Uniden America UC787 2.4 GHz Spread Spectrum Cordless Phone User Manual users manual
Uniden America Corporation 2.4 GHz Spread Spectrum Cordless Phone users manual
users manual
front cover
TRUC46_OM_B6 5/30/02 5:55 PM Page i
www.uniden.com
TRUC46_OM_B6 5/30/02 5:55 PM Page iii
Contents
WELCOME/FEATURES 3
QUICK REFERENCE GUIDE 5
CONTROLS AND FUNCTIONS 6
GETTING STARTED 8
Read This First 8
Checking the Package Contents 9
Setting up the Phone 10
Terminology 14
Setting Caller ID Options 15
Selecting a Language 17
Headset Installation 18
BASICS 20
Making and Receiving Calls 20
Redialing a Call 21
Ringer Volume Setup 22
Setting up the Vibrator Mode 22
Ringer Mute/Vibrator Stop 23
Ringer Tone Setting 23
Distinctive Ringer Setup 24
Adjusting the Earpiece Volume 24
Mute Microphone 25
Tone Dialing Switch-over 25
Traveling Out-of-Range 26
Selecting a Different Channel 26
Find Handset 26
Flash and Call Waiting 27
Voice Mail LED 27
PHONEBOOK 28
Storing Phone Numbers, Names,
Distinctive Rings, and Speed Dial 28
Steps for Entering Names and Special Characters 29
Viewing the Phonebook 31
Making Calls Using the Phonebook 32
Speed Dialing 32
Editing or Erasing a Stored Name, Phone Number,
Distinctive Ring, and Speed Dial 33
RocketDial (One Touch Dialing) 34
Chain Dialing 35
CALLER ID 36
Viewing the Caller ID List 37
Deleting Information from the Caller ID List 38
Using the Caller ID Message List 39
Call Waiting Deluxe Features 40
EXPANDING YOUR PHONE 41
Registering the Second Handset 41
Call Transfer Feature 42
Second Handset Operation 42
ADDITIONAL INFORMATION 44
Changing the Digital Security Code 44
Installing the Holster 45
Note on Power Sources 46
Maintenance 46
General Information 47
TROUBLESHOOTING 48
PRECAUTIONS & WARRANTY 49
I.C. NOTICE 51
INDEX 52
[ 2 ]
TRUC46_OM_B6 5/30/02 5:55 PM Page 2
INTRODUCTION/FEATURES [ 3 ]
Welcome
Features
Congratulations on your purchase of the Uniden cordless telephone. This phone is designed and
engineered to exacting standards for reliability, long life and outstanding performance. To enjoy
the best performance from this phone’s features, please read this manual carefully and save it
for future reference.
Note: Some illustrations in this manual may differ from the actual unit for
explanation purposes.
As an Energy Star® Partner, Uniden has determined that this product or product
models meets the Energy Star® guidelines for energy efficiency.
Energy Star® is a U.S. registered mark.
• 2.4 GHz Spread Spectrum Technology
• Two Handset Expandability
• Caller ID and Call Waiting Caller ID
• Dynamic Memory Location for Caller ID Messages and Phonebook Locations
(up to 100 numbers in total)
• Trilingual Language Option
• 5 Hour Talk Time
• 8 Day Standby Battery Life
• 3-Line, 16 Character Backlit Handset Display
• One Touch Dialing
• Call Transfer
• 32 Digit Redial / 3 Last Number Redial Locations
• 10 Distinctive Ring Options (6 ringers and 4 melodies)
• Flash and Pause
• Find Handset
• Hearing Aid Compatible
• Tone/Pulse Dialing
• Handset Earpiece and Ringer Volume Control
TRUC46_OM_B6 5/30/02 5:55 PM Page 3
INTRODUCTION/FEATURES[ 4 ]
The TRUC46 series features include AutoTalk™ and AutoStandby™. AutoTalk allows you to answer a call
by just removing the handset from the base so you don’t have to waste time pushing buttons.
AutoStandby allows you to hang up by simply returning the handset to the base.
To protect you against mis-billed calls, which might result from your phone being activated by other
equipment, the TRUC46 series has Random Code™ digital security, which automatically selects one of
over 65,000 digital security codes for the handset and base. Also, AutoSecure™ electronically locks your
phone when the handset is in the base.
RocketDial™ is a one touch speed dial key that automatically dials your most important or frequently
called number. The number dialed, is a preset number stored by the user.
Digital Spread Spectrum Technology utilizes a “wider frequency band” vs. a “single narrow band” used in
standard digital transmissions. The result is a more secure conversation with the clarity of digital sound,
extended range, and minimal interference from other cordless phones.
Be sure to visit our web site: www.uniden.com
Uniden® is a registered trademark of Uniden America Corporation.
AutoTalk, AutoStandby, Random Code, AutoSecure, and RocketDial
are trademarks of Uniden America Corporation.
TRUC46_OM_B6 5/30/02 5:55 PM Page 4
QUICK REFERENCE GUIDE [ 5 ]
QUICK REFERENCE GUIDE
INSTALL THE HANDSET BATTERY
Remove the cover.
Connect the
battery pack
connector with
the correct
polarity.
Replace the cover.
PLUG INTO AC POWER
Plug the AC adapter cord into the
base unit and then to a 120V AC
outlet.
Place the handset in the base .
Note:
You must charge the battery pack
continuous
for 15-20 hours before
using the phone.
Step 1 Charging the Battery Step 2 Connecting Step 4 Installing the Headset
Step 3 Setting up the Caller
ID Options/Language
CONNECT TO A PHONE LINE
When the handset battery pack is fully
charged, plug the telephone cord into
the base unit and then into a telephone
wall jack.
Your phone is set for tone dialing. If your
local network requires pulse dialing, please
see “Setting up the phone, Choose the
dialing mode” in your owner’s manual.
RED
BLACK
RED BLACK
Note: Three Caller ID options
are available: Auto Talk, Caller
ID on Call Waiting (CIDCW) and
Area Code.
To make or receive a call, you must install
one of the following headset.
Wear one of the headset.
Over the head type
Over the ear type
Plug the headset cord into the jack
on the top of the handset.
TO SELECT CALLER ID OPTIONS
Press MENU/MUTE.
Press UP or DOWN to move the
pointer to “Caller ID
Setup”, then press SELECT/CH.
Press UP or DOWN to move the
pointer to an option, then
press SELECT/CH.
Press UP or DOWN to change the
option setting.
Press SELECT/CH and return the
handset to the base.
TO CHOOSE THE LANGUAGE
Press MENU/MUTE.
Press UP or DOWN to move the
pointer to “Language”,
then press SELECT/CH.
Press UP or DOWN to change the
option setting.
Press SELECT/CH and return the
handset to the base.
TRUC46_OM_B6 5/30/02 5:56 PM Page 5
Controls and Functions
CONTROLS AND FUNCTIONS[ 6 ]
12 17
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1. Voice Mail LED
2. Headset Jack
3. LCD Display
4. TALK/FLASH Key
5. PB (Phonebook)/ROCKET
(RocketDial)/t(left cursor) Key
6. ▼DOWN Key
7. ▲UP Key
8. ✱/TONE Key
9. Handset Charging Contacts
10. END Key
11. CID (Caller ID)/s(right cursor) Key
12. MENU/MUTE Key
13. SELECT/CH (channel) Key
14. DEL (delete)/TRANS (transfer) Key
15. RDL (redial)/P (pause) Key
16. #Key
17. Handset Battery Compartment
TRUC46_OM_B6 5/30/02 5:56 PM Page 6
CONTROLS AND FUNCTIONS [ 7 ]
19
18
20 21 22
18. Base Antenna
19. PAGE Key
20. STATUS LED
21. DC Power Input
22. Telephone Line Jack
TRUC46_OM_B6 5/30/02 5:56 PM Page 7
GETTING STARTED[ 8 ]
Read this First
This cordless telephone must be set up before use. Follow these steps:
About the digital security code
This cordless telephone uses a digital
security code to prevent unauthorized
access to your base unit. This security
code prevents other cordless handsets
from making calls through your base unit.
If you want to reset the security code,
see page 44.
Step 1 (page 9)
Unpack the telephone and accessories.
Step 2 (page 10)
Secondly, choose the best location to set
up the base unit.
Step 5 (page 18)
Finally, install one of the headsets supplied
with your phone.
Step 3 (page 11 to 14)
Thirdly, insert the battery pack into the
handset. Connect the base unit. You must
charge the battery pack for 15-20 hours
before plugging into the phone line and
using the phone.
Step 4 (page 15 to 17)
Fourthly, set the Caller ID options, and store
your area code in the memory to use the Caller
ID service. Choose the language of your display.
Note: Skip the area code setting if your calling
area requires 10-digit dialing.
