User Manual
GMR4055-2CK, GMR4055-2CKHS
GMR4060-2CK, GMR4060-2CKHS
9B
2
13
9A
8
7
6
5
4
3
11
23
10
24
12
14 18
19 22
25
26
27
English
• 15 GMRS / 7 FRS Channels
• 7 Weather Channels
• 121 Privacy Codes
• Internal VOX Circuitry
• Up to 40 Mile Range*
• Backlit LCD Display
• Headset Jack
• 10 Selectable Call Tone Alerts
• 2 VOX earbuds
(GMR4055-2CKHS and
GMR4060-2CKHS)
• Power Boost PTT
• Roger Beep
• 2 Belt Clips
• Battery Charging Cradle
• Battery Level Meter
• 3 AA NiMH batteries per
radio (GMR4055)
• Lithium Ion battery pack
(GMR4060)
• 10 Hours Battery Life
• MicroUSB Charging Port
• Channel Monitor
• Channel Scan
• Vibrate
• NOAA Emergency /
Weather Channels with
ALERT
• Emergency Strobe
• Weather Resistant (JIS4)
1 Antenna 16 tx - Transmitting
2 MicroUSB port and
earbud jack
17 Vibe - Silent mode on
3 Push to Talk (PTT) 18 - Key Lock
4 Boost 19 call - Transmitting
5 Microphone 20 boost - Change transmis-
sion power from 1.0W
to 2.5W.
6 Channel Up/Down 21 vol - Volume level
selected.
7 Weather/Monitor 22 vox - VOX is on.
8 Speaker 23 scan - channel scan
feature on.
9 9A - Flashlight LED
9B - Flashlight button
24 Channel Number
10 Screen 25 hi/lo - transmitting in hi
power (1W) or low power
(0.5W)
11 MENU/Power 26 Privacy Code
12 Volume Up/Down 27 Weather Channel active
Weather Channel alert
13 Call/Lock 28 miniUSB port
14 rx - Receiving 29 Charging Contacts
15 - Battery Status 30 Charging LEDs
PACKAGE CONTENTS
Your package contains two radios, 6 AA rechargeable NiMH
batteries (GMR4055 models) or 2 Li-Ion battery packs
(GMR4060 models), one charging cradle, one AC adapter
with single miniUSB connector cable, two belt clips, and this
reference guide. The GMR4055-2CKHS and GMR4060-2CKHS
also include two VOX earbuds. To order Uniden accessories, visit
our web site at www.uniden.com or call 1-800-554-3988 during
regular business hours. Use only Uniden accessories (AC adapter
with microUSB plug).
GMRS LICENSE
The radio operates on the General Mobile Radio Service (GMRS)
frequencies when using Channels 1-7 and channels 15-22. You
must have a GMRS license issued by the Federal
Communications Commission to legally use these channels. For
licensing information and application forms, visit the FCC online at:
www.fcc.gov/wtb/uls or call the FCC hotline at 1-800-418-3676. If
you have any questions, you can contact the FCC direct at 1-888-
225-5322. No license is required for operation on channels 8-14
or operation on any channel in Canada.
INSTALL THE BATTERY
GMR4055 models use NiMH AA rechargeable batteries (included)
or 3 AA alkaline non-rechargeable batteries (not included).
GMR4060 models use Lithium Ion battery packs.
To install the batteries/battery pack:
1. Unscrew and remove the battery compartment cover.
2. Install the batteries/battery pack into the battery compartment. Be
certain to follow the instructions written on the label on the battery
pack. Installing the batteries/battery pack incorrectly will prevent
the unit from operating.
3. Replace and screw in the battery compartment cover.
BATTERY LEVEL AND
LOW BATTERY ALERT
This unit has a battery level meter on the display to indicate the
status of the batteries. When the battery in the unit is low, the
battery level meter icon flashes. Recharge the batteries/
battery pack immediately. If you are using alkaline batteries
(GMR4055 models only), you must replace the alkaline batteries in
order to continue using the radio.
