UOOSER TECHNOLOGY G33 Bluetooth Earphone G33 User Manual
SHENZHEN UOOSER TECHNOLOGY CO., LTD. Bluetooth Earphone G33
User Manual
Bluetooth Earphone G33
User Manual More functions
Function
Button
L
a.Press the function button once to answer
calls, Press Function Button twice to
reject calls.
b.Press the function button once to pause
while at Music Mode.
III III
IV
Main user interface Start Here
a. Open Charging Dock case,
take out the earbuds
open
b. Automatic Pairing
c. Pairing with cellphone Charging Micro USB
Charging Port
Power on/off
a.The LED flashes in Red and there is a
Voice Notice when the Battery Power Low.
b.Press the Power On/Off button before
charging
c.If there is no external power supply, the
LED ON in red, and it will be Off after
fully charged
d.If there is external power supply, LED
flashes in Blue while charging and it will
be on in Blue after fully charged
d. Power off
Bluetooth
Turn on Bluetooth
Device name
Available Devices
Air headset
Available Devices
Air headset
Open cellphone bluetooth and set it as Open
detection, when “Air Headset” appears in
available devices, press to connect. The LED
flash in Blue continuously.
(Voice Notice: Connected)
Press and hold 1s the function button for
either earbud, two earbuds will be powered
off at the same time.
For initial use, press 1s the function
button of the both earbuds respectively
to power on, the earbuds will pair with
each other automatically.
(Voice Notice: Power on --->TWS
Connected)
B
C
A
F
D
L R
Press and hold 1s
A.Contact Charging point
B.Function Button
C.Microphone
D.Charging USB Port
E.Charging Status LED
F.Power On/Off
Press and hold for 1s
Basic Parameter Security warning Warranty Warranty Card
QC Report info
Model #
Inspector
Date
User’s name
User’s telephone#
User’s Add
Date of purchase
Invoice #
Dealer’s name
Dealer’s Add
Dealer’s telephone#
Important Notice
Product Name：Air Headset Operation range：10m
Charging time：1.5 hours Call time：8 hours
Music Time：6 hours Charging Input：5V 1A
Battery Type：Polymer Li-Ion Battery Earbud weight：6g+6g
Important Notice for Single Earbud using
a.The earbuds can be used individually (each earbud pairs
to separate cellphone)
b.Before using as single earbud separate pairing, all the
previous “Air Headset” Pairing records need to be erased
c.While use Left (or Right) earbud separately, press and hold
the function button for 5s, earbud enters manual pairing
mode, the LED flashes between Red and Blue, open
cellphone Bluetooth and search for “Air Headset” and then
connect. The LED will be on in Blue after Successfully
connected. (Voice Notice: Pairing--->Connected)
d.After using the earbuds as single mode and go back to use
as dual earbuds connection, all “Air Headset” pairing records
in the cellphone need to be erased in advance.
Please make sure the product is fully charged before initial use.
Please use the brand adaptor complying safety requirements to charge
this product.
If your cellphone can not find “Air Headset”, please double check if your
cellphone Bluetooth is at “Equipment visible mode”. After initial pairing,
the earbuds will automatically pair for repeat use. If no use for a long
time, need to follow up pairing procedures to pair with the cellphone.
If there is one earbud has sound while in music mode, please restart
the earbuds or manually recover the default setting.
Please use the product in the temperature between 0 C-45 C. When
the enviroment temperature is too high or low, it may cause the
product malfunction.
Please keep the product dry, do not contact water
or humidity enviroment
Please do not drop, throw, pull/drag the product to prevent damage.
Please power off before clean the product.
Please use the product at proper volume while listenning music or
answering call, long time at high volume usage could lead to
permanent hearing loss.
The built in battery is not dismountable, please do not replace by
yourself. If it's really necessary, please ask help from authorized
service center.
Please dispose the product according to local law, can not treat it as
domestic garbage.
Without adult supervision, please keep the product out of reach of
children, the swallow of small components included may cause
asphyxia.
This product is covered under warranty for a period of oneyear from
the date of purchase limited to normal use and maintenance of the machine
parts, materials and functions. Problems and failures verified upon fur-
ther identification, will be provided free repair and replacement parts.
Limited to the following:
A. Headset is beyond the warranty period;
B. User does not follow the instructions. so that the headphone wire and
earplug broken.
C. Without the authorization to dismount, repair, alteration structures;
D. Can’t provide proof of purchase.
E. Man made damage.
F. Due to natural disasters and other force majeure (such as
earthquakes, fires) product failure of damage causes;
V
Default Setting recovery
Manually Default Setting recovery: Make
sure the power is enough, put two earbuds
close and then Press and Hold the both
function button for 10s, after the “Power
Off-->Power On-->Power Off” processes
completed, release both button and the
default setting recovery completed.
Press and hold both
buttons for 10s until
the earbuds power
off, the default
setting recovery
completed
VI
Press and hold for 5s,
enter manual pairing
(use left earbud as
sample)
FCC Caution：
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
