AX-90B

APEX Series AX-90 Professional Keyboard Stand with Quad Pod Base, Fully-adjustable Arms, and Automotive-quality Paint Finish

Quad Pod Base

Our patented Quad Pod technology delivers an

enhanced center of gravity, is tip resistant, and

in general, more stable than traditional column

keyboard stands. To add further stability, the legs are

made from super strong 6000 series aluminum and

they lock into place.

Sleek, New Design

The AX-90 is the ﬁnest looking keyboard stand on the

market. The modern look and shape of it is intended

to bring the keyboard into the spotlight. Plus, the

automotive-quality paint ﬁnish is ultra durable, will

stay looking new longer than other keyboard stands,

and is available in six hot colors.

Fully-adjustable Arms

As the only column stand with complete ergonomic

adjustment, the AX-90 was designed for the modern

keyboard player. Both sets of arms are completely

height, depth, and angle adjustable.

Simple Setup and Tear Down

The AX-90 sets up and tears down in seconds. The

arms and legs store safely inside the AX-90 column

when not in use (so you’ll never have to worry about

losing parts again), and lock into place with very little

effort. The tiers also feature memory positions, so

your keyboards will be exactly where you want them

to be - gig after gig.

Product Sheet

AX-90B

• AX-90B#16761,blackpearl

• Setupheight52”(1321mm)

• Tierheightrange19.25”-47.25”

 (449mm-1200mm)

• Tierdepthrange17.75”-23.75”

 (451mm-603mm)

• Tierangleadjustabilityrangehorizontal,

 6°,and12°up-6°,12°,18°,and24°down

• Weight39lbs.(17.7kg)

• Foldedlength59”(1499mm)

• Basediameter36.5”(927mm)

• Loadcapacityupto150lbs.(68kg)pertier

or300lbs.(136kg)total

AX-90 Tote Bag Included for FREE!

5836 Wright Drive • Loveland, CO 80538 • Phone. 1-800-525-5628 • Fax. 970.776.1941 • Web. w w w.ultimatesuppor t.com

AX-90B SPECS

R. 3, 09/07/09, 1S-ULT-AX-90W

Quad Pod legs

lock into place

and deliver

superior stability

Arms and legs

store safely inside

the column when

not in use

Arms are height,

depth, and angle

adjustable

Cable Channel

keeps cables from

getting into the way

of your performance

• Reinforcedhandlesandshoulderstrap

• Built-inmicboomaccessorypocket

• 600Dpolyexteriorconstruction

• 20mmdensityfoaminterior

• Heavy-duty#8zippers

AX-90BL

AX-90OR

5836 Wright Drive • Loveland, CO 80538 • Phone. 1-800-525-5628 • Fax. 970.776.1941 • Web. w w w.ultimatesuppor t.com

Product Sheet

APEX-Series

APEX- SERIES

The APEX Series Keyboard Stands represent over two decades of research and development and are used all over the world by gigging keyboard players

and touring musicians. The AX-90 and AX-48 Pro offer everything keyboard players loved about the original APEX keyboard stand while offering sleek new

designsandupdatedfeaturesthatsupportawholenewgenerationofkeyboardsandworkstations.TheAPEXSeriesisthenestlookingkeyboardstandson

themarket,andareintendedtoshinethespotlightonkeyboardplayers,whilesecurelysupportingtheirprizedinstruments.

AX-90B

AX-90W
