Uniden America UT042 PORTABLE FRS/GMRS PTT RADIO User Manual UT042ZH GMR2875 2CK 0722 1002 indd
Uniden America Corporation PORTABLE FRS/GMRS PTT RADIO UT042ZH GMR2875 2CK 0722 1002 indd
Users Manual
GMR2872-2CK/GMR2875-2CK
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
20
21
LIQUID CRYSTAL DISPLAY
19
*Range may vary depending on environmental and/or topographical conditions.
•
15 GMRS / 7 FRS Channels
•
142 Privacy Codes (CTCSS Tone
and DCS Code)
•
Up to 28 Mile Range*
•
Submersible design
•
Direct Call
•
143 Group Codes
•
Silent Mode
•
10 Selectable Call/Ring Tone Alerts
•
Backlit LCD Display
•
Roger Beep
•
Vibrate Reminder
(GMR2875 Only)
1 Antenna
2 PTT (Push-To-Talk) Button
3 Power Boost Button
4 Monitor Button
5 Channel Up/Down Key
6 Tone/Group Key
7 D-call Key
8 Menu/Power key
9 Volume Up/Down key
10 Enter/Lock Key
11 Weather/Alert Key
12 Microphone
13 Speaker
14 Battery Level Indicator
15 Sub Code Indicator
16 Alert Indicator
17 Group Indicator
18 Receive Indicator
19 Call Indicator
20 Channel Indicator
21 Missed Call Indicator
22 Charging Contacts
Congratulations on your purchase of the Uniden
GMR2872-2CK/GMR2875-2CK (General Mobile
Radio Service) waterproof radio. This lightweight,
palm-sized, radio is a state-of-the-art device,
equipped with many valuable features. Use it at
sporting events, to stay in contact with family and
friends, hiking, skiing, outdoors, or in a
neighborhood watch for vital communication - even
outside by the pool!
Your radio complies with JIS7 water-resistant
standards, which means the radio can be
submerged in 1.0 meters of water for 30
minutes without damage.
After your radio is submerged in water, you might
notice that the sound is distorted. This is because
there is still water remaining in and around the
speaker and microphone. Just shake the radio to
clear excess water, and the sound should return to
normal.
Note: If your radio is exposed to salt water, clean
your radio thoroughly with fresh water, and dry it
before turning it on.
PACKAGE CONTENTS
Your package contains two radios, two rechargeable
NiMH battery packs (#BP38), one AC adapter (#AD-
314), one charging cradle (#RC1282), two belt clips
and this reference guide. You can operate the unit
using the rechargeable NiMH battery pack.
To order the following optional accessories, visit our
web site @www.uniden.com or call 1-800-554-3988
during business hours.
Use only Uniden accessories.
• NiMH Battery Pack - #BP38
• Charging Cradle - #RC1282
• AC Adapter - #AD-314
GMRS LICENSE
The radio operates on the General Mobile Radio
Service (GMRS) frequencies when using
Channels 1-7 and channels 15-22. You must
have a GMRS license issued by the Federal
Communications Commission to legally use
these channels. For licensing information and
application forms, visit the FCC online at: www.
fcc.gov/wtb/uls or call the FCC hotline at 1-800-
418-3676. If you have any questions, you can
contact the FCC direct at 1-888-225-5322. No
license is required for operation on channels
8-14 or operation on any channel in Canada.
INSTALL THE BATTERY
Your radio uses a supplied NiMH battery pack.
To install the NiMH battery pack:
1) Make sure the radio is off.
2) Turn the screw holding the battery compartment
counterclockwise with a screwdriver, and hold
up the battery cover.
3) Put the NiMH battery pack in the battery
compartment applying the battery contacts to
the lower charge contacts. Be sure to follow the
instructions written on the battery pack’s label.
Installing the battery pack incorrectly will prevent
the unit from operating.
4) Before placing the battery cover back on the
radio, check the rubber seal around the battery
compartment and the ribbon of the battery pack
: make sure that the seal is in good condition
and that there is no foreign matter under the
seal.
