control Failure Messages
Failure
Messages Meaning Possible Solution
Fail—No Receiver Searched for receiver
but couldn’t find it • Move the grade to within
1.5% of the range needed
for the receiver to pickup
the beam
• Make sure the receiver is
not blocked from the laser
beam
• Make sure your laser
setup is stable
Fail—Lost
Receiver Searched and found a
receiver but lost it while
processing the function
• Make sure the beam path
to the receiver is not
blocked after any
functions on the remote
are activated
• Make sure your laser
setup is stable
• Check the remote for low
battery power
Fail—Mechanical
Limit The beam could not
scan across the entire
receiver
• Position the receiver so
that it is within the grade
limits of ±10% on the ∠
axis and +25% to –0.5%
on the ∠ axis
Fail—Rake Angle
Limit Axis alignment
computes a rake angle
greater than 40°
• Repeat the laser setup and
make sure the alignment is
correctly set
Wind Disturbance Windy conditions have
made detection of the
beam impossible
• Make sure the beam path
to the receiver is not
blocked after any
functions on the remote
are activated
• Make sure your laser
setup is stable
Fail—Time Out A step or stage could
not complete its
alignment function
within the allotted time
• Setup the laser so that it is
within leveling range
• Make sure your laser
setup is stable by
stabilizing the tripod
• Make sure the beam path
to the receiver is not
blocked after any
functions on the remote
are activated
Fail—Too Close The receiver is too
close to the laser • Move the receiver more
than 60 feet (20 m) from
the laser
• Remove any reflective
objects from the path of
the beam
Fail—Too Far The receiver is too far
from the laser • Operate the receiver within
500 feet (150 m) from the
laser
• Position the receiver’s
photocell to be within the
beam operating range
Fail—Low Battery Batteries are too low to
power the remote • Replace the batteries if
they are too low to power
the remote
Fail—General Unidentified error
Note: An axis symbol and the grade appear in the top of the LCD. If the axis
is in PlaneLok, a lock symbol appears after the grade value.
Laser Error Messages
The laser has error codes that indicate either a hardware or software problem.
If one of the following codes appears in the laser’s LCD, please return the
laser to an authorized Trimble service center:
• 0004
• 0008
• 0010
• 0020
• 0040
• 0080
• 0100
• 0200
• 0400
• 0800
• 1000
• 2000
• 4000
• 8000
For more information about returning the laser to a service center, please see
the “Request for Service and Parts” section of this manual.
Calibration
As with any precision instrument, the calibration needs checking on a regular
basis (such as the beginning of each job, or if the laser has been handled
roughly). If the laser is to be used below freezing, be sure to check
calibration under those conditions.
The laser has a calibration error when the laser plane coming out one side of
the laser is above true level, and the laser plane coming out the opposite side
is below true level. Adjusting the position of the laser plane requires making
minor adjustments the leveling mechanism using the up and down buttons on
the control panel.
When the laser is properly calibrated, it emits a 360° horizontal level plane so
that if the laser is turned 180° or 90° from its original position, the reading is
within ±5/16 in. per 300 ft (±8 mm/90 m) of the original position.
To check the horizontal calibration, you’ll need a tripod with a 5/8-11
threaded mount and a hand-held receiver. If you need to adjust the
calibration, having another person to help saves time.
Checking Calibration
1. Set up the laser 300 ft (90 m) from a wall.
2. Set the grade to 0.000% in both axes.
3. Raise/lower the receiver until you get an on-grade reading for the +∠
axis. Using the on-grade marking notch as a reference, make a mark on
the wall.
Note: For increased precision, use the fine-sensitivity setting (+1/16 in./+1.6
mm) on the receiver.
4. Rotate the laser 180° (–∠ axis toward the wall) and allow the laser to re-
level.
5. Raise/lower the receiver until you get an on-grade reading for the –∠
axis. Using the on-grade marking notch as a reference, make a mark on
the wall.