TRUC46_OM_B6 5/30/02 5:56 PM Page 8
GETTING STARTED [ 9 ]
Checking the Package Contents
Make sure you have received the following items in the package. If any of these items
are missing or damaged, contact the Uniden Parts Department.
• Base unit (1)
• Handset (1)
• AC adapter (1)
• Rechargeable battery (1)
• Telephone cord (1)
• Headset (2)]
• Holster (1)
Also included:
• This Owner’s Manual
• Other Printed Material
GETTING STARTED
Uniden Parts Department
(800) 554-3988
Hours: M-F 7:00 a.m. to 5:00 p.m. CST.
We can also be reached on the web at www.uniden.com.
TRUC46_OM_B6 5/30/02 5:56 PM Page 9
GETTING STARTED[ 10 ]
Setting up the Phone
Do the following steps:
A. Choose the best location C. Connect the base unit
B. Install the battery pack D. Choose the dialing mode
A. Choose the best location
Before choosing a location for your new phone, read “Installation Considerations” on page 50.
Here are some important guidelines you should consider:
Avoid excessive
moisture, extremely
low temperatures,
dust, mechanical
vibration, or shock
Avoid heat sources, such as
radiators, air ducts, and sunlight
Avoid television sets and
other electronic equipment
Avoid noise sources such as a window
by a street with heavy traffic
Avoid microwave ovens
Avoid personal computers
Avoid other cordless telephones
Choose a central location
TRUC46_OM_B6 5/30/02 5:56 PM Page 10
GETTING STARTED [ 11 ]
GETTING STARTED
B. Install the battery pack
Charge the battery pack for at least 15-20 hours before
plugging the phone line into your base unit.
1) Press down on the battery cover release and slide the cover
down until it comes off.
2) Connect the battery pack connector observing the correct
polarity (black and red wires) to the jack inside the battery
compartment.
Do not exert any force on this connection. It could cause
damage to the battery or to the handset. The plastic
connectors will fit together in only one way. Once you are
certain that you have made a good connection, then insert the
battery pack into the battery compartment. Do not pinch the
wires.
3) Securely close the battery compartment cover by sliding it up
until it snaps into place.
4) Place the handset in the charging cradle with the keypad
facing forward.
RED
BLACK
RED BLACK
•Use only the Uniden
battery (BT-925)
supplied with your
phone. Replacement
batteries are also
available through
the Uniden Parts
Department.
(See page 9.)
• Recharge your phone
on a regular basis by
returning the handset
to the base after each
phone call.
TRUC46_OM_B6 5/30/02 5:56 PM Page 11
GETTING STARTED[ 12 ]
Battery use time (per charge)
Fully charged
• 5 hours continuous use
• 8 days when the handset is in the standby mode
Cleaning the battery charging contacts
To maintain a good charge, it is important to clean the
battery contacts on the handset and base unit with a dry
cloth or a pencil eraser about once a month.
Do not use any liquids or solvents.
PAGE
STATUS
contacts
When you charge the handset, Caller ID summary screen and the name
of the handset, HS1 appears.
The last number dialed in the redial memory is retained for up to 2
minutes while you replace the battery pack.
Low battery alert
When the battery pack is very low and needs to be charged, the
phone is programmed to eliminate functions in order to save
power. If the phone is in the standby mode, ”Low Battery”
appears on the LCD and none of the keys will operate. If the
phone is in use, ”Low Battery” appears and the handset
beeps. Complete your conversation as quickly as possible and
return the handset to the base unit for charging.
TRUC46_OM_B6 5/30/02 5:56 PM Page 12
GETTING STARTED [ 13 ]
GETTING STARTED
•Use only the supplied AD-430 AC adapter.
Do not use any other AC adapter.
• Connect the AC adapter to a continuous power supply.
• Place the base unit close to the AC outlet so that you can unplug
the AC adapter easily.
C. Connect the base unit
1) Connect the AC adapter to the DC IN 9V jack and
to a standard 120V AC wall outlet.
2) Set the base on a desk or tabletop, and place
the handset in the base unit as shown.
3) Raise the antenna to a vertical position.
4) Make sure the status LED illuminates. If the LED does not
illuminate, check to see that the AC adapter is plugged in
and that the handset makes good contact with the base
charging contacts.
Place the power cord so
that it does not create
a trip hazard or where
it could become chafed
and create a fire or
electrical hazard.
• After installing the battery pack in the handset, charge your handset at least 15-20 hours
before plugging into the phone line. Once the handset battery pack is fully charged,
connect the telephone line cord to the base and telephone wall outlet.
5) Connect the telephone line cord to the TEL LINE jack and to
a telephone outlet once the handset is fully charged.
If your telephone outlet isn't modular type,
contact your telephone company for assistance.
Modular
TRUC46_OM_B6 5/30/02 5:56 PM Page 13
GETTING STARTED[ 14 ]
D. Choose the dialing mode
Most phone systems use tone dialing, which sends DTMF tones through the phone lines.
However some phone systems still use pulse dialing such as in rural areas. The default setting
is tone dialing. Depending on your dialing system, set the mode as follows:
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press UP or DOWN to move the pointer to “Dial Mode”.
3) Press SELECT/CH and the display will show the current setting.
(The initial setting is Tone.)
4) Press UP or DOWN to change the selection.
5) Press SELECT/CH, and you will hear a confirmation tone.
6) Press END to exit.
Throughout this manual, terms such as Standby and Talk Mode are used. Below is the
terminology explanation.
Standby Mode - The handset is not in use, is off the base, and TALK/FLASH has not been
pressed. A dial tone is not present and the display is blank.
Talk Mode - The handset is not on the base and TALK/FLASH has been pressed enabling a dial
tone. “Talk” appears on the display.
Terminology
• If you are not sure of
your dialing system,
set the unit to tone
dialing. Make a trial
call. If the call
connects, leave the
setting as is,
otherwise set the
unit to pulse dialing.
• If your phone system
requires pulse dialing
and you need to send
DTMF tones in certain
situations during a
call, you may
“switch-over” to tone
dialing. (Refer to
“Tone Dialing Switch-
over” on page 25.)
TRUC46_OM_B6 5/30/02 5:56 PM Page 14
GETTING STARTED [ 15 ]
GETTING STARTED
To change your Caller ID options:
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press UP or DOWN to move the pointer to
“Caller ID Setup”, then press SELECT/CH.
3) Press UP or DOWN to choose “Auto Talk” or “CIDCW”,
then press SELECT/CH.
4) Press UP or DOWN to change the selection.
AutoTalk: “Auto Talk On” or “Auto Talk Off”
CIDCW: “CIDCW On”, “CW Deluxe On” or “CIDCW Off”
5) Press SELECT/CH, and you will hear a confirmation tone.
To complete the setting, make sure to return the handset to the base.
Setting Caller ID Options
There are three Caller ID setup options available: AutoTalk, CIDCW (Caller ID on Call Waiting),
and Area Code. See page 16 for Area Code setup instructions.
AutoTalk allows you to answer the phone without pressing TALK/FLASH. If the phone rings
when AutoTalk is On, simply remove the handset from the base and the phone automatically
answers the call. Or if the handset is not on the base, press any number key, ✱/TONE, or #
to answer the call. If you set AutoTalk to Off, you must press TALK/FLASH to answer the call.
Caller ID on Call Waiting (CIDCW) performs the same as regular Caller ID on a call waiting
number. CW Deluxe allows you to handle call waiting calls in seven different ways. (See page 40)
You must subscribe to CIDCW from your phone company in order to use this feature.
The CW Deluxe is a separate service available through your phone company.
TRUC46_OM_B6 5/30/02 5:56 PM Page 15
GETTING STARTED[ 16 ]
Entering Your Area Code
If you enter a 3-digit area code number in the “Area Code” option, your local area code
does not appear in Caller ID messages. For calls received from outside your local area code,
you will see a full 10-digit number.
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press UP or DOWN to move the pointer to “Caller ID
Setup”, then press SELECT/CH.
3) Press UP or DOWN to move the pointer to “Area Code”,
then press SELECT/CH.
4) Use the number keypad (0to 9) to enter a 3-digit
area code.
5) Press SELECT/CH, and you will hear a confirmation tone.
• If your calling area
requires 10-digit
dialing, do not
program this option.
• When the area code
has already been
stored in memory,
the stored area code
will be displayed. To
change it, press
DEL/TRANS and the
number keypad to
enter the new
area code.
• To complete the
setting, press
SELECT/CH, then
return the handset
to the base.
TRUC46_OM_B6 5/30/02 5:56 PM Page 16
GETTING STARTED [ 17 ]
GETTING STARTED
Language option can be used to choose the language of your display. You can select
English, French, or Spanish.
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press DOWN to move the pointer to “Language“,
then press SELECT/CH.
3) Press UP or DOWN to choose English, French (Français),
or Spanish (Español).
4) Press SELECT/CH, and you will hear a confirmation tone.
