UTT TECHNOLOGIES REG03-UTT Wireless Router User Manual
SHANGHAI UTT TECHNOLOGIES CO., LTD. Wireless Router Users Manual
Users Manual
![](/img.php?id=2416146&img=bg1.png)
DATA SHEET
1
www.utt
g
lobal.com
A
C650W 750Mbps Intelligent
Dual-band Wireless Router
Highlights
-802.11ac/a/b/g/n, 750Mbps Wireless Speed
-3 x 5dBi antennas, 100 Meters Wireless Coverage
-2.4GHz band and 5GHz band
-WiFi Auto On/Off
-USB Cloud Storage
-Flexible bandwidth management to improve network performance
-Extremely friendly and straightforward Web UI
Overview
AC650W Intelligent Dual-band Wireless Router is a purpose-built solution designed for
SOHO enterprises, offices and household.
AC650W adopts 580MHz MTK CPU and equips 3 fixed 5dBi omni-antennas. It supports
802.11ac WiFi standard and is compatible with 802.11a/b/g/n. Moreover, it works on
2.4GHz band and 5 GHz band, minimizing interference among wireless networks. It
supports MIMO technology, which enables its wireless transmission rate up to 750Mbps.
With UTT self-developed operating system ReOS SE, AC650W support easy
management, which will guide users to finish the initial configuration one step by one step
automatically. Even users without network knowledge can get connected to Internet easily.
It can speed up online games by smart algorithm built in. It supports WDS to extend the
coverage of wireless network. It supports WiFi Auto On/Off to switch on and off WiFi at the
setting time. It supports parental control, which enables the parents to control the Internet
access right for children, preventing children getting addicted to Internet. It supports smart
QoS, which automatically allocates reasonable bandwidth for wireless stations, making
sure users can download movies and play video games at the same time. It also supports
files sharing by one USB port.
![](/img.php?id=2416146&img=bg2.png)
DATA SHEET
2
www.utt
g
lobal.com
Features
Wireless Speed
The maximum wireless transmission
speed can be up to 750Mbps. Large-scale
of wireless coverage and steady wireless
data transmission will meet user’s high
bandwidth demands for HDTV, streaming
media, games, video chat, wireless
monitoring and high-speed data
transmission.
Compatibility
Support IEEE 802.11ac, IEEE 802.11a,
IEEE 802.11b, IEEE 802.11g, IEEE
802.11n. The multi-protocol compatibility
promotes the capability for connecting to
other wireless products.
Wireless Mode
Offer multiple wireless operating modes:
AP, Wireless Repeater, Bridge and AP
Client, which can meet the demands of
different network to expand the wireless
network to a certain extent.
Wireless Security
Offer multiple wireless securities: WEP,
WPA-Enterprise, WPA2-Enterprise,
WPA-PSK and WPA2-PSK. Wireless
MAC address filtering provides customers
with comprehensive protection for wireless
transmission to keep your network far
away from intrusions and attacks.
WiFi Auto On/Off
AC650W offers a WiFi timer inside which
can automatically enable and disable WiFi
according to user’s configuration. It is
suggested to disable WiFi in night and
working time, it will greatly save the
electricity and reduce radiation.
USB Cloud Storage
Offers a USB 2.0 interface for external
storage. It also supports Samba Share
service locally and remotely. Once the
remote share function is enabled, USB
Flash disk or Harddisk can be used as a
Cloud Storage to save important
document anytime anywhere.
Flexible Bandwidth
This very unique function named Flexible
Bandwidth will largely optimize the
bandwidth utilization. And it only needs 2
steps: enable this function and set the
bandwidth for each Internet connection.
Flexible Bandwidth will guarantee the
webpage browse and essential network
applications.
1. Adjust the bandwidth for users and
applications flexibly, improve the
real-time network performance, and
recognize different application
accurately.
2. Supports priority queues to ensure
smooth transmission of applications
which require large bandwidth.
3. Improved network performance will
solve network congestion and
unreasonable bandwidth allocation.
Reasonable network traffic distribution,
optimized bandwidth utilization, stable,
fast, safe and efficient network
environment
![](/img.php?id=2416146&img=bg3.png)
DATA SHEET
3
www.utt
g
lobal.com
Internet Access Control
Provide personalized Internet access
control, which can meet all the needs of
users. Each host can take a different
access policy, including blocking IM
software (Yahoo messenger, MSN etc.),
blocking P2P software (Bit commit, Bit
torrent, etc.), blocking online games
(WOW.), blocking Face book and Twitter,
blocking online videos (YouTube) and
other abundant functions.
Support Domain name Filtering. Users can
either block websites or only allow
websites. Domain name filtering will make
the network management easy and
convenient.