5) Replace the battery compartment door. Tighten
the screws securely.
Note: If the rubber seal appears warn, nicked, or
dried out, replacement seals are available from
www.uniden.com or call 1-800-554-3988 during
business hours.
USING THE RADIO
SETTING UP GROUP MODE
USING THE RADIO BATTERY LEVEL AND LOW
BATTERY ALERT
This radio has a battery level meter that indicates
the status of the batteries. When the battery level is
low, the battery level meter icon flashes and
then BATT appears after 30 seconds. Recharge
the NiMH battery pack immediately.
Warning! To avoid the risk of personal injury or
property damage from fire or electrical shock, only
use the Uniden accessories specifically designated
for this product.
GMR2872-2CK/GMR2875-2CK RADIO
CHARGING THE RADIO
Your radio includes charging cradle and
rechargeable battery packs. Follow these
instructions to recharge the radios in a charging
cradle.
Make sure to turn the radio OFF before placing
the radio in the charging cradle.
Using the Charging Cradle
1) Connect the adapter's plug to DC IN 9V jack of
the charging cradle and plug the other end into
an AC outlet.
In order to get the most out of your new radio, read
this reference guide completely before attempting to
operate the unit.
Turning the Radio On and Adjusting the Volume
1) Press and hold the MENU/ to turn the radio
ON.
2) To change the volume level, press the
VO or to increase or decrease the volume
level then press ENTER/ .
3) Press and hold the MENU/ to turn the radio
OFF.
Choosing a Channel
Your radio has 22 channels and 142 Privacy codes
you can use to talk to others. In order to speak to
someone, both your radios must be set to the same
channel and Privacy code.
To choose a channel:
Press CH or to increase or decrease the
channel number displayed.
• To change the channel continuously, press
CH or , then repeatedly press and hold
CH or for more than 1 second.
Note: Channels 1-7 and 15-22 have a typical range
of up to 28 miles by pressing the Power Boost.
HI is displayed when you select a GMRS channel,
and LO is displayed when you select a FRS
channel.
2) Set the charging cradle on the desk or tabletop,
and place the radio in the charging cradle with
the keypad facing forward.
3) Make sure that the LED illuminates. Charge the
battery pack for 16 hours and remove the radio
from the charging cradle after charging.
Note:
• Charge time may vary depending on the battery
life remaining.
• For fastest charging, turn off the radio before
charging.
Warrning!:
• The charging cradle is not waterproof. If the
charging cradle falls into water, unplug it before
attempting to remove it from the water. Allow the
cradle to dry completely before reconnecting the
power.
• Wipe off dirt or shake water from your radio
before placing in the charging cradle if your
radio is soiled or wet.
In order to use Group Mode you need to initialize
a couple of settings in your radio:
• Set the radio to Group Mode
• Set a Group Code
• Set a Unit Number
• Set a "Nickname"
Setting the Radio to Group Mode
To set the radio to Group Mode, which enables
Direct Call, Auto Channel Change and All Call,
press and hold TONE/GROUP for 2 seconds. The
radio displays GRP and group code.
Note: In group mode, you cannot receive
transmissions from other radios unless they are
also set to the same channel and group code.
Setting the Group Code
Set the group code for your radio group from
0-142. Everyone in your group must select the
same group code in order to communicate with
each other.
1) Tap TONE/GROUP in group mode. Press
CH or to select the group number.
2) Press ENTER/ or TONE/GROUP to return to
normal operation.
Setting the Unit Number
Each radio in your group needs to be set to a
unique unit number, from 1-16.
1) Press MENU/ . Advance through the menu
until UNIT appears, and then press ENTER/ .
The current unit number flashes.
2) Press CH or to select the desired unit
number.
3) Press ENTER/ to continue to the next
section.
Setting Your Nickname
Your nickname appears on other units’ displays
when you make a All Call or direct call. This is
also the name that appears on other radio displays
when someone wants to make a direct call to you.
When no nickname is set, the unit number
appears.
1) Press MENU/ . Advance through the menu
until UNIT appears, and then press ENTER/ .