Selecting a Language
TRUC46_OM_B6 5/30/02 5:56 PM Page 17
GETTING STARTED[ 18 ]
The headsets will be used to make or receive a call. With these headsets, you can have
the convenience of hands free communication while using your cordless phone. Two types
of headsets are included, an over the head and an over the ear type.
Headset Installation
Make sure you have installed one of the headsets before making or receiving a call.
Over the Head Type (HS910)
1) Place the headset on your head so the speaker covers
your ear. The other end of the headset should rest
comfortably against the side of your head above your
ear. Do not place the end of the headband against the
other ear.
2) The microphone arm swings over the top of the headset
so you can wear the headset on the left or right ear.
Position the flexible arm so the microphone is about 2
inches away from your mouth.
3) To use the headset, pull back the headset cover and plug
the headset cord into the 2.5mm jack on the top of the
handset. This will automatically disable the speaker on
the phone and activate the microphone on the handset.
During a call, you may plug or unplug the headset
without interrupting your conversation.
TRUC46_OM_B6 5/30/02 5:56 PM Page 18
GETTING STARTED [ 19 ]
Over the Ear Type (CS100)
1) Press the headset to your ear, then loop the ear-hook
behind your ear as shown.
2) Point the microphone toward your mouth.
3) To use the headset, pull back the headset cover and plug
the headset cord into the 2.5mm jack on the top of the
handset. This will automatically disable the speaker on
the phone and activate the microphone on the handset.
During a call, you may plug or unplug the headset
without interrupting your conversation.
GETTING STARTED
TRUC46_OM_B6 5/30/02 5:56 PM Page 19
BASICS[ 20 ]
Making and Receiving Calls
To make or receive a call, you need to install one of the supplied headsets. (See page 18.)
Refer to page 15
“Setting Caller ID
Options” to turn the
AutoTalk feature On
if desired. Any key
answer can be used
only when AutoTalk
is set to On.
Handset On Base Handset Off Base
Wear the headset.
To answer a call Pick up the handset (AutoTalk) Press any number key, ✱/TONE,
or pick up the handset and or #(Any Key Answer), or
press TALK/FLASH. press TALK/FLASH.
To make a call 1) Pick up the handset. 1) Press TALK/FLASH.
2) Press TALK/FLASH. 2) Listen for the dial tone.
3) Listen for the dial tone. 3) Dial the number.
4) Dial the number.
OR OR
1) Pick up the handset. Dial the number, then
2) Dial the number, then press TALK/FLASH.
press TALK/FLASH.
To hang up Press END, or return the handset to the base (AutoStandby).
To enter a pause When you dial the number, press RDL/P before pressing
within the TALK/FLASH. “P” appears in the display which represents
dialing sequence a pause.
TRUC46_OM_B6 5/30/02 5:56 PM Page 20
BASICS [ 21 ]
BASICS
Redialing a Call
The last three phone numbers dialed can be quickly redialed.
Redialing from Standby Mode
1) Press RDL/P. The phone number that was last
dialed appears on the display.
2) Press RDL/P again. Each press of RDL/P will display
one of the last three numbers dialed.
3) Press TALK/FLASH. The selected number is dialed.
To hang up, press END.
Redialing from Talk Mode
1) Press TALK/FLASH.
2) Press RDL/P. The last number dialed will be displayed and redialed.
To hang up, press END.
• If the number
exceeds 32 digits,
only the first 32
digits are retained
for redial.
• If you have not
pressed any key for
30 seconds, the
phone returns to
standby mode.
• If you press END,
the operation is
canceled and the
phone will return to
the standby mode.
• If the redial memory
is empty, you will
hear a beep.
• When using the
redial feature in talk
mode, only the last
number dialed will
be displayed.
RDL/P
RDL/P
RDL/P
TRUC46_OM_B6 5/30/02 5:56 PM Page 21
[ 22 ]
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press UP or DOWN to move the pointer to
“Ringer Volume”, then press SELECT/CH.
3) Press UP or DOWN to move the pointer through the ringer
settings (Ringer Off, Ringer Low, or Ringer High).
You will hear a ringer or melody at the selected volume
(or does not ring when you select “Ringer Off”).
4) Press SELECT/CH, and you will hear a confirmation tone.
If you select
“Ringer Off”,
<Ringer Off>
appears on the
display when you
make or receive
calls, or charging
the handset.
Ringer Volume Setup
The vibrator mode allows you to vibrate the phone when you receive
a call and the handset is off the base.
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press UP or DOWN to move the pointer to “Vibrator Mode”,
then press SELECT/CH.
3) Press UP or DOWN to choose “Vibrator On” or
“Vibrator Off”.
4) Press SELECT/CH. You will hear a confirmation tone.
Setting up the Vibrator Mode
BASICS
TRUC46_OM_B6 5/30/02 5:56 PM Page 22
[ 23 ]
If you set the ringer
to Off, the ringer
tone will not sound.
You can temporarily mute the ringer tone and stop the vibrator. When the handset
is off the base and the phone is ringing, press END. The ringer tone and vibrator
will return to the previous setting starting with the next incoming call.
Ringer Mute/Vibrator Stop
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press UP or DOWN to move the pointer to “Ringer Tones”,
then press SELECT/CH.
You can choose from 6 ringers or 4 melodies:
- Ringer [Flicker, Clatter, Leap Frog, Ping Ball, Reminder,
Soft Alert]
- Melodies [Beethoven9, For Elise (Elise), Merry Christmas
(Merry-Xmas), Home Sweet Home (Hm Swt Hm)]
3) Press UP or DOWN to move the pointer. You will hear the
ringer or the melody as you scroll through the options.
4) Press SELECT/CH and you will hear a confirmation tone.
Ringer Tone Setting
BASICS
BASICS
TRUC46_OM_B6 5/30/02 5:57 PM Page 23
[ 24 ]
“Distinctive Ringer” allows you to preset memory locations with a designated ring tone.
When an incoming call is received and the Caller ID information matches the information in
one of the memory locations, the Distinctive Ring that has been stored for that particular
caller will sound.
If you have set multiple memory locations with distinctive rings, switching the setting to
“Distinctive Off” will result in no distinctive ringing. All incoming calls will have a
normal ring tone. Switching to “Distinctive On” will activate all programmed
distinctive ring memory locations.
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press UP or DOWN to move the pointer to “Distinct. Ring”,
then press SELECT/CH.
3) Press UP or DOWN to choose “Distinctive On” or
“Distinctive Off”.
4) Press SELECT/CH, and you will hear a confirmation tone.
Distinctive Ringer Setup
See ”Storing Phone
Numbers, Names.
Distinctive Rings,
and Speed Dial” on
page 28 for storing a
Distinctive Ring in
the Phonebook.
Adjusting the Earpiece Volume
The handset earpiece volume settings (Volume Low, Volume Medium, Volume High, and
Volume Maximum) can only be adjusted during a call. Press DOWN or UP to select the
volume setting. When you hang up, the phone keeps the last volume setting selected.
When you press UP in maximum volume level or DOWN in lowest volume level, an error tone sounds.
BASICS
TRUC46_OM_B6 5/30/02 5:57 PM Page 24
[ 25 ]
Mute Microphone
You can temporarily turn Off the microphone so that the person
you are talking with cannot hear you. During a telephone call
press and hold MENU/MUTE to turn Off the microphone, and
“Mute” appears on the display. Press MENU/MUTE again to
cancel muting.
Tone Dialing Switch-over
Some telephone companies use equipment that requires pulse
dialing (sometimes referred to as rotary dialing). If you need to
enter tone dialing digits, you can switch-over to tone dialing
during the call. For example, entering your bank account number
after you have called your bank.
Initially make your call with the pulse dialing mode. Once your
call connects, press ✱/TONE. Enter the desired number. These
digits will be sent as tone dialing. Once the call ends, the tone
mode is canceled and pulse dialing mode resumes.
If you press END to cancel muting, the call is disconnected and the
phone will return to standby mode.
• The tone feature
only applies when
the dial mode is set
to pulse.
• This special number
can be stored in a
memory location.
This is referred to as
Chain Dialing. (See
page 35.)
BASICS
BASICS
TRUC46_OM_B6 5/30/02 5:57 PM Page 25
BASICS[ 26 ]
Traveling Out-of-Range
During a call, as you begin to move your handset too far from your base unit, noise
increases. If you pass the range limits of the base unit, your call will terminate
within 30 seconds.
Find Handset
Selecting a Different Channel
If you encounter interference while using your phone, you can manually change
the phone’s channel for clear operation. This function works only when the phone
is in use.
Press SELECT/CH. “Scanning” appears on the display, indicating the phone is
changing to another channel. For more information on interference, refer to
“Radio Interference” on page 50.
To locate the handset, press PAGE on the base. The handset
beeps for 60 seconds, and “Paging” appears on the display.
