UTStarcom Korea Technologies GTX75 Quad-Band GSM/WCDMA Phone with Bluetooth User Manual Manual
UTStarcom Korea Technologies Ltd. Quad-Band GSM/WCDMA Phone with Bluetooth Manual
Contents
- 1. Manual
- 2. Users Manual
Manual
TABLE OF CONTENTS
CHAPTER 1. BEFORE USING YOUR PHONE
PACKAGE CONTENTS ............................................................................................ 6
HANDSET DESCRIPTION ........................................................................................ 7
THE FUNCTION KEYS .......................................................................................................... 8
DISPLAY INDICATORS .......................................................................................................... 9
BATTERY USAGE ................................................................................................. 12
BATTERY INSTALLATION.................................................................................................... 12
BATTERY REMOVAL ........................................................................................................... 12
BATTERY CHARGING ......................................................................................................... 13
USING SIM CARD ................................................................................................14
INSERTING THE SIM CARD ................................................................................................ 14
USING microSD CARD ......................................................................................... 15
INSERTING THE microSD CARD ......................................................................................... 15
REMOVING THE microSD CARD ........................................................................................ 15
USING QWERTY KEYPAD ....................................................................................16
BLOCKING ANTENNA WHILE MAKING A CALL ...................................................18
BATTERY HANDLING INFORMATION................................................................... 19
IEEE STANDARD FOR RECHARGEABLE BATTERIES FOR CELLULAR TELEPHONES .............. 19
CTIA BATTERY CERTIFICATION REQUIREMENTS ............................................................... 20
CHAPTER 2. BASIC OPERATION
TURNING THE PHONE ON/OFF ............................................................................22
SWITCHING TO LOCK MODE ............................................................................... 22
USING SHORTCUT BUTTON ................................................................................. 22
USING IDLE SCREEN ITEM .................................................................................. 23
USING THE TOUCHSCREEN .................................................................................24
MENU SUMMARY ............................................................................................... 26
12-UP MAIN MENU........................................................................................................... 26
LANDSCAPE MODE MENU ................................................................................................ 27
MAKING A CALL................................................................................................................ 29
ANSWERING CALLS .......................................................................................................... 30
WAIT/PAUSE FEATURE ...................................................................................................... 30
3-WAY CALLING ................................................................................................................ 31
CALLER ID FUNCTION ....................................................................................................... 31
CALL WAITING FUNCTION ................................................................................................ 31
ADJUSTING VOLUME ........................................................................................................ 32
1
PB
TABLE OF CONTENTS
MAKE AN INTERNATIONAL CALL ...................................................................................... 32
DURING A CALL .................................................................................................. 33
MUTE (UNMUTE) .............................................................................................................. 33
SPEAKERPHONE ................................................................................................................ 33
3-WAY CALLS .................................................................................................................... 33
VOICE MEMO .................................................................................................................... 34
CALL HISTORY ................................................................................................................... 34
FIND NAME ....................................................................................................................... 34
MESSAGING ...................................................................................................................... 34
BLUETOOTH....................................................................................................................... 34
MAKING AN EMERGENCY CALL ......................................................................... 35
911 IN LOCK MODE .......................................................................................................... 35
911 USING ANY AVAILABLE SYSTEM ................................................................................ 35
CHAPTER 3. MEMORY FUNCTION
STORING A PHONE NUMBER .............................................................................. 38
ENTERING LETTERS, NUMBERS & SYMBOLS ....................................................... 39
STANDARD INPUT MODE .................................................................................................. 41
NUMERIC MODE ............................................................................................................... 42
SYMBOL MODE ................................................................................................................. 42
EMOTICON MODE ............................................................................................................. 42
MAKING A CALL THROUGH THE CONTACT LIST ..................................................43
ONE-TOUCH DIALING ....................................................................................................... 43
CHAPTER 4. MENU FUNCTION
AT&T MUSIC ....................................................................................................... 46
MUSIC PLAYER .................................................................................................................. 46
SHOP MUSIC ..................................................................................................................... 47
MUSIC ID .......................................................................................................................... 48
XM RADIO ......................................................................................................................... 48
MUSIC VIDEOS .................................................................................................................. 48
THE BUZZ .......................................................................................................................... 49
COMMUNITY .................................................................................................................... 49
MUSIC APPS ...................................................................................................................... 49
MESSAGING ........................................................................................................50
CREATE NEW MESSAGE .................................................................................................... 50
3
2
3
2
TABLE OF CONTENTS
INBOX ............................................................................................................................... 51
OUTBOX ............................................................................................................................ 51
SENT ................................................................................................................................. 52
DRAFTS ............................................................................................................................. 52
EMAIL ............................................................................................................................... 53
IM ..................................................................................................................................... 53
VOICE MAIL ...................................................................................................................... 53
YELLOWPAGES .................................................................................................... 54
MEDIA NET ......................................................................................................... 55
MEDIA NET HOME ............................................................................................................ 55
FAVORITES ........................................................................................................................ 55
ENTER URL ........................................................................................................................ 56
HISTORY ............................................................................................................................ 56
SETTINGS .......................................................................................................................... 57
MEDIA MALL .......................................................................................................58
SHOP RINGTONES ............................................................................................................. 58
SHOP GAMES .................................................................................................................... 58
SHOP GRAPHICS ............................................................................................................... 58
SHOP MULTIMEDIA ........................................................................................................... 58
SHOP APPLICATIONS ......................................................................................................... 59
SHOP THEMES ................................................................................................................... 59
SHOP VIDEO ...................................................................................................................... 59
MEDIA NET HOMEPAGE .................................................................................................... 59
CELLUAR VIDEO .................................................................................................. 60
MY STUFF ...........................................................................................................61
RINGTONES&AUDIO .......................................................................................................... 61
IMAGES ............................................................................................................................. 62
VIDEOS .............................................................................................................................. 63
ADDRESS BOOK .................................................................................................. 64
FIND NAME ....................................................................................................................... 64
ADD NEW .......................................................................................................................... 69
GAMES&APPS .....................................................................................................70
GAMES .............................................................................................................................. 70
APPS ................................................................................................................................. 70
AT&T GPS ............................................................................................................ 71
ORGANIZER&TOOLS ...........................................................................................72
TABLE OF CONTENTS
SCHEDULER ..................................................................................................... 72
ALARM ............................................................................................................73
CALCULATOR ................................................................................................... 74
TIP CALCULATOR ............................................................................................. 74
TO DO .............................................................................................................. 74
WORLD TIME ................................................................................................... 75
NOTEPAD ......................................................................................................... 75
UNIT CONVERTER ............................................................................................ 76
VOICE MEMO .................................................................................................. 77
STOPWATCH .................................................................................................... 78
SETTINGS ............................................................................................................ 79
PROFILE ............................................................................................................................ 79
DISPLAY ............................................................................................................................ 80
BLUETOOTH....................................................................................................................... 82
DATE & TIME ..................................................................................................................... 83
PHONE .............................................................................................................................. 84
CALL .................................................................................................................................. 86
SECURITY .......................................................................................................................... 89
APPLICATIONS .................................................................................................................. 91
SOFTWARE UPDATE .......................................................................................................... 93
VOICE COMMANDS ............................................................................................ 94
CAMERA .............................................................................................................95
CHAPTER 5. SAFETY INFORMATION
SAFETY ................................................................................................................98
WARRANTY .......................................................................................................126
5
4
5
4
CHAPTER 1
BEFORE
USING
YOUR PHONE
CHAPTER 1
BEFORE USING YOUR PHONE
This chapter provides important information about your
UTStarcom handset including:
Package Contents
Handset Description
Battery Usage
Usage SIM Card
Usage microSD Card
Usage Qwerty Keypad
Blocking Antenna while Making a Call
Battery Handling Information
PACKAGE CONTENTS
This package should include all items pictured below.
If any are missing or different, immediately contact the retailer where
you purchased the phone.
7
6
Handset Standard Battery
Manual AC Charger
7
6
HANDSET DESCRIPTION
Earpiece
Main Display
with Touch
Screen
Shortcuts Key
QWERTY
Keypad
SEND Key END Key
Volume
Up/Down
Keys
AVR Key
Camera
Key
Power and
Hold Key
microSD/Ear Jack
or Charger slot
External
Speaker
Camera
Lens
Mirror
Microphone
HANDSET DESCRIPTION
THE FUNCTION KEYS
KEY Discriptions
End Key
Press and hold to turn the phone on/off. Press to lock the
phone.
Send Key
Press to make or receive a call or in idle mode, press to
access the All calls list.
End Key
Press to terminate a call or to return to idle mode.
Shortcut Key
Press to launch the Quick List such as Main Menu, Call,
Messaging, Browser, Music Player.
Voice Command Key
Activates Voice Command. Press enters voice command state
as default.
Camera Key
Press to launch the camera application.
Side Volume Key
Allows you to adjust the ringer volume in standby mode or
adjust the voice volume during a call. The volume key can
also be used to scroll up or down to navigate through the
different menu options. Press to ignore an incoming call and
mute the ringer.
9
8
9
8
HANDSET DESCRIPTION
DISPLAY INDICATORS
The idle mode display appears when you are not on a call or using the
menu. You must be in idle mode to dial a phone number.
Text & Graphic Area
Soft Key Indicators
Shows the functions currently assigned to each Option
Button and displays some icons.
Display Indicators
Display various icons.
Signal Strength
Current signal strength: the more lines, the stronger the signal.
Roaming
Phone is out of home area.
1x mode
Phone is in the 1x service area.
Airplane mode
Transmitting and receiving information is restricted.
Bluetooth connected
Indicates Bluetooth Connected.
Bluetooth on
Indicates Bluetooth mode.
Digital mode
Phone is in the digital service area.
Data securtiy
Appears when the phone is accesing a secure Web Site.
HANDSET DESCRIPTION
11
10
No service
Indicates the phone cannot receive a signal from the system.
TTY mode
Indicates your phone is active in TTY mode.
GPS icon
Indicates the Location Service of your phone is disabled/enabled.
Battery
Battery charging level — the more blocks, the stronger the charge.
Battery charging
Indicates the battery is charging.
Roaming call
Blinks when an roaming call is in progress.
Emergency call
Blinks when an emergency call is in progress.
Vibrate
Phone will vibrate to notify you of an incoming call.
Ringer off
Indicates the ringer volume is set to off.
Silence all
Phone is set to Silent - no sound will be made to notify you of incoming
calls or messages.
Level 5 or 1 & vibrate
Phone is set to ring and vibrate.
New text message
Indicates you have new text messages.
New voice messages
Indicates you have both text and voicemail messages.
Data service
Downloading is in progress.
11
10
HANDSET DESCRIPTION
1x mode
Phone is in the 1x service area.
Airplane mode
Transmitting and receiving information is restricted.
Bluetooth connected
Indicates Bluetooth Connected.
Bluetooth on
Indicates Bluetooth mode.
Digital mode
Phone is in the digital service area.
Data securtiy
Appears when the phone is accesing a secure Web Site.
Alarm & Schedule
Appears when either a calendar or an alarm is set.
Lock
Indicates your phone is locked.
Voice privacy
Indicates Voice Privacy mode.
BATTERY USAGE
13
12
BATTERY INSTALLATION
1.
Place the battery (label side up) on the back of the phone so the
metal contacts match up on the battery and in the battery cavity.
2.
Slide the battery down into the battery cavity until it locks into
place.
BATTERY REMOVAL
1.
Push up the release latch button, then slide the battery off the
phone.
2.
Lift the battery up and out of the battery cavity from the top of the
battery.
If the battery is not correctly placed in the compartment, the handset
will not turn on and/or the battery may detach during use.
Note
13
12
BATTERY USAGE
BATTERY CHARGING
POWER CONNECTION
1.
Plug the AC Charger into a standard outlet.
2.
Plug the other end of the AC Charger into the charging port on your
the upper side of your phone. The battery must be installed onto the
phone to work properly.
• When you charge the battery with the phone powered off, you will
see a charging status screen. You cannot operate the phone until it is
powered on.
• The battery is not charged at the time of purchase.
• Fully charge the battery before use.
• It is more efficient to charge the battery with the handset powered
off.
• The battery must be connected to the phone in order to charge it.
• Battery operating time gradually decreases over time.
• If the battery fails to perform normally, you may need to replace the
battery.
Hot Key
USING SIM CARD
15
14
INSERTING THE SIM CARD
You’ll always need a SIM card to use your mobile. This contains important
information about your mobile and network. The message “Insert SIM”
appears when the SIM card is not installed. Please take care of your SIM
card and don’t keep it near magnetic and electronic devices as this can
interfere with data storage and network operations.