CHARGING THE RADIO
If using rechargeable batteries/battery packs, two radios can be
charged directly by using the supplied charging cradle. A single
radio can charge using the miniUSB port to connect to a USB
power source. For fastest charging, turn off the radio before
charging.
Warning! To avoid the risk of personal injury or property damage
from fire or electrical shock, only use the Uniden accessories
specifically designated for this product.
Warning! Do not attempt to recharge Alkaline batteries
(GMR4055 models only).
Using the miniUSB Port
1. Connect the included AC adapter with miniUSB connector cable
to the radio's miniUSB port. Connect the other end to an outlet
that provides USB charging power (NOT to a USB hub).
2. Charge the batteries/battery pack for 16 hours until the battery
indicator stops flashing.
Using the Charging Cradle
1. Connect the included AC adapter with USB connector cable to the
charging cradle's miniUSB port. Connect the other end to a
standard 120V AC wall outlet.
2. Set the charging cradle on the desk or tabletop, and place the
radio in the charging cradle with the keypad facing forward.
3. Make sure that the LED illuminates. Charge the battery pack for
16 hours and remove the radio from the charging cradle after the
charging cradle LEDs turn off.
Note:
• Use only the supplied battery and AC adapter or approved
accessories from Uniden.
• Charge time may vary depending on the battery life remaining.
• Do not attempt to recharge alkaline batteries (GMR4055 models
only). Doing so can create a safety hazard or damage the radio.
• The battery must be installed for the unit to operate, even if the unit
is also connected to external power.
• If battery power is low, you cannot operate the radio even using
external power. Allow the batteries to charge before using. If you try
to transmit while power is low, the radio will automatically turn off.
USING EARBUDS
GMR4055-2CKHS and GMR4060-2CKHS come with VOX
earbuds. You can use earbuds for more private communications.
To use the earbud, lift the rubber cover from over the headset jack,
then plug in the earbud.
Important: Your radio is not weather resistant when using
earbuds. After removing an earbud, be sure to fully press the jack
cover into place to restore its weather resistant capability
USING THE RADIO
Turning the Radio On and Adjusting the Volume
1. Press and hold MENU/ to turn the radio ON. Iincrease the
speaker volume by pressing VOL ▲. To decrease the volume,
press VOL ▼.
2. Press and hold MENU/ again to turn the radio OFF.
Adjusting the Sound (Key Beeps)
Your radio emits a beep each time one of the keys
(except for the
PTT and CALL/LOCK) is pressed.
To turn this sound OFF, press
and hold CALL/LOCK while turning ON the radio. Repeat to turn
the sound back ON.
Choosing a Channel
Your radio has 22 channels and 121 Privacy codes you can use to
talk to others. In order to speak to someone, each of you must be
set to the same channel and Privacy code.
With the radio in "Normal" operating mode, press the CH ▲/CH ▼
key to increase or decrease the channel number displayed.
Note: Channels 1-7 have a typical range of up to 40 miles.
Channels 8-14 have a typical maximum range of up to 5 miles.
Channels 15-22 have a typical range of up to 40 miles. You can
see which GMRS or FRS channel is active by the icon. The hi
icon is displayed while on GMRS channels, and the lo icon is
displayed while on FRS channels.
Talking on Your Radio
To talk to others using the radio:
1. Press and hold the PTT button and speak in a clear, normal voice
about 2-3 inches away from the microphone. While you are
transmitting, the icon appears on the display. To avoid cutting
off the first part of your transmission, pause slightly after pressing
the PTT button before you start talking.
2. When you have finished speaking, release the PTT button. You
can now receive incoming calls. While receiving, displays.
Monitor Mode Feature
Your radio allows you to listen for weak signals on the current
channel at the press of a key.
To turn ON Monitor mode:
Press and hold WX/MON for 2 seconds until two beeps sound.
The receiver circuit stays open, and both noise and weak signals
can be heard. The icon stops blinking and disappears.
