Unication Co AP91-O01 Alphanumeric Pager User Manual
Unication Co Ltd Alphanumeric Pager
User Manual
![](/img.php?id=141922&img=bg1.png)
USER
MANUAL
Alphanumeric Pager
AP-91
CONTENTS
(1) Features 1
1-1 Front Side 1
Key Functions Table 1
1-2 Back Side 2
(2) Icons Description 3
2-1 Icons Location 3
2-2 Icons Explanation 4
(3) Function Setting 5
3 1 Power On/Off 5
![](/img.php?id=141922&img=bg2.png)
CONTENTS
3-9 Hour Alarm On/Off 12
3-10 Reminder On/Off 12
3-11 Stop Watch 13
3-12 Game 13
(4)Messages 14
4-1 Read messages 14
4-2 Messages setting 15
4-2-1 Lock On 15
4-2-2 Delete 15
4-2-3 MSG Alarm On/Off 16
4-2-4 Move to PF(Personal File) 16
![](/img.php?id=141922&img=bg3.png)
(1)Features
1-1.FRONT SIDE
Screen
Read/Set/
Power on Option menu/
Cancel/Lighter
Forward/
Add numeric
Backward/
Next
!!!"#$%&&
'()*%&&
'+,%
$#
-&./&0
;Key Functions Table
Each key has different function in each
KEY FUNCTION
MENU
OPTION
MENU
SETTING
MENU
∈read enter confirm
function cancel cancel
no backward Change
b
no forward next
∈Stand for
Stand for
Stand for
Remark:
Stand for
- 1 -
![](/img.php?id=141922&img=bg4.png)
1-2. BACK SIDE
Battery Door
;Battery safety
1. Use 3A 1.5V,alkaline battery.
2. Move the door away, replace a
new battery in battery.
3. Power off pager before changing.
4. Ensure the polarity of the battery
is correct.
- 2 -
(2)Icon description
2-1. Icon Location
WED 06/09/99
13 00
12 3 4 5 6 7 8 9 10 11 12
15
14
13
![](/img.php?id=141922&img=bg5.png)
2-2. Icons Explanation
1. Power on.
2. Auto on.
Auto off.
3. Out of range.
4. Vibrate mode.
Beep or melody mode.
No icon means no alert
5. OFF : power off
6. Low Battery
7. Message(s) locked.
- 3 -
8. message(s) alarm.
Maximum: 3 messages
9. Time of next alarm or count down.
press any key to stop alert.
10.Unread message.
11.Duplicate message.
12.Continuing message(Next Page)
13.Week:SUN MON TUE WEN
THR FRI SAT
14.Date:MM/DD/YY
15 Time:Hour/Minute
![](/img.php?id=141922&img=bg6.png)
- 4 -
(3)Functions Setting
WED 09/15/99 09:35
NEW:00
MAIL 00
MSG:00
Press to enter/select function menu.
1. POWER OFF
2. ALERT MODE
3. TONE MODE
4. ALARM SETTING
5. AUTO ON/OFF
6. DELETE ALL
7. DATE & TIME
8. PASSWORD
9. HOUR ALARM OFF
10. REMINDER OFF
11. STOP WATCH
12. GAME
3-1.Power on/off
3-1-1.Power off
Press to select power off
POWER OFF ?
YES
Press ∈ to confirm
3-1-2. Power on: Press ∈ for 2 seconds
-5 -
![](/img.php?id=141922&img=bg7.png)
3-2. Alert Mode
ALERT MODE
1. NO ALERT
2. VIBRATOR
3. TONE
Press or to select a mode
Press ∈ to enter
3-3. Tone Mode
1. POWER OFF
2. ALERT MODE
3. TONE MODE
4. ALARM SETTING
Press or to select TONE MODE;
Press ∈ to enter
TONE MODE
1. BEEP
2. MELODY
3-3-1. Beep
Press or to select BEEP;
Press ∈ to confirm
1 2 3 4 5 6 7
BEEP
Press or to select one;
Press ∈ to confirm
- 6 -
3-3-2. Melody
Press or to select MELODY;
Press ∈ to enter
1 2 3 4 5 6 7
MELOD
![](/img.php?id=141922&img=bg8.png)
Press or to select one;
Press ∈ to confirm
3-4. Alarm Setting
Press or to select ALARM SETTING;
Press ∈ to enter
1. DAILY ALARM
2. SPECIAL DATE
3. DOWN COUNTER
4. ALARM REPEAT ON
3-4-1. Daily Alarm
Press or to select DAILY ALARM;
Press ∈ to enter
DAILY ALARM
1. OFF 00 : 00
2. OFF 00 : 00
Press to input number;
Press to move;
Press ∈ to confirm
Maximun:2 alarms
- 7 -
3-4-2 Special Date
Press to select SPECIAL DATE;
Press ∈ to enter
SPECIAL DATE
1. OFF 01/01 00 : 00
2. OFF 01/01 00 : 00
3. OFF 01/01 00 : 00
Press to input number
Press to move,press ∈ to confirm
Maximun:3 alarms
4-3 Down Counter
Press to select DOWN COUNTER;
Press ∈ to enter
DOWN
00 MINUTES
COUNTER
![](/img.php?id=141922&img=bg9.png)
Press to input number;
Maximum:60 minutes.