1.
Lift the battery out of the mobile.
2.
Slide the SIM card in under the metal grooves in the SIM card slot.
Make sure the SIM card’s metal contacts are facing down and the cut
corner is at the upper left.
REMOVING THE SIM CARD
1.
Lift the battery out of the mobile.
2.
To remove the SIM card, slide it away from socket.
15
14
USING microSD CARD
INSERTING THE microSD CARD
The microSD card stores sounds, images, photos and videos, music, and
other files. To install your microSD card, use the following steps:
1.
With the microSD card slot opened, and
the gold contacts facing down, insert the
microSD card into the slot.
2.
Push the card in until it it clicks into place.
Close the microSD card slot.
REMOVING THE microSD CARD
To remove the microSD card, use the following steps:
1.
Open the microSD card slot. Use your
thumb to press and release the microSD
card. It will pop-out to allow you to remove
the card.
2.
Remove the card and close the microSD
card slot.
USING QWERTY KEYPAD
17
16
Your phone, with a specifically designed QWERTY keyboard, that
provides a superior typing experience on a small handheld for easy and
comfortable text writing. You can use all of the phone functions with the
keyboard either closed or open. When you open the keyboard you have
the extra benefit of a full messaging keyboard. The handheld includes
a fully-functional QWERTY keyboard you can use to compose text for
e-mail messages, notes, and so on.
Caps/Shift Key
To type upper-case letters, hold down the Shift key and then press
one or more letter keys. To type upper-case letters continuously,
use the CAPS-LOCK mode. To change to the CAPS-LOCK mode,
double-tap the Shift key. Once the CAPS-LOCK mode is set, you
can type upper-case letters only. To deactivate, double-tap the
Shift key again. To type an upper-case letter for the first letter of
a word only, simply press the Shift key once. Then, the first letter
you type will be upper case while the rest will be lower-case.
Enter Key
Press the Enter key to insert a line break.
17
16
USING QWERTY KEYPAD
FN Key
To type a special character or numbers, press the applicable key
while holding down the FN key. To type special characters or
numbers consecutively, use the FN-LOCK mode. To change to the
FN-LOCK mode, double-tap the FN key. You can type special
characters or numbers only in this mode. To deactivate, double-tap
the FN key again. To type a special character or number for the
first letter of a word only, simply press the FN key once. Then, the
first letter you type will be a special character or number while
the rest will be normal letters. To type a special character that is
not placed on the keyboard, press FN + Space.
Back Key
Press to return to the previous page.
DEL Key
Press the Delete key to delete a character to the left of the text
cursor.
TAB Key
Press to return to the Home screen.
Sym/Space Key
Press the Space key to type a blank space.
Press FN Key + Space Key, to open the Symbol Pad.
Arrow Key
Press the arrow keys for directional movement.
Numeric Key
Press FN Key + Corresponding Key, to enter number.
BLOCKING ANTENNA WHILE
MAKING A CALL
19
18
CORRECT/INCORRECT FINGER
POSITION
CORRECT FINGER POSITION INCORRECT FINGER POSITION
Your phone is equipped with an intenna. For optimal call quality, hold
the phone by the gripped edges on the side and avoid touching the top
and bottom of the phone.
Note
19
18
BATTERY HANDLING INFORMATION
IEEE STANDARD FOR RECHARGEABLE
BATTERIES FOR CELLULAR
TELEPHONES
• Do not disassemble or open, crush, bend or deform, puncture, or shred.
• Do not modify or remanufacture, attempt to insert foreign objects into
the battery, immerse or expose to water or other liquids, or expose to
fire, explosion, or other hazard.
• Only use the battery for the system for which it was specified.
• Only use the battery with a charging system that has been qualified
with the system per this standard. Use of an unqualified battery or
charger may present a risk of fire, explosion, leakage, or other hazard.
• Do not short circuit a battery or allow metallic or conductive objects to
contact the battery terminals.
• Replace the battery only with another battery that has been qualified
with the system per this standard. Use of an unqualified battery may
present a risk of fire, explosion, leakage, or other hazard.
• Promptly dispose of used batteries in accordance with local
regulations.
• Battery usage by children should be supervised.
• Provide an explanation of security implementation, per 10.2.1.
• Avoid dropping the phone or battery. If the phone or battery is
dropped, especially on a hard surface, and the user suspects damage,
take it to a service center for inspection.
• Improper battery use may result in a fire, explosion, or other hazard.
Ensure precautions were taken to minimize the potential for
foreign objects and / or liquids to enter the host device and
cause a short circuit either during the manufacturing process
or end-user operation.
Foreign Objects
BATTERY HANDLING INFORMATION
21
20
CTIA BATTERY CERTIFICATION
REQUIREMENTS
• Do not disassemble or open crush, bend or deform, puncture or shred
• Do not modify or remanufacture, attempt to insert foreign objects into
the battery, immerse or expose to water or other liquids, expose to fire,
explosion or other hazard.
• Only use the battery for the system for which it is specified
• Only use the battery with a charging system that has been qualified
with the system per this standard. Use of an unqualified battery or
charger may present a risk of fire, explosion, leakage, or other hazard.
• Do not short circuit a battery or allow metallic conductive objects to
contact battery terminals.
• Replace the battery only with another battery that has been qualified
with the system per this standard, IEEE-Std-1725-200x. Use of an
unqualified battery may present a risk of fire, explosion, leakage or
other hazard.
• Promptly dispose of used batteries in accordance with local
regulations
• Battery usage by children should be supervised.
• Avoid dropping the phone or battery. If the phone or battery is
dropped, especially on a hard surface, and the user suspects damage,
take it to a service center for inspection.
• Improper battery use may result in a fire, explosion or other hazard.
• For those host devices that utilize a USB port as a charging source, the
host device’s user manual shall include a statement that the phone
shall only be connected to products that bear the USB-IF logo or have
completed the USB-IF compliance program.
21
20
CHAPTER 2
BASIC
OPERATION
CHAPTER 2
BASIC OPERATION
This chapter addresses and explains the basic features of your
phone including:
Basic Operation
Menu Summary
Basic Functions
During a Call
Making an Emergency Call
BASIC OPERATION
TURNING THE PHONE ON/OFF
1.
To turn on the power, press and hold the POWER
button for a few seconds until power on AT&T
animation appears and the melody begins to
play at same time.
2.
To turn off the power, press and hold the
POWER button for a few seconds, then tap Yes icon.
3.
Power off AT&T animation appears and the melody begins to play
at same time.
SWITCHING TO LOCK MODE
Press the POWER button turns off the display temporarily and blinking
Lock Icon. You will still be able to receive messages and calls while your
device is in Lock Mode. Press the Lock Icon and Touch the Falling Key
or open QWERTY keyboard or press Shortcuts button will wake up your
device.
USING SHORTCUT BUTTON
You can quickly access a few shortcut programs are
added by default between running programs and
stop programs when you do not need to use them.
(Main Menu, Call, Messaging, Browser, Music
Player).
23
22
Your device also automatically goes into sleep mode when you leave
the device idle after a certain amount of time.
Note
23
22
BASIC OPERATION
USING IDLE SCREEN ITEM
From the Idle screen, you can access Main Menu, Call, AT&T Music and
Address Book.
From the Landscape mode screen, you can access Messaging, E-mail, IM,
Address Book and More.
USING THE TOUCHSCREEN
TO SELECT SCREEN MENU ITEM
1.
Tap any application or sub menu items to open it.
BASIC OPERATION
TO USING SCROLL BAR
1.
Tap and hold scroll bar and drag up or down. On some screens such
as webpages, you can also scroll side to side.
TO RETURN TO THE PREVIOUS SCREEN
1.
Tap return button.
25
24
25
24
BASIC OPERATION
MAKING A CALL WITH SCREEN DIAL BUTTON
1.
Simply touch the screen dial button with your finger to enter the
phone number.
TO RETURN TO THE IDLE SCREEN
1.
Press the END key below the display at any time
to return to the IDLE screen.
MENU SUMMARY
12-UP MAIN MENU
1. AT&T Music
1.1. Music Player
1.1.1. Now Playing
1.1.2. All Music
1.1.3. Albums
1.1.4. Artists
1.1.5. Play List
1.1.6. Genres
1.1.7. Settings
1.2. Shop Music
1.3. Music ID
1.4. XM Radio
1.5. Music Videos
1.6. The Buzz
1.7. Community
1.8. Music Apps
2. Messaging
2.1. Create New Message
2.2. Inbox
2.3. Outbox
2.4. Sent
2.5. Drafts
3. Yellowpages
4. MEdia Net
4.1. MEdia Net Home
4.2. Favorites
4.3. Enter URL
4.4. History
4.5. Settings
5. MEdia Mall
5.1. Shop Ringtones
5.2. Shop Games
5.3. Shop Graphics
5.4. Shop Multimedia
5.5. Shop Applications
5.6. Shop Video
5.7. MEdia Net Homepage
6. Celluar Video
7. My Stuff
7.1. Ringtones&Audio
7.2. Images
7.3. Videos
8. Address Book
9. Games&Apps
9.1. Games
9.2. Apps
10. AT&T GPS
11. Organizer&Tools
11.1. Scheduler
11.2. Alarm
11.3. Calculator
11.4. Tip Calculator
11.5. To Do
11.6. World Time
11.7. Notepad
11.8. Unit Converter
11.9. Voice Memo
11.10. Stopwatch
12. Settings
12.1. Profile
12.1.1. General
12.1.2. Outdoor
12.1.3. Meeting
27
26
27
26
MENU SUMMARY
12.1.4. Headset
12.1.5. Flight
12.2. Display
12.2.1. Wallpaper
12.2.2. Style
12.2.3. Greeting Banner
12.2.4. Backlight
12.2.5. Theme
12.3. Bluetooth
12.3.1. Bluetooth
12.3.2. Search Device
12.3.3. Paired Device List
12.3.4. My Phone’s Visibility
12.3.5. My Phone’s Name
12.3.6. Supported Services
12.4. Date&Time
12.4.1. Time Zone Update
12.4.2. Date Format
12.4.3. Time Format
12.5. Phone
12.5.1. Language
12.5.2. Network Selecting
12.5.3. Network Profile
12.5.4. USB Connection Mode
12.5.5. Memory Meter
12.5.6. Phone Information
12.6. Call
12.6.1. Answer Mode
12.6.2. Auto Redial
12.6.3. Minute Minder
12.6.4. Call Forwarding
12.6.5. Call Waiting
12.6.6. Caller ID
12.6.7. Call Barring
12.6.8. TTY
12.7. Security
12.7.1. Phone Lock
12.7.2. PIN Code Request
12.7.3. Change Phone Password
12.7.4. Change PIN Code
12.7.5. FDN
12.7.6. Master Reset
12.7.7. Master Clear
12.8. Applications
12.8.1. Messaging Settings
12.8.2. Browser Settings
12.8.3. Address Book Settings
12.8.4. Camera Settings
12.9. Software Update
12.9.1. Continue Update
12.9.2. Check for Update
MENU SUMMARY
LANDSCAPE MODE
MENU
1. Messaging
1.1. Create New Message
1.2. Inbox
1.3. Outbox
1.4. Sent
1.5. Drafts
2. E-mail
3. IM
4. Address Book
5. More
5.1. Call
5.2. AT&T Music
5.3. Recent Calls
5.4. YELLOWPAGES.COM
5.5. MEdia Net
5.6. MEdia Mall
5.7. Cellular Video
5.8. My Stuff
5.9. Games&Apps
5.10. AT&T GPS
5.11. Organizer&Tools
5.12. Settings
29
28
29
28
BASIC FUNCTIONS
MAKING A CALL
MAKE A CALL FROM PHONE
1.
Tap Call icon.
2.
On the Phone keypad, simply touch the keys with your finger to
enter the phone number. If you tap a wrong number, tap
Clear
to
erase a number. To erase the entire number, tap and hold
Clear
.
3.
Tap the
Call
on your device to place the call.
MAKE A CALL FROM PHONE BOOK
1.
Tap Phone Book icon. Phone Book list displayed.
2.
Tap and hold scroll bar and drag up or down with your finger.
3.
Tap the desired contact in the Phone Book list, and tap the phone
number that you want to call.
4.
Tap the
Call
on your device to place the call.
MAKE A CALL FROM CALL HISTORY
1.
On the Phone screen, press SEND key.
2.
You can select through all calls in Call History select from a category
of Call History types (All Calls, Received Calls, Dialed Calls, Missed
Calls).
