Uniden America UN042R UPCS Handset User Manual AccHS indb
Uniden America Corporation UPCS Handset AccHS indb
user manual
Rechargeable battery
pack (BT-1018)
Charger AC adapter
(PS-0035) Battery cover
DCX400 accessory
handset and
charger
Belt clip
If any items are missing or damaged, contact our Customer Care Line
immediately. Never use damaged products!
Need Help? Get answers 24/7 at our website: www.uniden.com.
If You... Contact Uniden’s... Phone Number
have a question or problem Customer Care Line* 817-858-2929 or 800-297-1023
need a part or accessory Parts Department* 800-554-3988
need special assistance due
to a disability
Accessibility Help
Line
800-874-9314
(voice or TTY)
* During regular business hours, Central Standard Time. Visit our website for detailed
business hours.
Important Safety Precautions!
When using your telephone equipment, basic safety precautions should always be followed
to reduce the risk of re, electric shock and injury to persons, including the following:
Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool.
Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a
re. They may explode. Check with local codes for possible special disposal instructions.
Do not place the handset in any charging cradle without the battery installed and the battery
cover securely in place.
SAVE THESE INSTRUCTIONS!
DCX400 Accessory Handset User's Guide
What's in the box?
2
Installing Your Handset
Charge the Battery
1) Unpack the handset, battery pack, and battery cover.
If the battery cover is already on the handset, press in
on the notch and slide the cover down and off.
2) Line up the red and black wires on the
battery pack with the label inside the
handset.
3) Push the battery pack connector in until it
clicks into place. Tug gently on the wires
to make sure the battery pack is securely
connected.
4) Place the cover over the battery
compartment and slide
it up into place.
5) Connect the AC adapter to the charger's
AC IN 8V
jack and set the plug into
the notch as shown. (This adapter
might already be connected.)
6) Plug the other end of the adapter into
a standard 120V AC power outlet.
7) Place the handset in the charger with
the display facing forward. The
CHARGE
light should turn on.
If... Try...
the
CHARGE
light does not
turn on
-reseating the handset.
-checking the AC adapter connection.
-seeing if the outlet is controlled by a wall switch.
Charge the handset completely (about 15 hours) before using it.
Red
Black
3
Registering to a Base
The accessory handset won't work until you register it to a base!
Compatible Bases
This handset is designed for use with Uniden's DECT4086 and DECT4096 bases. Other
Uniden DECT6.0 bases might be compatible with this handset. For the most up-to-
date list of which bases this handset is compatible with, see our website.
Registration Methods
There are three different registration methods, but it's easy to figure out which one
applies to your handset and base. Answer the two questions to register the handset
to one of the compatible bases.
Does the handset t in the base cradle?
Yes Place the handset in the base. The display should say
Handset Registering
.
No Does the base have an LCD display?
Yes 1. On the base, open the menu and select
Register Handset
.
2. On the handset, press and hold
POUND (#)
until the handset
display says
Handset Registering (
about 2 seconds).
No 1. Disconnect the base AC adapter.
2. On the base, press and hold
FIND
while you reconnect the adapter.
3. On the handset, press and hold
POUND (#)
until the display says
Handset Registering
(about 2 seconds).
After about 30 seconds, the handset display should say
Registration Complete
.
Test the connection
Pick up the handset and press
TALK
. Make sure you get a dial tone. (Press
END
to hang up.)
If... Try...
-you don't hear a dial tone
-the display says
Registration Failed
Making sure the handset is fully
charged, then trying again.
4
Important Information
Because the handset adapts to the base, the exact features and operation of the
handset will vary slightly depending on which base you register the handset to.
Refer to the user guide for the base you're registering the handset to for feature
descriptions.
All features and operation for the handset are described in the user's guide for
one of the bases listed under the Compatible Bases section.
User guides for all Uniden phones are available on our website for free
downloading.
Speci cations
AC Adapter Part number Input Voltage Output Voltage
PS-0035 120V AC, 60 Hz 8V AC @ 300mA
Battery pack Part number Capacity
BT-1018 500mAh, 2.4V DC
Use only the supplied AC adapters.