The current unit number flashes, then tap
ENTER/ . The radio displays n - - - - (or your
current nickname) with the first place in the
nickname flashing.
2) Press CH or to select the letter, then
ENTER/ to advance to the next letter until you
have entered your nickname.
3) Press MENU/ to confirm the setting and exit
the menu.
Using Group Mode
Group mode lets you make direct calls to other
people in your group without alerting the entire
group and also lets you quickly change everyone in
your group to another channel from a single radio.
Before using group mode, follow the instructions in
"Setting Up Group Mode" on every radio in your
group. Then, to record the unit ID and everyone’s
nickname in every radio, send a call to "All" from
each radio one time (see "Sending a Direct Call").
Sending a Direct Call
Direct Call lets you call everyone in your group at
once, or call a single person in your group without
anyone else in the group knowing. It is like a
"speed dial" directly to the person(s) you want to
talk to.
To call everyone in your group, press D CALL in
group mode. The radio flashes ALL. Then, press
D CALL or ENTER/ . Everyone in your group
receives a call "chirp" for about 3 seconds. When
the chirp ends, begin your conversation.
Note: When you make a direct call to "all," your
radio also sends out your nickname or ID so that it
will show up in the call list for everyone in your
group.
To call one person in your group, without having
other people know, press D CALL in group mode.
Then, use CH or to select the person you
want to call and press D CALL or ENTER/ . Your
radio sounds tones for 3 seconds as it sends the
call. When the selected person answers, you can
begin your conversation. You can silence the call
tones at any time by pressing PTT or Power
boost.
Your conversation remains private between you
and the person you called until 15 seconds after
your last conversation. Then, your radio
automatically exits private mode.
Automatically Changing Channels
Auto Channel Change lets you easily coordinate a
channel change for everyone in your group. You
might want to do this when you find you are getting
a lot of interference on your current channel. Or,
you can use this feature to change from a low-
power channel (8-14) to one of the high-powered
channels (1-7, 15-22) if you need more range (or to
a low-power channel if you need longer battery
life).
USING THE RADIO IN STANDARD MODE
Use the radio in standard (not group) mode when
you need to be able to communicate with radios
that do not have the group feature.
Choosing a Privacy Code
You can select a Privacy Code from 1-142 for each
channel. oFF (OFF) indicates no Privacy code
selected and your radio can receive a signal
regardless of the code settings of the transmitting
radio.
1) Press TONE/GROUP. The Privacy code
indicator flashes.
2) Press CH or to increase or decrease the
code. You can also select oFF.
3) Press ENTER/ or TONE/GROUP to return to
normal operation.
Note: Only tones 1-38 are standard across radio
brands. Other settings might differ from brand to
brand. See the specifications for the specific tones
used for each setting.
Channel Scan Feature
Your radio has a channel scan feature that lets you
easily scan all 22 channels. When an active
channel is detected, the radio pauses on that
channel until the channel is clear. Then after a
2-second delay, the radio resumes scanning.
Pressing PTT or Power boost while the scan is
paused on a channel lets you transmit on that
channel.
To turn on channel scan:
Press MENU/ . The radio displays SCAN, and
then press ENTER/ .The channel number
changes as the radio rapidly cycles through the
channels.
To turn off channel scan:
Press MENU/ , PTT, Power boost, D CALL or
WX/ALERT.
Talking on Your Radio
To talk to others using the radio:
1) Press and hold PTT or Power boost and speak
in a clear, normal voice about 2-3 inches away
from the microphone. While you transmit, TXHI
or TXLO appears on the display according to
the type of channel. To avoid cutting off the first
part of your transmission, pause slightly after
pressing PTT or Power boost before you start
talking.
2) When you finish speaking, release PTT or
Power boost. You can now receive incoming
calls. While receiving, RX appears on the
display.
Note: When you press Power boost, BOOS
appear on the display. The radio transmits at
maximum power when a GMRS channel is
selected. If Power boost is continuously pressed,
1 minute after you start pressing Power boost the
transmission stops and you hear a boost timeout
error tone.
