GETTING STARTED
(+1) 866-661-1218
www.tsicustomerservice.com
SN #: AE-12345-A
Date Code/ Code de Date/ Código Fecha:
MOVABLE HEATER
CFI-100-1
120V ~, 1500W, 60Hz
Twin-Star International, Inc.
www.twinstarhome.com
MADE IN CHINA
CONFORMS TO UL STD. 1278
CERTIFIED TO CSA STD. C22.2 NO.46
4005554
PRODUCT SPECIFICATIONS
1. e serial number is located on the back of the heater, the serial number is necessary for product warranty registration
and customer service.
2 . Go to www.tsicustomerservice.com for product warranty registration. If you are unable to complete registration save
your proof of purchase for warranty purposes.
Serial Number
Model Number
AC Input Power AC120V, 60Hz
Heater Power Consumption 1500 Watts
Standby Power Consumption < 1 W
Peak Music Power Output 300 W
www.tsicustomerservice.comA313
3
IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk of re, electrical shock, and injury to
persons including the following:
1. Read all instructions before using this appliance.
2. is appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this
appliance. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet (0.9 m) from
the front of this appliance and keep away from the sides and the rear.
WARNING: In order to avoid overheating, do not cover the heater.
3. CAUTION: Never leave the heater operating unattended. Extreme caution is necessary if unsupervised children or invalids are nearby.
4. e appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction.
5. Always unplug this appliance when not in use.
6. Do not operate any heater with a damaged cord or plug or aer the appliance malfunctions, or if it has been dropped or damaged
in any manner.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to
avoid a hazard.
8. Do not use outdoors.
9. is heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never locate this appliance where it may
fall into a bathtub or other water container.
10. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or the like. Arrange cord away from trac areas and
where it will not be tripped over.
11. To disconnect this appliance, turn controls to the o position, then remove plug from outlet.
12. Connect to properly grounded outlets only. is heater is for use on 120 volts. e cord has a plug as shown at A in Fig.1. Do not use a 2
prong adapters. Never use with an extension cord or relocatable power tap (outlet/power strip).
13. is appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with
the current CSA C22.1 Canadian Electrical Code or for U.S.A. installations, follow local codes and the National Electrical Code,
ANSI/NFPA NO.70.
14. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or re, or
damage the appliance.
15. To prevent a possible re, do not block air intakes or exhaust in any manner. Do not use on so surfaces, like a bed, where opening
may become blocked.
16. is appliance has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or ammable liquids are used
or stored. is heater should not be used as a drying rack for clothing. Christmas stockings or decorations should not be hung in
the area of it.
17. Use this appliance only as described in the manual. Any other use not recommended by the manufacturer may cause re, electric
shock or injury to persons.
18. CAUTION: Do not sit or stand on the heater; the heater may become unstable.
19. is heater may include a visual alarm to warn that parts of the heater are getting excessively hot. If the alarm ashes immediately turn
the heater o and inspect for any objects on or adjacent to the heater that may cause high temperatures.
DO NOT OPERATE THE HEATER WITH THE ALARM FLASHING!
1. Read all instructions before using this appliance.
2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving
this appliance. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet
(0.9 m) from the front of this appliance.
WARNING: In order to avoid overheating, do not cover the heater.
3. CAUTION: Whenever the heater is left operating and unattended, extreme caution is necessary if children or invalids are nearby.
4. The appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction.
5. Always unplug this appliance when not in use.
6. Do not operate any heater with a damaged cord or plug or after the appliance malfunctions, or if it has been dropped or
damaged in any manner.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order
to avoid a hazard.
8. Do not use outdoors.
9. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never locate this appliance where it
may fall into a bathtub or other water container.
10. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or the like. Arrange cord away from trafc areas
and where it will not be tripped over.
11. To disconnect this appliance, turn controls to the off position, then remove plug from outlet.
12. Connect to properly grounded outlets only, See Fig.1. Do not use a 2 prong adapters.
13. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes,
with the current CSA C22.1 Canadian Electrical Code or for U.S.A. installations, follow local codes and the National Electrical
Code, ANSI/NFPA NO.70.
14. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or re, or
damage the appliance.
15. To prevent a possible re, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where
opening may become blocked.
16. This appliance has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or ammable liquids are
used or stored. This replace should not be used as a drying rack for clothing. Christmas stockings or decorations should not be
hung in the area of it.22. Use this appliance only as described in the manual. Any other use not recommended by the
manufacturer may cause re, electric shock or injury to persons.
17. Always plug heaters directly into a wall outlet/ receptacle. Never use with an extension cord or relocatable power tap (outlet/
power strip).
