Uniden America UT024 PORTABLE FRS/GMRS RADIO User Manual USERS MANUAL
Uniden America Corporation PORTABLE FRS/GMRS RADIO USERS MANUAL
USERS MANUAL
GMR1035-2
*Range may vary depending on environmental and/or topographical conditions.
• 15 GMRS / 7 FRS Channels
• Long Battery Life
• Up to 10-mile Range*
• Channel Scan
• Channel Monitor
• Battery Strength Meter
• Call Button
• Roger Beep
• Keytone on/off
1 Antenna
2 PTT (Push-To-Talk) Button
3 Channel/Scan up Key
4 Call/lock Key
5 Channel/Scan down Key
6 Speaker
7 Volume up/Monitor Key
8 Power On/Off Key
9 Volume down/Monitor Key
10 Microphone
11 Channel Indicator
12 Receive Indicator
13 Battery Level Indicator
14 Transmit Indicator
Congratulations on your purchase of the
Uniden GMR1035-2 (General Mobile Radio
Service) radio. This lightweight, palm-sized,
radio is a state-of-the-art device, equipped
with many valuable features. Use it at sporting
events, to stay in contact with family and
friends, hiking, skiing, outdoors, or in a
neighborhood watch for vital communication.
PACKAGE CONTENTS
Your package contains the 2 GMR1035 radios,
6 AAA alkaline batteries, this reference guide
and 2 belt clips.
FCC GMRS LICENSE
The GMR1035-2 radio operates on the
General Mobile Radio Service (GMRS)
frequencies which require a Federal
Communications Commission license to
operate. For licensing information and
application forms, visit the FCC on-line
at:www.fcc.gov/wtb/uls or call the FCC
hotline at 1-800-418-3676. If you have any
questions you can contact the FCC direct at
1-888-225-5322.
INSTALL THE BATTERIES
Your GMR1035-2 radio uses 3 AAA alkaline
batteries for power. We recommend using high
quality alkaline batteries.
To install the batteries:
1) Make sure your radio is OFF.
2) Remove the battery compartment door by
pressing on and sliding the compartment
door, and remove the cover.
3) Install 3 AAA Alkaline batteries into the
battery compartment. Be certain to follow
the + and – symbols in the compartment.
Installing the batteries incorrectly will
prevent the unit from operating.
4) Replace the battery compartment door by
sliding the door into place.
USING THE RADIO
In order to get the most out of your new radio, read
this reference guide completely before attempting to
operate the radio.
Turning the Radio On and Adjusting the Volume
1) Press and hold the key to turn the radio ON.
2) To change the volume level press the vol/mon ▲
or ▼key to increase or decrease the volume
level.
3) Press and hold the key to turn the radio OFF.
Adjusting the Sound (Key Beeps)
Your radio emits a beep each time one of the keys
(except for the PTT button and call/lock key) is
pressed. The sound of the Key Beep will increase or
decrease depending on the volume level setting.
To turn OFF this beep:
Press and hold the call/lock key while turning ON
the radio.
To turn ON this beep:
Turn the radio OFF and ON again without pressing
the call/lock key.
Choosing a Channel
Your GMR1035-2 radio has 22 channels you can
use to talk to others. In order to speak to someone,
each of you must be set to the same channel.
To choose a channel:
Press the ch/scan ▲or ▼key to increase or
decrease the channel number displayed.
Channel Scan Feature
Your GMR1035-2 radio has a channel scan feature
that allows you to easily scan all 22 channels. When
an active channel is detected, the unit pauses on
that channel until the channel is clear. Then after a 2
second delay, the radio continues scanning.
Pressing PTT button while the scan is paused on a
channel will allow you to transmit on that channel.
To turn ON channel scan:
Press and hold either the ch/scan ▲or ▼key for
3 seconds. The channel number on the display will
rapidly cycle through the channels.
To turn OFF channel scanning:
Press either the ch/scan ▲or ▼key.
Talking on Your Radio
To talk to others using the radio:
1) Press and hold the PTT button and speak in a
clear, normal voice about 2-3 inches away from
the microphone.
While you are transmitting, the tx icon is
displayed. To avoid cutting off the first part of
your transmission, pause slightly after pressing
the PTT button before you start talking.
2) When you are finished speaking, release the
PTT button. You can now receive incoming calls.
While receiving, the rx icon is displayed.
Transmitting a Call Alert Tone
Your GMR1035-2 radio is equipped with a call tone
that will be transmitted when the call/lock key is
pressed.
To transmit the call tone, tap the call/lock key. The
tone will be transmitted.
Auto Squelch Feature
The GMR1035-2 is equipped with an automatic
squelch system which shuts off weak transmissions
and unwanted noise due to terrain conditions or if
you have reached your range limit.
