User Manual

GMR5088-2CKHS, GMR5095-2CKHS

GMR5098-2CKVP

CHARGING CRADLE

LIQUID CRYSTAL DISPLAY

20 21

Radio color/pattern varies

according to model number.

*Range may vary depending on environmental

and/or topographical conditions.

• 15 GMRS / 7 FRS Channels

• 7 Weather Channels

• 142 Privacy Codes (CTCSS

Tone and DCS Code)

• Up to 50 Mile Range*

• Internal VOX Circuitry

• TRU Waterproof™ (JIS7) —

Submersible and Floats

• Direct Call with Name Display

• 143 Group Codes

• Silent Mode

• 10 Selectable Call/Ring Tone

Alerts

• Backlit LCD Display

• Roger Beep

• Call Alert; Vibrate

• 2 Earbuds with VOX Mic or 2

Headset Boom Mics

1 Antenna 13 Weather

2Push to Talk 14 Enter/Lock

3 Boost 15 Battery Level

4 Monitor 16 Group Number

5 Channel Up/Down 17 Group Indicator

6 Tone 18 RX (Receive) or TX

(Transmit) Indicator

7 D Call 19 VOX Indicator

8 Microphone 20 Missed Call Indicator

9 Speaker 21 Alert Indicator

10 Flashlight/Monitor 22 Channel Number

11 Menu/Power 23 Charging contacts

12 Volume Up/Down 24 Charging LEDs

Congratulations on your purchase of a Uniden

GMRS (General Mobile Radio Service)

waterproof radio. These lightweight, palm-sized,

radios are state-of-the-art devices. The

GMR5088-2CKHS and GMR5095-2CKHS

models include earbud vox mics. GMR5098-

2CKVP includes two VOX headset boom mics.

Use them at sporting events to contact family

and friends, while hiking, skiing, or outdoors, or

in a neighborhood watch for vital communication

— even outside by the pool! Don't worry; they

float!

Your radio complies with JIS7 water-

resistant standards, which means the radio

can be submerged in 1.0 meters of water for

30 minutes without damage.

• The radio will only meet this rating if fully

assembled and all rubber seals and the jack

cover are well maintained and correctly fitted.

This means that the Headset plug is not inserted,

and the Headset jack cover and the battery pack

are attached and securely fastened.

• After your radio is submerged in water, you might

notice that the sound is distorted. This is because

water remains in and around the speaker and

microphone. Just shake the radio to clear excess

water, and the sound should return to normal.

Note: If your radio is exposed to salt water,

clean your radio thoroughly with fresh water

and dry it before turning it on.

PACKAGE CONTENTS

Your package contains two radios, 6

rechargeable AA NiMH batteries, one AC adapter

with microUSB connector, one charging cradle, 2

earbud/mic headsets for GMR5095-2CKHS and

GMR5088-2CKHS (GMR5098-2CKVP has two

headset boom mics), two belt clips, and this

reference guide. To order the following optional

accessories, visit our web site at www.uniden.

com. Use only Uniden accessories.

• NiMH Batteries – #BP-38

• Charging Cradle – #RC-1289

• Headset Boom Mic – #ZA-133 or ZA-160

• AC Adapter – #AD-0001

• Carabiner Clip – #TSTD0720002

GMRS LICENSE

The radio operates on the General Mobile

Radio Service (GMRS) frequencies when

using Channels 1-7 and channels 15-22. You

must have a GMRS license issued by the

Federal Communications Commission to

legally use these channels.

For licensing information and application

forms, visit the FCC online at: www.fcc.gov/

wtb/uls or call the FCC hotline at 1-800-418-

3676. If you have any questions, you can

contact the FCC direct at 1-888-225-5322. No

license is required for operation on channels

8-14 or operation on any channel in Canada.

INSTALL THE BATTERY

Each radio uses 3 rechargeable AA NiMH

batteries for power (included). It can also use

non-rechargeable AA alkaline batteries (not

included). To install the NiMH batteries:

1. Turn the screw holding the battery

compartment counterclockwise with a

screwdriver and lift up the battery cover,

2. Insert the NiMH batteries in the battery

compartment according to the directions

indicated on the battery. Installing the

batteries incorrectly will prevent the unit from

operating.