6. Measure the difference between the two marks. If they differ more than
5/16 in. (8 mm), the laser needs calibrating.
Adjusting the Calibration at the Laser
1. Position the receiver at the midpoint of the two marks on the wall.
2. Add/subtract grade in the appropriate axis using the up/down buttons.
The grade appears in the LCD.
Note: The up/down buttons needed to calibrate the ∠ axis on single slope
lasers are “hidden” behind the control panel.
3. When the beam is centered in the receiver, use the following “hidden”
button sequence to store the new calibration value and to zero out the
grade display:
a) Press and hold the manual button
b) Quickly press and release the power button (do NOT press the
power button long enough to turn off the laser
c) Press and release the up button for the ∠ axis
d) Release the manual button
e) The grade display will zero out to indicate calibration is
complete.
4. Rotate the laser 180° back to the original face. Make sure this axis is less
than 5/16 in. (8 mm) from the midpoint line.
Note: If additional adjustment is required, repeat steps 1-3 above.
5. After adjusting the ∠ axis, rotate the laser 90°. Repeat the above starting
with the –∠axis facing the wall.
Adjusting the Calibration Using the Radio Remote Control
1. Position the receiver at the midpoint of the two marks on the wall.
2. Add/subtract grade in the appropriate axis using the grade
increase/decrease modes (one-way radio remote control: Grade Bump;
two-way radio remote control: Grade Change).
3. When the beam is centered on the receiver’s LCD, use the following
radio remote control button sequence to store the new calibration point
and to zero out the grade display:
f) Turn off the radio remote control
g) Press and hold the manual button
h) Turn on the radio remote control. “Calibration” appears in the
LCD.
i) Press the enter button to confirm the selection.
j) The grade display on the laser and two-way radio remote
control will zero out to indicate calibration is complete.
4. Rotate the laser 180° back to the original face. Make sure this axis is less
than 5/16 in. (8 mm) from the midpoint line.
Note: If additional adjustment is required, repeat steps 1-3 above.
5. After adjusting the ∠ axis, rotate the laser 90°. Repeat the above starting
with the –∠axis facing the wall.
Request for Service and Parts
Our goal is to provide prompt and efficient service through competent
service dealers. To locate your local dealer or authorized Trimble Service
Center for service, accessories, or spare parts, contact one of our offices
listed below.
United States Of America
Trimble Engineering and Construction
Division.
5475 Kellenburger Road
Dayton, Ohio 45424-1099 U.S.A.
Phone: (937) 233-8921
(800) 538-7800
Fax:(937) 233-9441
Internet:
www.trimble.com
Germany
Trimble Engineering and Construction
Division
AM Prime Parc 11
Raunheim, Germany 65479
Phone: 6142 2100 221
Fax: 6142 2100 240
France
Trimble France
Parc Hightec VI
9, Avenue du Canada
Les Ulis Courtaboeuf Cedex
France 91966
Phone: 1 6918 6376
Fax: 1 6918 6327
United Kingdom
Trimble UK
Mensura House
Blackstone Rd Huntingdon
Cambridgeshire PE 19
United Kingdom
Phone: 1480 433 555
Fax: 1420 562-589
Netherlands
Trimble Netherlands
Prof. Dr. Dorgelolaan 20
5613 AM Eindhoven
The Netherlands
Phone: 4045 1855
Fax: 4046 6089
Sweden
Trimble Sweden
Box 64 Rinkebyvagen 17
Dandyerd, Sweden 18211
Phone: 8622 1000
Fax: 8753 2464
Italy
SpeKtra
Via Trieste 26/28
1-20059 Vimercate Milan Italy
Phone: 039 625051
Fax: 039 6619077
Belgium
Trimble Belgium
Oostjachtpark 9
9100 Sint-Niklaas
Belgium
Phone: 3780 7823
Fax:
Australia
Trimble Australia
Level 1, 123 Gotha Street
Fortitude Valley, Queensland 4006
PO Box 769 Spring Hill
Queensland, Australia 4004
Spain
Intrac, S.A.
