Turning Technologies RCQR01 Low Power RF Module User Manual
Turning Technologies, LLC Low Power RF Module Users Manual
Users Manual
Rhein Tech Laboratories, Inc. Client: Turning Technologies, LLC
360 Herndon Parkway Model: RCQR01
Suite 1400 Standards: FCC 15.249/IC RSS-210
Herndon, VA 20170 ID’s: R4WRCQR01/5994A-RCQR01
http://www.rheintech.com Report #: 2014063
Page 38 of 55
Appendix M: Manual
Please refer to the following pages.
USER MANUAL
RCQR01 RF Module
ii
Revision History:
Rev
Date
Description
A
4/21/2014
iii
Table of Contents
1.0 RCQR01 RF MODULE ....................................................................................................................................... 4
1.1 DESCRIPTION ....................................................................................................................................................... 4
1.2 FCC, IC COMPLIANCE INFORMATION .................................................................................................................. 4
1.3 STANDARDS AND GUIDELINES ............................................................................................................................. 4
1.4 FCC/IC COMPLIANCE .......................................................................................................................................... 5
1.5 EU COMPLIANCE ................................................................................................................................................. 5
4
1.0 RCQR01 RF Module
1.1 Description
The RCQR01 is a low power wireless response keypad module. The RCQR01 module is used to interact with an
audience so they can provide real time feed back to questions. It communicates at 2.4GHz, GFSK to a base station.
The overall operation of the RCQR01 module is controlled by a single chip microcontroller-transceiver IC. This
microcontroller-transceiver is powered from approximately 3V and uses a 16MHz reference. The microcontroller
handles control of the RF communications, LCD, and keypad inputs.
RF communications uses the 2.4 GHz transceiver. The transceiver also uses the 16 MHz reference oscillator for
TX/RX, and is also powered by 3V. The transceiver uses an integral inverted F antenna on the PCB. The antenna
gain is approximately 3 dBi.
1.2 FCC, IC Compliance Information
RCQR01 RF Module
Responsible Party Pertaining to the Declaration of Conformity
Turning Technologies, LLC
255 W. Federal Street
Youngstown, OH 44503
(330) 599-4948
1.3 Standards and Guidelines
This device complies with the following USA/Canada Regulations:
The USA Federal Communications Commission (FCC) Rules and Regulations
Industry Canada Rules and Regulations
This device complies with the following national and international standards:
FCC Part 15.249 (10-01-13): Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875
MHz, and 24.0-24.25 GHz.
IC RSS-210 Issue 8: Low power license-exempt radio-communications devices (all frequency bands):
Category 1 equipment.
EN 301 489-1 (V1.9.2)
EN 301 489-3 (V1.6.1)
EN 300 220-2 (V2.4.1)
EN 60950-1:2006 + A11:2009 + A12:2011 + A1:2010 + AC:2011
5
1.4 FCC/IC Compliance
Changes or modifications to the device that are not approved by the manufacturer could void the user’s authority to
operate the device.
This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference and (2) this device
must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux la Partie 15 des règlements de la FCC et CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
1.5 EU Compliance
This device is a 2.4 GHz low power response system controller intended for residential and commercial use in all
EU and EFTA member states .
Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary,
Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, The Netherlands, Norway, Poland, Portugal, Romania,
Slovak Republic, Slovenia, Spain, Sweden, Switzerland/ Lichtenstein, United Kingdom
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