Monitor Mode Feature
Your GMR1035-2 radio allows you to listen for weak
signals on the current channel at the press of a key.
To turn ON monitor mode:
Press and hold the vol/mon ▲or ▼key.
The rx icon will blink.
To turn OFF monitor mode:
Press the vol/mon ▲or ▼key. The rx icon will
stop blinking and disappears.
Automatic Power Save Feature
Your GMR1035-2 has a unique circuit designed to
dramatically extend the life of the batteries. If there is
neither a transmission nor an incoming call within 2
seconds, your radio switches to the Power Save mode.
The radio is still able to receive transmissions in this
mode.
KEYLOCK ON/OFF
Press and hold the call/lock key until the "L"
appears. After 1 second, the LCD will return to the
channel display.
To exit Keylock on mode, press and hold call/lock
again.
Note: While in keylock on mode, it will still receive
transmissions.
SPECIFICATIONS
Channels 15 GMRS / 7 FRS
Operating Frequency UHF 462.5500-
467.7125 MHz
Power Source 3 AAA Alkaline Batteries
Battery Life 20 Hours typical
(5/5/90 duty cycle)
Frequency Chart
Ch. Freq.
[MHz]
Cross Ref. Ch. Freq.
[MHz]
Cross Ref.
1 462.5625 FRS & GMRS 1 12 467.6625 FRS 12
2 462.5875 FRS & GMRS 2 13 467.6875 FRS 13
3 462.6125 FRS & GMRS 3 14 467.7125 FRS 14
4 462.6375 FRS & GMRS 4 15 462.5500 GMRS 11
5 462.6625 FRS & GMRS 5 16 462.5750 GMRS 8
6 462.6875 FRS & GMRS 6 17 462.6000 GMRS 12
7 462.7125 FRS & GMRS 7 18 462.6250 GMRS 9
8 467.5625 FRS 8 19 462.6500 GMRS 13
9 467.5875 FRS 9 20 462.6750 GMRS 10
10 467.6125 FRS 10 21 462.7000 GMRS 14
11 467.6375 FRS 11 22 462.7250 GMRS 15
ROGER BEEP
Roger Beep is a BEEP that is sent automatically at
the end of transmissions.
Roger Beep can be heard through the speaker
when both Roger beep and Key Beep are set to
ON. When Roger beep is set to ON and Key Beep
OFF, Roger Beep will not be heard from the
speaker but it will be transmitted to your party.
When Roger Beep is set to OFF, Roger Beep
neither be heard nor transmitted.
To turn OFF Roger Beep:
Press and hold the ch/scan ▲key while turning
ON the radio.
To turn ON Roger Beep:
Turn the radio OFF and ON again without pressing
ch/scan ▲key.
Note: If you press either the ch/scan ▲
or ▼key while the unit is pausing on a
channel, scanning will resume.
*UT024ZH_GMR1035-2_E_1117 11/17/06 5:35 PM Page 1
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Important: Changes or modifications to this unit
not expressly approved by Uniden could void your
authority to operate this unit. Your radio is set up
to transmit a regulated signal on an assigned
frequency. It is against the law to alter or adjust the
settings inside the radio to exceed those limitations.
Any adjustments to your radio must be made by
qualified technicians.
To be safe and sure:
• Never open your radio’s case.
• Never change or replace anything in your radio
except the batteries.
Your radio might cause TV or radio interference
even when it is operating properly. To determine
whether your radio is causing the interference, turn
it off. If the interference goes away, your radio is
causing it. Try to eliminate the interference by
moving your radio away from the receiver. If you
cannot eliminate the interference, the FCC requires
that you stop using the radio.
Hazardous Environments: Do not operate the
radio in hazardous environments. Explosion or fire
may result. Do not operate the radio near
unshielded electrical blasting caps.
Under certain conditions, radios can interfere with
blasting operations and may cause an explosion.
Turn your radio OFF to prevent accidental
transmission when in a blasting area or in areas
posted: "Turn off two-way radio." Construction
crews often use remote control RF devices to set
off explosives.
Care and Safety: To clean the radio, use a soft
cloth dampened with water. Do not use cleaners or
solvents because they can harm the body of the
unit and leak inside, causing permanent damage.
Use a dry, lint-free cloth to clean the battery
contacts. Do not submerge the unit in water. If the
unit gets wet, turn it off and remove the batteries
immediately.
Dry the battery compartment with a soft cloth to
minimize potential water damage. Leave the battery
compartment cover off overnight to ensure
complete drying. Do not use the radio until the unit
is completely dry.
Important: Evidence of original purchase is
required for warranty service.
WARRANTOR: UNIDEN AMERICA
CORPORATION ("Uniden")
ELEMENTS OF WARRANTY: Uniden warrants, for
one year, to the original retail owner, this Uniden
Product to be free from defects in materials and
craftsmanship with only the limitations or exclusions
set out below.