Support IP/MAC address binding, invalid
IP address or MAC address filtering and
easy blacklist and Whitelist setting. UTT
router supports binding all the dynamic
IP/MAC entries with only one-click
operation.
Parental Control
Support parental control. Parents can set
websites and applications children can
access at specific time. It is helpful to
prevent children from accessing unhealthy
web pages or getting addicted to Internet.
Configuration and Management
Offer user-friendly Web interface which
delivers an easy-to-use platform with rich
functions. It supports easy management,
which will guide users to finish the initial
configuration one step by one step
automatically. Even users without network
knowledge can get connected to Internet
easily.
Offer System Status, Wireless Host List
and Flow Statistics, which deliver a
convenient platform to trap and remove
network faults.
Key Features
◆Support static IP, DHCP and PPPoE connection
◆Support DSL, FTTX+LAN and Cable Modem Internet access
◆4 10M/100M LAN ports, 1 10M/100M WAN ports
◆1USB2.0tosharefiles
◆Three 5 dBi Antennas support MIMO
◆Support IEEE 802.11ac, IEEE 802.11a,IEEE 802.11b, IEEE 802.11g and IEEE
802.11n wireless speed up to 750Mbps
◆Work on 2.4GHz band and 5GHz band
◆Support multiple wireless operating modes: Access Point, Wireless Repeater, Bridge
and AP Client
◆WEP, WPA-Enterprise, WPA2-Enterprise, WPA-PSK and WPA2-PSK
◆Support SSID Broadcast Control and hiding
◆Support WiFi Auto On/Off
![](/img.php?id=2416146&img=bg4.png)
DATA SHEET
4
www.utt
g
lobal.com
Specification Description
◆Support parental control
◆Support WMM (Wi-Fi Multimedia, Wireless Multimedia) function
◆Wireless MAC address filter, Whitelist, blacklist, one-click filtering of wireless address
◆SupportNAT,NAPT,DMZ
◆Support DDNS(No-IP,DYNDNS)
◆Support UPnP
◆Support USB Cloud Storage
◆Support DHCP Server, DHCP Client and DHCP static binding
◆Support Web Authentication
◆Support IP/MAC binding
◆Support fixed rate limiting
◆Support flexible bandwidth control, speeding up common online games
◆Support built-in firewall, defense against ARP spoofing, Port scanning, DDoS/DoS
attack
◆Support packet filtering based on IP address, protocol. port
◆Support filtering on URL, key words and DNS on application layer
◆Support limitation on maximum NAT sessions
◆Support Notification
◆Support Internet Application Audit
◆Support Internet access control, security management and network maintenance
◆Support static routing
◆Support VPN pass-through
◆Web user interface and Quick Wizard
◆System update through HTTP
◆Configuration file backup and restore
◆Display of wireless host status and system status
◆Support SNTP
![](/img.php?id=2416146&img=bg5.png)
DATA SHEET
5
www.utt
g
lobal.com
Port
LAN 4 RJ45 ports(Auto-Negotiation, auto MDI/MDIX)
WAN 1 RJ45 port(Auto-Negotiation, auto MDI/MDIX)
USB 2.0 1
CPU 580MHz
Antennas 3*5dBi
Button Reset, Power
LED
Power light: PWR
Wireless light: WLAN
Link/Act: WAN/LAN
Dimensions (H x W x D): 192mm*130mm*26mm
Weight: 0.25 kg
Temperature: -20~55 Degree Celsius
Altitude: 0 ~ 4000 m
Relative humidity: 10~90%, non-condensing
Power Input: 6W
Voltage: FJ-SW1201000DC 、100-240V~50/60Hz 0.6Amax 、12V
1000mA
Protocols and Standards: IP, TCP, ARP, UDP, ICMP, NAT, DHCP, SNTP, TELNET,
HTTP, PPP, SNMP, PPPoE, PAP, CHAP,
Physical Specifications: Each port supports Auto-Negotiation, auto MDI/MDIX and
provides status LEDs.
Routing Protocols: Static routing
User Interface: Web GUI
Attention:This device complies with Part 15 of the FCC Rules . Operation is subject
to the following two conditions :(1) This device may not cause harmful interference,and (2)
this device must accept any interference received ,including interference that may cause
undesired operation.
Copyright ©2000-2014, Shanghai UTT Technologies Co., Ltd.
All rights reserved.
UTT®HiPER®NE®are registered trademarks of Shanghai UTT Technologies Co., Ltd.
Other trademarks and registered trademarks of products mentioned in this publication may be the
properties of their respective owners and are only used for identification purposes.
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