3. Before placing the battery cover back on the

radio, check the rubber seal around the

battery compartment. Make sure that the seal

is in good condition and that there is no

foreign matter under it.

4. Replace the battery compartment door.

Tighten the screws securely.

Note: If the rubber seal appears worn, nicked,

or dried out, replacement seals are available

from www.uniden.com.

CHARGING THE RADIO

Follow these instructions to charge or recharge

your radios.

Make sure to turn the radio OFF before

placing it in the charging cradle.

1. Insert the adapter's microUSB plug to DC IN

5V USB jack of the charging cradle and plug

the other end into an AC outlet.

2. Set the charging cradle on a stable desk or

tabletop and place the radios in the charging

cradle with the keypad facing forward.

3. Make sure that the LED illuminates. Charge

the batteries for 16 hours and remove the

radio from the charging cradle after charging.

Note:

• Use only the supplied batteries and AC adapter

or approved accessories from Uniden.

• Charge time may vary depending on the battery

life remaining.

• The batteries must be installed for the unit to

operate, even if the unit is also connected to

external power.

• If battery power is low, you cannot operate the

radio even using external power. Allow the

batteries to charge before using. If you try to

transmit while power is low, the radio will

automatically turn off.

• Charge time may vary depending on the battery

speak to someone, both your radios must be set

to the same channel and Privacy code.

To choose a channel:

Press CH or , then press CH or

to increase or decrease the channel

number displayed.

To scroll through the channels, press CH or

, then press and hold CH or for more

than 1 second.

Note: Channels 1-7 and 15-22 have a typical

range of up to 50 miles by pressing BOOST.

HI displays when you select a GMRS

channel, and LO displays when you select

an FRS channel.

SETTING UP GROUP MODE

Group mode lets several people talk on the

same channel in a separate group. In order to

use Group mode, you need to initialize specific

settings in your radio:

• Set the radio to Group mode.

• Set a Group Code.

• Set a Unit Number.

• Set a "Nickname."

Setting the Radio to Group Mode

To set the radio to Group mode, which enables

Direct Call, Auto Channel Change, and All Call,

press and hold TONE/GROUP for 2 seconds.

The radio displays GRP and group code.

Note: In Group mode, you cannot receive

transmissions from other radios unless

they are also set to the same channel and

group code.

Setting the Group Code

Set the group code for your radio group from

0-142. Everyone in your group must select the

same group code in order to communicate with

each other.

1. PressTONE/GROUP in Group mode. Press

CH or to select the group number.

2. Press ENTER/ or TONE/GROUP to return

to normal operation.

Setting the Unit Number

Each radio in your group needs to be set to a

unique unit number, from 1-16.

1. Press MENU/ . Advance through the menu

until UNIT appears, and then press ENTER/

. The current unit number flashes.

2. Press CH or to select the desired unit

number.

3. Press ENTER/ to continue to the next

section.

Setting Your Nickname

Your nickname appears on other units’ displays

when you make an All Call or Direct Call. This is

also the name that appears on other radio

displays when someone wants to make a Direct

Call to you. Without a nickname, the unit

number shows.

1. Press MENU/ . Advance through the menu

until UNIT appears, and then press ENTER/

. The current unit number flashes, then

press ENTER/ . The radio displays - - - -

(or your current nickname) with the first place

in the nickname flashing.

2. Press CH or to select the letter, then

ENTER/ to advance to the next letter until

you have entered your nickname.

3. Press MENU/ to confirm the setting and

exit the menu.

Using Group Mode

Group mode lets you make direct calls to other

people in your group without alerting the entire

group and also lets you quickly change

everyone in your group to another channel from

a single radio. Before using Group mode, follow

the instructions in "Setting Up Group mode" on

every radio in your group. Then, to record the

unit ID and everyone’s nickname in every radio,

send a call to "All" from each radio one time

(see "Sending a Direct Call").

Sending a Direct Call

Direct Call lets you call everyone in your group

at once, or call a single person in your group

without anyone else in the group knowing. It is

like a "speed dial" directly to the person(s) you

want to talk to.

To call everyone in your group, press D CALL in

Group mode. The radio flashes ALL. Then,

press D CALL or ENTER/ . Everyone in your

group receives a call "chirp" for about 3

seconds. When the chirp ends, begin your

conversation.