P.A.E. Casablanca 1 C/Jose
4 B-5 28100 Alcobendas
Madrid, Spain
Phone: 914 841 900
Fax: 914 841 901
Japan
Trimble Japan
Shin-Ohashi Riverside
Bldg 101 3F, 4F
1-8-2 Shin-Ohashi Kohtoh-ku
Tokyo, Japan 135-0007
Phone: 35638 5018
Fax: 33631 0712
Before returning your system for repair, be sure to do the following:
1. Put a note into the package identifying yourself as the owner.
2. Explain the operating difficulty.
3. Include a return address and telephone number.
4. If the equipment is under warranty, provide verification of the date of
purchase.
5. Pack the equipment securely for shipment in its original carrying case.
6. Return the equipment prepaid and insured to your local dealer or
authorized Trimble Service Center.
7. Request estimate of charges for non-warranty or other service work
before repair begins. If estimates are not requested, repair work will
begin immediately.
All certified outlets have factory-trained personnel and use authorized
replacement parts to ensure proper and quick return. For long-distance
shipments, UPS, 2nd-Day Air, or airfreight is recommended.
Except for one-way transportation charges, there will be no charge for repairs
caused by problems due to defective materials and/or workmanship under
warranty.
EMC Declaration of Conformity
This laser has been tested and found to comply with the limits for a Class B
digital device for radio noise for digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communication, and
is pursuant to part 15 of the Federal Communication Commission (FCC)
rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This laser generates radio
frequency. If it's not used in accordance with the instructions, it may cause
harmful interference to radio or television reception. Such interference can be
determined by turning the laser off and on. You are encouraged to try
eliminating the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the laser and the receiver.
For more information, consult your dealer or an experienced radio/television
technician.
CAUTION: Changes or modifications to the laser that are not expressly
approved by Trimble could void authority to use the equipment.
Application of Council Directive(s): 89/336/EEC
Manufacturer’s Name: Trimble
Manufacturer’s Address: 5475 Kellenburger Road
Dayton, Ohio 45424-1099 U.S.A.
European Representative Address: Trimble Engineering and
Construction S GmbH
Am Prime Parc 11
D-65479 Raunheim, Germany
Model Number(s): GL7XX
Conformance to Directive(s): EC Directive 89/336/EEC using
EN55022 and EN50082-1
Equipment Type/Environment: ITE/residential, commercial & light
industrial
Product Standards: Product meets the limit B and
methods of EN55022
Product meets the levels and
methods of
IEC 801-2, 8 kV air, 4 kV contact
IEC 801-3, 3 V/m 26 to 1000 MHz
80%, @ 1 kHz
IEC 801-4, ac leads 2 kV
Warranty
Trimble warrants the GL700 series lasers, radio remote control, and receiver
to be free of defects in material and workmanship for a period of two years
and one year respectively. This warranty period is in effect from the date the
system is delivered by Trimble or its authorized Dealer to the purchaser, or is
put into service by a Dealer as a demonstrator or rental components.
Additionally, items covered by the standard Trimble one-year warranty are
the accessories. All other components not manufactured by Trimble but sold
as a part of the system such as tripods and grade rods, will carry a 90-day
warranty or the manufacturer’s warranty, whichever is greater.
Trimble or its Authorized Service Center will repair or replace, at its option,
any defective part of components of which notice has been given during the
warranty period. A Warranty Registration Card must be filled out properly
and on file with Trimble Service Department before warranty repair or
replacement can be approved. Travel and per diem expenses, if required, to
and from the place where repairs are made will be charged to the purchaser at
the prevailing rates.
Customers should send products to the nearest Authorized Factory Service
Center for warranty repairs, freight prepaid. In countries with Trimble
Subsidiary Service Centers, the repaired products will be returned to the
customer, freight prepaid.