3.
Select the desired contact or phone number, and tap
Call
.
BASIC FUNCTIONS
ANSWERING CALLS
1.
When your phone rings or vibrates, tap the Send Key to answer the
incoming call. (Depending on your phone’s settings, you may also
answer incoming calls by opening the phone or by pressing any digit
key.)
2.
To end a call, press the End Key.
WAIT/PAUSE FEATURE
Pauses are used for automated systems (i.e., Voicemail, calling cards).
Insert a pause after a phone number then enter another group of
numbers. The second set of numbers is dialed automatically after the
pause. This feature is useful for dialing into systems that require a code.
1.
To insert a wait/pause, enter a phone number then press and hold the
* Type button for a few seconds until “T“(“T“ appears) or press and
hold the # Type button for a few seconds until “P“(“P” apperas).
2.
Tap the
Call
to dial.
31
30
•
Type “P“
: A hard pause stops the calling sequence until further input from
you.
•
Type “T“
: A two second pause stops the calling sequence for two seconds
and then automatically send the remaining digits.
To ignore incoming calls, tap
Ignore
.
In “Auto Answer Mode“, a call is automatically answered after five
seconds of ring tones.
Note
31
30
BASIC FUNCTIONS
3-WAY CALLING
With 3-Way Calling, you can talk to two people at the same time. When
using this feature, the normal airtime rates will be applied for each of
the two calls.
1.
Enter a number you wish to call then tap
Call
.
2.
Once you have established the connection, enter the second number
you wish to call then tap
Call
.
3.
When you’re connected to the second party, tap
Call
again to begin
your 3-Way call.
CALLER ID FUNCTION
Identifies caller by displaying their phone number. If the caller’s name
and number are already stored in your phone book, their name will
appear. This is a system dependent feature. Please contact your service
provider for details.
CALL WAITING FUNCTION
Notifies you of an incoming call when you are already on a call by
sounding a beep tone and displaying the caller’s phone number.
1.
To answer another call while on the phone, press the Send Key. This
places the first call on hold. To switch back to the first caller, press
the Send Key again.
Call Waiting is a system dependent feature. Please contact your service
provider for details.
Note
BASIC FUNCTIONS
ADJUSTING VOLUME
Adjusts the volume of the ringer, key beep and earpiece.
1.
In idle mode, press the Side Volume Key up or down. Choose
from “General“, “Outdoor“, “Meeting“, “Vibrate“, “Silent“, “OFF“
or “Level 1 ~ Level 7“.
MAKE AN INTERNATIONAL CALL
1.
Tap and hold the number 0 key on the Phone keypad until the + sign
appears. The + replaces the international prefix of the country that
you are calling.
2.
Enter the full phone number you want to dial, and press the Call
button on your device.
33
32
• To adjust the conversation phone volume, you must do it during a call.
Adjusting the volume at another time will affect the ring, notification,
and Music sound levels.
• When you activate Vibrate mode, sound will automatically be muted
and your device will vibrate when an incoming call is received.
Note
33
32
DURING A CALL
MUTE (UNMUTE)
If you press Mute during a call, the person you are speaking with cannot
hear you or any sounds from your side of the conversation. However, you
can still hear them. To activate Mute during a call, tap
Mute
.
SPEAKERPHONE
To activate speakerphone during a call:
1.
To activate the speakerphone while in answering or calling modes,
tap
Speaker On
(Speakerphone On/Off).
3-WAY CALLS
To call a second party during a call, dial the number or select it from the
directory by accessing the menu during a call.
1.
Tap
Options
, then tap
3-Way Calls
.
• To deactivate, tap
Unmute
.
• The phone will automatically unmute in “Emergency Call“ or “Callback
Mode“.
DURING A CALL
VOICE MEMO
To record a voice memo during a call:
1.
Tap
Options
, then tap
Voice Memo
.
CALL HISTORY
Displays call information:
1.
Tap
Options
, then tap
Call History
.
FIND NAME
To select a phone number in your internal Contact List:
1.
Tap
Options
, then tap
Find Name
.
MESSAGING
To send a text message during a call:
1.
Tap
Options
, then tap
Voice Messaging
.
BLUETOOTH
To connect to a Bluetooth-enabled device, such as a wireless headset
(sold separately):
1.
Tap
Options
, then tap
Bluetooth
.
35
34
35
34
MAKING AN EMERGENCY CALL
The 911 feature puts the phone in the Emergency Call Mode when you
dial the preprogrammed emergency number 911. It also operates in Lock
Mode and outside the service area.
911 IN LOCK MODE
The 911 call service is available even in Lock Mode.
1.
Enter “911”, then tap
Call
.
2.
The call connects.
3.
When the call ends, the phone returns to Lock Mode.
911 USING ANY AVAILABLE SYSTEM
1.
Enter “911”, then tap
Call
.
2.
The call connects.
3.
The phone maintains Emergency Mode and the phone can receive
an incoming call from any available system.
However, it can’t make a call.
The 911 call does not appear in the recent call list.
Note
MEMO
37
36
37
36
CHAPTER 3
MEMORY
FUNCTION
CHAPTER 3
MEMORY FUNCTION
This chapter addresses memory functions including:
Storing a Phone Number
Entering Letters, Numbers & Symbols
Making a Call Through the Contact List
STORING A PHONE NUMBER
The phone book stores up to 500 entries.
1.
Enter the phone number, tap
Options
>
Save Contact
.
2.
Tap “New entry“ or “Existing entry“. If “Existing entry” is selected,
your contact list is displayed. Choose the entry to add the number,
then tap
Done
. Select the type of number you are adding from the
icon list, tap
Type of phone
. Tap
Save
. Tap primary phone number,
then tap
Select
to save contact.
3.
If “New entry“ is selected, the New entry icon list appears. Tap to
choose the type of number you are adding. Tap to select. Enter a
name(First Name and Last Name). To change the input mode, tap
Options
. Tap to enter information in other fields for the contact.
Fields include “First Name”, “Last Name”, “Mobile”, “No Group”,
“Ringtone”.
•
Phone number:
To insert a other phone number for the contact, enter the
phone number. Tap to select type (Mobile, Office, Home,
Pager, Other) of phone number.
•
Group:
To set a group for the contact, highlight the Group Name. Tap to
select “No Group“, “Business“, “Family“ or “Friends“.
•
Ringtone:
To set a ringtone for the contact, highlight a Ringtone. Tap to
select “voice_#.amr“, “AT&T Ringtone“, “Basic Ringtone 1
~ Basic Ringtone 3“, “Sky lounge”, “Rainforest”, “Fighters”,
“Love”, “Funny guy” or “Happiness”.
39
38
39
38
STORING A PHONE NUMBER
Tap
Options
to access the following options:
•
Home FAX
•
Office FAX
•
E-mail
•
URL
•
Instant Message
•
•
Birthday
•
Company
•
Job Title
•
Address
•
Memo
4.
To store the entry in your contact list, tap
Save
to save contact.
ENTERING LETTERS,
NUMBERS & SYMBOLS
The input mode will automatically be activated when it is necessary to
enter letters and numbers. There are 4 available modes: Alphabet mode
(Abc/ABC), Numeric mode (123), Symbol mode (Symbols) and Emoticon
mode (Emoticon). The input mode indicator appears on the lower
portion of the display when letters and numbers are entered.
Key
Tap
Options
Press
SYM Key
To change the entry mode -
[Symbols] [Emoticon] [Add
Media] [Add Contacts]
[Sending Settings] [Add
Format] [Save Drafts] [Add
Slide].
Press to accept a word and
add a space.
Key
Press
Del Key
Press
CAP Key
Press to delete a character
to “Del” key.
Press to select the letter
case: [Abc] [ABC].
Key
Press
FN Key
Press
FN
and
CAP Key
To enter a number or
symbol: [123] [1bc].
To enter a number or
symbol: [1BC].
41
40
41
40
ENTERING LETTERS,
NUMBERS & SYMBOLS
STANDARD INPUT MODE
Use the digit keys to enter letters, numbers and characters.
1.
Enter letters using the keypad. To change the input mode,
tap
CAP Key
>
Abc
.
2.
To enter a space, tap “SYM“ Key. The cursor will automatically move
to the next column.
3.
Repeat until letters are entered.
4.
To delete one letter, tap
Del Key
.
To delete the entire entry, tap and hold
Del Key
.
Select Abc mode, tap
CAP Key
>
Abc
. When you select this mode,
the C icon appears as a visual confirmation.
- Find the key that corresponds to the letter you want to enter.
- Press it as many times as needed for the letter to appear on the
screen.
E.G.
ENTERING LETTERS,
NUMBERS & SYMBOLS
NUMERIC MODE
Allows you to enter numbers.
1.
Tap
FN Key
>
123
.
2.
To enter a number, press its corresponding digit key.
SYMBOL MODE
Allows you to enter symbols.
1.
Tap
Options
>
Symbols
.
2.
Tap the /, symbol you want to enter >
Done
.
EMOTICON MODE
Allows you to enter Emoticons.
1.
Tap
Options
>
Emoticon
.
2.
Tap the /, emoticon you want to enter >
Done
.
43
42
43
42
MAKING A CALL THROUGH
THE CONTACT LIST
ONE-TOUCH DIALING
Ideal for frequently dialed numbers, this feature allows entries in your
contact list to be dialed via the keypad with only one or two key presses.
In order for One-Touch Dialing to properly work, it must be enabled.
ONE-TOUCH DIALING
2-9: Press and hold the corresponding memory number for more than
1 second.
• If no phone number is stored in the location entered, “Empty” will
appear on the screen.
• If One Touch Dial is set to Off: Enter the speed dial location number
then press the Send Key.
• Location 1 is reserved for voicemail. Location 2-9 are unassigned.
To assign a speed dial location, please see page 66.
Note
45
44
45
44
NOTE
45
44
45
44
This chapter addresses accessing the menu and using its
functions and features to customize your phone.
CHAPTER 4
MENU
FUNCTION
CHAPTER 4
MENU FUNCTION
AT&T Music
Messaging
Yellowpages
MEdia Net
MEdia Mall
Celluar Video
My Stuff
Address Book
Games&Apps
AT&T GPS
Organizer&Tools
Settings
Voice Commands
Camera
AT&T MUSIC
MUSIC PLAYER
The built in Media Player is an application that can play music files. The
music player supports files with extensions AAC, AAC+, eAAC+, MP3,
WMA, 3GP, MPEG, MP4, and M4A. Launching the Media Player allows
you to navigate within your Media Player folders and select playback
material.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
Music Player
.
•
Now Playing:
Opens the current play list >
Now Playing
.
•
All Music
: View entire playlist in theinternal/external memory
>
All Music
.
•
Albums
: View Plays music files information >
Albums
.
•
Artist:
View Plays music files information >
Artist
.
•
Play List
: Create user own playlists bychoosing songs from the All Songs
menu list >
Play List
.
•
Genres:
View Plays music files information >
Genres
.
•
Settings
- Play Via:
Tap “Phone” or “Bluetooth”.
- Shuffle:
Tap “On” or “Off”.
- Repeat:
Tap “All” or “Bluetooth”.
- Equalizer:
Tap “Normal”, “Rock”, “Pop”, “Classical”, “Jazz” or “Bass”.
47
46
47
46
AT&T MUSIC
SHOP MUSIC
AT&T MusicTM can be used to shop for ringtones, Answer TonesTM and
songs from some of your favorite music stores.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
Shop Music
.
•
History:
Display the site that user visited.
•
Display:
Select “Page Map” or “Page Layout”.
•
Search:
Enter the text >
Search
.
•
Tool
- Send URL:
Send a URL to message.
- Page Info:
Display to site information.
- Save Item:
Save a item to
“Phone” or “SD Card”.
•
Settings
- Help:
User to help information.
- Certificates:
Display the site information.
- Preferences:
User Cheacked site preferances. Tap “Yes” or “No”.
- Clear Cache:
Tap “Yes” or “No”.
- Clear Cookies:
Tap “Yes” or “No”.
- Clear History:
Tap “Yes” or “No”.
- Clear Auto-complete:
Tap “Yes” or “No”.
49
48
49
48
MUSIC ID
Music ID is an application which uses the onboard microphone to
analyze a song sample and then compare it to a remote database of
songs. Once the application completes the analysis of the song sample,
it then provides you with the name of the song, artist and album art as
well as opportunities to buy related content.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
Music ID
.
XM RADIO
This service allows you to stream over 40 channels of commercial-free
music through your handset.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
XM Radio
.