Note: When you make a direct call to "all," your

radio also sends out your nickname or ID so

that it will show up in the call list for everyone in

your group.

To call one person in your group without having

other people know, press D CALL in Group

mode. Then, use CH or to select the

person you want to call and press D CALL or

ENTER/ . Your radio sounds tones for 3

seconds as it sends the call. When the selected

person answers, you can begin your

conversation.

You can silence the call tones any time by

pressing PTT or BOOST.

Your conversation remains private between you

and the person you called until 15 seconds after

Channel Scan Feature

Your radio has a channel scan feature that lets

you easily scan all 22 channels. When an active

channel is detected, the radio pauses on that

channel until the channel is clear. Then after a

2-second delay, the radio resumes scanning.

Pressing PTT or BOOST while the scan is

paused on a channel lets you transmit on that

channel.

To turn on channel scan:

Press MENU/ . The radio displays SCAN.

Press ENTER/ .The channel number changes

as the radio rapidly cycles through the channels.

Use the radio in Standard (not Group) mode

when you need to be able to communicate with

radios that do not have the group feature.

Talking on Your Radio

To talk to others using the radio:

1. Press and hold PTT or BOOST and speak in

a clear, normal voice about 2-3 inches away

from the microphone. While you transmit,

TXHI or TXLO appears on the display

according to the type of channel. To avoid

cutting off the first part of your transmission,

pause slightly after pressing PTT or BOOST

before you start talking.

2. When you finish speaking, release PTT or

BOOST. You can now receive incoming calls.

While receiving, RX appears on the display.

Note:

• When you press BOOST, BOOST appear on

the display. The radio transmits at maximum

power when a GMRS channel is selected.

• If BOOST, PTT or VOX is continuously used, 1

minute after you start using the feature the

transmission stops and you hear a timeout error

tone.

Monitor Mode Feature

Your radio lets you listen for weak signals on

the current channel at the press of a key.

To turn on the Monitor mode:

• Press and hold LIGHT/MON for 2 seconds until

two beeps sound for continuous listening. The

receiver circuit stays open, so you hear both the

noise and weak signals.

To turn off Monitor mode:

Press LIGHT/MON to return to the previous

mode. MON and RX disappear.

Navigating through the Normal Menu

Your radio has a Menu function to access

advanced features. In order to use Auto

Channel Change, you need to set your radio to

Group mode.

Start

Scanning

Scan

Mode

Silent

Mode

ON-OFF

Auto

Channel

Change

Channel

Change

VOX

Level

OFF, 1-5

1-10

Call

Tone

Unit

Setting

Unit

Number

Roger

Beep

ON-OFF

Beep

Tone

ON-OFF

Setting

Nickname

1. To enter the menu, press MENU/ .

2. Press MENU/ again to advance through

the menu. After the last menu item, the radio

exits to the previous mode.

3. Other ways to exit the Menu function are:

a. Press PTT, BOOST, LIGHT/MON, D

CALL, WX/ALERT or TONE/GROUP.

b. Wait 10 seconds until the radio

automatically returns to the previous

mode.

Setting Silent Mode

When you turn on Silent mode, all incoming

calls are muted, the display backlight flashes,

and the channel indicator displays SLNT and

CALL to alert you to an incoming call. If you do

not respond to the call within 15 seconds, the

backlight turns off. The GMR5095 will also

vibrate to remind you that you missed a call.

Silent mode is disabled for 15 seconds when

you transmit, receive, or press any other button.

To set Silent mode:

1. Enter the menu. Advance through the menu

until the SLNT displays, then press ENTER/

. The current setting flashes.

2. Press

to display on, then press ENTER/

Note: To prevent unwanted silent alerts, be sure

to use a Privacy Code or Group Code whenever

you use the Silent mode feature.

You can hear the received voice when you turn

on channel scan and an active channel is

detected, even during Silent mode.

Missed Call Alerts

If you receive an incoming call while Silent

mode is on and do not respond, the radio will

turn on the Missed Call icon. If you are using

Group mode, the radio will also indicate who

made the call.

The GMR5095 will also remind you of a missed

call by vibrating every minute after the call for 3

minutes.