To turn OFF Monitor mode:
Press and hold WX/MON for 2 seconds to return to "Normal"
mode; two beeps sound and the icon stops blinking and
disappears.
Advanced Functions (Menus)
Use MENU/ to access your radio's advanced functions.
Normal Sub Code Scan Silent VOX
Level
Call
Tone
WX
Alert Normal
OFF, 1-121 ON/OFF ON/OFF OFF,
1-5
1-10 ON/OFF
1. Press MENU/ to enter the menus.
2. Additional presses of MENU/ advance you through the menus
until exiting to "Normal" operating mode (a double beep sounds).
You can also press any key except
CH ▲
/
CH ▼
or
VOL ▲/
VOL ▼
or tap PTT to exit Menu mode.
Privacy Code
Each of the channels 1-22 may have a Privacy code (oF or 1-121)
selected. Code oF (OFF) indicates no Privacy code selected and
your radio can receive a signal regardless of the code settings of
the transmitting radio.
1. Press MENU/ to enter Menu mode. The Privacy code
indicator flashes.
2. Press
CH ▲
/
CH ▼
key to increase or decrease the Privacy
code number displayed. You can also select oF (OFF) at this
stage.
3. Press MENU/ to exit Menu mode.
4. Press any key other than
CH ▲
/
CH ▼
or
VOL ▲/VOL ▼
or
press PTT and the radio returns to Idle mode in 10 seconds.
Scan
Your radio has a channel scan feature that allows you to easily
scan all 22 channels. When an active channel is detected, the
radio pauses on that channel until the channel is clear. Then, after
a 2 second delay, the radio continues scanning. Pressing the PTT
button while the scan is paused on a channel allows you to
transmit on that channel.
To turn ON channel scan:
1. Press MENU/ repeatedly until the scan... icon and oF blink.
2. Press
CH ▲
/
CH ▼ t
o select Scan mode and press MENU/
to start it.
To turn OFF channel scan:
1. Press MENU/ with the scan setting of oF.
2. Press any key other than CH ▲ / CH ▼, VOL ▲/VOL ▼,
or Flashlight to turn channel scan off in 10 seconds.
Voice Operated Transmission
Your radio is equipped with a user selectable Voice Operated
Transmitter (VOX) that can be used for automatic voice
transmissions. The VOX feature is designed to be used with a
headset with a microphone. Transmission is initiated by speaking
into the microphone instead of pressing PTT.
To select VOX level:
1. Press MENU/ repeatedly until the vox icon and the VOX
sensitivity level
(
oF
,
1-5
) blink
.
2. Press
CH ▲
/
CH ▼
to change the VOX sensitivity levels. Use
level 1 to increase
sensitivity to voice in normally quiet
environments
, and use a higher level to reduce undesired
activation in very noisy environments.
Call Tone
Your radio is equipped with 10 selectable call tones that are
transmitted when CALL/LOCK is pressed.
To select a call tone:
1. Press MENU/ repeatedly until the CALL icon and Call Tone
start to blink on the display.
2. Press
CH ▲
/
CH ▲
to move through the available call tones.
Each tone will be heard through the speaker but will not be
transmitted. Cycle through these tones and stay on the tone you
want to select.
3. Exit Call Tone to set the selected tone.
Setting Silent Mode
When you turn on Silent mode, all incoming calls are muted; if you
receive a call, the unit vibrates and the backlight flashes. If you do
not respond to the call within 15 seconds, the backlight turns off.
The radio will also vibrate to remind you that you missed a call.
Silent mode is disabled for 15 seconds when you transmit, receive,
or press any other button.
Press MENU/ repeatedly until vibe and the current setting start
to blink on the display.
To turn ON Silent mode:
1. Press
CH ▲
to turn Silent mode on; on displays.
2. To exit the Menu, press the MENU/ key to advance through
the Menu until exiting to "Normal" mode. vibe appears.