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk of re, electrical shock, and injury
to persons including the following:
2
ABFig.1
SAVE THESE INSTRUCTIONS
www.tsicustomerservice.comA313
4
INSTALLATION INSTRUCTIONS
1
2
1. Open reglass box cover by holding and pressing
hook in the middle of box;
2. Carefully remove tray cover and place reglass in;
then re-install the tray cover.
Tray Cover
Hook
www.tsicustomerservice.comA313
5
OPERATION INSTRUCTIONS
e heater can be operated by either the remote control or the control panel.
Control Panel
Display
TIMER
www.tsicustomerservice.comA313
6
OPERATION INSTRUCTIONS
FUNCTION
POWER e POWER button supplies power to all the functions of
the heater. Pressing the POWER button again the heater will
be put in standby mode.
With the power on press and hold the POWER button on the
control panel for 10 seconds to disable the heater funtion.
ICON DESCRIPTION
SPEAKER
TIMER Pressing the timer button will cycle through the timer
settings; 30 minutes, 1 Hour, 2H, 3H, 4H, 5H, 6H, 7H, 8H,
9H and o.
e thermostat setting range is 62°F - 82°F or 17°C - 27°C or
continously ON.
e thermostat is adjustable by 2°F increments.
e up and down buttons“ + - ”on the remote will increase /
decrase temperature setting.
To change between °F and °C press and hold the HEATER
button on the control panel for 3 seconds.
ere are 5 brightness levels that can be selected.
FLAME
HEATER
With the power on, press the Speaker button on the control
panel to switch between bluetooth and line in.
Pressing and holding the speaker button for 3 seconds will
turn turn o the audio system.
Adjust the volume if Speaker is ON
Adjust the Timer if the Timer is ON
Adjust the Flame Brightness if the Flame is ON
Adjust the Heater Temperature if the Heater is ON
ADJUSTMENT
BLUE
LINE IN
CLOCK
HEATER
SPEAKER
FLAME
TIMER
MUTE Press MUTE button on the remote to mute and un-mute the
volume.
www.tsicustomerservice.comA313
7
OPERATION INSTRUCTIONS
FUNCTION ICON DESCRIPTION
BLUE Press BLUE button on the remote to switch to Bluetooth input.
LINE IN Press LINE IN button on the remote to switch to Line input.
CLOCK Press CLOCK button on remote to show the current time.
For manual time setting:
Hold “CLOCK” for 3 seconds until the hour digits ash.
Press the “VOLUME + / -” buttons to set the hour.
Press “CLOCK” again. e minute digits will ash.
Press the “VOLUME + / -” buttons to set the minutes.
Press “CLOCK” to conrm.
BLUE
LINE IN
CLOCK
HEATER
SPEAKER
FLAME
TIMER
PREV/NEXT In Bluetooth mode, press PREV/NEXT buttons on remote to
change the current track.
BLUE
LINE IN
CLOCK
HEATER
SPEAKER
FLAME
TIMER
PLAY/PAUSE In Bluetooth mode, press PLAY/PAUSE button on remote to
play or pause the selected track.
TREBLE Press TREBLE button on remote to adjust the TREBLE up
or down.
BASS Press BASS button on remote to adjust the BASS up or down.
VOLUME Press VOLUME button on remote to adjust the volume.
www.tsicustomerservice.comA313
8
TROUBLESHOOTING
Problem Root Cause Corrective Action
Display shows “ ” e thermostat sensor is
broken or disconnected.
Unplug the replace, remove the back panel of the replace and check that the
thermostat is plugged into the main circuit board. If this does not solve the
problem contact customer service for a replacement thermostat sensor.
Display shows “ ” e thermostat sensor is
broken.
Contact customer service for a replacement thermostat sensor.
Display shows “ ” Manual Reset overheat
protection has triggered.
Inspect the heater and check that the air inlets and outlets are not blocked as this
may cause overheating. Unplug the heater for 30 minutes and allow it to cool
down. Replug and operate, monitor the heater for signs of
overheating, if the problem persist discontinue use of the heater and
contact customer service.
Display shows “ ” Power cord overheating
protection has activated.
Check your heater cord and plug connections. Faulty wall outlet connections
or loose plugs can cause the outlet or plug to overheat. Be sure the plug ts tight
in the outlet. Heaters draw more current than small appliances, overheating of
the outlet may occur even if it has not occurred with the use of other appliances.
During use check frequently to determine if your plug outlet or faceplate is
HOT! If so, discontinue use of the heater and have a qualied electrician check
and/or replace the faulty outlet(s).
Heater does not blow
warm air.
Cool down cycle
Normal operation, will continue to run for several minutes before shutting
down. Times will vary based on temperatures. During this time cool air will
blow.
