Specifications
Interface:
RJ-45 Jacks with Auto MDI/MDIX crossover
Standard Compliance:
IEEE 802.11g Wireless Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
ANSI/IEEE Standard 802.3 N-Way Auto-negotiation
Protocol:
CSMA/CA with ACK
Management:
Web-based
Data Rate:
Up to 54Mbps
Max Forwarding Rate:
14,880 pps Ethernet port
Max Filtering Rate:
148,800 pps per Fast Ethernet port
LED Indicators:
Per Port: Link/Activity for WLAN and WAN
Per Unit: Power, Status
Network Cables:
Category 5/5e/6 UTP Cables for 100Base-TX (up to 100m)
Dimensions:
147mm (W) x 115mm (H) x 35mm (D)
Enclosure:
Plastic
Antenna:
Dual diversity antennas with one internal
printed antenna and one external detachable/ upgradeable 2
dB Gain dipole antenna
Range Coverage:
Indoor: Up to 50 meters)
Outdoor: Up to 200 meters
Operating Temperature:
0˚C to 40˚C (32˚F to 104˚F)
Operating Humidity:
0% to 95% (Non-condensing)
Power Supply:
External power adapter 5V DC / 2.5A
EMI:
FCC Class B, CE Mark
Safety:
cUL, UL
Warranty:
Lifetime Warranty
Software Features:
908 Canada Court
City of Industry, CA 91748 U.S.A.
Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880
www.unicomlink.com e-mail: info@unicomlink.com
©UNICOM 2007. UNICOM is a trademark of UNICOM Electric, Inc. All rights reserved.
Specifications subject to change without notice.
082507 UNILT0005WP
PART NUMBER DESCRIPTION
802.11g Wireless Router
with 4 Port Fast Ethernet Switch
WEP-72104G-1 802.11g Wireless Router
with 4 Port Fast Ethernet Switch
• Management: Web Based Management
• Frequencies: 2.412GHz ~ 2.4835GHz
• IP Management: TCP/IP, NAT, PPPoE/PPTP,
HTTP, DHCP Server/Client
• Number of Selectable Channels: USA & Canada,
11 channels; Europe, 13 channels;
Japan, 14 channels
• Protocols: TCP, UDP
• Filtering: MAC address filtering,Protocol filtering
• Routing: DMZ and VPN Support
• Firewall: WPA, WPA-PSK
• Security: 64/128Bit WEP
• Virtual Server: Up to 24 nodes
• VPN PassThrough: PPTP, IPSec