• BOOST for Maximum

Range*

• Headset Jack

• Auto Channel Change

Call

• Battery Level Meter

• Rechargeable NiMH

Batteries

• Dual Charging Cradle

with AC Adapter

• Channel Monitor

• Channel Scan

Group Scan

• Keypad Lock

• Emergency Weather

Alert

• Emergency Light

your last conversation. Then, your radio

automatically exits Private mode.

Automatically Changing Channels

Auto Channel Change lets you easily coordinate

a channel change for everyone in your group.

You might want to do this when you find you are

getting a lot of interference on your current

channel. You also use this feature to change

from a low-power channel (8-14) to one of the

high-powered channels (1-7, 15-22) for more

range (or to a low-power channel if you need

longer battery life).

To start an auto channel change, on any radio

in the group, press MENU/ . Advance through

the menu until CHCX appears, then press

ENTER/ . The current channel flashes. Use

CH or to select the target channel. You

can check whether the selected channel is

clear. Then press D CALL or ENTER/ .

Your radio chirps for about 10 seconds while it

sends out the channel change signal. As each

radio receives the channel change signal, it

chirps once, then changes to the new channel.

To ensure all radios make it to the new channel,

we recommend you:

• Make sure you are in an open environment,

where the radio will get the best range.

• Optimize range during the channel change signal

by raising the radio over your head to give the

best possible height.

• Do a "roll call" on the new channel after the

move to be sure no one was left behind. If you

missed someone, return to the previous channel

and issue the signal again.

USING THE RADIO IN

STANDARD MODE

Use the radio in Standard (not Group) mode

when you need to be able to communicate with

radios that do not have the group feature.

Choosing a Privacy Code

You can select a Privacy Code from 1-142 for

each channel. oF (off) indicates no Privacy

Code selected and your radio can receive a

signal regardless of the code settings of the

transmitting radio.

1. Press TONE/GROUP. The Privacy Code

indicator flashes.

2. Press CH or to increase or decrease

the code. You can also select oF.

3. Press ENTER/ or TONE/GROUP to return

to normal operation.

Note: Only tones 1-38 are standard across

radio brands. Other settings might differ

from brand to brand. See the specifications

for the specific tones used for each setting.

Voice Operated Transmission

Your radio is equipped with a user selectable

Voice Operated Transmitter (VOX) that can be

used for automatic voice transmissions. The VOX

feature is designed to be used with a headset with

a microphone. Initiate transmission by speaking

into the remote microphone instead of pushing

PTT and BOOST. To select the VOX level:

1. Press MENU/ . Advance through the Menu

until VOX appears on the display, then press

ENTER/ . The current level (off, 1-5) flashes.

Level oF (off) disables VOX, while levels 1-5

set the sensitivity of the VOX circuit.

2. Press either CH or to reach the desired

VOX sensitivity level, then press ENTER/ .

Use level 1 for increased sensitivity to voice in

normally quiet environments, and use a higher

level to reduce undesired activation in very

noisy environments.

Transmitting a Call Tone

Your radio is equipped with 10 selectable call

tones that are transmitted when you press D

CALL in Standard mode.

The selected tone also will be heard when

someone places a direct call to you.

To select a call tone:

1. Press MENU/ . Advance through the menu

until CALL appears, then press ENTER/ . The

current call tone number (1-10) flashes.

2. Press CH or to increase or decrease the

number to the desired call tone. Each tone will

be heard through the speaker. Press ENTER/

to select a call tone.

To transmit the selected call tone, press D CALL.

The selected tone is transmitted for a fixed length

of time. Press PTT or BOOST to cancel.

Roger Beep

Roger Beep is a beep that is sent to notify the end

of transmission (both PTT and VOX transmission).

You can hear Roger Beep through the speaker

when both Roger Beep and Beep Tone are on.

When Roger Beep is on and Beep Tone is off, you

do not hear Roger Beep, but it is transmitted to

your party.

To adjust Roger Beep, press MENU/ . Advance

through the menu until RGR appears, then press

ENTER/ . The current setting flashes.

To turn off Roger Beep:

Press CH to display oF, then press ENTER/

To turn on Roger Beep:

Press CH to display on, then press ENTER/

Adjusting the Sound (Beep Tone)

Your radio sounds a beep each time you

press a key (except for PTT and BOOST).

life remaining.