Paging is canceled when pressing any key on the handset or
PAGE on the base. Additionally, if you receive an incoming
call, page is canceled.
If the handset
battery is
completely drained,
the handset will not
beep when paging.
TRUC46_OM_B6 5/30/02 5:57 PM Page 26
BASICS [ 27 ]
BASICS
Flash and Call Waiting
If you have Call Waiting service and a call waiting tone sounds
while you are on a call, press TALK/FLASH to accept the waiting
call. There is a short pause, then you will hear the new caller.
To return to the original caller, press TALK/FLASH again.
Voice Mail LED
The voice mail LED on the handset is designed to work with your
voice mail service provided by your local telephone company.
The LED flashes when you have new incoming messages in the
voice mail service.
You may need to occasionally reset the indicator if it remains On
after you’ve retrieved your messages. To reset the indicator,
when the phone is in the standby mode press and hold PAGE on
the base until the paging sound stops (about 5 seconds).
You must subscribe
through your local
telephone company
to receive Call
Waiting Service.
TRUC46_OM_B6 5/30/02 5:57 PM Page 27
PHONEBOOK[ 28 ]
Phonebook allows you to dial a number using just a few key presses.
Your phone stores names/numbers in the phonebook memory location, and you can search
names in alphabetical order. You have a total of 100 locations that can be used for the
phonebook (including the Speed dials) and Caller ID messages.
1) When the phone is in the standby mode, press PB/ROCKET/t. The handset displays the
number of the phonebook locations used, and information on searching and storing
phonebook locations.
(1st line) the number of the phonebook locations used
(2nd line) How to search (Press the number keypad, UP or DOWN)
(3rd line) How to enter the storing operation (Press SELECT/CH)
2) Press SELECT/CH, then “Store/Edit Name” appears.
3) Store the name (up to 16 characters) by using the number keypad.
• See the “Steps for entering names and special characters” (see page 29).
• Use CID/sand PB/ROCKET/tto move the cursor to the desired location.
• Use DEL/TRANS to delete characters as needed.
• Press and hold DEL/TRANS to delete all the characters.
If a name is not required, go to step 4.
4) Press SELECT/CH to store the name, then
“Store/Edit No.” appears.
5) Press the number keypad to enter the phone number
(up to 20 digits), then press SELECT/CH to store the number.
Storing Phone Numbers, Names, Distinctive
Rings, and Speed Dial
• If you press END or
don’t press a key
within 30 seconds
while in the storing
operation, the phone
will return to the
standby mode.
• When the memory is
full, you will hear a
beep and “Memory
Full” appears. You
cannot store names
and numbers.
• The pause key
counts as one digit.
Pressing RDL/P more
than once increase
the length of pause
between numbers.
If you get an incoming call, a transferring call, or page, the operation is canceled.
Phonebook
TRUC46_OM_B6 5/30/02 5:57 PM Page 28
PHONEBOOK [ 29 ]
6) “Distinctive Ring” appears. Then press UP or DOWN to
move the pointer to one of the Distinctive Ring options, then
press SELECT/CH.
7) “Speed Dial” appears. Then press DOWN to move the pointer
to select the speed dial location (10 locations: SPD1-SPD0).
8) Press SELECT/CH. You will hear a confirmation tone and
“Done!” appears on the display.
PHONEBOOK
If you choose not to store a “Distinctive Ring”, simply select
the “No Selectn” option.
If you choose not to store the name/number as a Speed Dial, simply
select the “No Selectn” option.
Steps for Entering Names and Special Characters
Refer to the letters on the number keys to select the desired characters. With each press
of a number key (0-9), the displayed character appears in the following order: Upper case
letters first, lower case letters next and finally the number corresponding to the key.
Number of times key is pressed
If you select a speed
dial location where a
number is already
stored, the new
number will replace
the old number, and
the old number will
be stored as a
phonebook location.
TRUC46_OM_B6 5/30/02 5:57 PM Page 29
PHONEBOOK[ 30 ]
For example, to enter Uniden:
1) When the phone is in the standby mode, press PB/ROCKET/t. The handset displays the
number of phonebook locations you have stored, and how to search and store the
phonebook locations.
2) Press SELECT/CH, then “Store/Edit Name” appears.
3) Press 8twice.
4) Press 6five times.
5) Press 4six times.
6) Press 3four times, then press CID/sto move the cursor to the right.
7) Press 3five times.
8) Press 6five times.
9) When finished, press SELECT/CH.
To continue to store the telephone number, proceed to step 5 on page 28.
If the next character uses the same number key, you must press CID/sto move the cursor over. Otherwise
the next time you press the number key, it changes the character that was previously set.
If you make a mistake while entering a name
Use PB/ROCKET/tor CID/sto move the cursor to the incorrect character. Press DEL/TRANS
to erase the wrong character, then enter the correct character. To delete all characters, press
and hold DEL/TRANS.
TRUC46_OM_B6 5/30/02 5:57 PM Page 30
PHONEBOOK [ 31 ]
PHONEBOOK
•“/SD” appears on
the display when
you review the
RocketDial, and
“/SPDn” appears
when you review a
Speed dial.
• If you view the
phonebook during a
call and receive a
CIDCW (Caller ID on
Call Waiting), the
viewing operation
will be canceled.
• If you press END
while in the
operation, the phone
will return to the
standby mode
(or a call will be
disconnected when
you view the
phonebook during
a call).
• If you don’t press a
key within 30
seconds while in the
operation, the phone
will return to the
standby mode (or
back to a call when
you view the
phonebook during
the call).
Viewing the Phonebook
Your phone stores names/numbers in the phonebook memory locations, and you can search
names in alphabetical order. You can view the phonebook during a call as well as when the
phone is in the standby mode.
1) Press PB/ROCKET/t.
If you press PB/ROCKET/tduring a call, the following
screen appears.
2) Press UP or DOWN, or the number keypad to view the
phonebook locations.
a) Alphabetical order
Ascending order: Press DOWN to view locations. The location in the RocketDial
appears first in the display. Each time DOWN is pressed, phonebook locations appear
in ascending order.
Descending order: Press UP to view locations. A name starting with a number or a mark,
or <No Name> appears first. Each time UP is pressed, phonebook locations appear in
descending order.
b) From a number key
Refer to the letters on the number keys to select the first letter of the desired name.
Press a number key until any name with the same initial is displayed (See the table in
“Steps for Entering Names and Special Characters” on page 29).
For example, to search for “Uniden”, press 8 two times. Press DOWN or UP until the name
is displayed. If you press UP while the first name in “U” is displayed, a name starting
with “T” will appear, or if you press DOWN while the last name in “U” is displayed, a
name starting with “V” will appear.
3) Press PB/ROCKET/t(if you view the phonebook during a call) or END.
TRUC46_OM_B6 5/30/02 5:57 PM Page 31
PHONEBOOK[ 32 ]
Making Calls Using the Phonebook
From Standby Mode
1) When the phone is in the standby mode, press PB/ROCKET/t.
2) Press UP or DOWN to view the phonebook locations
(see “Viewing the Phonebook” on page 31).
3) Press TALK/FLASH. The displayed number is dialed.
From Talk Mode
1) Press TALK/FLASH.
2) Press PB/ROCKET/t.
3) Press UP or DOWN to view the phonebook locations
(see “Viewing the Phonebook” on page 31).
4) Press SELECT/CH. The number in the displayed phonebook location is dialed.
Speed Dialing
If you select a speed dial memory location (10 locations: SPD1 - SPD0) when storing a phone
number in the phonebook dial location, you can use the speed dialing feature. When the
phone is in the standby mode, press and hold a number key (0-9) associated with the speed
dial, then press TALK/FLASH. The phone number in the speed dial (SPD1 - SPD0) is dialed.
TRUC46_OM_B6 5/30/02 5:57 PM Page 32
PHONEBOOK [ 33 ]
PHONEBOOK
1) When the phone is in the standby mode, press PB/ROCKET/t.
2) Press UP or DOWN, or the number keypad to view the phonebook
locations (see “Viewing the Phonebook” on page 31).
a. Editing the Stored Data
1) When the phonebook location to be edited appears,
press SELECT/CH. “Store/Edit Name” appears.
2) Follow the steps 3 to 7 under “Storing Phone Numbers, Names, Distinctive
Rings and Speed Dial” on page 28-29 to complete editing operation.
3) Press SELECT/CH. You will hear a confirmation tone and “Done!” appears on
the display.
b. Deleting the Stored Data
1) When the phonebook location to be deleted appears,
press DEL/TRANS. “Delete Memory?” appears.
2) Press UP to move the pointer to “Yes”.
3) Press SELECT/CH. You hear a confirmation tone. “Deleted!”
appears in the display.
