UTC Fire & Security Americas Corporation, Inc. Wireless touchpad

Users Manual

1
,QVWDOODWLRQ,QVWUXFWLRQV
Preliminary 9/24/04
*(6HFXULW\
'
Product
Summary
The touchpad controls a Concord 4 system and receives RF signals from the panel or a trans-
ceiver to display system messages and sound system status beeps and alarms.
Installation Installation Guidelines
• The touchpad can be portable or mounted on a wall.
• Concord™ systems can accommodate a maximum of 96 wireless sensors/zones.
• Do not mount the touchpad in areas that are likely to expose it to moisture.
• Avoid areas with excessive metal or electrical wiring, including furnace and utility rooms.
Tools and Supplies
• Screwdrivers
• Drill with bits
• Mounting screws and anchors (included)
Mounting
The touchpad can be mounted on any interior wall (protected from the elements).
¾To mount the module on a wall:
1.
2.
3.
Figure 1.Mounting Hole Locations
4.
5.
6. I
Figure 2.Attaching Touchpad to Mounting Plate
Figure Under Construction
Figure Under Construction
'RFXPHQW1XPEHU;;5HY$
6HSWHPEHU
35(/,0,1$5<
'LDORJ,FRQL]HG/&'7RXFKSDG
3DUW1R5
2Dialog Iconized LCD Touchpad Installation Instructions
Preliminary 9/24/04
Programming This section describes how to add (learn) the touchpad into Concord 4 panels.
¾To add the touchpad to Concord 4 panel memory:
1.
2.
Testing
Specifications Compatibility: ........................... Concord 4 panel and SuperBus 2000 RF Transceiver
Power Required:........................ 12 VDC nominal 200 mA maximum draw
Operating Frequency:................ 319.5 MHz
Storage Temperature: ................ -30° to 140°F (-34° to 60°C)
Operating Temperature: ............ 32° to 140°F (0° to 60°C)
Maximum Humidity: ................ 90% relative humidity, noncondensing
Wireless Signal Range: ............. 1,000 feet typical open air (may vary with application)
Dimensions: ............................. XXX” x XXX” x XXX” (L x W x H)
FCC Notice This device complies with FCC Rules Part 15. Operation is subject to the following two conditions.
This device may not cause harmful interference.
This device must accept any interference that may be received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by GE Security can void the user’s authority to oper-
ate the equipment.
FCC ID: B4Z-863-WILT