Monitor Mode Feature
Your radio lets you listen for weak signals on the
current channel at the press of a key.
To turn on the Monitor Mode:
• For brief listening, press MON. MON appears
and RX flashes.
• Press and hold MON for 2 seconds until two
beeps sound for continuous listening. The
receiver circuit stays open, so you hear both the
noise and weak signals.
To turn off Monitor Mode:
Press MON to return to the previous mode. MON
and RX disappear.
Navigating through the Normal Menu
To access the advanced features of your radio has
a Menu function. In order to use Auto Channel
Change, you need to set your radio to Group
Mode.
1) To enter the menu, press MENU/ .
2) Additional presses of MENU/ advances you
through the menu. After the last menu item, the
radio exits to the previous mode.
3) Other ways to exit the Menu function are:
a. Press PTT, Power boost, MON, D CALL,
WX/ALERT or TONE/GROUP.
b. Wait 10 seconds until the radio automatically
returns to the previous mode.
Setting Silent Mode
When you turn on the silent mode, all incoming
calls are muted: the radio flashes the display
backlight, the channel indicator, SLNT and CALL
to alert you to an incoming call. If you do not
respond to the call within 15 seconds, the backlight
turns off. The GMR2875 will also vibrate to remind
you that you missed a call. Silent mode is disabled
for 15 seconds when you transmit, receive, or
press any other button.
To set the silent mode:
1) Enter the menu. Advance through the menu until
the SLNT appears, then press ENTER/ . The
current setting flashes.
2) Press CH to display on, then press ENTER/
.
Note: To prevent unwanted silent alerts, be sure to
use a Privacy code or group code whenever you
use the Silent mode feature.
You can hear the received voice when you turn on
channel scan and an active channel is detected
even during silent mode.
Missed Call Alerts
If you receive an incoming call while silent mode is
on and do not respond, the radio will turn on the
Missed Call icon. If you are using the Group Mode,
the radio will also indicate the person who made
the call.
The GMR2875 will additionally remind you of a
missed call by vibrating every minute after the call
for 3 minutes.
Scan
Mode
Silent
Mode
Auto
Channel
Change
Call
Tone
Unit
Setting
Roger
Beep
Beep
Tone
Start
Scanning
ON-OFF Channel
Change
1-10
Setting
Unit
Number
Setting
Nickname
ON-OFF
ON-OFF
•
Power Boost Button for
Maximum Range
•
All Call
•
Auto Channel Change Call
•
Battery Charger
•
Battery Level Meter
•
Channel Monitor
•
Channel Scan
•
Group Scan
•
Keypad Lock
•
NOAA Emergency /
Weather Channels
•
Emergency Weather Alert
To start an auto channel change, on any radio in
the group tap MENU/ . Advance through the
menu until CHCX appears, then press ENTER/ .
The current channel flashes. Use CH or to
select the target channel. You can check whether
the selected channel is clear. Then press D CALL
or ENTER/ .
Your radio chirps for about 10 seconds while it
sends out the channel change signal. As each
radio receives the channel change signal, it chirps
once, then changes to the new channel.
To ensure all radios make it to the new channel,
we recommend you:
• Make sure you are in an open environment,
where the radio will get the best range.
• Optimize range during the channel change
signal by raising the radio over your head to
give the best possible height.
• Do a "roll call" on the new channel after the
move to be sure no one was left behind. If you
missed someone, return to the previous channel
and issue the signal again.
Transmitting a Call Tone
Your radio is equipped with 10 selectable call tones
that are transmitted when you press D CALL in
standard mode. The selected tone will be also heard
when someone places a direct call to you.
To select a call tone:
1) Enter the menu. Advance through the menu until
CALL appears, then press ENTER/ . The
current call tone number (1-10) flashes.
2) Press CH or to increase or decrease the
number to the desired call tone. Each tone will be
heard through the speaker.
To transmit the selected call tone, press D CALL.
The selected tone is transmitted for a fixed length of
time. Call Tone is cancelled if you press PTT or
Power boost.