Not reaching set
temperature.
Perform a master reset; turn o and unplug unit. Hold down main power but-
ton on the unit itself. Continue to hold button down while plugging unit back
in. Once unit is plugged back in continue to hold button for 5 seconds and then
release. Turn unit back on and temperature should ash 72 degrees then display
the ambient room temperature.
Not reaching set
temperature.
Unit is designed to be used as a supplemental heat source in conjunction with a
primary heat source.
Temperature display not
matching room
temperature read by other
thermostats.
Calibration
Press and hold timer button, 00 ashes then a single digit between -9 degrees to
9 degrees will appear. At this point release the timer button and use the arrow
up/down button to adjust the temperature variance up to 9 degrees +/- . Aer
10 second without control input the heater will exit thermostat calibration.
e heater is taking a long
time to reach desired room
temperature.
Improper use of unit Unit is designed to be used as a supplemental heat source in conjunction with a
primary heat source.
Location
Your unit should always be positioned on an inside wall with proper insulation.
e heater provides supplemental heating for up to 1000 sq/ in conjunction
with a primary heat source.
Location e back and side of the heater should be greater than 6 inches away from ob-
jects for proper air intake.
Use of surge protector/
extension cord. Plug unit directly into the wall outlet.
Temperature will not
change.
Defective control panel
circuit board. Replace control panel circuit board.
Heater does not turn on
but other functions work
ne.
Manual reset needed
Turn the POWER to “OFF” and unplug the unit from the wall outlet for 5 min-
utes. Aer 5 minutes plug the unit back into wall outlet, and operate as normal.
If the problem persist contact customer service.
Unit continues to run aer
reaching set temperature/
or powering o.
Cool down cycle Normal operation, will continue to run for several minutes before shutting
down. Times will vary based on heating. UNIT WILL BLOW COOL AIR.
Heat turns on randomly. Ambient room
temperature scan.
Normal operation, unit will periodically run to test air temperature.
Will run 3 minute of cool air and 3 minutes of warm air.
Buttons do not work. Defective control panel
circuit board. Replace control panel circuit board.
Control panel does not
illuminate.
Defective control panel
circuit board. Replace control panel circuit board.
Remote Control is not
working.
No batteries or battery
power. Change the remote batteries.
poor signal
Operate remote transmitter at a slow measured pace. Press the remote control
buttons with an even motion and gentle pressure. Repeatedly pressing buttons in
rapid succession may cause the transmitter to malfunction.
Distance Operate the remote at a distance less than 20 feet from the front of the
appliance; point the remote at the control panel.
www.tsicustomerservice.comA313
9
EXPLODED VIEW
Part Part Name Part Number
1Blower/Heater Assembly Y15-S157-P01
2 Main Circuit Board Y15-S157-P15
3Power Circuit Board Y15-S157-P78
4Upper Flame Circuit Board Y15-S157-UF
5 Main Speaker Y15-S157-MS
6 Bass Speaker Y15-S157-BS
7Spinner Y15-S157-P11
8Spinner Motor Y15-S157-P10
9Lower Flame Circuit Board Y15-S157-LF
10 Uplight PCBA Y15-S157-UP
11 Fireglass Tray Y15-S157-FT
12 Control Panel Circuit Board Y15-S157-P32
13 Remote Control P121
www.tsicustomerservice.comA313
10
FCC/IC INFORMATION
BATTERY REPLACEMENT
Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance could
void user’s authority to operate the equipment.
NOTE: is equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part
15 of the FCC Rules. ese limits are designed to provide reasonable protection against harmful interference in a
residential installation. is equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) is device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
is Class B digital apparatus complies with Canadian ICES-003.
When the remote control stops operating or its range seems reduced, it is time to replace the battery with a new one.
1. e battery compartment is located on the back end of the remote.
2. Press and slide the battery door open and remove the old battery.
3. Insert 1pc CR2025 battery, checking that the + and - sides of the battery match inside the battery compartment.
4. Replace the battery compartment door.
CAUTION:
• Always purchase the correct size and grade of battery most suitable for the intended use.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and also those of the device prior to battery installation.
• Ensure the batteries are installed correctly with regard to polarity (+ and -).
• Remove batteries from equipment which is not to be used for an extended period of time.
• Remove used batteries promptly.
Note: Caution do not ingest batteries. If batteries are swallowed immediately call poison control.
www.tsicustomerservice.comA313
11
3-YEAR LIMITED WARRANTY
e manufacturer warrants that your new Speaker is free from manufacturing and material defects for a period of three years
from date of puchase, subject to the following conditions and limitations.
1. Install and operate this Electric Appliance in accordance with the installation and operating instructions furnished with the
product at all times. Any unauthorized repair, alteration, willful abuse, accident, or misuse of the product shall nullify
this warranty.
