UTC Fire and Security Americas 869-FOB 319.5MHz AM 4-BUTTON DESIGNER FOB User Manual

UTC Fire & Security Americas Corporation, Inc. 319.5MHz AM 4-BUTTON DESIGNER FOB

Contents

User Manual

1
,QVWDOODWLRQ,QVWUXFWLRQV
*(6HFXULW\
'
PRELIMINARY 12/30/04
Product Summary
The Flip Top KeyChain Touchpad enables the
user to turn the system on and off after exiting or
before entering the home or to turn on the siren
and to call the central monitoring station if there is
an emergency. If lamp modules have been
installed, the KeyChain Touchpad can be used to
turn all lights using the lamp modules on or off.
Installation Overview
General Information
The KeyChain Touchpad is a lithium battery-
powered, wireless touchpad designed to fit on a
keychain, in a pocket or purse. It provides users a
convenient option for the following system opera-
tions:
•Arm the system (doors, windows, and motion
sensors)
•Arm the system with no entry delay (if pro-
grammed)
•Disarm the system
•Trigger Panic alarms
•Turn system controlled lights on or off
•Open the garage door or turn outside lights on
(if programmed)
Installation Guidelines
Use the following guidelines when adding Key-
chain Touchpads to the system:
•KeyChain Touchpads are learned into the Con-
trol Panel as sensors or touchpads.
•KeyChain Touchpads when programmed as
sensors are programmed as a non-supervised
sensor.
•Each learned KeyChain Touchpad uses one of
the available sensor numbers.
•KeyChain Touchpads can be programmed with
no entry delay.
Programming
Follow these instructions to program the touch-
pad:
1. Open the control panel cover.
2. Enter Utility Access Code 1 or 2 using the red-
numbered buttons.
3. Press Add from the Start Menu.
4. Press the Sensor/Remote button from the Main
menu and you will hear keychain remote.
Note: When adding sensors, if you wish to use a more
descriptive location you may press the option button to
use the compass directions (north, north east, east,
south east, south, south west, west, north west).
5. Press DONE.
6. Enter the sensor type number (01, 03, 06, or 07)
with the red numbered keys.
Note: If you wish to use a sensor number other than
the next available, enter a 2 digit sensor number with
the red numbered keys immediately after entering the
sensor type.
7. Press the lock and unlock buttons simulta-
neously until the transmitter LED is lit.
Testing Flip Top KeyChain Touchpads
Used with the SIMON® Control Panel
Perform Sensor Test
The following steps describe the guidelines for
testing sensors.
1. Open the Control Panel cover.
2. Enter the Utility Access Code 1 or 2 using the
red-numbered buttons.
3. Press the Test button once.
4. Press DONE.
5. Trip the sensor by pressing the Lock and
Unlock buttons simultaneously until the LED is
lit.
0+]$0%XWWRQ
'HVLJQHU)RE
Document No. 466-2207 Rev. A
December 2004
2
6. Note the number of siren beeps indicating how
many RF packets the Control Panel received
from the sensor. You should hear 7-8 beeps.
Specifications
Model No.: 600-1003-95R
RF Frequency: 319.5 MHz
Compatibility: Simon and Concord™ control panels
Battery Type: 3 V lithium battery
Estimated Battery Life: 5 to 8 years
Dimensions (mm): 58 x 37 x 12 (L x W x H)
FCC NOTICE
This device complies with FCC Rules Part 15. operation is
subject to the following two conditions:
1) This may not cause harmful interference.
2) This device must accept any interference that may be
received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by Inter-
active Technologies, Inc. can void the user’s authority to
operate the equipment.
FCC ID: B4Z-869-FOB