• Do not recharge alkaline batteries. Doing so can

create a safety hazard or damage the radio.

• For faster charging, turn off the radio before

charging.

Warning!

• The charging cradle is not waterproof. If the

charging cradle falls in the water, unplug it before

attempting to remove it from the water. Allow the

cradle to dry completely before reconnecting the

power.

• Wipe off dirt or shake water from your radio

before placing in the charging cradle if your radio

is soiled or wet.

USING A HEADSET

GMR5088-2CKHS and GMR5095-2CKHS both

come with an earbud headset with mic on the

cord. The GMR5098-2CKVP comes with boom

mic headset. To use a headset, lift the rubber

cover from over the headset jack, then plug in

the headset.

Important: Your radio is not waterproof when

using a headset jack. When you remove the

headset, be sure to fully press the jack cover

into place to restore its waterproof capability.

USING RADIO BATTERY LEVEL

AND LOW BATTERY ALERT

This radio has a battery level meter that

indicates the battery power level. When the

battery level is low, the battery level meter icon

flashes and then BATT appears after 30

seconds. Recharge the NiMH batteries

immediately.

Warning! To avoid the risk of personal injury or

property damage from fire or electrical shock,

only use the Uniden accessories specifically

designated for this product.

USING THE RADIO

In order to get the most out of your new radio,

read this reference guide completely before

attempting to operate it.

Turning the Radio On and Adjusting

the Volume

1. Press and hold MENU/ to turn the radio

on.

2. Press VO or to increase or decrease

the volume level then press ENTER/ .

3. Press and hold MENU/ to turn the radio

off.

Choosing a Channel

Your radio has 22 channels and 142 Privacy

codes you can use to talk to others. In order to

To adjust the sound, press MENU/ . Advance

through the menu until TONE appears, then press

ENTER/ . The current setting flashes.

To turn off the beep:

Press CH to display oF, then press ENTER/ .

To turn on the beep:

Press CH to display on, then press

ENTER/ .

Key Lock

Press and hold the ENTER/ until LOCK appears.

To turn Keylock off, press and hold ENTER/

again.

Note:

• If Keylock is on, the radio can still receive

transmissions. Use D CALL in Standard mode, VO

or , PTT, BOOST, LIGHT/MON, and MENU/

to turn the radio on or off.

• The radio retains the keylock status even when you

cycle power.

Using the Flashlight

You can use this radio in an emergency. If you

press LIGHT/MON, the radio turns on the high-

intensity LED flashlight on your radio. Depending

on how you set it up, the LED functions as a

flashlight, flashes “S O S” in international Morse

Code, is always on, or is off.

Note: Your radio operates normally when the

SOS strobe is activated.

1. Press LIGHT/MON while this light is turned off,

the Strobe Light emits the SOS signal. (Strobe

SOS mode)

2. And then, press LIGHT/MON once more, it will

turn on continuously. (Always On mode)

3. And then, press LIGHT/MON while Always On

mode, the light will be turned off.

Automatic Power Save Feature

Your radio has a unique circuit designed to

dramatically extend the life of the battery. If you do

not transmit and do not receive an incoming call

within 3 seconds, your radio switches to the Power

Save mode. The radio is still able to receive

transmissions in this mode.

LCD Backlight

The LCD Backlight automatically turns on when any

key (except for PTT and BOOST) is pressed. The

LCD remains lit for 10 seconds before turning off.

USING THE WEATHER RADIO

Your radio can receive weather broadcasts from the

NOAA National Weather Service. When in Weather

Radio Alert mode, the system functions as it does

in Standard mode or Group mode but also monitors

the selected weather channel for alerts when not

communicating. While using the Weather Radio,

you are not able to receive GMRS communications.

1. To turn on the Weather Radio Broadcast mode,

press WX/ALERT. WX appears.

2. Press CH or to increase or decrease the

number to the desired Weather Channel.

3. To exit the Weather Radio Broadcast mode, press

WX/ALERT. WX disappears.

When in the Weather Radio Broadcast mode, you

can only set the Beep Tone from the Menu mode.