To turn OFF Silent mode:
1. Press
CH ▼
to display oF.
2. To exit the Menu, press the MENU/ key to advance through
the Menu until exiting to "Normal" mode. vibe disappears.
Note: To prevent unwanted silent alerts, be sure to use a Privacy
code whenever you use the Silent mode feature. You can hear the
received voice when you turn on channel scan and an active
channel is detected even during Silent mode.
Missed Call Alerts
If you receive an incoming call while Silent mode is on and do not
respond, the radio will turn on the Missed Call icon.
The radio will additionally remind you of a missed call by vibrating
every minute after the call for 3 minutes.
Key Lock
To lock the keypad:
Press and hold CALL/LOCK; displays.
These functions are not affected by Key Lock:
• Volume Adjust • Call Tone Transmission
• PTT Transmission • Boost
• Power Off • Enter Monitor Mode
• Flashlight
To unlock the keypad:
Press and hold CALL/LOCK again; disappears.
Automatic Power Save
Your radio has a circuit designed to dramatically extend the life of
the batteries. If there is
no transmission or an incoming call within
3 seconds,
your radio switches to Power Save mode. The radio is
still able to receive transmissions in this mode.
LCD Backlight
The LCD Backlight automatically turns ON when any key (except
the PTT button) is pressed. It stays lit for 10 seconds before
turning OFF.
Roger Beep
Roger Beep is a beep sound that that is sent to indicate the end of
transmission (both PTT and VOX transmission). Roger Beep can
be heard through the speaker when both Roger Beep and Key
Beep are set to ON. When Roger Beep is set to ON and Key Beep
is set to OFF, Roger Beep will not be heard from the speaker but it
will be transmitted to your party. When Roger Beep is set to OFF,
Roger Beep will neither be heard nor transmitted.
To change Roger Beep setting:
Press and hold VOL ▲ while turning the radio on and off. If Roger
Beep is ON, it will be turned off; if it is OFF, it will be turned on.
LED Flashlight with SOS
The radio is equipped with an LED flashlight that can also flash an
SOS signal during emergencies. Press the Flashlight button to
cycle through the options.
• Press - turn on flashlight. (Quick press - turn off flashlight)
• Press and hold - turn on SOS signal.
• From SOS - Press to turn off SOS signal and return to flashlight.
• From flashlight - Press to turn off flashlight.
Note: The flashlight will also work when the radio is off.
USING THE WEATHER RADIO
Your radio can receive weather broadcasts from the NOAA
National Weather Service. When in the Weather Radio Alert mode,
the system functions as it does in standard mode but also monitors
the selected weather channel for alerts when not communicating.
While using the Weather Radio, you are not able to receive GMRS
communications.
Your radio can receive weather broadcasts from the NOAA
National Weather Service. When in the Weather Radio Alert mode,
the system functions as it does in standard mode but also monitors
the selected weather channel for alerts when not communicating.
While using the Weather Radio, you are not able to receive GMRS
communications.
1. To turn on the Weather Radio Broadcast mode, press WX/MON.
The icon appears.
2. Press
CH ▲/CH ▼
to increase or decrease the number to the
desired Weather Channel.
3. To exit the Weather Radio Broadcast mode, press WX/MON. The
icon disappears.
Choosing an Emergency/Weather Channel
There are 7 NOAA channel frequencies available and these
frequencies are common between the US and Canada. You need
to know what frequency is being transmitted in your location.
Press MENU/ repeatedly until the
alert
icon and the current
setting start to blink on the display.
To turn ON Weather Alert:
1. Press
CH ▲
to display on.
2. To exit the Menu, press the MENU/ key to advance you
through the Menu until exiting to "Normal" mode.
alert
icon
appears.
3. When the unit receives a warning signal, it beeps for 5 seconds.
alert
and channel indicator flash.
To turn OFF Weather Alert:
1. Press
CH ▼
to display oF.
2. To exit the Menu, press the MENU/ key advance you through
the Menu until exiting to "Normal" mode.
alert
icon disappears.
