UCOMM TECHNOLOGY SC200 SWING CADDIE User Manual manual swing2 eng 150313
UCommTechnology Co., Ltd. SWING CADDIE manual swing2 eng 150313
User manual
Positioning Swing Caddie :
1~1.5 meters (40~60 inches)
directly behind the ball
Range : 30~300 meters / yards
Ball
1~1.5 meter
Swing Caddie
Swing Caddie
User Manual
* Distance Voice Output
* Loft angle selectable
* Instant feedback via LCD display
* Practice swing measurement.
* Distance adjustment by atmospheric pressure
* 3 Modes : Practice, Target, Approach.
* Daily and overall stats for each club
* Shot count and time display
* Simultaneous display
< Approach Mode : >
- Before the shot: Displays a randomly generated target distance.
(range: 40~100 meters/yards)
After the shot: Displays your shot (carry or total) distance.
Use the + or – button to generate a new target distance
In Random Mode, Swing Caddie scores each shot for accuracy
* The pre-shot display shows your total score for the round. (perfect score: 100)
* The post-shot display shows your score for the preceding shot. (perfect score: 10)
* Tip: A bonus point (+1) will be awarded for matching the exact target distance!
* One round in Random Mode is 10 shots.
< Stats >
- Displays your average stats for each club.
(shot distance, swing speed, ball speed, smash factor) 클럽별 평균 샷 정보 보기
-Press and hold the C (CLUB/STATS) button or press the STATS button on
the remote control to enter Stats Mode.
-Use the + or – button to switch between average stats for the last
100 shots (ALL) and average stats for the day (DAY).
-Press and hold the + button or press the BALL/SMASH button on the
remote control. to switch between ball speed and smash factor
-Press and hold the C (CLUB/STATS) button to reset stats.
Display
Picture 1 : Accumulated average stats
Club(I4) avg. carry distance (182yards) avg. swing speed (85mph) avg.
ball speed (118mph) Avg. smash factor 1.39 max carry distance (210 yards)
Picture 2 : Avg. in today
Club(I4) avg. carry distance (170 yards) avg. swing speed (80mph) avg.
ball speed (104mph) Avg. smash factor 1.30 min carry distance (140 yards)
* Select club directly using Remote control
▶ Package Contents
- Sensor : Doppler radar sensor
- Frequency : K band 24 GHz
- Power : 4ea *1.5 V-AAA Battery
- Battery : About 25 hours
- Dimension : 77(W) X 150(H) X 25(T) mm
- Weight : Approx, 206 g (including battery)
- Operating temperature : 0℃ ~ 50℃
▶ Specification
SC200 / Pouch / Remote Control / 4x AAA Batteries / User Manual
Remote Control
Mode selection
Club selection
Club swing speed
Score
remained battery total shot
Avg
Total work out time
Ball speed Smash Factor
(The ratio of ball speed to swing speed))
Indicates the efficiency of speed
transfer from the club head
to the golf ball
Game score in target/
approach mode
Average data for each club
Positioning
Tip
Carry Distance
Swing Speed
Ball Speed
Smash Factor
“MAKE GOLF Practice FUN!”
MODE : Select the desired mode in 3 modes (Practice > Target > Approach )
STATS : Displays your average stats for each club (STATS > Club selection)
SLEEP : Power saving mode (Saves energy and prolongs battery life during
breaks) Press any button on the device or remote control to out of
sleep mode
Club selection : Press the button with club number
Customer Center
Toll free : +1-888-939-3978
Email: support@voicecaddie.com
Website: www.voicecaddie.com
Basic Usage
Unit Selection: Press and hold the – button on the Swing Caddie.
Device only : unit selection is only available on the device,
not remote control.
Mode Selection: Press the M (mode) button on the Swing Caddie
or on the remote control.
Club Selection: Press the C (club/stats) button on the
Swing Caddie or select your desired club on the remote control.
PRACTICE RANDOM TARGET
PRACTICE TARGETRANDOM
W1 W3 W4 W5 W6 W7 U3 U4 U5 U6
U7 I4 I5 I6 I7 I8 I9 PW AW SW
YARD METER MPH KM/H
Practice Mode
Displays immediate feedback on the preceding shot.
Time Played
Mode
Swing Speed
Ball Speed
Club
Total Shot Count
Shot Distance
Smash Factor
The ratio of ball speed to swing speed.
Indicates the efficiency of speed transfer
from the club head to the golf ball.
Ball Speed / Smash Factor Selection: Press and hold the + button or
press the BALL/SMASH button on the remote control.
Target Mode
Before the shot: Displays your target distance.
Target Distance
Shot Count
Total Score
Shot Distance
Score
After the shot: Displays your shot (carry) distance.
Use the + and – buttons to set your target distance.
(range: 40~200 meters/yards) (increment: 5 meters/yards)
The pre-shot display shows your total score for the round. (perfect score: 100)
The post-shot display shows your score for the preceding shot. (perfect score: 10)
One round in Target Mode is 10 shots.
In Target Mode, Swing Caddie scores each shot for accuracy.
Tip: A bonus point (+1) will be awarded for matching the exact target distance!
Data for practice swings are not stored or displayed.
Swing Caddie measures carry distance and does not account for run.
1
The range of the remote control may be reduced in direct sunlight.
2
3
Data for aberrant shots are not stored or displayed.
4
Data for shots that fly to the far left or right may not be accurate.
Swing Caddie is recommended for indoor use.
5
6
7Caution: Inserting the battery reversely may result in explosion.
Notes Warranty
One Year Limited Warranty
Voice Caddie warrants this hardware product against defects in materials and workmanship for a
period of one year from the date of original retail purchase. If a defect exists, at its option Voice
Caddie will (1) repair the product at no charge, (2) exchange the product with a product that is new or
like-new and is at least functionally equivalent to the original product, or (3) refund the purchase price
of the product. Voice Caddie shall have no obligation to repair, replace or refund until the customer
returns the defective product to Voice Caddie. This warranty does not apply: (1) to damage caused
by accident, abuse, misuse, misapplication, or non-Voice Caddie products; (2) to damage caused by
service performed by anyone who is not a Voice Caddie Authorized Service Provider; or (3) to a
product or part that has been modified without the written permission of Voice Caddie.
For more information on Voice Caddie’s warranty and return policy, please visit www.voicecaddie.com
FCC CERTIFICATION
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions : (1) this device may not cause
harmful interference,and (2) this device must accept any interference received,
including interference that may cause undesired operation.
(Caution) The user that changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum 20 cm between the radiator and
your body. This transmitter must not be collocated or operating in conjunction with any other
antenna or transmitter unless authorized to do so by the FCC.
Product Name
Model Name
Purchase Date
Purchaser’s
Address
Full Name
Warranty Period
Swing Caddie
SC200
Telephone
1 year after the date of purchase
(Excludes battery and other components)
Serial Number