Roger Beep
Roger beep is a beep that is sent to notify the end
of transmission. You can hear the roger beep can
be heard through the speaker when both roger beep
and Beep Tone are on. When roger beep is on and
Beep Tone is off, you do not hear the roger beep,
but it is transmitted to your party.
To adjusting the roger beep, enter MENU/ .
Advance through the menu until RGR appears, then
press ENTER/ . The current setting flashes.
To turn OFF roger beep:
Press CH to display oF, then press ENTER/ .
To turn ON roger beep:
Press CH to display on, then press ENTER/ .
Adjusting the Sound (Beep Tone)
Your radio sounds a beep each time you press a
key (except for PTT and Power boost).
To adjusting the sound, enter MENU/ . Advance
through the menu until TONE appears, then press
ENTER/ . The current setting flashes.
To turn OFF this beep:
Press CH to display oF, then press ENTER/ .
To turn ON this beep:
Press CH to display on, then press ENTER/ .
Key Lock
Press and hold the ENTER/ until the LOCK
appears.
To exit Keylock on mode, press and hold ENTER/
again.
Note:
• While in keylock on mode, you can still use the
radio to receive transmissions, use D CALL in
Standard mode, VO or , PTT, Power
boost, MON, and MENU/ to turn on or off the
radio.
UT042ZH_GMR2875-2CK_0722_1002.indd 1UT042ZH_GMR2875-2CK_0722_1002.indd 1 7/22/2009 10:09:43 AM7/22/2009 10:09:43 AM
Channels 15 GMRS/7 FRS/7 Weather
Sub Codes 38 Sub-Audible Tones
104 DCS Codes
Operating Frequency
GMRS/FRS: 462.5500 - 467.7125 MHz
WX: 162.4000 - 162.5500 MHz
Power Source NiMH Battery Pack (BP38)
Range Channel 1-7 up to 18 miles
(28 miles with Power boost
button)
Channel 8-14 up to 5 miles
Channel 15-22 up to 18 miles
(28 miles with Power boost
button)
Battery Life 12 Hours typ. - NiMH
Battery Pack (5/5/90 duty
cucle)
Frequency Chart
Ch. Freq. [MHz] Cross Ref. Ch. Freq. [MHz] Cross Ref.
1 462.5625 FRS & GMRS 1 12 467.6625 FRS 12
2 462.5875 FRS & GMRS 2 13 467.6875 FRS 13
3 462.6125 FRS & GMRS 3 14 467.7125 FRS 14
4 462.6375 FRS & GMRS 4 15 462.5500 GMRS 11
5 462.6625 FRS & GMRS 5 16 462.5750 GMRS 8
6 462.6875 FRS & GMRS 6 17 462.6000 GMRS 12
7 462.7125 FRS & GMRS 7 18 462.6250 GMRS 9
8 467.5625 FRS 8 19 462.6500 GMRS 13
9 467.5875 FRS 9 20 462.6750 GMRS 10
10 467.6125 FRS 10 21 462.7000 GMRS 14
11 467.6375 FRS 11 22 462.7250 GMRS 15
CTCSS Chart (Hz)
Code Freq. Code Freq.