• When Weather Alert is activated, the highest priority is given to
this function. It checks the weather alert signals every 5
seconds. When the unit finds a warning signal, it switches to
the warning receive mode automatically.
• Weather Alert is activated even if Beep Tone is turned off.
NOAA Weather Radio Frequency List
Ch. Frequency (MHz) CH. Frequency (MHz)
1162.550 5162.450
2162.400 6162.500
3162.475 7162.525
4162.425
SPECIFICATIONS
Channels 15 GMRS/7 FRS/7 Weather
Privacy Codes 121 Sub-Audible Tones
38 CTCSS/83 DCS Codes
* Range may vary depending on environmental and/or
topographical conditions.
© 2015 Uniden America Corp. Issue 1, October 2015
All rights reserved Printed in China.
Operating Freq.
GMRS/FRS 462.5500 - 467.7125 MHz
WX 162.4000 - 162.5500 MHz
Power Source GMR4055: 3 AA NiMH Batteries or 3
AA Alkaline batteries (not included)
GMR4060: Li-Ion battery back
Range Channels 1 -7: up to 40 miles
Channels 8 - 14: up to 5 miles
Channels 14 - 22: up to 40 miles
FREQUENCY CHART
CH. Freq. Cross-Ref. CH. Freq. Cross-Ref.
1 462.5625 FRS & GMRS 1 12 467.6625 FRS 12
2 462.5875 FRS & GMRS 2 13 467.6875 FRS 13
3 462.6125 FRS & GMRS 3 14 467.7125 FRS 14
4 462.6375 FRS & GMRS 4 15 462.5500 GMRS 11
5 462.6625 FRS & GMRS 5 16 462.5750 GMRS 8
6 462.6875 FRS & GMRS 6 17 462.6000 GMRS 12
7 462.7125 FRS & GMRS 7 18 462.6250 GMRS 9
8 467.5625 FRS 8 19 462.6500 GMRS 13
9 467.5875 FRS 9 20 462.6750 GMRS 10
10 467.6125 FRS 10 21 462.7000 GMRS 14
11 467.6375 FRS 11 22 462.7250 GMRS15
DCS CODE LIST
Tone
No.
Octal
Code
Tone
No.
Octal
Code
Tone
No.
Octal
Code
39 023 67 174 95 445
40 025 68 205 96 464
41 026 69 223 97 465
42 031 70 226 98 466
43 032 71 243 99 503
44 043 72 244 100 506
45 047 73 245 101 516
46 051 74 251 102 532
47 054 75 261 103 546
48 065 76 263 104 565
49 071 77 265 105 606
50 072 78 271 106 612
51 073 79 306 107 624
52 074 80 311 108 627
53 114 81 315 109 631
54 115 82 331 110 632
55 116 83 343 111 654
56 125 84 346 112 662
57 131 85 351 113 664
58 132 86 364 114 703
59 134 87 365 115 712
60 143 88 371 116 723
61 152 89 411 117 731
62 155 90 412 118 732
63 156 91 413 119 734
64 162 92 423 120 743
65 165 93 431 121 754
66 172 94 432
CTCSS Chart (Hz)
Code Freq. Code Freq. Code Freq.
oF OFF 13 103.5 26 162.2
1 67.0 14 107.2 27 167.9
2 71.9 15 110.9 28 173.8
3 74.4 16 114.8 29 179.9
4 77.0 17 118.8 30 186.2
5 79.7 18 123.0 31 192.8
6 82.5 19 127.3 32 203.5
7 85.48 20 131.8 33 210.7
8 88.5 21 136.5 34 218.1
9 91.5 22 141.3 35 225.7
10 94.8 23 146.2 36 233.6
11 97.4 24 151.4 37 241.8
12 100.0 25 156.7 38 250.3
RBRC INFORMATION
As part of our commitment to protect the
environment and conserve natural resources,
Uniden voluntarily participates in an RBRC®
industry program to collect and recycle used
Ni-MH and Li-Ion batteries within the US.