Editing or Erasing a Stored Name, Phone
Number, Distinctive Ring, and Speed Dial
TRUC46_OM_B6 5/30/02 5:57 PM Page 33
PHONEBOOK[ 34 ]
Storing the RocketDial
1) When the phone is in the standby mode, press PB/ROCKET/t.
2) Press DOWN once to display the RocketDial menu, then press
SELECT/CH. Store the name, phone number, and distinctive
ring by following the steps 3 to 6 under “Storing the Phone
Numbers, Names, Distinctive Rings and Speed Dial” on page
28-29.
3) Press SELECT/CH. You will hear a confirmation tone and “Done!”
appears on the display.
Making calls with the RocketDial
When the phone is in the standby mode, press and hold
PB/ROCKET/t. The number in the rocket location is dialed.
Deleting the RocketDial
1) When the phone is in the standby mode, press PB/ROCKET/t.
2) Press DOWN to display the RocketDial menu.
3) Press DEL/TRANS.
4) Press UP to move the pointer to “Yes”.
5) Press SELECT/CH. You will hear a confirmation tone.
RocketDial (One Touch Dialing)
You can store a number you dial often in the RocketDial. The
rocket dialing allows you to dial a number with one key press.
Memory location for
the RocketDial is
independent from
the memory location
for the phonebook.
TRUC46_OM_B6 5/30/02 5:57 PM Page 34
PHONEBOOK [ 35 ]
PHONEBOOK
Chain Dialing
The memory locations in the handset are not limited to phone numbers. You
can also store a group of numbers (up to 20 digits), that you need to enter
once your call connects. This is referred to as Chain Dialing.
An example of this is a bank account number. Store the special number in the
Phonebook location (refer to “Storing Phone Numbers, Names, Distinctive
Rings and Speed Dial” on page 28.). Once you have called your bank, and
when you are prompted to enter the account number, press PB/ROCKET/tand
DOWN to select the number in the Phonebook location, then press SELECT/CH.
TRUC46_OM_B6 5/30/02 5:57 PM Page 35
CALLER ID[ 36 ]
You must subscribe to Caller ID service to use this feature.
When the telephone rings, the Caller ID feature allows you to view the caller’s name and
phone number on the display before you answer the phone. Additionally, you can dial the
displayed number and store the information for memory dialing.
Make sure you have turned on the Caller ID/Call Waiting feature. (See page 15.)
Important:
Memory locations for Caller ID messages and Phonebook locations are common, you can store
up to 100 in total. A Caller ID message is not stored when you have stored 100 of the
phonebook locations. The earliest Caller ID message is overwritten when you have stored 100
of the phonebook locations and Caller ID messages in total.
• If you answer a call
before the Caller ID
message is received
(Example: before the
second ring), the
Caller ID message
will not appear.
• When the call is
received via a
telephone company
that does not offer
Caller ID service, the
caller´s phone
number and name do
not appear. (This
includes some
international calls.)
• When the call is via
a private branch
exchange (PBX), the
caller´s phone
number and name
may not appear.
If you get an incoming call, a transferring call, or page, the operation is canceled.
1) When the Caller ID message is received, the display shows the caller’s name and phone
number along with the date and time. The
incoming call information is stored in the
Caller ID record. If the Caller ID service
includes the caller’s name, the name will
appear on the display. (up to 15 characters.)
You may receive any one of the following messages:
When invalid data is received “Incomplete Data”
When a private name is received “Private Name”
When a private number is received “Private Number”
When a unknown name is received “Unknown Name”
When a unknown number is received “Unknown Number”
2) When you pick up the phone, the display changes to “Talk”.
(AutoTalk feature is set to On.)
Caller ID
TRUC46_OM_B6 5/30/02 5:57 PM Page 36
CALLER ID [ 37 ]
CALLER ID
Viewing the Caller ID List
The Caller ID list stores information for incoming calls – even unanswered calls.
You can store 100 of the Caller ID messages and phonebook locations (including
Speed dials) in total. You can view the Caller ID list during a call or when the
phone is in the standby mode.
1) Press CID/s.
The summary screen appears. The screen shows the number of
new messages and the total number of messages.
2) View Caller ID messages by following the procedure.
From new to old:
a. Press DOWN to display the latest Caller ID message.
b. Press DOWN to see the previous message.
From old to new:
a. Press UP to display the earliest Caller ID message.
b. Press UP to see the next message.
In alphabetic order:
Press the number keypad (2-9and 0) to display the Caller ID messages in
alphabetical order. Refer to the letters on the number keys to select the
desired letter.
3) Press CID/s(if you view the Caller ID list during a call) or END.
Once you view the Caller ID list in alphabetical order, you cannot switch to the Caller ID
display in historical order (from new to old or from old to new) unless you exit the operation.
• The number of calls
from the same Caller
ID appears next to
the received time.
Once you have
reviewed the new
message, the number
will be cleared
and disappears.
• If you press end
while in the
operation, the phone
will return to the
standby mode (or a
call will be
disconnected when
you view the Caller
ID list during a call).
• If you don’t press a
key within 30
seconds while in the
operation, the phone
will return to the
standby mode (or
back to a call when
you view the Caller
ID list during a call).
TRUC46_OM_B6 5/30/02 5:57 PM Page 37
CALLER ID[ 38 ]
Deleting a Caller ID message
1) While the incoming Caller ID information is displayed,
press DEL/TRANS. “Delete Message?” appears.
2) Press UP or DOWN to choose “Yes” or “No”.
3) Press SELECT/CH or DEL/TRANS.
When the pointer is at “Yes”: A tone sounds and the Caller ID message is deleted.
The next or previous Caller ID message is then displayed.
When the pointer is at “No”: The display returns to the Caller ID message.
Deleting all Caller ID names/numbers
1) Press CID/s.
2) Press DEL/TRANS.
3) Press UP or DOWN to choose “Yes” or “No”.
4) Press SELECT/CH or DEL/TRANS.
When the pointer is at “Yes”: A tone sounds and all stored Caller ID messages are deleted.
When the pointer is at “No”: The display returns to the summary screen.
Deleting Information from the Caller ID List
TRUC46_OM_B6 5/30/02 5:57 PM Page 38
CALLER ID [ 39 ]
CALLER ID
Calling a party from the Caller ID list
From Standby mode
1) Press CID/s. The summary screen appears. The screen shows
the number of new messages and the total number of messages.
2) Use the number keypad (2-9and 0), UP, or DOWN to view the
Caller ID message list.
3) Press TALK/FLASH. The displayed phone number dials automatically.
From Talk mode
1) Press TALK/FLASH.
2) Press CID/s. The summary screen appears.
3) View the Caller ID message you want to dial.
4) Press SELECT/CH. The displayed phone number will be dialed.
Long Distance calls and Area Code Setting/Cancellation
While the incoming Caller ID information is displayed, pressing ✱/TONE will place or
remove the prefix “1” in the display to set the call for a long distance call, or pressing #
will set or cancel an area code. (See page 16.)
Storing Caller ID messages in the Phonebook/RocketDial
Messages shown in the Caller ID list can be stored in the phonebook. Using the incoming
call information (i.e., Caller ID list), the phone number of the party on the Caller ID list
can be stored in memory.
1) When the phone is in the standby mode, while the incoming
Caller ID information is displayed, press PB/ROCKET/t.
2) Press UP or DOWN to choose “Store in PB?” (Phonebook
locations) or “Store in SD?” (RocketDial location). To
cancel Storing, select “Cancel”.
Using the Caller ID Message List
• You cannot make a
call from the Caller ID
list if your phone is
connected to a
private branch
exchange (PBX).
• When a long distance
call has been set,
“1” appears in
the display.
• If a call comes in via
a telephone system
that does not offer
Caller ID service, no
information is stored.
Talk
8002971023
TRUC46_OM_B6 5/30/02 5:57 PM Page 39
CALLER ID[ 40 ]
Call Waiting Deluxe Features
• To activate features,
select “CW Deluxe
On” in the Caller ID
setup. See page 15.
• You can also answer
a waiting call
immediately by
pressing TALK/FLASH,
the first caller will
be placed on hold.
To return to the
original caller, press
TALK/FLASH again.
Your TRUC46 series gives you new options for call waiting. At the touch of a button, you can
place the caller on hold, send them to your voice mail service, or conference them into your
current call. You may be required to subscribe to Call Waiting and Call Waiting Deluxe to use
these features. Not all features are available in all areas. Check with your local telephone
company for details.
1) When you receive a call waiting call, press MENU/MUTE for a list of options.
2) Press UP or DOWN, or the number keypad (1-7) to select an option. For example:
• You cannot store a Caller ID message in the phonebook if a phone number does not appear in the message.
• You cannot set the distinctive ring or speed dial in this step. If you would like to set these options, edit
the stored data.
• Even if the memory locations are full, the message will be stored in the Phonebook, however, the message
will be erased from the Caller ID List.