oFF OFF 20 131.8
1 67.0 21 136.5
2 71.9 22 141.3
3 74.4 23 146.2
4 77.0 24 151.4
5 79.7 25 156.7
6 82.5 26 162.2
7 85.4 27 167.9
8 88.5 28 173.8
9 91.5 29 179.9
10 94.8 30 186.2
11 97.4 31 192.8
12 100.0 32 203.5
13 103.5 33 210.7
14 107.2 34 218.1
15 110.9 35 225.7
16 114.8 36 233.6
17 118.8 37 241.8
© 2009 Uniden America Corporation
All rights reserved Printed in China
UTZZ01042ZZ(0)
SPECIFICATIONS
18 123.0 38 250.3
19 127.3
Tone Octal
No. Code
39 023
40 025
41 026
42 031
43 032
44 043
45 047
46 051
47 054
48 065
49 071
50 072
51 073
52 074
53 114
54 115
55 116
56 125
57 131
58 132
59 134
60 143
61 152
62 155
63 156
64 162
65 165
66 172
67 174
68 205
69 223
70 226
71 243
72 244
73 245
Tone Octal
No. Code
74 251
75 261
76 263
77 265
78 271
79 306
80 311
81 315
82 331
83 343
84 346
85 351
86 364
87 365
88 371
89 411
90 412
91 413
92 423
93 431
94 432
95 445
96 464
97 465
98 466
99 503
100 506
101 516
102 532
103 546
104 565
105 606
106 612
107 624
108 627
Tone Octal
No. Code
109 631
110 632
111 654
112 662
113 664
114 703
115 712
116 723
117 731
118 732
119 734
120 743
121 754
122 036
123 053
124 122
125 145
126 212
127 225
128 246
129 252
130 255
131 266
132 274
133 325
134 332
135 356
136 446
137 452
138 454
139 455
140 462
141 523
142 526
DCS Code List
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Important: Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to
operate this device. Your radio is set up to transmit
a regulated signal on an assigned frequency. It is
against the law to alter or adjust the settings inside
the radio to exceed those limitations. Any
adjustments to your radio must be made by
qualified technicians.
To be safe and sure:
• Never open your radio’s case.
• Never change or replace anything in your radio
except the batteries.
Your radio might cause TV or radio interference
even when it is operating properly. To determine
whether your radio is causing the interference, turn
it off. If the interference goes away, your radio is
causing it. Try to eliminate the interference by
moving your radio away from the receiver. If you
cannot eliminate the interference, the FCC requires
that you stop using the radio.
Hazardous Environments: Do not operate the
radio in hazardous environments. Explosion or fire
may result. Do not operate the radio near
unshielded electrical blasting caps.
Under certain conditions, radios can interfere with
blasting operations and may cause an explosion.
Turn your radio OFF to prevent accidental
transmission when in a blasting area or in areas
posted: "Turn off two-way radio." Construction
crews often use remote control RF devices to set
off explosives.
Care and Safety: To clean the radio, use a soft
cloth dampened with water. Do not use cleaners or
solvents because they can harm the body of the
unit and leak inside, causing permanent damage.
Use a dry, lint-free cloth to clean the battery
contacts. Do not submerge the unit in water. If the
unit gets wet, turn it off and remove the batteries
immediately.
Dry the battery compartment with a soft cloth to
minimize potential water damage. Leave the
battery compartment cover off overnight to ensure
complete drying. Do not use the radio until the unit
is completely dry.
Important: Evidence of original purchase is
required for warranty service.
WARRANTOR: UNIDEN AMERICA
CORPORATION ("Uniden")
ELEMENTS OF WARRANTY: Uniden warrants,
for one year, to the original retail owner, this
Uniden Product to be free from defects in materials
and craftsmanship with only the limitations or
exclusions set out below.
WARRANTY DURATION: This warranty to the
original user shall terminate and be of no further
effect 12 months after the date of original retail
sale. The warranty is invalid if the Product is:
(A) damaged or not maintained as reasonable or
necessary, (B) modified, altered, or used as part
of any conversion kits, sub-assemblies, or any
configurations not sold by Uniden, (C) improperly
installed, (D) serviced or repaired by someone
other than an authorized Uniden service center for
a defect or malfunction covered by this warranty,
(E) used in any conjunction with equipment or parts
or as part of any system not manufactured by
Uniden, or (F) installed or programmed by anyone
other than as detailed by the owner’s manual for
this product.
STATEMENT OF REMEDY: In the event that the
product does not conform to this warranty at any
time while this warranty is in effect, warrantor will
either, at its option, repair or replace the defective
unit and return it to you without charge for parts,
service, or any other cost (except shipping and
handling) incurred by warrantor or its
representatives in connection with the performance
of this warranty. Warrantor, at its option, may
replace the unit with a new or refurbished unit.