Any evidence of negligent, abnormal use, accident, or any attempt to repair
equipment by other than factory-authorized personnel using Trimble certified
or recommended parts, automatically voids the warranty.
Special precautions have been taken to ensure the calibration of the laser;
however, calibration is not covered by this warranty. Maintenance of the
calibration is the responsibility of the user.
The foregoing states the entire liability of Trimble regarding the purchase and
use of its equipment. Trimble will not be held responsible for any
consequential loss or damage of any kind.
This warranty is in lieu of all other warranties, except as set forth above,
including an implied warranty mechantability of fitness for a particular
purpose, are hereby disclaimed.
Trimble
Model GL-700 Series Laser Systems
Quick-Reference Card
Single Grade, Dual Grades, Long Range, and Steep-Grade Lasers
Features and Functions
Laser
1. Power Button—turns the laser on/off.
2. Status LED—shows the status of various conditions including an
internal, electronic, or a mechanical error (solid red), low-battery
(flashing yellow), manual mode (flashing red), HI alert (fast flashing
red), and out-of-level (flashing green).
3. Manual Button—changes the laser from automatic self-leveling to
manual mode.
4. ∠ Axis Up and Down Buttons—change the grade for the ∠ axis.
5. Rotation-Control Button—changes the laser beam rotation speed (300,
600, and 900 rpm).
6. ∠ Axis Up and Down Buttons (dual-grade laser only)—change the
grade for the ∠ axis.
7. Axis-Alignment Buttons—rotates the grade axis clockwise or
counterclockwise. Rotating the grade axis simulates turning the laser on
its tripod, with fine adjustment capability.
8. Liquid Crystal Displays (LCDs)—show the percentage of grade,
approximate charge of the batteries, beam's rotation speed, and axis
alignment (if other than zero). The single-grade laser has one LCD.
9. Antenna (for radio remote-control lasers only)—sends and receives
signals to and from the remote control.
10. Sunshade—protects the lighthouse from the environment.
11. Lighthouse—is the 360° exit window for the laser beam. The lighthouse
is sealed and protects the internal components from the environment.
12. Rotor—contains the rotating laser beam.
13. Handle—allows you to carry the laser easily.
14. Battery Recharging Receptacle—is the 4-pin receptacle that the battery
recharger plugs into.
15. Battery Housing—holds six D-cell Ni-Cd, Ni-MH, or backup alkaline
batteries.
16. 5/8-11 Tripod Mount—allows the laser to be connected to a standard
5/8-11 tripod or column mount.
17. Sighting Guides—are used to visually align the laser with a directional
hub or grade stake.
18. Axis-Alignment Marks—correspond with both laser axes and are used
to align the laser in the correct grade direction.
One-Way and Two-Way Radio Remote Controls (for radio equipped lasers
only)
1. Power/Standby Button—turns the remote control on/off and
activates/deactivates standby mode.
2. Manual Button—changes the laser from automatic self-leveling to
manual mode.
3. Mode Button—allows you to choose the laser’s operational mode,
which includes grade change, automatic axis alignment, grade
matching, PlaneLok, grade bump, grade reverse, manual, and beam
rotation speed.
4. Up and Down Buttons—increase/decrease the grade for the ∠ and ∠
axes and increase/decrease the laser beam’s rotation speed. When the
laser is in manual mode, these buttons can also be used to
increase/decrease the slope of the laser beam.
5. Left and Right Buttons—increase/decrease the slope of the ∠ axis when
the laser is in manual mode.
6. Liquid Crystal Display (LCD)—shows the mode messages, beam’s
rotation speed, and percentage of grade (on two-way remote control
only).
7. Remote Port Contacts—transfer operation and elevation information
between the remote control and the receiver.
8. Antenna—transfers signals between the radio remote control and laser.
9. Enter Button—is a multifunctional button confirms the selection made
from the laser’s operational mode and activates the backlighting
function.