MUSIC VIDEOS
The Music Videos homepage is a component of the AT&T Video
service. This page provides you with links to some of the most popular
multimedia content.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
Music Videos
.
AT&T MUSIC
49
48
49
48
THE BUZZ
This service allows you to navigate through Top 20 chart songs (in a
variety of categories). Other features of this service include streaming
entertainment news about your favorite music artists, access to an
artists main page (containing discographies, ringtones, concert dates,
etc.), concert information, games, and setup options for your own
personal billboard notifications.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
The Buzz
.
COMMUNITY
This Community is a place where you can find a listing of various fan
sites that provide sound clips, wallpapers, bios, discographies, and other
information about an artist.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
Community
.
MUSIC APPS
Music Apps is a group of internet-based music applications, including
MySpace,Billboard Mobile Channel, Hip Hoptionary, Hip Hop Official by
GoTV, and a search option for other features. All of these applications
are by subscription only, and require a large amount of data streaming.
AT&T strongly recommends that if you subscribe to one of these
subscription services that you also subscribe to an appropriate unlimited
Data rate plan for your handset.
1.
In Idle mode, tap
Manu icon
and select
AT&T Music
>
Music Apps
.
AT&T MUSIC
MESSAGING
CREATE NEW MESSAGE
To send a new message:
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Create New
Message
.
2.
Tap
To
, input the phone number then tap
Message
.
From the
To
screen, tap
Options
to choose from:
•
Recent message:
Look up a number from your recent message list.
•
Recent Calls:
Look up a number from your recent call list.
•
Contacts:
Look up a phone number from your Contact list.
•
Change to To:
Change to input mode.
•
Change to CC:
Change to input mode, tap
To
.
•
Change to BCC:
Change to input mode, tap
CC
.
3.
Tap
Message
, input your message.
From the
Message
screen, tap
Options
to choose from:
•
Symbols:
Allows you to enter symbols.
•
Emoticon:
Allows you to enter emoticon.
•
Add Media:
Allows you to add this contact to your media.
•
Add Contacts:
Allows you to add this contact to your contacts.
•
Add Format:
Allows you to add this contact to your format.
•
Add slide:
Allows you to add this contact to your slide.
4.
To send message, tap
Send
.
51
50
51
50
MESSAGING
INBOX
The Inbox manages messages you’ve received.
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Inbox
.
2.
Tap a message. The message is displayed.
From the
Inbox
screen, tap
Options
to choose from:
•
Call:
Place a call to the number the message was sent from.
•
Forward:
Send the message to another person.
•
Save:
Saves the message in the Saved folder.
•
Save contact:
Save the phone number in contacts.
•
Erase:
Delete the messages
•
Cancel:
Cancel the message.
OUTBOX
To manage Outbox messages:
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Outbox
.
2.
To delete a message, tap
Options
. Tap
Select & Delete
or
Delete All
>
Yes
/
No
.
2.
Tap a message. The message is displayed.
From the
Outbox
screen, tap
Options
to choose from:
•
Send:
Resend the selected message to the original recipient.
•
Save:
Saves the message in the Saved folder.
•
Save contact:
Save the phone number in contacts.
•
Erase:
Delete the message.
•
Edit:
Change the recipient’s number and send a message.
MESSAGING
SENT
To manage Sent messages:
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Sent
.
2.
To delete a message, tap
Options
. Tap
Select & Delete
or
Delete All
>
Yes
/
No
.
2.
Tap a message. The message is displayed.
From the
Sent
screen, tap
Options
to choose from:
•
Send:
Resend the selected message to the original recipient.
•
Save:
Saves the message in the Saved folder.
•
Save contact:
Save the phone number in contacts.
•
Erase:
Delete the message.
•
Edit:
Change the recipient’s number and send a message.
DRAFTS
To manage Drafts messages:
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Drafts
.
2.
To delete a message, tap
Options
. Tap
Select & Delete
or
Delete All
>
Yes
/
No
.
3.
Tap a message. The message is displayed.
From the
Sent
screen, tap
Options
to choose from:
•
Symbols:
Allows you to enter symbols.
•
Emoticon:
Allows you to enter emoticon.
•
Add Media:
Allows you to add this contact to your media.
•
Add Contacts:
Allows you to add this contact to your contacts.
•
Add Settings:
Allows you to add this contact to your settings.
•
Add Format:
Allows you to add this contact to your format.
•
Add slide:
Allows you to add this contact to your slide.
53
52
53
52
MESSAGING
4.
To send message, tap
Send
.
EMAIL
You need to create a new account to use for retrieving and sending
email messages.
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Email
.
IM
Your handset comes with the ability to sign onto Instant Messaging.
You must first create an active account using your PC, and then you can
connect and chat using the following applications:
•
AOL Instant Messenger
•
Windows Live Messenger
•
Yahoo! Messenger
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
IM
.
VOICE MAIL
Voicemail allows callers to leave voice messages in your voice mailbox,
and lets you review, play, and delete your voice messages any time you
are in your Carrier’s network coverage area.
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Voice Mail
.
•
Call voicemail: Call your voicemail.
• Last voicemail detail: View last voicemail information.
• Clear voicemail icon: Delete the voice mail icon.
YELLOWPAGES
1.
In Idle mode, tap
Manu icon
and select
Yellowpages
.
55
54
55
54
MEDIA NET
MEDIA NET HOME
Your phone is connected to the network and loads the MEdia Net
homepage.
1.
In Idle mode, tap
Manu icon
and select
MEdia Net
>
MEdia Net
Home
.
FAVORITES
While navigating through either the Internet or the MEdia Net pages,
you can bookmark a site to quickly and easily access it at a future time.
The URL addresses of the bookmarked sites are stored in the Favorites
folder, wherein you can either use the 6-preset URL addresses or store
your own favorite URL addresses.
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Drafts
.
2.
Tap a bookmark item on the Favorite list. The preset URLs consist of:
•
My Account
•
Chat
•
News
•
Sports
•
Weather
•
Cellular Video
Tap
Options
to access the following options:
•
Add Folder:
Allows you to add this contact to your folder.
•
Add Favorite:
Allows you to add this contact to your favorite.
•
Delete All:
“Delete all Items?“will be display >
Yes/No.
MEDIA NET
3.
Tap
Go
to launch the website.
Tap
Options
to access the following options:
•
Send:
Resend the selected message to the original recipient.
ENTER URL
When you are prompted to enter text, the currently active text input
mode is indicated on the screen. To change the text input mode,
press the key one or more times.
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Enter URL
.
2.
Tap a bookmark item on the Favorite list. The preset URLs consist of:
The following modes are available:
•
T9Word:
Allows you to enter characters by pressing one key per letter. In
this mode, you can use only the tap “T9” to display alternative
words.
•
Abc:
Allows you to enter alphabet characters.
•
123:
Allows you to enter numbers.
•
Symbols:
Allows you to enter symbols.
•
Cancel:
Cancel the enter URL.
3.
Tap
Go
to go there directly.
HISTORY
The History list provides you with a list of the most recently visited web
sites. These entries can be used to return to previously unmarked web
pages.
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
History
.
2.
Tap a bookmark item on the History list.
57
56
57
56
MEDIA NET
3.
Tap
Delete All
, “All Items will be deleted. Delete all?“ will be display
>
Yes
/
No
.
SETTINGS
1.
In Idle mode, tap
Manu icon
and select
Messaging
>
Settings
.
•
Help
•
Certificates
•
Preferences
•
Clear Cache
•
Clear Cookies
•
Clear History
•
Clear Auto-complete
MEDIA MALL
The Media Mall topics covered in this section are shopping for
Ringtones, Games, Graphics, Multimedia, Applications, Themes, Videos
and MEdia Net Home the MEdia Home site.
SHOP RINGTONES
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
Shop Ringtones
.
SHOP GAMES
The Shop Games menu option allows you to shop for games using the
built-in browser. You can download new games to your Games folder.
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
Shop Games
.
SHOP GRAPHICS
The Shop Graphics menu option allows you to shop for graphic images
using the built-in browser. You can download new images to your
Graphics folder.
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
Shop Graphics
.
SHOP MULTIMEDIA
The Shop Multimedia menu option allows you to shop for multimedia
files (videos) using the built-in browser. You can download new videos
to your Videos folder.
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
Shop Multimedia
.
59
58
59
58
MEDIA MALL
SHOP APPLICATIONS
The Shop Applications menu option allows you to shop for application
files using the built-in browser. You can download the new applications
to your Applications folder.
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
Shop Applications
.
SHOP VIDEO
The Shop Video menu option allows you to shop for videos online. You
can download the new applications to your My Stuff folder. To access
this menu option, use the following steps:
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
Shop Video
.
MEDIA NET HOMEPAGE
The MEdia Net Home menu option allows you to quickly access your
Cingular MEdia Net homepage using the built-in browser. This page
gives you quick access to information such as local weather, sports
scores, horoscope information and quick links to the previously
mentioned shopping sites.
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
MEdia Net Homepage
.
CELLUAR VIDEO
CELLUAR VIDEO
1.
In Idle mode, tap
Manu icon
and select
MEdia Mall
>
Celluar Video
.
61
60
61
60
MY STUFF
Content (graphics and ringtones) downloaded from “MetroWEB“
- will be stored in the “My Stuff” folder of the device.
RINGTONES & AUDIO
1.
In Idle mode, tap
Manu icon
and select
My Stuff
>
Ringtones & Audio
.
2.
Tap
Phone
or
SD Card
.
Tap
Options
to access the following options:
•
Copy to SD Card
•
Delete Multimedia
3.
Tap
voice_#.amr
,
AT&T Ringtone
,
Basic Ringtone 1~3
,
Sky lounge
,
Rainforest
,
Fighters
,
Love
,
Funny guy
and
Happiness
.
Tap
Options
to access the following options:
•
Send Message
•
Assign
•
Rename
4.
Tap
Play
, to play.
5.
Tap
Delete
, “Delete item?“ will be display >
Yes
/
No
.
MY STUFF
IMAGES
You can download graphics directly to your phone when browsing
MetroWEB! Here is how to download graphics.
1.
In Idle mode, tap
Manu icon
and select
My Stuff
>
Images
.
2.
Tap
Phone
or
SD Card
.
Tap
Options
to access the following options:
•
Copy to SD Card
•
Delete Multimedia
3.
Tap
,
Wallpaper_01
~
Wallpaper_10
.
4.
Tap
Preview
, to preview a image.
Tap
Options
to access the following options:
•
Send Message
•
Assign to Wallpaper
•
Rename
5.
Tap
Delete
, “Delete item?“ will be display >
Yes
/
No
.
63
62
63
62
MY STUFF
VIDEOS
The Shop Video menu option allows you to shop for videos online. You
can download the new applications to your My Stuff folder. To access
this menu option, use the following steps:
1.
In Idle mode, tap
Manu icon
and select
My Stuff
>
Images
.
2.
Tap
Phone
or
SD Card
.
Tap
Options
to access the following options:
•
Copy to SD Card
•
Delete Multimedia
3.
Tap
Video#.3gp
.
4.
Tap
Play
, to play a video.
Tap
Options
to access the following options:
•
Send Message
•
Rename
5.
Tap
Delete
, “Delete item?“ will be display >
Yes
/
No
.
ADDRESS BOOK
Stores up to 500 entries, each of which can be assigned to a group.
Entries can be retrieved by name or group.
1.
In Idle mode, tap
Manu icon
and select
Address Book
.
FIND NAME
Retrieves an entry by name and calls the primary number by simply
pressing the Send Key . You can review all the entries stored in your
contacts list or quickly find an entry by entering a name or its character
string.
1.
The list of names in your contacts is displayed alphabetically.
2.
Enter a name or scroll through the list. If more than one contact is
listed, highlight the contact you want.
3.
Tap the contact. The contact information is displayed.
4.
To edit the contact information, tap
Edit
. The Edit Contact screen will
appear with the selected contact information shown.
See page 38 for “Storing a Phone Number“.
5.
To save the entry, tap
Save
.
To return to the previous page, tap
BACK
.
6.
Tap
Options
to access the following options:
• Group List
• Speed Dial List
• Copy to
• Delete Contat
• Service Dial Number
• My Number
• Address Settings
65
64
65
64
ADDRESS BOOK
GROUP LIST
Allows you to classify phone entries into groups. Existing groups
include “No Group“, “Business“, “Family“, “Friends“. A maximum of
30 groups is allowed.
1.
In Idle mode, tap
Manu icon
and select
Address Book
>
Options
>
Group List
.