Choosing an Emergency/Weather Channel

There are 7 NOAA channel frequencies available

and these frequencies are common between the US

and Canada. You need to know what frequency is

being transmitted in your location.

1. Press and hold WX/ALERT. appears.

2. When the unit receives a warning signal, it beeps

for 5 seconds. and channel indicator flash.

3. To turn off Weather Alert, press and hold

WX/ALERT. disappears.

• When Weather Alert is activated, the highest priority

is given to this function. It checks the weather alert

signals every 7 seconds. When the unit finds a

warning signal, it switches to the Warning Receive

mode automatically.

• Weather Alert is activated even if Beep Tone is off.

NOAA Weather Radio Frequency List:

Chan. Freq.

(MHz)

Chan. Freq.

(MHz)

1 162.550 5 162.450

2 162.400 6 162.500

3 162.475 7 162.525

4 162.425

SPECIFICATIONS

Item Specication

Channels 15 GMRS/7 FRS/7 Weather

Privacy

Codes

38 Sub-Audible Tones

104 DCS Codes

Operating Frequency (MHz)

GMRS/FRS: 462.5500 - 467.7125

WX: 162.4000 - 162.5500

Power

Source

NiMH Batteries (#BP-38)

Range

(Chan.)

Miles

1-7 Up to 18 (up to 50 with BOOST)

8-14 Up to 5

Item Specication

15-22 Up to 18 (up to 50 with BOOST)

Battery Life

(Hours)

10 Hours (typical) -- NiMH

Batteries (5/5/90 duty cycle)

FREQUENCIES

Frequency Chart

CH. Freq. Cross-Ref. CH. Freq. Cross-

Ref.

1 462.5625 FRS & GMRS 1 12 467.6625 FRS 12

2 462.5875 FRS & GMRS 2 13 467.6875 FRS 13

3 462.6125 FRS & GMRS 3 14 467.7125 FRS 14

4 462.6375 FRS & GMRS 4 15 462.5500 GMRS 11

5 462.6625 FRS & GMRS 5 16 462.5750 GMRS 8

6 462.6875 FRS & GMRS 6 17 462.6000 GMRS 12

7 462.7125 FRS & GMRS 7 18 462.6250 GMRS 9

8 467.5625 FRS 8 19 462.6500 GMRS 13

9 467.5875 FRS 9 20 462.6750 GMRS 10

10 467.6125 FRS 10 21 462.7000 GMRS 14

11 467.6375 FRS 11 22 462.7250 GMRS15

CTCSS & DCS CODES

CTCSS Chart (Hz)

Code Freq. Code Freq. Code Freq.

oF OFF 13 103.5 26 162.2

1 67.0 14 107.2 27 167.9

2 71.9 15 110.9 28 173.8

3 74.4 16 114.8 29 179.9

4 77.0 17 118.8 30 186.2

5 79.7 18 123.0 31 192.8

6 82.5 19 127.3 32 203.5

7 85.48 20 131.8 33 210.7

8 88.5 21 136.5 34 218.1

9 91.5 22 141.3 35 225.7

10 94.8 23 146.2 36 233.6

11 97.4 24 151.4 37 241.8

12 100.0 25 156.7 38 250.3

DSC Code List

Tone

No.

Octal

Code

Tone

No.

Octal

Code

Tone

No.

Octal

Code

39 023 67 174 95 445

40 025 68 205 96 464

41 026 69 223 97 465

42 031 70 226 98 466

43 032 71 243 99 503

44 043 72 244 100 506

45 047 73 245 101 516

46 051 74 251 102 532

47 054 75 261 103 546

48 065 76 263 104 565

49 071 77 265 105 606

50 072 78 271 106 612

51 073 79 306 107 624

52 074 80 311 108 627

53 114 81 315 109 631

54 115 82 331 110 632

55 116 83 343 111 654

56 125 84 346 112 662

57 131 85 351 113 664

58 132 86 364 114 703

59 134 87 365 115 712

60 143 88 371 116 723

61 152 89 411 117 731

62 155 90 412 118 732

63 156 91 413 119 734

64 162 92 423 120 743

65 165 93 431 121 754

66 172 94 432

RBRC Information

As part of our commitment to

protect the environment and

conserve natural resources,

Uniden voluntarily participates

in an RBRC® industry program

to collect and recycle used Ni-MH batteries

within the US. Please call 1-800-8-BATTERY for

information on Ni-MH battery recycling in your

area. (RBRC® is a registered trademark of the

Rechargeable Battery Recycling Corporation.)

