Mustang™ ZT Mustang Colt™ ZT
Engine 22 HP* Kohler® CourageTM 19 HP* Kohler® CourageTM
Cylinders 2 1
Engine Start Electric Electric
Lubrication Full-pressure with
spin-on oil filter
Full-pressure with
spin-on oil filter
Engine Oil Capacity
1.6 quart 1.6 quart
Transmission Dual hydrostatic EZT w/1" axles Dual hydrostatic EZT
Steering 2-way adjustable lap bars 2-way adjustable lap bars
Frame Fully welded stamped steel Fully welded stamped steel
Front Axle Pivoting, greasable Pivoting, greasable
Front Tire Bearings Polycarbonate NSB-90 Polycarbonate NSB-90
Alternator 15 amp regulated 15 amp regulated
Battery 235 cold crank amp 235 cold crank amp
Safety Systems Operator presence Operator presence
PTO Clutch Electronic fingertip engagement Electronic fingertip engagement
Deck Lift Hand lever Hand lever
Seat High-back, lever adjustable High-back, lever adjustable
Cup Holder Standard Standard
Parking Brake Mechanical Mechanical
System Monitor Standard Standard
Forward Speed 6 mph 5.5 mph
Reverse Speed 3 mph 3 mph
Front Tires 13" x 5"-6" 11" x 4"-5"
Rear Tires 18" x 9.5"-8" 18" x 6.5"-8"
Turning Radius Zero Zero
Fuel Capacity 3 gallon 3 gallon
Wheelbase 43.5" 43.5"
Overall Length 67" 67"
Estimated Weight 527 lbs 480 lbs
Cutting Width/Blades
50" triple-blade, 3-in-1 42" triple-blade, 3-in-1
Greasable Spindles Standard Standard
Cutting Height 1.5"-4", 6-position
height adjustment
1.5"-4", 6-position
height adjustment
Deck Construction 12-gauge, floating, stamped 13-gauge, floating, stamped
Deck Drive System Belt driven Belt driven
Anti-Scalping
Wheels 4 adjustable gauge, greasable 2 adjustable gauge, greasable
Accessories Optional mulch kit/
optional bagger
Optional mulch kit/
optional bagger
Warranty** 2-year limited residential 2-year limited residential
Zero-Turn
Mowers
Mustang™ ZT
Mustang
Colt™ ZT
Double Bagger • •
Mulch Kit • •
Zero-Turn
Accessories
*As rated by engine manufacturer.
Ze r o -Turn SpecificaTionS