2. is warranty is non-transferable, and is made to the original owner, provided that the purchase was made through
an authorized supplier of the product.
3. e warranty is limited to the repair or replacement of part(s) found to be defective in material or workmanship,
provided that such part(s) have been subjected to normal conditions of use and service, aer said defect is conrmed
by the manufacturer’s inspection.
4. e manufacturer may, at its discretion, fully discharge all obligations with respect to this warranty by refunding
the wholesale price of the defective part(s).
5. Any installation, labor, construction, transportation, or other related costs/expenses arising from defective part(s),
repair, replacement, or othe wise of same, will not be covered by this warranty, nor shall the manufacturer assume
responsibility for same.
6. e owner/user assumes all other risks, if any, including the risk of any direct, indirect or consequential loss or
damage arising out of the use, or inability to use the product,except as provided by law.
7. All other warranties – expressed or implied –with respect to the product, its components and accessories, or any
obligations/liabilities on the part of the manufacturer are hereby expressly excluded.
8. e manufacturer neither assumes, nor authorizes any third party to assume on its behalf, any other liabilities with
respect to the sale of the product.
9. e warranties as outlined within this document do not apply to non accessories used in conjunction with the
installation of this product.
10.is warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
is warranty is void if:
a. e Speaker is subjected to prolonged periods of dampness or condensation.
b. Any unauthorized alteration, willful abuse, accident, or misuse of the product.
c. You do not have the original receipt of purchase.
CUSTOMER SERVICE
www.tsicustomerservice.com
For Customer Service Call 1-866-661-1218
Questions? Our experts are standing by assist you at our Toll-Free help line, we can help you with assembly, and, if
necessary replace damaged/missing parts. Assistance is available 7 days a week/24 hours a day/365 days per year.
IMPORTANT:
Before contacting Customer Service please have this information available:
• Serial Number
• Model Number
• Sales Receipt or Proof of Purchase
WARNING – TO REDUCE THE
RISK OF FIRE:
1) Do not place any objects such as furniture, papers, clothes,
and curtains closer than 3 feet(0.9 m) to the front of the
heater and keep them away from the sides and rear when
the heater is plugged in.
2) Do not place the heater near a bed because objects such
as pillows or blankets can fall off the bed and be ignited by
the heater.
3) Always unplug heater when not in use.
4) Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or relocatable power tap
(outlet/power strip).
5) Check your heater cord and plug connections. A loose
fitting outlet can cause the plug to overheat or cause a fire.
Be sure plug fits tight in the outlet. Check frequently during
use to make sure plug and outlet are not hot. If so,
discontinue using heater and have outlet replaced by a
qualified electrician.
Note: Heaters draw more current than small appliances,
overheating of the outlet may occur even if it has not occurred
with the other appliances.
DO NOT REMOVE THIS TAG!
AVERTISSEMENT – POUR
DIMINUER LE DANGER
D'INCENDIE :
1) Quand le chauffage est en marche, ne placer aucun objet,
tels que des meubles, du papier, des vêtements et des rideaux
à une distance inférieure à 90 cm de la face avant du chauffage
et les éloigner des faces latérales et arrière.
2) Ne pas placer le chauffage près de la literie, car les objets tels
que les coussins ou draps peuvent tomber du lit et être
enflammés par le chauffage.
3) Toujours débrancher le chauffage quand il n’est pas utilisé.
4) Toujours brancher le chauffage directement à une prise
murale. Ne jamais utiliser une rallonge, prise ou multiprise
électrique non fixe.
5) Vérifier votre cordon du chauffage et les prises enfichables. Un
branchement lâche de la prise de courant murale peut provoquer
une surchauffe ou un risque d’incendie. Assurez-vous que le
connecteur tient bien fermement dans la prise de courant murale.
Vérifier fréquemment pendant le fonctionnement que la fiche du
cordon et que la prise de courant ne soient pas chaud. Si c’est
le cas, cesser d’utiliser le chauffage et faites remplacer la prise
de courant par un électricien qualifié.
Note: Les chauffages consomment plus de courant que les petits
appareils électriques, la surchauffe de la prise de courant murale
peut survenir même si elle ne s’est pas produite avec l’utilisation
d’autres appareils.
NE PAS ENLEVER CETTE
ÉTIQUETTE !
EF 100*250MM
www.tsicustomerservice.comA313
12
www.tsicustomerservice.com
This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that
this device does not cause harmful interference.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Caution: The user is cautioned that changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
For a Class B digital device or peripheral, the instructions furnished the user shall include the
following or similar statement, placed in a prominent location in the text of the manual:
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