10. Mounting Clip—allows the remote control to be connected to a grade-
rod holster, belt, or a screw on a wall.
11. Battery Housing—holds two AA alkaline batteries.
Accessories
Connector Cable
1. Contacts—transfers grade-display signals between the hand-held
receiver and radio remote control.
2. Mounting Plate—connects to the back of a hand-held receiver so that
the radio remote control and hand-held receiver can transfer signals.
3. 12-ft (4-m) Cable—transfers signals between the radio remote control
and a hand-held receiver.
4. Clamp—connects to the radio remote control so signals can be
transferred between the hand-held receiver and radio remote control.
5. Mounting Guides—fit into the mounting channels on the back of a
hand-held receiver so that signals can be transferred between the radio
remote control and hand-held receiver.
Remote Holster
1. Mounting Slot—provides an opening for the radio remote control clip to
be slipped into.
2. Mounting Strap—allows the radio remote control to be connected to the
grade rod for automatic alignment functions. The holes in the strap
accommodate grade rods of varying sizes.
Battery Recharger
1. 4-Socket Plug w/ Retaining Collar—connects to the 4-pin receptacle on
the laser.
2. Grounded Receptacle—connects to a grounded electrical power cord.
External Power Cord
1. Alligator Clips (+ and -)—connect to the positive (+) and negative (-)
terminals on a 12 V dc battery.
2. 4-Socket Plug—connects to the 4-pin receptacle on the laser.
Quick-Disconnect Adapter
The quick-disconnect adapter allows you to quickly connect/disconnect the
laser from the tripod.
3 1/2-8 Adapter
The 3 1/2-8 adapter allows you to connect the laser, which has a 5/8-11
threaded mount, to a tripod or other mounting device that has a 3 1/2-8
threaded mount. The carrying case is designed to that the adapter can remain
attached to the laser while the laser is being stored in the case.
Steep-Grade Adapter
The steep-grade adapter allows the internal leveling mechanism of the steep-
grade laser to level the laser at grades greater than 25%.
Offset Plate
The offset plate mounts to the steep-grade adapter and eliminates offset
errors when the laser is being used for steep-grade applications by
maintaining the laser’s rotor position over the laser’s mounting threads. This
adapter HAS to be used when performing a steep-grade axis alignment that
is perpendicular to the steep-grade axis.
How to Use the Laser System
Laser
Powering the Laser
Batteries
Depending on the laser system configuration that you purchase, the laser is
shipped with either rechargeable nickel-cadmium (Ni-Cd) or nickel/metal-
hydride (Ni-MH) batteries. Even if you buy a laser that uses Ni-Cd batteries,
you can upgrade to Ni-MH batteries. Alkaline batteries can also be used as a
backup; however, rechargeable batteries should be reinstalled in the laser as
soon as possible.
Installing/Removing the Batteries
CAUTION: The batteries should be removed when storing the laser more
than 30 days.
1. Remove the four screws from the battery housing. Remove the battery-
housing compartment.
2. Install/remove the batteries.
Note: When installing the batteries, be sure to note the positive (+) and
negative (-) diagram inside of the housing.
Note: The laser has reverse polarity protection. If the batteries are put in
wrong, no damage occurs to the laser but it does not work. Allow it one
minute to recover after the batteries have been installed correctly.
3. Put the battery-housing compartment in place and reinstall the four
screws.
To let you know when the batteries are getting low, the status LED flashes.
When the status LED flashes yellow, the laser has less than one hour of
running time. When the status LED remains on solid yellow, the batteries
have less than five minutes running time.
Connecting the Laser to a Tripod
All lasers have a 5/8-11 tripod mount on the bottom of the laser. Depending
on the laser system you purchase, additional mounting adapters may be
shipped with your laser. The long-range (agricultural) laser system includes
a quick-disconnect adapter and a 3 1/2-8 adapter. The steep-grade laser
system includes a steep-grade adapter and offset plate.