Your radio might cause TV or radio interference

even when it is operating properly. To determine

whether your radio is causing the interference,

turn it off. If the interference goes away, your radio

is causing it.

Try to eliminate the interference by moving your

radio away from the receiver. If you cannot

eliminate the interference, the FCC requires that

you stop using the radio.

Hazardous Environments: Do not operate the

radio in hazardous environments. Explosion or fire

may result. Do not operate the radio near

unshielded electrical blasting caps.

Under certain conditions, radios can interfere with

blasting operations and may cause an explosion.

Turn your radio OFF to prevent accidental

transmission when in a blasting area or in areas

posted: "Turn off two-way radio." Construction

crews often use remote control RF devices to set

off explosives.

Care and Safety: To clean the radio, use a soft

cloth dampened with water. Do not use cleaners or

solvents because they can harm the body of the

unit and leak inside, causing permanent damage.

Use a dry, lint-free cloth to clean the battery

contacts.

COMPLIANCE INFORMATION

FCC Compliance Statement: This device complies

with Part 15 of the FCC rules. Operation is

subjected to the following two conditions: (1) this

device may not cause harmful interference, and (2)

this device must accept any interference received,

including interference that may cause undesired

operation.

This device complies with Industry Canada license-

exempt RSS standard(s).Operation is subject to the

following two conditions: (1) this device may not

cause interference, and (2) this device must accept

any interference, including interference that may

cause undesired operation of the device.

Changes or modifications not expressly approved

by the party responsible for compliance could void

your authority to operate the equipment.

Avis de conformité à la FCC : Ce dispositif a été

testé et s’avère conforme à l’article 15 des

règlements de la Commission fédérale des

communications (FCC). Ce dispositif est soumis

aux conditions suivantes: 1) Ce dispositif ne doit

pas causer d’interférences nuisibles et; 2) Il doit

pouvoir supporter les parasites qu’il reçoit, incluant

les parasites pouvant nuire à son fonctionnement.

Cet appareil est conforme aux normes RSS

exemptes de licences d’Industrie Canada. Son

fonctionnement est soumis aux deux conditions

suivantes : (1) cet appareil ne doit pas causer

d’interférences nuisibles et (2), il doit pouvoir

accepter les interférences, incluant celles pouvant

nuire à son fonctionnement normal.

Tout changement ou modification non approuvé

expressément par la partie responsable pourrait

annuler le droit à l’utilisateur de faire fonctionner cet

équipement.

RF EXPOSURE INFORMATION

WARNING! Read this information before using the

radio. In August 1996 the Federal Communications

Commission (FCC) of the United States with its

action in Report and Order FCC 96-326 adopted an

updated safety standard for human exposure to

radio frequency electromagnetic energy emitted by

FCC regulated transmitters.

Those guidelines are consistent with the safety

standard previously set by both U.S. and

international standards bodies. The design of the

radio complies with the FCC guidelines and these

international standards.

Never allow children to operate the radio without

adult supervision and the knowledge of the following

guidelines.

WARNING! It is up to the user to properly operate

this radio transmitter to ensure safe operation.

Please adhere to the following:

Use only the supplied or an approved antenna.

Unauthorized antennas, modifications, or

attachments could impair call quality, damage the

radio, or result in violation of FCC regulations.

Do not use the radio with a damaged antenna. If a

damaged antenna comes into contact with the skin,

a minor burn may result. Please contact your local

dealer for a replacement antenna.

Hand-held Operation (Held-to-Face)

This device was evaluated for typical hand-held

(held-to-face) operations with a 1 inch spacing from

the front of the radio. For hand-held operation, the

radio should be held 1 inch from the user's face

inorder to comply with FCC RF exposure

requirements.

For more information about RF exposure, please

visit the FCC web site at www.fcc.gov.