Please call 1-800-8-BATTERY for information on Ni-MH and Li-Ion
battery recycling in your area. (RBRC® is a registered trademark of the
Rechargeable Battery Recycling Corporation.)
Care and Safety: To clean the radio, use a soft cloth dampened with
water. Do not use cleaners or solvents because they can harm the
body of the unit and leak inside, causing permanent damage. Use a
dry, lint-free cloth to clean the battery contacts. Do not submerge the
unit in water. If the unit gets wet, turn it off and remove the batteries
immediately.
Dry the battery compartment with a soft cloth to minimize potential
water damage. Leave the battery compartment cover off overnight to
ensure complete drying. Do not use the radio until the unit is
completely dry.
REGULATORY INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Important: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate this device. Your radio is set up to transmit a regulated signal
on an assigned frequency. It is against the law to alter or adjust the
settings inside the radio to exceed those limitations. Any adjustments
to your radio must be made by qualified technicians.
To be safe and sure:
• Never open your radio’s case.
• Never change or replace anything in your radio except the batteries.
Your radio might cause TV or radio interference even when it is
operating properly. To determine whether your radio is causing the
interference, turn it off. If the interference goes away, your radio is
causing it. Try to eliminate the interference by moving your radio away
from the receiver. If you cannot eliminate the interference, the FCC
requires that you stop using the radio.
Hazardous Environments: Do not operate the radio in hazardous
environments. Explosion or fire may result. Do not operate the radio
near unshielded electrical blasting caps.
Under certain conditions, radios can interfere with blasting operations
and may cause an explosion. Turn your radio OFF to prevent
accidental transmission when in a blasting area or in areas posted:
"Turn off two-way radio." Construction crews often use remote control
RF devices to set off explosives.
Care and Safety: To clean the radio, use a soft cloth dampened with
water. Do not use cleaners or solvents because they can harm the
body of the unit and leak inside, causing permanent damage. Use a
dry, lint-free cloth to clean the battery contacts. Do not submerge the
unit in water. If the unit gets wet, turn it off and remove the batteries
immediately.
Dry the battery compartment with a soft cloth to minimize potential
water damage. Leave the battery compartment cover off overnight to
ensure complete drying. Do not use the radio until the unit is
completely dry.
WARNING! Read this information before using the radio. In August
1996 the Federal Communications Commission (FCC) of the United
States with its action in Report and Order FCC 96-326 adopted an
updated safety standard for human exposure to radio frequency
electromagnetic energy emitted by FCC regulated transmitters.
Those guidelines are consistent with the safety standard previously set
by both U.S. and international standards bodies. The design of the
radio complies with the FCC guidelines and these international
standards.
Never allow children to operate the radio without adult supervision and
the knowledge of the following guidelines.
WARNING! It is up to the user to properly operate this radio
transmitter to insure safe operation. Please adhere to the following:
Do not use the radio with a damaged antenna. If a damaged antenna
comes into contact with the skin, a minor burn may result. Please
contact your local dealer for a replacement antenna.
IC INFORMATION
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
Unauthorized changes or modifications to this equipment may void
compliance with I.C. Rules. Any change or modification must be
approved in writing by Uniden. Changes or modifications not approved
by Uniden could void the user’s authority to operate the equipment.
L’appareil est conforme aux normes d’Industrie Canada. Son
fonctionnement est soumis aux deux conditions suivantes : (1) Ce
dispositif ne doit pas causer d’interférences et (2), il doit pouvoir
accepter les interférences, incluant celles pouvant nuire à son
fonctionnement normal.
Tous les changements apportés à cet appareil, s’ils ne sont pas
expressément approuvés par Uniden ou toute utilisation de celui-ci
d’une autre manière que celle décrite dans ce guide peut annuler votre
autorisation de le faire fonctionner.