The laser can also be connected to a standard tripod, column clamp, or other
mounting device. If you’re using the laser without a tripod, however, make
sure you set the laser on a stable surface.
1. Insert the tripod’s 5/8-11 screw into the laser’s threaded 5/8-11 tripod
mount.
2. Turn the screw counterclockwise to hold the laser securely in place.
3. To detach the laser from the tripod, turn the screw clockwise.
Turning On/Off the Laser
1. Press the power button to turn on the laser.
Note: The laser always powers up in the automatic self-leveling mode. If the
laser is out of its self-leveling range and remains out of it for more than 30
minutes, the laser shuts down completely.
Note: When the laser is initially turned on, the LCD shows the approximate
charge of the batteries, the laser beam’s rotation speed, and manual axis-
alignment position if it’s other than zero. After the LCD shows this
information, the last-entered grade immediately appears in the LCD. The
status LED flashes green to indicate that the laser is self-leveling. After the
laser has self-leveled at the indicated grade, the laser beam rotates and the
status LED stops flashing.
Note: After the laser has been level for more than 30 minutes, the HI alert
activates. If the laser is disturbed (tripod bumped, etc.) so that when it re-
levels the laser beam elevation changes by more than 1/8 in. (2.5 mm), the
HI alert shuts down the laser and rotor, and the status LED flashes red two
times per second (twice the manual-mode rate).
2. To turn off the laser, press and hold the power button for three seconds.
Selecting the Rotation Speed
The laser has three laser beam rotation speeds—300, 600, and 900 rpm. The
rotation speed can be changed at any time to meet your job-site conditions.
Use 600 rpm for held-held receivers and most machine-control systems.
The rotation speed can also be changed using either of the radio remote
controls. The rotation speed appears in the two-way radio remote control’s
LCD. If you’re using a one-way radio remote control, you must look at the
laser’s LCD for this information. For more information about using the radio
remote control, see the operator’s manual.
1. Repeatedly press and release the rotation-control button until the desired
rotation speed appears in the LCD.
Note: The selected rotation speed briefly appears in the LCD. After a few
seconds, the selected percentage of grade appears in the LCD.
Changing the Grade Value
The grade value for both axes can be changed using two methods—standard
and quick-change. The standard method is used for entering small changes
in the grade value. The quick-change method is used for setting grade to
zero and entering large changes in the grade value.
The grade value can also be changed using either of the radio remote
controls. The grade value appears in the two-way radio remote control’s
LCD. If you’re using a one-way radio remote control, you must look at the
laser’s LCD for this information. For more information about using the radio
remote control, see the operator’s manual.
Standard Method
Note: The grade value can be quickly set to 0.000% by simultaneously
pressing and releasing the up and down buttons for the axis you want to
change.
1. Press and hold the up or down button for the axis you want to change
until the correct grade value appears in the laser’s LCD.
Note: The speed of the grade value change increases with the amount of time
the button is held down.
Note: Grade values from -0.500 to 9.999% are displayed in thousandths of a
percents. Grade values greater than 10% are displayed in hundredths of a
percent.
Note: All changes to the axis-alignment rotation made prior to changing the
grade value using the standard method are retained.
Quick-Change Method
1. Simultaneously press and hold the up and down buttons for the axis you
want to change to set the grade value to 0.000%.
Note: The grade value for the ∠ axis increases in 1.00% increments. The
grade value for the ∠ axis increases in 5.00% increments.
2. Continue pressing and holding the up and down buttons until the correct
grade value appears in the laser’s LCD.
Note: When the grade value for either axis reaches its highest amount, the
grade value switches to the lowest value for that axis. In the ∠ axis, for
example, the value switches from +10.00% to –10.00%. In the ∠ axis, the
value switches from 25.00% to -0.500%. For steep-grade lasers, the value
switches from 110.00% to -0.500%.