• If data is already stored in the RocketDial, the old data will be overwritten by the new data.
3) Press SELECT/CH. You will hear a confirmation tone.
DOWN
4 times
DOWN
2 times
3) Press SELECT/CH. A confirmation screen will appear.
Your TRUC46 series is pre-programmed with seven call waiting options. You may select to
ask the calling party to hold, send them a busy message, forward them to your voice mail,
or answer and drop the first caller. You may also select to conference them into the current
call or, at any time, choose to drop the first or drop the last caller.
Check with your local telephone company for a full list of options.
TRUC46_OM_B6 5/30/02 5:57 PM Page 40
EXPANDING YOUR PHONE [ 41 ]
EXPANDING YOUR
PHONE
Your phone supports up to 2 handsets (the original handset and the second handset). You
can now place a fully featured cordless handset anywhere AC power is available to connect
the handset charger. Additionally, you can transfer an outside call to another handset.
Expanding Your Phone
• We refer to the TXC400 handset as the second handset, and the TRUC46 handset as the original
handset in this section.
• Before use, you need to charge the battery pack for at least 15-20 hours, and for the TXC400
handset, register the handset.
• If the registration fails, “Registration Failed” appears. Register the TXC400 again.
• You must complete the registration operation within 30 seconds, or the phone returns to the
standby mode.
Registering the Second Handset
You need to register the second handset before using. To register the second
handset, do the following steps.
1) Unplug the AC adapter of the TRUC46.
2) Press and hold PAGE on the TRUC46 base, while you plug in the AC Adapter, until the
status LED on the base flashes.
3) Press TALK/FLASH on the TXC400’s handset. “Handset Registering” appears.
When the operation is finished, you will hear a confirmation tone and
“Registration Complete” will appear. The status LED is no longer illuminated.
If you changed the digital security code of the TRUC46:
You need to perform the following steps:
1) De-register the digital security code of the TXC400. (For instructions, see “Change the
Digital Security Code” in the owner’s manual supplied with the original unit.
2) Register the TXC400 to the original base by following the steps above.
TRUC46_OM_B6 5/30/02 5:57 PM Page 41
EXPANDING YOUR PHONE[ 42 ]
To transfer a call (to the second handset)
1) Press DEL/TRANS during a call. The call will automatically be
placed on hold and the transfer tone sounds.
2) When the other handset receives the call, the transfer tone
stops. To cancel the transfer, press DEL/TRANS or TALK/FLASH
on the handset.
To receive a transferred call (from the second handset)
Pick up a handset (when AutoTalk is set to On), or press
TALK/FLASH to answer the transferred call. Additionally, you can
answer the transferred call by pressing any number key, ✱/TONE,
or #(when AutoTalk is set to On).
Call Transfer Feature
You can transfer an outside call to the other handset.
If you transfer the call and it is not picked up after 5 minutes,
the call will be disconnected.
Setting up
Charging
Charge the second handset for 15-20 hours before using.
Dialing mode
Dialing mode is a universal setting. When the mode is changed on the original handset,
the setting for the second handset is changed as well.
Second Handset Operation
TRUC46_OM_B6 5/30/02 5:57 PM Page 42
EXPANDING YOUR PHONE [ 43 ]
EXPANDING YOUR
PHONE
CIDCW
• CIDCW setting is a universal setting. When the setting is changed on the original
handset, the CIDCW setting for the second handset is changed as well.
• CW Deluxe setting is independent from the original handset. To set the CW Deluxe setting
on the second handset, do the following.
1) When the phone is in the standby mode, press MENU/MUTE.
2) Press DOWN or UP to move the pointer to “Caller ID Setup”,
then press SELECT/CH.
3) Press DOWN or UP to select “CW Deluxe”, then press SELECT/CH.
4) Press DOWN or UP to select “CW Deluxe On” to active CW Deluxe features,
then press SELECT/CH.
Operation
Making and receiving calls
If you press TALK/FLASH on the handset while the other handset is in use, you will hear
a beep and the handset will return to the standby mode.
Security code
You can change the digital security code, only from the original handset.
Memory locations (Redial memory/Dynamic memory locations)
Memory locations in the original handset and the second handset are independent.
Page
If you press any key on a handset while paging, the paging sound from the other handset
will stop as well.
Caller ID
• When you receive a CIDCW during a call, the Caller ID information will not be displayed
or stored in the other handset.
• To display CIDCW on the second handset, you must turn On the CIDCW or CW Deluxe on
the original unit.
Others
• You can’t use or purchase the second handset as an alternative of the original handset.
• Save this owner’s manual. The TXC400 owner’s manual describes only the instructions
specific to the second handset. For detailed operation, refer to this owner’s manual.
TRUC46_OM_B6 5/30/02 5:57 PM Page 43
ADDITIONAL INFORMATION[ 44 ]
The digital security code is an identification code used to connect the handset and
the base unit. Normally, setting the code is not necessary. The first time you charge
your handset, the security code is automatically set. (See “About the digital security
code”, page 8.) In the rare situation that you suspect another cordless telephone is
using the same security code, you can change the code. To change the digital
security code, deregister the code, then register a different code.
Deregister the Security Code
1) Remove the handset from the base. In the standby mode, press and hold
DEL/TRANS and END until you hear a confirmation tone.
2) Press UP to select “Yes”, then SELECT/CH. You will hear a confirmation tone, and
“Deregistration Complete” appears.
Changing the Digital Security Code
• If you have not pressed any key for 30 seconds while in the de-registering operation, the
phone returns to the standby mode.
• While in de-registering operation, if you receive an incoming call, page, or transferring call, or
charge the handset, or press TALK/FLASH or END, the operation is canceled .
• While in de-registering operation, if you receive CIDCW when the speakerphone is used, the
operation is cancelled.
TRUC46_OM_B6 5/30/02 5:57 PM Page 44
ADDITIONAL INFORMATION [ 45 ]
ADDITIONAL
INFORMATION
Register the Security Code
1) Unplug the AC adapter.
2) Press and hold PAGE on the base, while you plug in the AC Adapter, until the
STATUS LED on the base flashes.
3) Press TALK/FLASH. “Handset Registering” appears.
When the registration operation is finished “Registration complete”
appears and the STATUS LED is no longer illuminated. You will hear a
confirmation tone and the phone returns to the standby mode.
• You must complete the registration operation within 30 seconds, or the phone returns to the
standby mode.
• During the registration operation, you cannot receive an incoming call, page, or make a call.
Installing the Holster
• Line up the groove on the back of the handset with the groove
on the holster. It fits in the holster only one way.
• Slide the phone into the holster.
• Use the spring clip to attach the holster to your belt or pocket.
• To use the function keys, slide the phone out of the holster.
TRUC46_OM_B6 5/30/02 5:57 PM Page 45
ADDITIONAL INFORMATION[ 46 ]
Note on Power Sources
Battery replacement and handling
When the operating time becomes short, even after a battery is recharged, please replace the battery.
With normal usage, your battery should last about one year.
Please contact your place of purchase or the Uniden Parts Department for a replacement battery. (See page 9)
Warning:
To avoid the risk of personal injury or property damage from fire or electrical shock, only use the Uniden
battery model and Uniden adapter model specifically designated for this product.
Power Failure
During the period that the power is off, you will not be able to make or receive calls with the telephone.
Caution
• Use the specified Uniden battery pack (BT-925).
• Do not remove the battery from the handset to charge it.
• Never throw the battery into a fire, disassemble it, or heat it.
• Do not remove or damage the battery casing.
Maintenance
When slightly dirty
Wipe with a soft, dry cloth.
When very dirty
Wipe with a soft cloth that has been dampened with
diluted, neutral detergent. Dry with a dry cloth.
When the charging terminals become dirty
Wipe with a dry cloth or a pencil eraser, if necessary.
Caution
Do not use paint thinner, benzene, alcohol,
or other chemical products.
Doing so may discolor the surface of the
telephone and damage the finish.
TRUC46_OM_B6 5/30/02 5:57 PM Page 46
ADDITIONAL INFORMATION [ 47 ]
ADDITIONAL
INFORMATION
General Information
The phone complies with FCC Parts 15 and 68. Operating temperature: 0 ºC to +50 ºC (+32 ºF to +122 ºF)
AC Adapter Information
AC Adapter part number: AD-430
Input Voltage: 120V AC 60Hz
Output Voltage: 9V DC 600 mA
Battery Information
Battery part number: BT-925
Capacity: 600 mAH, 3.7 V
Battery use time (per charge)
From fully charged
Talk mode duration: 5 hours
Standby mode duration: 8 days
Recharge your phone on a regular basis by returning the handset to the base after each phone call. When the
operating time becomes short, even after the battery is recharged, please replace the battery. With normal usage,
the battery should last about one year.