Body-Worn Operation

This device was tested for typical body-worn

operations using the supplied belt-clip. To

maintain compliance with FCC RF exposure

requirements, Body-worn operations are

restricted to the supplied belt-clip. For hand-

held operation, the radio should be held 1

inch from the user's face. The use of

accessories that do not satisfy these

requirements may not comply with FCC RF

exposure requirements and should be

avoided. For more information about RF

exposure, please visit the FCC web site at:

www.fcc.gov.

For body worn operation, this device has

been tested and meets the Industry Canada

OF ANY NATURE WHATSOEVER, WHETHER

EXPRESS, IMPLIED OR ARISING BY OPERATION

OF LAW, INCLUDING, BUT NOT LIMITED TO ANY

IMPLIED WARRANTIES OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE.THIS

WARRANTY DOES NOT COVER OR PROVIDE

FOR THE REIMBURSEMENT OVERPAYMENT OF

INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states do not allow this exclusion or limitation

of incidental or consequential damages so the above

limitation or exclusion may not apply to you.

LEGAL REMEDIES: This warranty gives you specific

legal rights, and you may also have other rights

which vary from state to state. This warranty

is void

outside the United States of America and Canada.

PROCEDURE FOR OBTAINING PERFORMANCE

OF WARRANTY: If, after following the instructions in

the owner’s manual you are certain that the Product

is defective, pack the Product carefully (preferably in

its original packaging). Disconnect the battery from

the Product and separately secure the battery in its

own separate packaging within the shipping carton.

The Product should include all parts and accessories

originally packaged with the Product. Include

evidence of original purchase and a note describing

the defect that has caused you to return it.The

Product should be shipped freight prepaid, by

traceable means, to warrantor at:

Uniden America Service

C/O Saddle Creek

743 Henrietta Creek Road, Suite 100

Roanoke, TX 76262

RF exposure guidelines when used with

Uniden accessories supplied or designated

for this product. Use of other accessories

may not ensure compliance with Industry

Canada RF exposure guidelines.

Fonctionnement de l’appareil, lorsque porté

sur le corps. Cet appareil a été testé et s’est

avéré conforme aux normes d’Industrie

Canada et approuvé pour le port sur le corps

à l’aide des accessoires Uniden inclus et

conçus pour cet appareil. L’utilisation

d'accessoires ne respectant pas les

exigences d'exposition RF d’Industrie

Canada doit être évitée.

ONE YEAR LIMITED

WARRANTY

Important: Save your receipt! Evidence of

original purchase is required for warranty service.

WARRANTOR: UNIDEN AMERICA

CORPORATION ("Uniden")

ELEMENTS OF WARRANTY: Uniden warrants, for

one year, to the original retail owner, this Uniden

Product to be free from defects in materials and

craftsmanship with only the limitations or exclusions

set out below.

WARRANTY DURATION: This warranty to the

original user shall terminate and be of no further

effect 12 months after the date of original retail

sale. The warranty is invalid if the Product is:

(A) damaged or not maintained as reasonable or

necessary, (B) modified, altered, or used as part of

any conversion kits, sub-assemblies, or any

configurations not sold by Uniden, (C) improperly

installed, (D) serviced or repaired by someone

other than an authorized Uniden service center for

a defect or malfunction covered by this warranty,

(E) used in any conjunction with equipment or parts

or as part of any system not manufactured by

Uniden, or (F) installed or programmed by anyone

other than as detailed by the owner’s manual for

this product.

STATEMENT OF REMEDY: In the event that the

product does not conform to this warranty at any

time while this warranty is in effect, warrantor will

either, at its option, repair or replace the defective

unit and return it to you without charge for parts,

service, or any other cost (except shipping and

handling) incurred by warrantor or its

representatives in connection with the performance

of this warranty. Warrantor, at its option, may

replace the unit with a new or refurbished unit.

THE LIMITED WARRANTY SET FORTH ABOVE IS

THE SOLE AND ENTIRE WARRANTY

PERTAINING TO THE PRODUCT AND IS IN LIEU

OF AND EXCLUDES ALL OTHER WARRANTIES

Uniden America ON5095 Two Ways Radio of GMRS, FRS, Weather receiver User Manual GMR5095 12032015 indd

Uniden America Corporation Two Ways Radio of GMRS, FRS, Weather receiver GMR5095 12032015 indd

User Manual

Navigation menu

Namespaces

Views

Navigation