Note: All changes to the axis-alignment rotation made prior to changing the
grade value using the quick-change method are cancelled.
Activating/Deactivating Manual Mode
Manual mode bypasses the laser’s automatic self-leveling mode so you can
use the laser in vertical mode. Manual mode also allows you to tilt the laser
beyond its built-in sloping capability so you can perform steep-sloping
horizontal applications.
Manual mode can also be activated/deactivated using either of the radio
remote controls. The words “Manual Mode” appear in the two-way radio
remote control’s LCD when manual mode is activated. If you’re using a one-
way radio remote control, you must look at the laser’s LCD for this
information. For more information about using the radio remote control, see
the operator’s manual.
1. Make sure the laser is on and in the orientation appropriate for your
application needs (horizontal or vertical).
2. Press the manual mode button.
Note: When manual mode is activated, the status LED flashes red once per
second and scrolling horizontal segments appear in the LCD.
3. To adjust the laser in the ∠ axis so that the laser beam matches the
desired slope or grade, use the ∠ axis up and down buttons on the laser or
radio remote control.
4. To adjust the laser in the ∠ axis so that the laser beam matches the
desired slope or grade, use the ∠ axis up and down buttons on the laser or
the left and right buttons on the radio remote control.
5. To resume automatic self-leveling mode, press the manual button on the
laser or radio remote control again.
Aligning the Axis Manually
The manual axis alignment buttons rotate the grade axis electronically
(simulates turning the laser on its tripod, with fine adjustment capability up
to a maximum of ±40 degrees).
1. Set up the laser over a reference point. Make sure the laser is positioned
so that the ∠ and ∠ axes are pointing in the right direction.
2. Using the sighting guides as guide, rotate the laser on its tripod to align
the laser to the direction hub.
3. Turn on the laser and allow it to self-level.
4. Connect a receiver to a grade rod and turn on the receiver. Make sure you
position the receiver so that it is at the correct elevation for the distance
(and grade) from the laser to the direction hub.
5. Set the grade rod on the direction hub.
Note: If only one person is manually aligning the laser, use a bipod
(commonly used with prism poles) to keep the grade rod plumb when
placing is on the direction hub.
6. Press the appropriate manual axis alignment button to align the laser
plane to the receiver. The clockwise axis alignment button rotates the
laser clockwise; the counterclockwise axis alignment button rotates the
laser counterclockwise.
7. Press and hold the axis alignment button until you get an on-grade
reading on the receiver.
Radio Remote Control (One-Way and Two-Way)
The radio remote control is a hand-held device that allows you to send
operational commands to the laser from a remote location. These operational
commands include changing grade values, rotation speed, and operating
modes. The radio remote control HAS to be used for the following advanced
alignment features:
• Automatic Axis Alignment
• Grade Reverse
• Grade Matching
• PlaneLok
See your operator’s manual for detailed setup and operation of these
advanced features.
A solid “T” symbol appears in the right corner of the LCD to indicate that
the link between the radio remote control and laser is complete. A flashing
bar above the “T” indicates that communication with the laser is established.
When the radio remote control is connected to a receiver, an “R” appears in
the right corner of the radio remote control’s first display line indicating that
a connection has been made and the power is on.
When using the radio remote control, make sure its antenna is pointing
skyward.
Turning On/Off the Radio Remote Control
1. Press the power button to turn on the radio remote control.
Note: When the two-way radio remote control is initially turned on, the axes
symbols and last-entered grade for each axis briefly appear in the LCD.
2. To turn off the radio remote control, press and hold the power button
for 3 seconds.
Selecting the Operational Mode
The mode button allows you to choose the laser’s operational mode, which
includes changing grade, automatic axis alignment, grade matching,
PlaneLok, grade bump, grade reverse, manual, and beam rotation speed.
1. Repeatedly press and release the mode button to cycle through the
operational menu. The menu selections appear in the radio remote
control’s LCD.