A replacement Uniden adapter and battery may be purchase Uniden accessories at your local Uniden dealer or by
contacting the Uniden Parts Department (800) 554-3988. Hours are from 7:00 a.m. to 5:00 p.m. CST, Monday
through Friday. We can also be reached on the web at www.uniden.com.
Specifications, features, and availability of optional accessories are all subject to change without prior notice.
If the handset is left off of the base, the actual Talk mode duration will
be reduced respective to the amount of time the handset is off the base.
TRUC46_OM_B6 5/30/02 5:57 PM Page 47
TROUBLESHOOTING[ 48 ]
Troubleshooting
If your phone is not performing to your expectations, please try these simple steps first.
Symptom Suggestion
The status LED won’t illuminate when • Make sure the AC adapter is plugged into the base and wall outlet.
the handset is placed in the base. • Make sure the handset is properly seated in the base.
• Make sure the charging contacts on the handset and base are clean.
The audio sounds weak • Move the handset and/or base to a different location away from metal objects
and/or scratchy. or appliances and try again.
• Press SELECT/CH to help eliminate background noise.
• Make sure that you are not too far from the base.
Can’t make or receive calls. • Make sure you have installed one of the headsets.
• Check both ends of the base telephone line cord.
• Make sure the AC adapter is plugged into the base and wall outlet.
• Disconnect the AC adapter for a few minutes, then reconnect it.
• Change the digital security code (See page 44).
• Make sure that you are not too far from the base.
The handset doesn’t ring or receive • The battery pack may be weak. Charge the battery on the base unit
a page. for 15-20 hours.
• The handset may be too far away from the base unit.
• Place the base unit away from appliances or metal objects.
• Change the digital security code (See page 44).
Severe noise interference. • Keep the handset away from microwave ovens, computers, remote control toys,
wireless microphones, alarm systems, intercoms, room monitors, fluorescent lights,
and electrical appliances.
• Move to another location or turn off the source of interference.
The Caller ID does not display. • The handset was picked up before the second ring.
• The call was placed through a switchboard.
• Call your local telephone company to verify your Caller ID service is current.
The handset doesn’t communicate • Change the digital security code (See page 44).
with the base or the other handset. • Make sure that you registered the second handset.
The second handset can’t join • Only one handset at a time can talk with an outside caller. To allow a different
the conversation. handset to talk to the caller, transfer the call to the other handset.
If you still have a problem. • Call our customer hotline at 1-800-297-1023.
TRUC46_OM_B6 5/30/02 5:57 PM Page 48
PRECAUTIONS & WARRANTY [ 49 ]
PRECAUTIONS &
WARRANTY
Precautions!
Before you read anything else, please observe the following:
Warning!
Uniden America Corporation DOES NOT represent this unit to be
waterproof. To reduce the risk of fire, electrical shock, or damage to
the unit, DO NOT expose this unit to rain or moisture.
Rechargeable Nickel-Metal-Hydride Battery Warning
• This equipment contains a rechargeable Nickel-Metal-Hydride
battery.
• Nickel is a chemical known to state of California to cause cancer.
• The rechargeable Nickel-Metal-Hydride battery contained in this
equipment may explode if disposed of in a fire.
• Do not short-circuit the battery.
• Do not charge the rechargeable Nickel-Metal-Hydride battery used
in this equipment in any charger other than the one designed to
charge this battery as specified in the owner’s manual. Using
another charger may damage the battery or cause the battery to
explode.
Rechargeable Nickel-Metal-Hydride
Batteries Must Be Recycled or
Disposed of Properly
Important Safety Instructions
When using your telephone equipment, these basic safety
precautions should always be followed to reduce the risk of fire,
electrical shock, and injury to persons:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Use a
dry cloth for cleaning without liquid or aerosol cleaners.
4. Do not use this product near water; for example, near a
bathtub, wash bowl, kitchen sink or laundry tub, in a wet
basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table.
The telephone may fall, causing serious damage to the unit.
6. Slots and openings in the cabinet and the back or bottom are
provided for ventilation. To protect the product from
overheating, these openings must not be blocked or covered.
This product should never be placed near or over a radiator or
heat register. This product should not be placed in a built-in
installation unless proper ventilation is provided.
7. This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your dealer or
local power company.
8. Do not allow anything to rest on the power cord. Do not locate
this product where the cord will be damaged by persons
walking on it.
9. Do not overload wall outlets and extension cords, as this can
result in the risk of fire or electrical shock.
10. Never push objects of any kind into this product through
cabinet slots, as they may touch dangerous voltage points or
short out parts that could result in a risk of fire or electric
shock. Never spill liquid of any kind on the product.
11.
To reduce the risk of electric shock, do not disassemble this
product. Take it to qualified service personnel when service or
repair work is required. Opening or removing covers may expose
you to dangerous voltages or other risks. Incorrect reassembly can
cause electric shock when the appliance is subsequently used.
12. Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. When the power supply cord is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally when following the
operating instructions. (Adjust only those controls that are
covered by the operating instructions. Improper adjustment
of other controls may result in damage and will often require
extensive repair work by a qualified technician.)
E. If the product has been dropped or the cabinet has
been damaged.
F. If the product exhibits a distinct change in performance.
13. Do not use the telephone to report a gas leak in the vicinity of
the leak.
Additional Battery Safety Precautions
Caution! To reduce the risk of fire or injury to persons by the
battery, read and follow these instructions:
1. Use only the Uniden battery pack specified in the
owner’s manual.
2. Do not dispose of the battery pack in a fire. The cell may
explode. Check the Nickel Metal Hydride battery disposal
package insert for disposal instructions.
3. Do not open or mutilate the battery pack. Released electrolyte
is corrosive and may cause damage to the eyes or skin. It may
be toxic if swallowed.
4. Exercise care in handling the battery in order not to short the
battery with conducting materials such as rings, bracelets, and
keys. The battery or conductor may overheat and cause burns.
5. Charge the battery pack provided with or identified for use with
this product only in accordance with the instructions and
limitations specified in the owner¬s manual provided for
this product.
6. Observe proper polarity orientation between the battery pack
and battery charger.
SAVE THESE INSTRUCTIONS!
Important Electrical Considerations
Unplug all electrical appliances when you know an electrical storm is
approaching. Lightning can pass through your household wiring and
damage any device connected to it. This phone is no exception.
WWaarrnniinngg!!
Please do not attempt to unplug any appliance during an
electrical storm.
The FCC Wants You To Know
Changes or modifications to this product not expressly approved by
Uniden, or operation of this product in any way other than as
detailed by the owner’s manual, could void your authority to
operate this product. The equipment cannot be used on public coin
phone service provided by the telephone company. Connection to
party line service is subject to state tariffs. (Contact the state
public utility commission, public service commission or corporation
commission for information.)
Range
Your new phone is designed to achieve the maximum possible range
by transmitting and receiving according to the highest
specifications set forth by the FCC. We have rated this phone to
operate at a maximum distance with the qualification that the
range depends upon the environment in which the telephone is
used. Many factors limit range, and it would be impossible to
include all the variables in our rating. The Maximum Range rating
of this phone is meant to be used as a means of comparison
against other range claims.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
TRUC46_OM_B6 5/30/02 5:57 PM Page 49
PRECAUTIONS & WARRANTY[ 50 ]
Telephone Line Problems
The FCC has granted the telephone company the right to disconnect
service in the event that your phone causes problems on the
telephone line. Also, the telephone company may make changes in
facilities and services which may affect the operation of your unit.
However, your telephone company must give adequate notice in
writing prior to such actions to allow you time for making
necessary arrangements to continue uninterrupted service.
If you are having trouble with your telephone service, you must
first disconnect your phone to determine if it is the cause of your
problem. If you determine that it is the cause, you must leave it
disconnected until the trouble has been corrected.
Radio Interference
Radio interference may occasionally cause buzzing and humming in
your cordless handset, or clicking noises in the base. This
interference is caused by external sources such as TV, refrigerator,
vacuum cleaner, fluorescent lighting, or electrical storm. Your unit
is NOT DEFECTIVE. If these noises continue and are too distracting,
please check around your home to see what appliances may be
causing the problem. In addition, we recommend that the base not
be plugged into a circuit that also powers a major appliance
because of the potential for interference. Be certain that the
antenna on the unit is fully extended when needed.
In the unlikely event that you consistently hear other voices or
distracting transmissions on your phone, you may be receiving
radio signals from another cordless telephone or other source of
interference. If you cannot eliminate this type of interference, you
need to change to a different channel.
Finally, it should be noted that some cordless telephones operate
at frequencies that may cause interference to nearby TVs and VCRs.
To minimize or prevent such interference, the base of the cordless
telephone should not be placed near or on top of a TV or VCR. If
interference is experienced, moving the cordless telephone farther
away from the TV or VCR will often reduce or eliminate
the interference.