Be sure to use the proper adapter for the base and any chargers.
Do not place the power cord where it creates a trip hazard or where it could
become chafed & create a fire or electrical hazard.
Do not place the unit in direct sunlight or subject it to high temperatures.
Battery Information
Fully charged, the battery should provide about 10 hours of talk time and about 7
days of standby time. For best results, return the handset to the cradle after each
call to keep it fully charged.
Keep an eye on the battery status icon. When the battery gets too low, the
handset shows a low battery alert. If you hear a strange beep during a call, check
the display: if you see the low battery alert, finish your conversation as quickly as
possible and return the handset to the cradle. If the handset is in standby, none of
the keys will operate.
With normal use, the battery should last about one year. Replace the battery
when the talk time becomes short even when the battery is charged. To buy a
replacement battery, call the Parts Department listed on the front cover.
5
Rechargeable Nickel-Metal-Hydride Battery Warning
CAUTION! Risk of explosion if battery is replaced by an incorrect type!
Dispose of used batteries according to the instructions. Do not open or
mutilate the battery. Disconnect the battery before shipping this product.
This equipment contains a rechargeable Nickel-Metal-Hydride battery.
Nickel is a chemicals known to the State of California to cause cancer.
Do not short-circuit the battery.
The rechargeable battery contained in this equipment may explode if disposed of in a re.
Do not charge the battery used in this equipment in any charger other than the one
designed to charge this battery as speci ed in the owner's manual. Using another charger
may damage the battery or cause it to explode.
Rechargeable batteries must be recycled or disposed of properly.
Uniden works to reduce lead content in PVC coated cords in our products &
accessories.
Warning! The cords on this product and/or accessories contain
lead, a chemical known to the State of California to cause birth
defects or other reproductive harm. Wash hands after handling.
Compliance Information
Changes or modi cations to this product not expressly approved by Uniden, or operation
of this product in any way other than as detailed by the owner’s manual, could void your
authority to operate this product.
FCC Part 15 information
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, & (2) This device
must accept any interference received, including interference that may cause undesired
operation. Privacy of communications may not be ensured when using this phone.
FCC PART 15.105(b): Note: This equipment has been tested & found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses & can radiate radio frequency energy &, if
not installed & used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
6
in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment o & on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit di erent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
To insure the safety of users, the FCC has established criteria for the amount of radio
frequency energy various products may produce depending on their intended usage.
This product has been tested & found to comply with the FCC's exposure criteria. For
body worn operation, the FCC RF exposure guidelines were also met when used with the
Uniden accessories supplied or designed for this product. Use of other accessories may
not ensure compliance with FCC RF exposure guidelines & should be avoided.
The antenna(s) used for the base-unit must be installed to provide a separation distance
of at least 20 cm from all persons & must not be collocated or operated in conjunction
with any other antenna or transmitter.
Industry Canada (I.C.) Notice
Terminal equipment
NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment
Technical Speci cations. This is con rmed by the registration number. The abbreviation
IC before the registration number signi es that registration was performed based on a
Declaration of Conformity indicating that Industry Canada technical speci cations were
met. It does not imply that Industry Canada approved the equipment.
NOTICE: The Ringer Equivalence Number (REN) for this terminal equipment is marked
on the equipment itself. The REN assigned to each terminal equipment provides an
indication of the maximum number of terminals allowed to be connected to a telephone
interface. The termination on an interface may consist of any combination of devices
subject only to the requirement that the sum of the Ringer Equivalence Numbers of all
the devices does not exceed 5.
Radio equipment
The term IC before the radio certi cation number only signi es that Industry Canada
technical speci cations were met. Operation is subject to the following two conditions: (1)
7
this device may not cause interference, & (2) this device must accept any interference,
including interference that may cause undesired operation of the device. "Privacy of
communications may not be ensured when using this telephone".
One-year Limited Warranty
Important: Evidence of original purchase is required for warranty service.