Add new group
1.
Tap
Add New
to add a new group name.
2.
Input a new group name.
3.
To save a new group, tap
Save
.
Setting a ringer type for a group
1.
Select an existing group name.
2.
Tap
Options
>
Set Group Ringtone
.
3.
Tap “voice_#.amr“, “AT&T Ringtone”, Basic Ringtone 1 ~ Basic
Ringtone 3”, “Sky lounge”, “Rainforest”, “Fighters”, “Love”,
“Funny guy” or “Happiness”.
4.
Tap
Save
.
ADDRESS BOOK
Change group name
1.
Select the group you want to rename. Only new groups you added
can be changed. The default groups “Business“, “Family“ and
“Friends“ cannot be renamed.
2.
Tap
Options
>
Rename Group
.
3.
Input a new group name.
4.
To change the name, tap
Save
.
Delete group
1.
Select an existing group name. Only new groups you added can be
changed. The default groups “Business“, “Family“ and “Friends“
cannot be deleted.
2.
Tap
Options
>
Delete Group
.
3.
“Delete Group“ will be display >
Yes
/
No
.
SPEED DIAL LIST
In idle mode, calls can be placed to numbers stored in Speed Dial by
pressing & holding the location number on the key pad.
1.
In Idle mode, tap
Manu icon
and select
Address Book
>
Options
>
Group List
.
67
66
Speed Dial must be activated.
Note
67
66
ADDRESS BOOK
2.
To assign a phone number to a location, select the location then
tap
Assign
.
3.
Tap a name from your contact list. If the contact has more than
1 number saved, tap the correct number for the Speed Dial
location is shown.
4.
Tap
Done
to save the number to the Speed Dial location. You will
see the contact name next to the Speed Dial location number in
the Speed Dial lists.
5.
Tap
Reset All
, “Reset all speed dial?” will be display >
Yes
/
No
.
COPY TO
1.
Tap
Options
>
Copy to
.
2.
Tap “Phone -> SIM“ or “SIM -> Phone”.
3.
Tap the contact you want to remove, tap check or uncheck.
Or, Tap
All
.
4.
To remove all phone number, tap
Done
.
5.
“Copy to selected contacts?” will be display >
Yes
/
No
.
“Empty” appears if the location is available.
Note
ADDRESS BOOK
DELETE CONTACT
To delete the selected entry.
1.
Tap
Options
>
Delete Contact
.
2.
Tap the contact you want to delete, tap check or uncheck.
Or, Tap
All
.
3.
To delete all phone number, tap
Done
.
4.
“Delete selected contacts?” will be display >
Yes
/
No
.
SERVICE DIAL NUMBER
1.
Tap
Options
>
Service Dial Number
.
MY NUMBER
Displays your phone number.
1.
Tap
Options
>
My Number
.
2.
Your phone number will be displayed.
3.
To return to the previous page,
BACK
.
ADDRESS SETTINGS
1.
Tap
Options
>
Address Settings
.
Tap
Options
to access the following options:
•
Save Location:
Tap “Always Ask“, “Phone” or “SIM” >
Save
.
•
View:
Tap “All“, “Phone” or “SIM” >
Save
.
•
Memory Status:
Check the current status of the external memory card in
this menu.
69
68
69
68
ADDRESS BOOK
•
SIM Number Type:
Tap “Rename”, “Delete” >
Save
.
•
Change hidden key:
Input the new hidden key.
7.
To call the selected number, tap Send icon.
ADD NEW
Adds a new entry.
1.
Tap
Add New
.
2.
Fill in the fields as they are selected.
Phone Book fields:
•
First Name:
Enter first name >
Save
.
•
Last Name:
Enter last name >
Save
.
•
Number Type:
Tap “Mobile”, “Home”, “Office”, “Pager”, “Home FAX”,
“Office FAX” or “Etc Number”.
•
No Group:
Tap “No Group”, “Business”, “Family” or Friends”
>
Done
.
•
Ringtone:
Tap “voice_#.amr“, “AT&T Ringtone”, Basic Ringtone 1 ~ Basic
Ringtone 3”, “Sky lounge”, “Rainforest”, “Fighters”, “Love”,
“Funny guy” or “Happiness”
>
Save
.
3.
To save the entry, Tap
Save
. To return to the previous page,
Tap
BACK
.
See page 38 for more detailed information about storing a number.
Note
GAMES&APPS
GAMES
1.
In Idle mode, tap
Manu icon
and select
Games&Apps
>
Games
.
APPS
1.
In Idle mode, tap
Manu icon
and select
Games&Apps
>
Apps
.
71
70
71
70
AT&T GPS
AT&T GPS
1.
In Idle mode, tap
Manu icon
and select
Games&Apps
>
AT&T GPS
.
2.
Tap
AT&T Navigator
.
ORGANIZER&TOOLS
SCHEDULER
Sets an event and reminds you of that event.
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Scheduler
.
ADD NEW EVENT
1.
Tap to choose a date in the calendar. Tap
Add
to add an event to the
calendar.
•
Title:
Enter the event title.
•
Date:
Enter the date >
Done
.
•
Time:
Enter the time. Tap
AM
/
PM
>
Done
.
•
Date:
Enter the date >
Done
.
•
Time:
Enter the time. Tap
AM
/
PM
>
Done
.
•
Summary:
Enter the summary
>
Save
.
•
Location:
Enter the location
>
Save
.
•
Alarm:
Tap “Off”, “On Time”, “15 Min before.”, “1Hour before.”, “1Day
before.”, “2Days before.”, “1 Week before.”
>
Save
.
•
Repeat:
Tap “Once”, “Daily”, “Mon to Fri”, Mon to Sat”, “Weekly”,
“Monthly”, “Annually”
>
Save
.
2.
Tap
Save
.
3.
The date of the event will be marked on your calendar.
VIEW ADDED CALENDAR
1.
Tap / to a date in the calendar, then tap to view the event for
that day.
4.
Tap
Add
to add an event to the calendar.
73
72
73
72
ORGANIZER&TOOLS
Tap
Options
to access the following options:
•
Select & Delete:
“Delete Selected Items?“ >
Yes
/
No
.
•
Delete All:
“Delete all Items?“will be display >
Yes
/
No
.
2.
Tap event to see the details for the event.
3.
Tap
Edit
to edit the event, then tap
Save
to save the event.
4.
Tap
Delete
to delete event in the calendar. “Delete Schedule?”
will be displayed >
Yes
/
No
.
TODAY CALENDAR
1.
Tap
Today
.
ALARM
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Alarm
.
2.
Tap
Add
to set a new alarm.
•
Set:
Tap “On“ or “Off“ >
Done
.
•
Time:
Enter the time. Tap
AM
/
PM
>
Done
.
•
Repeat:
Tap “Once”, “Mon to Fri”, Mon to Sat”, “Set to Sun” or “Daily”
>
Done
.
•
Snooze:
Tap “5 min“, “10 min“, “15 min“ or “20 min“ >
Done
.
•
Ring type:
Tap select a ringtone for the alarm sound.
3.
Tap
Save
.
4.
Tap
Delete All
to delete event in the calendar. “Delete all Items?”
will be displayed >
Yes
/
No
.
ORGANIZER&TOOLS
CALCULATOR
The calculator allows you to perform general mathematical functions,
such as addition, subtraction, multiplication, and division.
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Calculator
.
2.
Enter the numbers to get the value you want. To cancel a
calculation, tap
C
.
TIP CALCULATOR
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Tip Calculator
.
TO DO
In to do list, you can add events to remember the special days or event .
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
To Do
.
2.
Tap
Add
to set a new to do.
•
Title:
Enter the title
>
Save
.
•
Date:
Tap to choose a date in the calendar.
•
Summary:
Enter the summary
>
Save
.
•
Priority:
Tap “High”, “Normal”, “Low” >
Save
.
•
Status:
Tap
“In Progress”, “Completed” >
Save
.
3.
Tap
Save
.
Tap
Options
to access the following options:
•
Select & Delete:
“Delete Selected Items?“ >
Yes
/
No
.
•
Delete All:
“Delete all ToDo?“will be display >
Yes
/
No
.
75
74
75
74
ORGANIZER&TOOLS
WORLD TIME
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
World
Time
.
2.
Tap
Set
, then tap / to choose a city.
•
DST:
Specifies whether the current time of the selected place is adjusted to
Daylight Savings Time.
3.
Tap
Done
.
4.
Tap
Delete All
to delete world time. “Delete all Items?” will be
displayed >
Yes
/
No
.
NOTEPAD
To access the notepad:
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Notepad
.
ADD MEMO
1.
Tap
Add
to add a new memo.
2.
To input a memo >
Save
.
3.
Tap
Del. All
to delete world time. “Erase all?” will be displayed
>
Yes
/
No
.
VIEW MEMO
1.
The list of all memos, in saved order is displayed.
2.
Tap a memo.
ORGANIZER&TOOLS
EDIT MEMO
1.
The list of all memos, in saved order is displayed.
2.
Tap a memo.
3.
Tap
Edit
to edit the memo >
Save
.
DELETE MEMO
1.
The list of all memos, in saved order is displayed.
2.
Tap a memo.
3.
Tap
Delete
. “Erase this memo?” will appear on the display >
Yes
/
No
.
UNIT CONVERTER
In unit converter, you can get a weight and length in converted value.
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Unit Converter
.
•
Unit:
Tap “Distance”, “Area”, “Volume”, “Mass” or “Temperature” >
Done
.
•
Input:
Tap “mm”, “cm”, “m”, “km”, “in”, “ft”, “yd” or “mi” >
Done
.
•
Output:
Tap “mm”, “cm”, “m”, “km”, “in”, “ft”, “yd” or “mi” >
Done
.
2.
Tap
Reset
.
77
76
77
76
ORGANIZER&TOOLS
VOICE MEMO
Voice Memo allows you to record a reminder message that can be up to
4 minutes. To record a memo:
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Voice Memo
.
2.
To record a voice memo, Tap
Start
.
To pause/resume a voice memo, Tap
Pause
/
Resume
.
3.
To stop recording a voice memo, Tap
Stop
.
•
Save:
Saving voice_# in my stuff.
(
Manu icon
>
My Stuff
>
Ringtones&Audio
)
•
Save & Send Msg:
To save and send message.
•
Cancel:
To cancel voice memo.
ORGANIZER&TOOLS
STOPWATCH
You can simultaneously time up to 10 different events.
1.
In Idle mode, tap
Manu icon
and select
Organizer&Tools
>
Stopwatch
.
2.
To measure a time period:
• To start, tap
Start
.
• To stop the timing, tap
Stop
.
To continue timing, tap
Cont.
.
• Tap
Lap
to save the time at one instance. You can show up to 10 times.
• To stop the stopwatch, tap
Stop
.
• To review the results, Scroll through.
• To reset it, tap
Reset
.
79
78
79
78
SETTINGS
Customizes your phone and optimizes performance through a variety of
settings.
PROFILE
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Profile
.
2.
Tap
General
,
Outdoor
,
Meeting
or
Headset
.
•
Call Alert Type:
Tap Ring, Vibrate, Ring & Vibrate, Ring After Vibrate or
Silence >
Save
.
•
Ring Tone:
Tap Phone or SD Card.
Tap AT&T Ringtone, Basic Ringtone 1 ~ Basic Ringtone 3, Sky
lounge, Rainforest, Fighters, Love, Funny guy, Happiness >
Save
.
•
Ring Volume:
Tap Off or Volume 1 ~ Volume 7 >
Save
.
•
Message Alert Type:
Tap Ring Once, Ring Periodically, Ring &Vibrate or
Silent >
Save
.
•
Message Tone:
Tap Tone 1, Tone 2 or Off >
Save
.
•
Keypad Volume:
Tap Off or Volume 1 ~ Volume 7 >
Save
.
•
Multimedia Volume:
Tap Off or Volume 1 ~ Volume 7 >
Save
.
3.
Tap
Flight
.
Tap On or Off >
Save
.
SETTINGS
DISPLAY
WALLPAPER
Allows you to choose the kind of background to be displayed on the
phone.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Wallpaper
.
2.
Tap “Pic#” or “Wallpaper_01 ~ Wallpaper_10”.
3.
Tap
Save
.
STYLE
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Style
.
2.
Tap “Digital clock”, “Digital clock”, “Analog clock”, “Dual clock”,
“Calendar” or “Idle screen”.
3.
Tap
OK
.
GREETING BANNER
The greeting is your personal label for your phone. It appears on the
main screen along the top of the display.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Greeting Banner
.
2.