More than One Cordless Telephone
If you want to use more than one cordless telephone in your home,
they must operate on different channels. Press the channel key to
select a channel that provides the clearest communication.
Cordless Telephone Privacy
Cordless telephones are radio devices. Communications between the
handset and base of your cordless telephone are accomplished by
means of radio waves which are broadcast over the open airways.
Because of the inherent physical properties of radio waves, your
communications can be received by radio receiving devices other
than your own cordless telephone unit. Consequently, any
communications using your cordless telephone may not be private.
Installation Considerations
Selecting a Location
Before choosing a location for your new phone, there are some
important guidelines you should consider:
• The location should be close to both a phone jack and
continuous power outlet. (A continuous power outlet is an AC
outlet which does not have a switch to interrupt its power.)
• Keep the base and handset away from sources of electrical noise
such as motors or fluorescent lighting.
•
Be sure there is sufficient space to fully extend the base antenna.
• The base can be placed on a desk or tabletop or mounted on a
standard telephone wall plate.
• You should charge your new phone for 15-20 hours before
completing the installation or using the handset.
Telephone Line Outlets
There are two types of phone outlets:
Modular Jack
Most phone equipment available now uses modular jacks. Phone
cords are fitted with a molded plastic connector which plugs into
this type of jack. If you do not have modular phone jacks,
contact your local telephone company for information about
their installation.
Hardwired Jack
Some equipment is wired directly to a phone jack, and these types
of installations require a modular jack converter. This type of
installation is not difficult; however, you should contact your
Uniden telephone dealer or a telephone supply store for advice
about the proper adapter or converter for your particular situation.
Connecting the Telephone Cords
Consider these safety guidelines before connecting the
telephone cords:
CCaauuttiioonn!!
•Never install telephone wiring during a lightning storm.
•Never touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected.
•Use caution when installing or modifying telephone lines.
Applying Power to the Base
This phone requires an AC outlet, without a switch to interrupt
power, and the included AC adapter. To relieve strain on the DC
plug when the phone is placed on a desk or table, wrap the power
cord around the strain relief notch on the bottom of the base.
NOTE: Place the power cord so that it does not create a trip
hazard, or where it could become chafed and create a
fire or other electrical hazards.
Plug the AC Adapter into a standard 120 VAC wall outlet.
Do not use an outlet controlled by a wall switch.
Use only the Uniden AC Adapter supplied with
this phone.
One Year Limited Warranty
Important: Evidence of original purchase is required
for warranty service.
WARRANTOR: UNIDEN AMERICA CORPORATION (“Uniden”)
ELEMENTS OF WARRANTY: Uniden warrants, for one year, to the
original retail owner, this Uniden Product to be free from defects
in materials and craftsmanship with only the limitations or
exclusions set out below.
WARRANTY DURATION: This warranty to the original user shall
terminate and be of no further effect 12 months after the date of
original retail sale. The warranty is invalid if the Product is (A)
damaged or not maintained as reasonable or necessary, (B)
modified, altered, or used as part of any conversion kits,
subassemblies, or any configurations not sold by Uniden, (C)
improperly installed, (D) serviced or repaired by someone other
than an authorized Uniden service center for a defect or
malfunction covered by this warranty, (E) used in any conjunction
with equipment or parts or as part of any system not manufactured
by Uniden, or (F) installed or programmed by anyone other than as
detailed by the owner’s manual for this product.
STATEMENT OF REMEDY: In the event that the product does not
conform to this warranty at any time while this warranty is in
effect, warrantor will either, at its option, repair or replace the
defective unit and return it to you without charge for parts,
service, or any other cost (except shipping and handling) incurred
by warrantor or its representatives in connection with the
performance of this warranty. Warrantor, at its option, may replace
the unit with a new or refurbished unit. THE LIMITED WARRANTY
SET FORTH ABOVE IS THE SOLE AND ENTIRE WARRANTY PERTAINING
TO THE PRODUCT AND IS IN LIEU OF AND EXCLUDES ALL OTHER
WARRANTIES OF ANY NATURE WHATSOEVER, WHETHER EXPRESS,
IMPLIED OR ARISING BY OPERATION OF LAW, INCLUDING, BUT NOT
LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. THIS WARRANTY DOES NOT
COVER OR PROVIDE FOR THE REIMBURSEMENT OR PAYMENT OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not
allow this exclusion or limitation of incidental or consequential
damages so the above limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state.
This warranty is void outside the United States of America.
PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY: If, after
following the instructions in the owner’s manual you are certain
that the Product is defective, pack the Product carefully
(preferably in its original packaging). The Product should include
all parts and accessories originally packaged with the Product.
Include evidence of original purchase and a note describing the
defect that has caused you to return it. The Product should be
shipped freight prepaid, by traceable means, to warrantor at:
Uniden America Corporation
Parts and Service Division
4700 Amon Carter Blvd.
Fort Worth, TX 76155
(800) 297-1023, 8 a.m. to 5 p.m. CST, Monday through Friday
TRUC46_OM_B6 5/30/02 5:57 PM Page 50
I.C. NOTICE [ 51 ]
I.C. NOTICE
I.C. Notice
TERMINAL EQUIPMENT
NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment Technical Specifications.
This is confirmed by the registration number. The abbreviation, IC, before the registration number signifies
that registration was performed based on a Declaration of Conformity indicating that Industry Canada
technical specifications were met. It does not imply that Industry Canada approved the equipment.
NOTICE: The Ringer Equivalence Number (REN) for this terminal equipment is marked on the equipment itself.
The REN assigned to each terminal equipment provides an indication of the maximum number of terminals
allowed to be connected to a telephone interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of
all the devices does not exceed five.
RADIO EQUIPMENT
The term “IC:” before the radio certification number only signifies that Industry Canada technical
specifications were met.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the device.
“Privacy of communications may not be ensured when using this telephone”.
TRUC46_OM_B6 5/30/02 5:57 PM Page 51
INDEX[ 52 ]
Index
0 - 9
10 ring options ..........................23
A
Area Code..................................16
AutoTalk....................................15
B
Battery pack
Preparing and charging..............11
Replacement and handling ........46
C
Caller ID ..................................36
Caller ID service ......................36
Calling....................................39
Call Waiting........................15, 40
Deleting..................................38
Setting ..................................15
Storing ..................................39
Using ....................................39
Viewing ..................................37
Call transfer feature ....................42
Chain dialing ............................35
Channel ....................................27
D
Deluxe Call Waiting Features ........40
Dialing mode..............................14
Digital security code................8, 44
Distinctive Ringer ......................24
E, F, G, H
Earpiece volume ........................24
General information ....................47
Headset installation ....................18
Holster ....................................45
I, J, K, L
I.C. Notice ................................51
Important Safety Instructions ......49
Language ..................................17
M, N, O
Maintenance ..............................46
Making a call ............................20
Mute ........................................25
One touch dialing ......................34
P, Q
Package contents..........................9
Phonebook ................................28
Editing ..................................34
Erasing ..................................34
Making calls ............................32
Storing ..................................28
Viewing ..................................31
Precautions................................49
R
Receiving a call..........................20
Redialing a call ..........................21
Registering the second handset ....41
Ringer volume ............................22
RocketDial ................................34
S
Second handset operation ............42
Setting up ................................10
Base unit ................................13
Handset ..................................11
Speed dialing ............................32
T, U, V, W, X, Y, Z
Transferring a call ......................42
Receive from the second handset 42
Transfer to the second handset ....42
Troubleshooting..........................48
Vibrator ....................................22
Voice Mail LED............................27
Warranty ..................................50
TRUC46_OM_B6 5/30/02 5:57 PM Page 52
At Uniden, we’ll take care of you!
If you need any assistance with this product, please call our Customer Hotline at
1-800-297-1023
PLEASE DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.
Our Uniden representatives will be happy to help you with any matters regarding
the operation of this unit, available accessories, or any other related matters.
Thank you for purchasing a Uniden product.
Hours: M-F 8:00 AM to 5:00 PM CST.
May be covered under one or more of the following U.S. patents:
4,511,761 4,523,058 4,595,795 4,797,916 5,381,460 5,426,690
5,434,905 5,491,745 5,533,010 5,543,605 5,574,727 5,581,598
5,650,790 5,660,269 5,661,780 5,663,981 5,671,248 5,696,471
5,717,312 5,732,355 5,754,407 5,758,289 5,768,345 5,787,356
5,794,152 5,801,466 5,825,161 5,838,721 5,864,619 5,893,034
5,912,968 5,915,227 5,929,598 5,930,720 5,960,358 5,987,330
6,044,281 6,070,082 6,125,277 6,253,088
?
Accessibility
For information on the accessibility features of this product, please call
1-800-874-9314 (V/TTY)
TRUC46_OM_B6 5/30/02 5:57 PM Page 53
back cover
TRUC46_OM_B6 5/30/02 5:57 PM Page 54