Hand-Held Operation (Held-to-Face)
This device was evaluated for typical hand-held (held-to-face)
operations with a 1 inch spacing from the front of the radio. For hand-
held operation, the radio should be held 1 inch from the user's face in
order to comply with FCC RF exposure requirements.
Body-Worn Operation
This device was evaluated for body-worn operations with the supplied
belt-clip accessory. (All necessary accessories are included in the
package; any additional or optional accessories are not required for
compliance with the guidelines.) Third party accessories (unless
approved by the manufacturer) should be avoided as these might not
comply with FCC RF exposure guidelines.
For body worn operation, this device has been tested and meets the
Industry Canada RF exposure guidelines when used with Uniden
accessories supplied or designated for this product. Use of other
accessories may not ensure compliance with Industry Canada RF
exposure guidelines.
Fonctionnement de l’appareil, lorsque porté sur le corps. Cet appareil a
été testé et s’est avéré conforme aux normes d’Industrie Canada et
approuvé pour le port sur le corps à l’aide des accessoires Uniden
inclus et conçus pour cet appareil. L’utilisation d'accessoires ne
respectant pas les exigences d'exposition RF d’Industrie Canada doit
être évitée.
ONE-YEAR WARRANTY
IMPORTANT: SAVE YOUR RECEIPT! Evidence of original purchase
is required for warranty service.
WARRANTOR: UNIDEN AMERICA CORPORATION ("Uniden")
ELEMENTS OF WARRANTY: Uniden warrants, for one year, to the
original retail owner, this Uniden Product to be free from defects in
materials and craftsmanship with only the limitations or exclusions set
out below.
WARRANTY DURATION: This warranty to the original user shall
terminate and be of no further effect 12 months after the date of
original retail sale. The warranty is invalid if the Product is:
(A) damaged or not maintained as reasonable or necessary, (B)
modified, altered, or used as part of any conversion kits, sub-
assemblies, or any configurations not sold by Uniden, (C) improperly
installed, (D) serviced or repaired by someone other than an
authorized Uniden service center for a defect or malfunction covered
by this warranty, (E) used in any conjunction with equipment or parts or
as part of any system not manufactured by Uniden, or (F) installed or
programmed by anyone other than as detailed by the owner’s manual
for this product.
STATEMENT OF REMEDY: In the event that the product does not
conform to this warranty at any time while this warranty is in effect,
warrantor will either, at its option, repair or replace the defective unit
and return it to you without charge for parts, service, or any other cost
(except shipping and handling) incurred by warrantor or its
representatives in connection with the performance of this warranty.
Warrantor, at its option, may replace the unit with a new or refurbished
unit.
THE LIMITED WARRANTY SET FORTH ABOVE IS THE SOLE AND
ENTIRE WARRANTY PERTAINING TO THE PRODUCT AND IS IN
LIEU OF AND EXCLUDES ALL OTHER WARRANTIES OF ANY
NATURE WHATSOEVER, WHETHER EXPRESS, IMPLIED OR
ARISING BY OPERATION OF LAW, INCLUDING, BUT NOT LIMITED
TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.THIS WARRANTY DOES
NOT COVER OR PROVIDE FOR THE REIMBURSEMENT
OVERPAYMENT OF INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow this exclusion or limitation of incidental or
consequential damages so the above limitation or exclusion may not
apply to you.
LEGAL REMEDIES: This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state. This
warranty is void outside the United States of America and Canada.
PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY:
If, after following the instructions in the owner’s manual you are certain
that the Product is defective, pack the Product carefully (preferably in
its original packaging). Disconnect the battery from the Product and
separately secure the battery in its own separate packaging within the
shipping carton. The Product should include all parts and accessories
originally packaged with the Product. Include evidence of original
purchase and a note describing the defect that has caused you to
return it.The Product should be shipped freight prepaid, by traceable
means, to warrantor at:
Uniden America Corporation
C/O Saddle Creek
743 Henrietta Creek Road, Suite 100
Roanoke, TX 76262
LI-Ion