Tap “On” or “Off”.
81
80
81
80
SETTINGS
3.
If you select “On”, the current greeting text is displayed.
Tap
Del
to delete the greeting, then enter your new greeting.
Tap
Options
to change the input mode.
4.
Tap
Save
.
BACKLIGHT
Turn on the backlight on the display and keypad for easy viewing in dark
places.
DISPLAY
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Backlight
>
Display
.
2.
Tap “5 secs“, “10 secs“, “20 secs“, “1 min“ or “3mins“.
3.
Tap
Save
.
KEYPAD
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Backlight
>
Keypad
.
2.
Tap “5 secs“, “10 secs“, “20 secs“ or “Always off“.
3.
Tap
Save
.
THEME
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Theme
.
2.
Tap “Gray“ or “Blue“.
3.
Tap
Save
.
SETTINGS
BLUETOOTH
BLUETOOTH
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Bluetooth
>
Bluetooth
.
2.
Tap “On” or “Off”.
SEARCH DEVICE
Searches for Bluetooth devices in possible range.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Bluetooth
>
Search Device
.
PAIRED DEVICE LIST
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Bluetooth
>
Paired Device List
.
MY DEVICE VISIBILITY
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Bluetooth
>
My Device Visibility
.
2.
Tap “On” or “Off”.
MY DEVICE NAME
To assign my device name.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Bluetooth
>
My Device Name
.
83
82
83
82
SETTINGS
2.
Input your device name.
3.
Tap
Save
.
SUPPORTED SERVICES
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Bluetooth
>
Supported Services
.
2.
Tap “Headset”, ”Stereo Headset”, ”Handsfree”, ”Dial up
Networking”, ”A/V Remote Control” or “Serial Port”.
DATE & TIME
Allows you to change the date and time settings.
TIME ZONE UPDATE
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Date & Time
>
Time Zone Update
.
2.
Tap “Auto Update” or “Manually”.
3.
Tap
Save
.
DATE FORMAT
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Date & Time
>
Date Format
.
2.
Tap “Sun Jan 06”, ”Jan 06 Sun”, ”Sun Jan.06.1980” or “1980.
Jan.06 Sun”.
3.
Tap
Save
.
SETTINGS
TIME FORMAT
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Date & Time
>
Time Format
.
2.
Tap “12 Hour” or “24 Hour”.
3.
Tap
Save
.
PHONE
LANGUAGE
Selects the language in which letters are displayed on the screen.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Phone
>
Language
.
2.
Tap “English” or “Spanish”.
3.
Tap
Save
.
NETWORK SELECTINGS
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Phone
>
Network Selectings
.
2.
Tap “Automatic” or “Manually”.
3.
Tap
Save
.
NETWORK PROFILE
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Phone
>
Network Profile
.
85
84
85
84
SETTINGS
USB CONNECTION MODE
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Phone
>
USB Connection Mode
.
2.
Tap “Music Sync”, ”Mass Storage” or “Data Service”.
3.
Tap
Save
.
MEMORY METER
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Phone
>
Memory Meter
.
2.
Tap “Phone” or “SD Card”.
3.
Your phone’s Games & Apps, Music & Ringtones, Graphics & Videos
and MMS information are displayed.
PHONE INFORMATION
Displays your phone’s information:
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Phone
>
Phone Information
.
2.
Your phone’s My mobile number, IMEI, S/W ver, H/W ver, Config
Version, Network band, Manufacturer and Model information are
displayed.
SETTINGS
CALL
ANSWER MODE
This feature allows you to select the answer mode.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
Answer Mode
.
2.
Tap “Any Key” or “Talk Key”.
•
Any Key:
Press any key to answer an incoming call.
•
Talk Key:
Press talk key to answer a call.
3.
Tap
Save
.
AUTO REDIAL
Automatically redials a phone number after a set time interval.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
Auto Redial
.
2.
Tap “On” or “Off”.
3.
Tap
Save
.
MINUTE MINDER
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
Minute Minder
.
2.
Tap “On” or “Off”.
3.
Tap
Save
.
87
86
87
86
SETTINGS
CALL FORWARDING
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
Call Forwarding
.
2.
Tap
Unconditional
,
Busy
,
No Reply
or
Not Reachable
.
•
Activate:
To request the network to activate call waiting.
•
Deactivate:
To request the network to deactivate call waiting.
•
Check Status:
To check if the function is active or not.
3.
Tap
Deactivate All
.
CALL WAITING
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
Call Waiting
.
2.
Tap
All Call
,
Voice Call
or
Data Call
.
•
Activate:
To request the network to activate call waiting.
•
Deactivate:
To request the network to deactivate call waiting.
•
Check Status:
To check if the function is active or not.
CALLER ID
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
Caller ID
.
2.
Tap
Show My Number
,
Hide My Number
,
Network
or
Check Status
.
•
Show My Number:
Caller ID is show.
•
Hide My Number:
Caller ID is Hide.
•
Network:
Caller ID is Network.
•
Check Status:
To check the status.
SETTINGS
CALL BARRING
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
Call Barring
.
2.
Tap
All Outgoing
,
Outgoing Int’l
,
Except Home
,
All Incoming
,
Incoming Roaming
.
•
Activate:
To request the network to activate call waiting.
•
Deactivate:
To request the network to deactivate call waiting.
•
Check Status:
To check if the function is active or not.
Tap
Deactivate All
or
Change Password
.
TTY
Your phone is able to operate with a TTY(Teletypewriter) device. This
feature is system dependent and may not be available in all areas.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Call
>
TTY
.
2.
Tap
TTY Full
,
TTY + Talk
,
TTY + Hear
or
TTY Off
.
3.
Tap
Save
.
89
88
89
88
SETTINGS
SECURITY
Prevents others from using the phone without permission and allows
access to security features only after inputting a password.
PHONE LOCK
Turn on the lock to prevent the phone from being used without entering
the password first.
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Security
>
Phone Lock
.
2.
Tap “On” or “Off”.
3.
Tap
Save
.
PIN CODE REQUEST
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Security
>
PIN Code Request
.
2.
Tap “On” or “Off”.
3.
Tap
Save
.
CHANGE PHONE PASSWORD
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Security
>
Change Phone Password
.
2.
Enter your New Password >
Done
, then enter your Verify Password
>
Done
. Enter your Current Password >
Done
.
SETTINGS
CHANGE PIN CODE
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Security
>
Change PIN Code
.
2.
Tap
PIN1
or
PIN2
.
FDN
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Security
>
FDN
.
2.
Tap
FDN
or
FDN List
.
•
FDN:
Tap “On” or “Off” >
Save
.
•
FDN List:
Tap
Add New
. Enter a “Name” and “Phone number“ >
Save
.
MASTER RESET
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Security
>
Master Reset
.
2.
“Intialize all settings to default value. Proceed?“ will be display.
Tap
Yes
or
No
.
MASTER CLEAR
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Security
>
Master Clear
.
2.
“Master Clear erases all data and contents. Proceed?“ will be
display. Tap
Yes
or
No
.
91
90
91
90
SETTINGS
APPLICATIONS
MESSAGING SETTINGS
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Applications
>
Messaging Settings
.
•
Text Message
- Message Center Number :
Send a text message, you can get the address
of the SMS center by using this menu.
- Email Gateway:
Send the text message to an Email Address via this
gateway.
- Text Templates:
View and edit the template messages or create new
messages.
•
Multimedia Message
- Default Slide Duration:
Tap “2 sec.”, “5 sec.” or “10 sec.” >
Save
.
- Priority:
Tap “High”, “Normal” or “Low” >
Save
.
- Validity Period:
Tap “1 Hour”, “2 Hours”, “1 Day”, “1 Week” or
“Maxinum” >
Save
.
- Request Delivery Receipt:
Tap “On” or “Off” >
Save
.
- Request Read Receipt:
Tap “On” or “Off” >
Save
.
- Automatic Download:
Tap “On” or “Off” >
Save
.
- Send Delivery Receipt:
Tap “On” or “Off” >
Save
.
- Send Read Receipt:
Tap “On” or “Off” >
Save
.
- Message Center:
Tap “Name” or “MMSC URL”. Enter a text >
Save
.
•
Voicemail:
To change user voice mail number.
•
Auto Erase:
Tap “On” or “Off” >
Save
.
SETTINGS
BROWSER SETTINGS
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Applications
>
Browser Settings
.
2.
Tap
Add
.
3.
Enter the browser settings >
Save
.
ADDRESS BOOK SETTINGS
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Applications
>
Address Book Settings
.
•
Save Location:
Tap “Always Ask”, “Phone” or “SIM” >
Save
.
•
View:
Tap “All”, “Phone” or “SIM” >
Save
.
•
Memory Status:
Check the current status of the external memory card in
this menu.
•
SIM Number Type:
Tap “Rename”, “Delete” >
Save
.
•
Change hidden key:
Input the new hidden key.
CAMERA SETTINGS
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Applications
>
Camera Settings
.
•
Camera
- Resolution:
Tap “1280x960”, “640x480” or “320x240” >
Save
.
- Quality:
Tap “Economy”, “Normal” or “Fine” >
Save
.
- Save To:
Tap “Phone Memory” or “SD Card” >
Save
.
•
Camcorder
- Resolution:
Tap “320x240” or “176x144” >
Save
.
- Quality:
Tap “Economy”, “Normal” or “Fine” >
Save
.
- Save To:
Tap “Phone Memory” or “SD Card” >
Save
.
93
92
93
92
SETTINGS
SOFTWARE UPDATE
MESSAGING SETTINGS
1.
In Idle mode, tap
Manu icon
and select
Settings
>
Software Update
>
Messaging Settings
.
•
Continue Update:
This menu is used to resume a postponed software
update.
•
Check for Update:
“Check the Cingular server for a new software update?
The software update process will not delete any
personal data on your phone.” will be display.
Tap
OK
or
No
.
VOICE COMMANDS
Your phone is equipped with an AVR (Advanced Voice Recognition)
feature. This feature allows you to make calls or use the phone’s
functions by simply using your voice. All you have to do is talk into the
phone, and the phone will recognize your voice and complete tasks by
itself.
1.
In Idle mode, press Side VR Key(Advanced Voice Recognition).
2.
When prompted, say one of the following commands:
•
Call
•
Digit Dial
•
Voicemail
•
My Phone Number
•
Status
•
Help
3.
To setup the voice command, tap
Set
.
•
VR results:
Tap “One” or “Three best”.
•
Voice Calibration:
Tap “Words calibration” or ”Digits calibration”.
•
Prompts:
Tap “Mode” or “Timeout”.
•
Number format:
Tap “Accept any” or “North America”.
4.
To return to the previous page, tap
BACK
.
95
94
95
94
CAMERA
TAKE A PICTURE
Taking pictures with your phone's built-in camera is as simple as
choosing a subject, pointing the lens,and pressing a button.
1.
In Idle mode, press Side Camera Key >
Take a Picture
.
2.
Using the phone ’s Main LCD as a viewfinder, aim the camera lens
at your subject.
Tap
Options
to choose from:
• View Photo: The list of the photos in the currently selected memory appears.
• Self timer: To select self timer 0ff, 5 sec or 10 sec.
• White Balance: Allows you to select the white balance mode to adjust the
color balance of photos.
• Image effect: To select image effect Normal, Gray, Negative, Sepia, Emboss,
Sketch.
• Fun frame: Highlight a fun frame from the list.
• Resolution: To select resolution 1280x960, 640x480, 320x240.
• Quality: To select Quality Economy, Normal or Fine.
• Save To: To select save to
“Phone Memory”, “SD Card”
.
3.
Tap
Done
, until the shutter sounds.
MEMO
97
96
97
96
CHAPTER 5
SAFETY
INFORMATION
CHAPTER 5
SAFETY INFORMATION
Read this information before using your handheld portable
Cellular Telephone.
Safety
Warranty
SAFETY
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
Read This Information Before Using Your Handheld
Portable Cellular Telephone
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal
in some states. Remember, safety comes first. Check the laws and
regulations on the use of phones in the areas where you drive. Always
obey them.If you must use your phone while driving, please:
• Give full attention to driving. Driving safely is your first responsibility.
• Use hands-free operation and/or one-touch, speed dialing, and auto
answer modes.
• Pull off the road and park before making or answering a call.
An air bag inflates with great force. DO NOT place objects, including
either installed or portable wireless equipment, in the area over the air
bag or in the air bag deployment area. If in-vehicle wireless equipment
is improperly installed and the air bag inflates, serious injury could
result.