WARRANTY DURATION: This warranty to the
original user shall terminate and be of no further
effect 12 months after the date of original retail
sale. The warranty is invalid if the Product is:
(A) damaged or not maintained as reasonable or
necessary, (B) modified, altered, or used as part
of any conversion kits, sub-assemblies, or any
configurations not sold by Uniden, (C) improperly
installed, (D) serviced or repaired by someone
other than an authorized Uniden service center for
a defect or malfunction covered by this warranty,
(E) used in any conjunction with equipment or parts
or as part of any system not manufactured by
Uniden, or (F) installed or programmed by anyone
other than as detailed by the owner’s manual for
this product.
STATEMENT OF REMEDY: In the event that the
product does not conform to this warranty at any
time while this warranty is in effect, warrantor will
either, at its option, repair or replace the defective
unit and return it to you without charge for parts,
service, or any other cost (except shipping and
handling) incurred by warrantor or its
representatives in connection with the performance
of this warranty. Warrantor, at its option, may
replace the unit with a new or refurbished unit.
THE LIMITED WARRANTY SET FORTH ABOVE
IS THE SOLE AND ENTIRE WARRANTY
PERTAINING TO THE PRODUCT AND IS IN LIEU
OF AND EXCLUDES ALL OTHER WARRANTIES
OF ANY NATURE WHATSOEVER, WHETHER
EXPRESS, IMPLIED OR ARISING BY
OPERATION OF LAW, INCLUDING, BUT NOT
LIMITED TO ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.THIS WARRANTY DOES
NOT COVER OR PROVIDE FOR THE
REIMBURSEMENT OVERPAYMENT OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow this exclusion or limitation
of incidental or consequential damages so the
above limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you
specific legal rights, and you may also have other
rights which vary from state to state. This warranty
is void outside the United States of America and
Canada.
PROCEDURE FOR OBTAINING PERFORMANCE
OF WARRANTY: If, after following the instructions
in the owner’s manual you are certain that the
Product is defective, pack the Product carefully
(preferably in its original packaging). The Product
should include all parts and accessories originally
packaged with the Product. Include evidence of
original purchase and a note describing the defect
that has caused you to return it.The Product should
be shipped freight prepaid, by traceable means, to
warrantor:
ONE YEAR LIMITED WARRANTYFCC INFORMATION
WARNING! Read this information before using
the radio
In August 1996 the Federal Communications
Commission (FCC) of the United States with its
action in Report and Order FCC 96-326 adopted
an updated safety standard for human exposure to
radio frequency electromagnetic energy emitted by
FCC regulated transmitters.
Those guidelines are consistent with the safety
standard previously set by both U.S. and
international standards bodies. The design of the
radio complies with the FCC guidelines and these
international standards.
Never allow children to operate the radio without
adult supervision and the knowledge of the
following guidelines.
WARNING! It is up to the user to properly operate
this radio transmitter to insure safe operation.
Please adhere to the following:
Use only the supplied or an approved antenna.
Unauthorized antennas, modifications, or
attachments could impair call quality, damage the
radio, or result in violation of FCC regulations.
Do not use the radio with a damaged antenna. If a
damaged antenna comes into contact with the skin,
a minor burn may result. Please contact your local
dealer for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn
operations using the supplied belt-clip.
To maintain compliance with FCC RF exposure
requirements, Body-worn operations are restricted
to the supplied belt-clip.
For hand-held operation, the radio should be held
1 inch from the user's face. The use of accessories
that do not satisfy these requirements may not
comply with FCC RF exposure requirements and
should be avoided.
For more information about RF exposure, please
visit the FCC web site at www.fcc.gov.
FCC RF EXPOSURE INFORMATION
Covered under one or more of the following
U.S. patents:
4,684,870 4,734,049 5,203,015 5,214,789
5,491,745 5,497,508 5,517,677 5,557,606
5,574,994 5,610,946 5,613,201 5,625,870
5,627,876 5,628,059 5,634,196 5,634,205
5,678,176 5,697,096 5,717,312 5,722,070
5,787,345 5,901,341 6,021,326 6,084,861
6,163,691 6,195,415 6,353,730 6,839,550
6,980,770
Uniden America Corporation
Parts and Service Division
4700 Amon Carter Blvd., Fort Worth, TX 76155
(800) 297-1023, 7:00 a.m. to 7:00 p.m. CST,
Monday through Friday: 9:00 a.m. to 5:00 p.m. CST,
Saturday, Sunday and Holidays
(except Thanksgiving and Christmas).
www.uniden.com
© 2007 Uniden America Corporation
All rights reserved Printed in China
UTZZ01024ZZ(0)
*UT024ZH_GMR1035-2_E_1117 11/17/06 5:35 PM Page 2