WARRANTOR: UNIDEN AMERICA CORPORATION ("Uniden")
ELEMENTS OF WARRANTY: Uniden warrants, for one year, to the original retail owner,
this Uniden Product to be free from defects in materials & craftsmanship with only the
limitations or exclusions set out below.
WARRANTY DURATION: This warranty to the original user shall terminate & be of no
further e ect 12 months after the date of original retail sale. The warranty is invalid if
the Product is (A) damaged or not maintained as reasonable or necessary, (B) modi ed,
altered, or used as part of any conversion kits, subassemblies, or any con gurations
not sold by Uniden, (C) improperly installed, (D) serviced or repaired by someone other
than an authorized Uniden service center for a defect or malfunction covered by this
warranty, (E) used in any conjunction with equipment or parts or as part of any system not
manufactured by Uniden, or (F) installed or programmed by anyone other than as detailed
by the owner's manual for this product.
STATEMENT OF REMEDY: In the event that the product does not conform to this warranty
at any time while this warranty is in e ect, warrantor will either, at its option, repair
or replace the defective unit & return it to you without charge for parts, service, or any
other cost (except shipping & handling) incurred by warrantor or its representatives
in connection with the performance of this warranty. Warrantor, at its option, may
replace the unit with a new or refurbished unit. THE LIMITED WARRANTY SET FORTH
ABOVE IS THE SOLE & ENTIRE WARRANTY PERTAINING TO THE PRODUCT & IS IN LIEU OF &
EXCLUDES ALL OTHER WARRANTIES OF ANY NATURE WHATSOEVER, WHETHER EXPRESS,
IMPLIED OR ARISING BY OPERATION OF LAW, INCLUDING, BUT NOT LIMITED TO ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
THIS WARRANTY DOES NOT COVER OR PROVIDE FOR THE REIMBURSEMENT OR PAYMENT
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow this exclusion
or limitation of incidental or consequential damages so the above limitation or exclusion
may not apply to you.
8
LEGAL REMEDIES: This warranty gives you speci c legal rights, & you may also have other
rights which vary from state to state. This warranty is void outside the United States of
America & Canada.
PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY: If, after following the
instructions in the owner's manual you are certain that the Product is defective, pack the
Product carefully (preferably in its original packaging). Disconnect the battery from the
Product & separately secure the battery in its own separate packaging within the
shipping carton. The Product should include all parts & accessories originally packaged
with the Product. Include evidence of original purchase & a note describing the defect
that has caused you to return it. The Product should be shipped freight prepaid, by
traceable means, to warrantor at:
Uniden America Service
4700 Amon Carter Blvd.
Fort Worth, TX 76155
Uniden® is a registered trademark of Uniden America Corporation.
Call waiting, CID, CIDCW, & Voice Mail are telephone line services. Your phone supports
these services, but you have to arrange for them through your telephone provider. Contact
your provider for details.
The pictures in this manual are for example only. Your phone may not look exactly like the
pictures.
May be covered under one or more of the following U.S. patents:
5,671,248 5,717,312 5,732,355 5,754,407 5,758,289 5,768,345 5,787,356 5,794,152 5,801,466
5,825,161 5,864,619 5,893,034 5,912,968 5,915,227 5,929,598 5,930,720 5,960,358 5,987,330
6,044,281 6,070,082 6,076,052 6,125,277 6,253,088 6,314,278 6,321,068 6,418,209 6,618,015
6,714,630 6,782,098 6,788,920 6,788,953 6,839,550 6,889,184 6,901,271 6,907,094 6,914,940
6,940,867 6,953,118 7,023,176 7,030,819 7,146,160 7,203,307 7,206,403 7,310,398 7,460,663
Other patents pending.
As an Energy Star® Partner, Uniden has
determined that this product meets the
Energy Star® guidelines for energy e ciency.
Energy Star® is a U.S. registered mark.
© 2009 Uniden America Corp. Printed in Vietnam
Fort Worth, TX, 76050 UUZZ01690BZ(0)