WARNING!:
Failure to follow these instructions could lead to serious
personal injury and possible property damage.
99
98
99
98
SAFETY
ELECTRONIC DEVICES
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
Most modern electronic equipment is shielded from RF energy.
However, certain electronic equipment may not be shielded against the
RF signals from your wireless phone. Therefore, use of your phone must
be restricted in certain situations.
PACEMAKERS
The Health Industry Manufacturers Association recommends that
a minimum separation of six (6”) inches be maintained between
a handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are consistent
with the independent research byand recommendations of Wireless
Technology Research.
Never come closer than six (6) inches to a person with a heart
pacemaker implant when using your phone. Doing so could result in
interference with the function of the pacemaker.
Persons with pacemakers:
• ALWAYS keep the phone more than six inches from your pacemaker
when the phone is turned on.
• Do not carry the phone in a breast pocket.
• Use the ear opposite the pacemaker to minimize the potential for
interference.
• If you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.
SAFETY
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In
the event of such interference, you may want to consult your service
provider (or call the customer service line to discuss alternatives).
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer
of your device to determine if they are adequately shielded from
external RF energy. Your physician may be able to assist you in
obtaining this information.
HOSPITALS AND HEALTH CARE FACILITIES
Turn your phone OFF in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or healthcare
facilities may be using equipment that could be sensitive to external RF
energy.
VEHICLES
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer or
its representative regarding your vehicle. You should also consult the
manufacturer of any equipment that has been added to your vehicle.
POSTED FACILITIES
Turn your phone OFF where posted notices so require.
101
100
101
100
SAFETY
AIRCRAFT
FCC regulations prohibit using your phone while in the air. Turn your
phone OFF before boarding an aircraft. Always request and obtain prior
consent and approval of an authorized airline representative before
using your phone aboard an aircraft. Always follow the instructions of
the airline representative whenever using your phone aboard an aircraft,
to prevent any possible interference with airborne electronic equipment.
BLASTING AREAS
To avoid interfering with blasting operations, turn your phone OFF when
in a “blasting area” or in areas posted “Turn off two-way radio”. Obey
all signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always,
clearly marked. They include fueling areas such as gas stations: below
deck on boats: fuel or chemical transfer or storage facilities: vehicles
using liquefied petroleum gas (such as propane or butane): areas where
the air contains chemicals or particles, such as grain, dust, or metal
powders: and any other area where you would normally be advised to
turn off your vehicle’s engine.
SAFETY
SAFETY INFORMATION FOR FCC RF
EXPOSURE
Warning! Read this information before using your
phone.
In August 1996 the Federal Communications Commission (FCC) of the
United States with its action in Report and Order FCC 96-326 adopted
an updated safety standard for human exposure to radio frequency
electromagnetic energy emitted by FCC regulated transmitters. Those
guidelines are consistent with the safety standard previously set by
both U.S. and international standards bodies. The design of this phone
complies with the FCC guidelines and these international standards.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the back
of the phone kept 2.0 cm from the body. To maintain compliance with
FCC RF exposure requirements, use only belt-clips, holsters or similar
accessories that maintain a 2.0 cm separation distance between the
user’s body and the back of the phone, including the antenna. The use
of belt-clips, holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that do not satisfy
these requirements may not comply with FCC RF exposure requirements,
and should be avoided.
For more information about RF exposure, please visit the FCC website at
www.fcc.gov.
103
102
103
102
SAFETY
SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO
WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure
to radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through periodic
and thorough evaluation of scientific studies. The standards include a
substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with
the phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while operating can be
well below the maximum value. This is because the phone is designed
to operate at multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output. Before a phone model is
available for sale to the public, it must be tested and certified to the FCC
that it does not exceed the limit established by the government adopted
requirement for safe exposure.
SAFETY
SAFETY
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the ear is
1.1 W/Kg and when worn on the body, as described in this user guide,
is 1.06 W/Kg. (Body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various phones and
at various positions, they all meet the government requirement for safe
exposure.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on O6Y-GTX75.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association (CTIA)
website at http://www.phonefacts.net.
* In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations
in measurements.
105
104
SAFETY
105
104
SAFETY
FDA CONSUMER UPDATE
U.S. Food and Drug Administration
Cell Phone Facts Consumer
Information on Wireless Phones
1. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to handheld wireless phones
with built-in antennas, often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose the user to measurable
radiofrequency energy (RF) because of the short distance between the
phone and the user’s head. These RF exposures are limited by Federal
Communications Commission safety guidelines that were developed
with the advice of FDA and other federal health and safety agencies.
When the phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF exposure
decreases rapidly with increasing distance from the source. The so-
called “cordless phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far lower power levels,
and thus produce RF exposures well within the FCC’s compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using wireless phones. There is no proof,
however, that wireless phones are absolutely safe. Wireless phones emit
low levels of radiofrequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in the standby
mode. Whereas high levels of RF can produce health effects (by heating
tissue), exposure to low level RF that does not produce heating effects
causes no known adverse health effects.
SAFETY
Many studies of low level RF exposures have not found any biological
effects. Some studies have suggested that some biological effects may
occur, but such findings have not been confirmed by additional research.
In some cases, other researchers have had difficulty in reproducing those
studies, or in determining the reasons for inconsistent results.
3 . What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as wireless phones before they can be sold,
as it does with new drugs or medical devices. However, the agency
has authority to take action if wireless phones are shown to emit
radiofrequency energy (RF) at a level that is hazardous to the user. In
such a case, FDA could require the manufacturers of wireless phones
to notify users of the health hazard and to repair, replace or recall the
phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, FDA has urged the wireless phone industry to take a number of
steps, including the following:
• Support needed research into possible biological effects of RF of the
type emitted by wireless phones:
• Design wireless phones in a way that minimizes any RF exposure to
the user that is not necessary for device function: and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health
FDA belongs to an interagency working group of the federal agencies
that have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies belong
to this working group:
107
106
107
106
SAFETY
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency
working group activities, as well.
FDA shares regulatory responsibilities for wireless phones with the
Federal Communications Commission (FCC). All phones that are sold
in the United States must comply with FCC safety guidelines that limit
RF exposure. FCC relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than
do the wireless phones themselves, the RF exposures that people get
from these base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations are thus not the
primary subject of the safety questions discussed in this document.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many
studies have suffered from flaws in their research methods. Animal
experiments investigating the effects of radiofrequency energy (RF)
exposures characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories. A few
animal studies, however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory animals.
SAFETY
However, many of the studies that showed increased tumor
development used animals that had been genetically engineered or
treated with cancer-causing chemicals so as to be pre-disposed to
develop cancer in the absence of RF exposure.Other studies exposed
the animals to RF for up to 22 hours per day. These conditions are not
similar to the conditions under which people use wireless phones, so
we don’t know with certainty what the results of such studies mean for
human health. Three large epidemiology studies have been published
since December 2000. Between them, the studies investigated any
possible association between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic neuroma, tumors of
the brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects from
wireless phone RF exposures. However, none of the studies can answer
questions about long-term exposures, since the average period of phone
use in these studies was around three years.
5. What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of
people actually using wireless phones would provide some of the data
that are needed. Lifetime animal exposure studies could be completed in
a few years. However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if one exists.
Epidemiological studies can provide data that is directly applicable to
human populations, but 10 or more years’ follow-up may be needed
to provide answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a cancer-causing
agent and the time tumors develop - if they do - may be many, many
years.
109
108
109
108
SAFETY
The interpretation of epidemiological studies is hampered by difficulties
in measuring actual RF exposure during day-to-day use of wireless
phones. Many factors affect this measurement, such as the angle at
which the phone is held, or which model of phone is used.
6. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priority
animal studies are conducted to address important questions about the
effects of exposure to radiofrequency energy (RF).
FDA has been a leading participant in the World Health Organization
International Electromagnetic Fields (EMF) Project since its inception in
1996. An influential result of this work has been the development of a
detailed agenda of research needs that has driven the establishment of
new research programs around the world. The Project has also helped
develop a series of public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet Association (CTIA)
have a formal Cooperative Research and Development Agreement
(CRADA) to doresearch on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded research is
conducted through contracts to independent investigators. The initial
research will include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad assessment
of additional research needs in the context of the latest research
developments around the world.
SAFETY
7. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products--and at this point we do not
know that there is--it is probably very small. But if you are concerned
about avoiding even potential risks, you can take a few simple steps
to minimize your exposure to radiofrequency energy (RF). Since time
is a key factor in how much exposure a person receives, reducing the
amount of time spent using a wireless phone will reduce RF exposure.
• If you must conduct extended conversations by wireless phone every
day, you could place more distance between your body and the
source of the RF, since the exposure level drops off dramatically with
distance. For example, you could use a headset and carry the wireless
phone away from your body or use a wireless phone connected to a
remote antenna
Again, the scientific data do not demonstrate that wireless phones are
harmful. But if you are concerned about the RF exposure from these
products, you can use measures like those described above to reduce
your RF exposure from wireless phone use.
8. What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps to
lower exposure to radiofrequency energy (RF), the measures described
above would apply to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF exposure. Some
groups sponsored by other national governments have advised that
children be discouraged from using wireless phones at all.
111
110
111
110
SAFETY
For example, the government in the United Kingdom distributed leaflets
containing such a recommendation in December 2000. They noted that
no evidence exists that using a wireless phone causes brain tumors
or other ill effects. Their recommendation to limit wireless phone use
by children was strictly precautionary: it was not based on scientific
evidence that any health hazard exists.
9. Do hands-free kits for wireless phones reduce risks from
exposure to RF emissions?
Since there are no known risks from exposure to RF emissions from
wireless phones, there is no reason to believe that hands-free kits
reduce risks. Hands-free kits can be used with wireless phones for
convenience and comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source of the RF
emissions, will not be placed against the head. On the other hand, if the
phone is mounted against the waist or other part of the body during use,
then that part of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety requirements regardless
of whether they are used against the head or against the body. Either
configuration should result in compliance with the safety limit.
10. Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF emissions from
wirelessphones, there is no reason to believe that accessories that claim
to shield the head from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use special phone cases,
while others involve nothing more than a metallic accessory attached to
the phone.
SAFETY
Studies have shown that these products generally do not work as
advertised. Unlike “hand-free” kits, these so-called “shields” may
interfere with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an increase
in RF absorption. In February 2002, the Federal trade Commission
(FTC) charged two companies that sold devices that claimed to
protect wireless phone users from radiation with making false and
unsubstantiated claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
11. What about wireless phone interference with medical
equipment?
Radiofrequency energy (RF) from wireless phones can interact with
some electronic devices. For this reason, FDA helped develop a detailed
test method to measure electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless telephones. This test
method is now part of a standard sponsored by the Association for the
Advancement of Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and many other groups,
was completed in late 2000. This standard will allow manufacturers to
ensure that cardiac pacemakers and defibrillators are safe from wireless
phone EMI.
FDA has tested hearing aids for interference from handheld wireless
phones and helped develop a voluntary standard sponsored by the
Institute of Electrical and Electronic Engineers (IEEE). This standard
specifies test methods and performance requirements for hearing aids
and wireless phones so that that no interference occurs when a person
uses a “compatible” phone and a “compatible” hearing aid at the same
time. This standard was approved by the IEEE in 2000.
113
112
113
112
SAFETY
FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interference be
found to occur, FDA will conduct testing to assess the interference and
work to resolve the problem.
Updated July 29, 2003
For more information, please visit the FDA website at http://www.fda.
gov/cellphones.
EMERGENCY CALLS
Never rely solely upon your wireless phone for essential communications
(e.g., medical emergencies), if it can be avoided, since a wireless phone
requires a complex combination of radio signals, relay stations and
landline networks for its operation. Consequently, emergency calls
may not always be possible under all conditions on all wireless phone
systems. Your wireless phone, however, may sometimes be the only
available means of communication at the scene of an accident. When
making an emergency call, always give the recipient all necessary
information as accurately as possible. Never terminate an emergency
call until you have received clearance to do so.
FCC ENHANCED 911 (E911) RULES
Background
The Federal Communications Commission (FCC) requires wireless
carriers to transmit specific latitude and longitude location (Automatic
Location Identification = ALI) information as well as “911” calls to
Public Safety Answering Points (PSAPs) to identify the location of the
caller in case of emergency.
SAFETY
Generally, the rules require that carriers identify an E911 caller’s location
within 50 meters of the actual location for 67 percent of calls and within
150 meters of the actual location for 95 percent of calls. GTX-75’s ALI
Capability
The GTX-75 is an ALI-capable phone equipped with a GPS (Global
Positioning System) receiver supporting a satellite-based GPS ALI-
capable network to comply with the FCC’s ALI requirements.