3-4-4 Alarm Repeat On
Press to select on/off;
Press ∈ to confirm
ALARM REPEAT
ON
OFF
- 8 -
.Alarm repeats every 5 minutes and
continuing for 30 minutes.
3-5. Auto on/off
Press or to select DAILY ALARM;
Press ∈ to enter
AUTO ON/OFF
DISABLE
ON TIME 00:00
OFF TIME 00:00
Press to input number;
Press to move;
Press ∈ to confirm
3-6.Delete All
Press or to select DELETE ALL;
Press ∈ to enter
1. GENERAL MESSAGE
2. MAIL DROP 1
3. MAIL DROP 2
4. MAIL DROP 3
Press or to select;
Press ∈ to confirm
![](/img.php?id=141922&img=bga.png)
- 9 -
;The locked messages have to be
unlocked before delete.
3-7. Date & Time
Press or to select DATE & TIME;
Press ∈ to enter
DATE & TIME
WED 15/09/99 00:33
Press to move;
Press to input date & hour;
Press ∈ to enter
3-8. Password
Press or to select PASSWORD;
Press ∈ to enter
PASSWOR
ON
OFF
Press to select on/off Press ∈ to confirm
- 10 -
3-8-1. Setting Password
NEW PASSWORD
ENTER: *•* *
![](/img.php?id=141922&img=bgb.png)
Press keys total 4 times to set up password
PASSWORD VERIFY
ENTER: * * *
Input again to verify.
;The fourth * is not displayed
3-8-2. Changing Password
①Press or to select PASSWORD:
②Press ∈ to enter
③Enter the former password,
④Press to select on;
⑤Enter new password and enter again
to verify.
- 11 -
3-8-3 Cancel Password
①Press or to select PASSWORD:
②Press ∈ to enter
③Enter the former password,
④Press to select on;
⑤Press ∈ to confirm
3-9. Hour Alarm On/Off
Press or to select HOUR ALARM
ON/OFF;
Press ∈ to enter
HOUR INDICATOR
ON
OFF
![](/img.php?id=141922&img=bgc.png)
Press to select on;
Press ∈ to confirm
3-10. REMINDER ON/OFF
Press or to select REMINDER ON/OFF;
Press ∈ to enter
REMINDER
ON
OFF
- 12 -
Press to select on;
Press ∈ to confirm
;Reminder ON alerts for un-read
messages every 3 minutes and
continue for 10 times.
3-11.Stop Watch
Press or to select STOP WATCH;
Press ∈ to enter
STOP WATCH
00:00
Press or to start;
Press or again to stop
Press ∈ to back start.
12. GAME
Press or to select GAME;
Press ∈ to enter
INPUT NO. : 0000
ANSWER : 0A 0B
Press to move;
Press to input number;
Press ∈to check result.
![](/img.php?id=141922&img=bgd.png)
- 13 -
(4)MESSAGES
4-1. Read Message
Press ∈ to enter MESSAGE menu;
1. GENERAL MESSAGE
2. MAIL DROP 1
3. MAIL DROP 2
4. MAIL DROP 3
5. PERSONAL FILE
Press or to select mail boxes
(Mail boxes includes: general
message, mail drop and Personal file);
Press ∈ to enter
02 09/16/99 14:30
]2⊥22999678
Press or to select message;
Press ∈ to read
- 14 -
4-2. Message Setting
![](/img.php?id=141922&img=bge.png)
Pree to enter function menu.
1.LOCK ON
2.DELETE
3.MSG ALARM ON
4.MOVE TO
4-2-1. Lock On/Off
Press or to select LOCK ON;
Press ∈ to confirm
Maximum capacity:8 messages
4-2-2. Delete
Press or to select DELETE;
Press ∈ to enter;
Press or to select YES/NO;
Press ∈ to confirm
*PS.
Delete Mail Drop Message:
Message will be deleted automatically
After capacity is full
Maximum capacity:4 messages
- 15 -
4-2-3. MSG Alarm On/Off
Press to select MSG ALARM ON;
Press ∈ to enter
SET MESSAGE ALARM
ON 09/17 18:00
Press to select on/off and input number;
Press to move;
Press ∈ to enter
![](/img.php?id=141922&img=bgf.png)
NOTE: THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND
(2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE AECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
NOTICE:THE CHANGES OR MODIFICATIONS NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD
VOID THE USER’S AUTHORITY TO OPERATION THE EQUIPMENT.
02 09/16/99 14:00
[2]22999678
4-2-4. Move to PF
Press or to select Move To PF;
Press ∈ to enter
MOVE TO
YES
NO
Press ∈ to confirm
- 16-