The network compliance with the above FCC requirements is dependent
on: (a) the use of digital technology by the wireless network: (b) GPS
satellite signals being able to reach the handset (such transmissions do
not always work indoors, for example) : and (c) handset signals reaching
wireless “base stations” (atmospheric and environmental conditions
may cause variations in handset receiving signal strength).
Also the transmission of the ALI information is subject, in part, to system
constraints within the wireless network to which the E911 signal is
transmitted and over which UT Starcom has no control.
Finally, customers are advised that the GTX-75’s ALI capability is to be
used for E911 purposes only.
This feature allows you to place an emergency call even if your phone is
in “Phone Lock” or “Restrict” mode when you dial the preprogrammed
emergency number, 911, #911, or *911. It also operates in out-of-
service areas. The phone maintains the emergency mode until you
press the End Key after disconnecting an emergency call. In emergency
call mode, the phone can receive an incoming call from any available
system.
115
114
115
114
SAFETY
To call “911” in “Phone Lock” or “Restrict” mode.
1.
In Idle mode, tap
Call icon
, tap “1 Key”, “1 Key”, “9 Key”.
2.
Tap
Call
or Send Key. “911” and “Emergency” will appear on the
screen.
COMPLIANCE WITH OTHER FCC
REGULATIONS
OPERATING PROCEDURES
Never violate any of the following Rules and Regulations of the FCC
when using your Cellular Phone. Such violations are punishable by fine,
imprisonment or both.
• Never use obscene, indecent, or profane language.
• Never use your Cellular Phone to send false distress calls.
• Never wiretap or otherwise intercept a phone call, unless you have
first obtained the consent of the parties participating in the call.
• Never make any anonymous calls to annoy, harass, or molest other
people.
• Never charge another account without authorization, to avoid
payment for service.
• Never willfully or maliciously interfere with any other radio
communications.
• Never refuse to yield the line when informed that it is needed for an
Emergency Call. Also, never take over a line by stating falsely that it is
needed for an emergency.
SAFETY
GENERAL SAFETY
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of equipment.
Before operating, read all instructions and cautionary markings on the
product, battery and adapter/charger.
Failure to follow the directions below could result in serious bodily injury
and/or property damage due to battery liquid leakage, fire or rupture.
• DO NOT use or store this equipment in a place where it will be
exposed to high temperatures, such as near an open flame or
heat-emitting equipment.
• DO NOT drop your device or subject it to severe shock. When not
using, lay down the unit to avoid possible damage due to instability.
• DO NOT expose this equipment to rain or spilled beverages.
• DO NOT use unauthorized accessories.
• DO NOT disassemble the phone or its accessories. If service or repair
is required, return unit to an authorized UTStarcom cellular service
center. If unit is disassembled, the risk of electric shock or fire may
result.
117
116
117
116
SAFETY
ANTENNA
ANTENNA SAFETY
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could impair call
quality, damage the phone, or result in violation of FCC regulations.
Please contact your local dealer for replacement antenna.
Do not use the phone with a damaged antenna. If a damaged antenna
comes into contact with the skin, a minor burn may result. Please
contact your local dealer for replacement antenna.
BATTERY
BATTERY SAFETY
Your device uses a removable and rechargeable lithium ion battery.
Please contact customer service for assistance should you need a
replacement battery.
DO’s
• Only use the battery and charger approved by the manufacturer.
• Only use the battery for its original purpose.
• Try to keep batteries in a temperature between 41°F (5°C) and 95°F
(35°C).
• If the battery is stored in temperatures above or below the
recommended range, give it time to warm up or cool down before
using.
SAFETY
• Completely drain the battery before recharging. It may take one to
four days to completely drain.
• Store the discharged battery in a cool, dark, and dry place.
• Purchase a new battery when its operating time gradually decreases
after fully charging.
• Properly dispose of the battery according to local regulations.
DON’Ts
• Don’t attempt to disassemble the battery – it is a sealed unit with no
serviceable parts.
• Don’t expose the battery terminals to any other metal object (e.g., by
carrying it in your pocket or purse with other metallic objects such as
coins, clips and pens). This can short circuit and critically damage the
battery.
• Don’t leave the battery in hot or cold temps. Otherwise, it could
significantly reduce the capacity and lifetime of the battery.
• Don’t dispose of the battery into a fire.
Lithium ion batteries are recyclable. When you replace your built-in
battery, please request the repair center to recycle the battery in
accordance with RBRC standards. When disposing of the battery by
yourself, please call RBRC at (800) 822-8837 for proper disposal tips.
Never touch any fluid that might leak from the built-in battery. Such
liquid when in contact with the eyes or skin, could cause injury to the
skin or eyes. Should the liquid come into contact with the eyes, irrigate
the eyes thoroughly with clean water and immediately seek medical
attention. In the event the liquid comes into contact with the skin or
clothing, wash it away immediately with clean water.
119
118
119
118
SAFETY
ADAPTER/CHARGER
CHARGER
The charger designed by UTStarcom for this unit requires the use of a
standard 120 V AC power source for its operation.
• Never attempt to disassemble or repair a charger.
• Never use a charger if it has a damaged or worn power cord or plug.
Always contact a UTStarcom authorized service center, if repair or
replacement is required.
• Never alter the AC cord or plug on your charger. If the plug will not fit
into the available outlet, have a proper outlet installed by a qualified
electrician.
• Never allow any liquids or water to spill on the charger when it
is connected to an AC power source. Always use the authorized
UTStarcom charger to avoid any risk of bodily injury or damage to
your cellular phone or battery.
• Never attempt to connect or disconnect the charger with wet hands.
Always unplug the charger from the power source before attempting
any cleaning. Always use a soft cloth dampened with water to clean
the equipment, after it has been unplugged.
Handling the cord on this product or cords associated with accessories
sold with this product, will expose you to lead, a chemical known to the
State of California to cause birth defects or other reproductive harm.
Wash hands after handling. Always disconnect the charger from the
power source when it is not in use.
SAFETY
Handling the cord on this product or cords associated with accessories
sold with this product, will expose you to lead, a chemical known to the
State of California to cause birth defects or other reproductive harm.
Wash hands after handling. Always disconnect the charger from the
power source when it is not in use.
121
120
SAFETY
GAMES
SEIZURES/BLACKOUTS
Warning
A very small percentage of individuals may experience epileptic seizures
when exposed to certain light patterns or flashing lights. Exposure to
certain patterns or backgrounds on a computer screen, or while playing
video games, may induce an epileptic seizure in these individuals.
Certain conditions may induce previously undetected epileptic symptoms
even in persons who have no history of prior seizures or epilepsy.
If you, or anyone in your family, have an epileptic condition, consult
your physician prior to playing. If you experience any of the following
symptoms while playing a video or computer game -- dizziness, altered
vision, eye or muscle twitches, loss of awareness, disorientation, any
involuntary movement, or convulsions -- IMMEDIATELY discontinue use
and consult your physician before resuming play.
123
122
123
122
SAFETY
Repetitive Motion Injuries
When you play games on your phone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your
body. Follow these instructions to avoid problems such as tendonitis,
carpal tunnel syndrome, or other musculoskeletal disorders:
• Take a minimum 15-minute break every hour of game playing.
• If your hands, wrists, or arms become tired or sore while playing, stop
and rest for several hours before playing again.
• If you continue to have sore hands, wrists, or arms during or after play,
stop playing and see a doctor.
RECYCLE YOUR CELL PHONE!
Carriers marketing this cell phone have an in-store phone take-back
program. Consumers can drop off their used wireless devices to
specified carrier retail outlets for recycling purposes. For a list of carrier
members and collection sites, visit the cellular industry’s recycling
website www.recyclewirelessphones.com.
To mail in your old wireless device to UTStarcom Personal
Communications for recycling purposes, simply package your old
wireless device and any accessories (including discharged batteries) in
appropriate shipping materials and mail to: For Recycling UTStarcom
Personal Communications LLC 555 Wireless Blvd. Hauppauge, NY 11788
Wireless phones also can be donated to the Wireless Foundation’s
DONATE A PHONE® CALL TO PROTECT® campaign. This charitable cause
collects wireless phones to benefit victims of domestic violence. All
donated phones are tax deductible. You may mail the phone to: CALL TO
PROTECT, 2555 Bishop Circle, West Dexter, MI 48130.
SAFETY
-OR-
Drop the phone off at a local collection center. For a list of collection
centers, visit www.wirelessfoundation.org/CalltoProtect/dropoff.cfm
Before returning any wireless device for recycling purposes, please
remember to terminate your service on the device, clear the device of
any stored information and remove the device’s SIM card, if it has one
(please contact your wireless provider to find out if your device contains
a SIM card and for assistance on how to remove it).
FCC COMPLIANCE INFORMATION
This device complies with Part 15 of FCC Rules.Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
INFORMATION TO USER
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
125
124
125
124
SAFETY
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/ tv technician for help.
CAUTION:
The user who makes changes or modifications to the unit
without the express approval by the manufacturer will void
user authority to operate the equipment.
WARRANTY
MANUFACTURER’S WARRANTY
12 MONTH LIMITED WARRANTY
UTStarcom Personal Communications (the Company) warrants to the
original retail purchaser of this UTStarcom handheld portable cellular
telephone, that should this product or any part thereof during normal
consumer usage and conditions, be proven defective in material or
workmanship that results in product failure within the first twelve (12)
month period from the date of purchase, such defect(s) will be repaired
or replaced (with new or rebuilt parts) at the Company’s option, without
charge for parts or labor directly related to the defect(s).
The antenna, keypad, display, rechargeable battery and battery charger,
if included, are similarly warranted for twelve (12) months from date
of purchase. This Warranty extends only to consumers who purchase
the product in the United States or Canada and it is not transferable or
assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage:
(b) Product whose mechanical serial number or electronic serial number
has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive temperatures
or extreme environmental conditions:
(d) Damage resulting from connection to, or use of any accessory or
other product not approved or authorized by the Company:
(e) Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts:
127
126
127
126
WARRANTY
(f) Product damaged from external causes such as fire, flooding, dirt,
sand, weather conditions, battery leakage, blown fuse, theft or
improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the
product, for geographic coverage, for inadequate signal reception by the
antenna or for communications range or operation of the cellular system
as a whole. When sending your wireless device to UTStarcom Personal
Communications for repair or service, please note that any personal data
or software stored on the device may be inadvertently erased or altered.
Therefore, we strongly recommend you make a back up copy of all data
and software contained on your device before submitting it for repair
or service. This includes all contact lists, downloads (i.e. third-party
software applications, ringtones, games and graphics) and any other
data added to your device. In addition, if your wireless device utilizes a
SIM or Multimedia card, please remove the card before submitting the
device and store for later use when your device is returned, UTStarcom
Personal Communications is not responsible for and does not guarantee
restoration of any third-party software, personal information or memory
data contained in, stored on, or integrated with any wireless device,
whether under warranty or not, returned to UTStarcom Personal
Communications for repair or service.
To obtain repairs or replacement within the terms of this Warranty, the
product should be delivered with proof of Warranty coverage (e.g. dated
bill of sale), the consumer’s return address, daytime phone number and/
or fax number and complete description of the problem, transportation
prepaid, to the Company at the address shown below or to the place of
purchase for repair or replacement processing.
WARRANTY
In addition, for reference to an authorized Warranty station in your area,
you may telephone in the United States (800) 229-1235, and in Canada
(800) 465-9672 (in Ontario call 416-695-3060).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS
LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN
NO EVENT, SHALL THE COMPANY’S LAIBILITY EXCEED THE PURCHASE
PRICE PAID BY PURCHASER FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL
BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY
ACTION FOR BREACH OF ANY WARRANTY MUST BE BROUGHT WITHIN
A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL PURCHASE.
IN NO CASE SHALL THE COMPANY BE LIABLE FOR AN SPECIAL
CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS
OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER.
THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN RENDERING
SERVICE UNDER THIS WARRANTY OR LOSS OF USE DURING THE TIME
THE PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of
this product.
Some states or provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitation or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state or province to
province.
129
128
129
128
WARRANTY
IN USA: UTStarcom Personal Communications 555 Wireless Blvd.
Hauppauge, NY 11788 (800) 229-1235
IN CANADA: UTStarcom Canada Company 5535 Eglinton Avenue West
Suite# 234 Toronto, ON M9C 5K5 (800) 465-9672