THE LIMITED WARRANTY SET FORTH ABOVE
IS THE SOLE AND ENTIRE WARRANTY
PERTAINING TO THE PRODUCT AND IS IN LIEU
OF AND EXCLUDES ALL OTHER WARRANTIES
OF ANY NATURE WHATSOEVER, WHETHER
EXPRESS, IMPLIED OR ARISING BY
OPERATION OF LAW, INCLUDING, BUT NOT
LIMITED TO ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.THIS WARRANTY
DOES NOT COVER OR PROVIDE FOR THE
REIMBURSEMENT OVERPAYMENT OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow this exclusion or limitation
of incidental or consequential damages so the
above limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you
specific legal rights, and you may also have other
rights which vary from state to state. This warranty
is void outside the United States of America and
Canada.
PROCEDURE FOR OBTAINING PERFORMANCE
OF WARRANTY: If, after following the instructions
in the owner’s manual you are certain that the
Product is defective, pack the Product carefully
(preferably in its original packaging). Disconnect
the battery from the Product and separately secure
the battery in its own separate packaging within the
shipping carton. The Product should include all
parts and accessories originally packaged with the
Product. Include evidence of original purchase and
a note describing the defect that has caused you to
return it.The Product should be shipped freight
prepaid, by traceable means, to warrantor at:
ONE YEAR LIMITED WARRANTYREGULATORY INFORMATION
WARNING! Read this information before using
the radio. In August 1996 the Federal
Communications Commission (FCC) of the United
States with its action in Report and Order FCC
96-326 adopted an updated safety standard for
human exposure to radio frequency
electromagnetic energy emitted by FCC regulated
transmitters.
Those guidelines are consistent with the safety
standard previously set by both U.S. and
international standards bodies. The design of the
radio complies with the FCC guidelines and these
international standards.
Never allow children to operate the radio without
adult supervision and the knowledge of the
following guidelines.
WARNING! It is up to the user to properly operate
this radio transmitter to insure safe operation.
Please adhere to the following:
Use only the supplied or an approved antenna.
Unauthorized antennas, modifications, or
attachments could impair call quality, damage the
radio, or result in violation of FCC regulations.
Do not use the radio with a damaged antenna.
If a damaged antenna comes into contact with the
skin, a minor burn may result. Please contact your
local dealer for a replacement antenna.
Hand-held Operation (Held-to-Face)
This device was evaluated for typical hand-held
(held-to-face) operations with a 1 inch spacing from
the front of the radio. For hand-held operation, the
radio should be held 1 inch from the user's face in
order to comply with FCC RF exposure
requirements.
For more information about RF exposure, please
visit the FCC web site at www.fcc.gov.
RF EXPOSURE INFORMATION
Covered under one or more of the following
U.S. patents:
5,203,015 5,214,789 5,491,745 5,497,508
5,517,677 5,557,606 5,574,994 5,625,870
5,627,876 5,634,196 5,678,176 5,697,096
5,717,312 5,722,070 5,787,345 5,901,341
6,021,326 6,084,861 6,163,691 6,195,415
6,353,730 6,618,015 6,839,550 6,980,770
7,102,568 7,138,945 7,200,358 7,251,453
Uniden America Service
4700 Amon Carter Blvd. Fort Worth, TX 76155
(800) 297-1023 during regular business hours
(CST)
(See www.uniden.com for current hours of
operation.)
USING THE WEATHER RADIO
Your radio can receive weather broadcasts from the
NOAA National Weather Service. When in the
Weather Radio Alert mode, the system functions as it
does in standard mode but also monitors the selected
weather channel for alerts when not communicating.
While using the Weather Radio, you are not able to
receive GMRS communications.
1) To turn on the Weather Radio Broadcast mode,
press WX/ALERT. WX appears.
2) Press CH or to increase or decrease the
number to the desired Weather Channel.
3) To exit the Weather Radio Broadcast mode, press
WX/ALERT. WX disappears.
• When in the Weather Radio Broadcast mode, you
can only set the Beep Tone from the Menu mode.
Choosing an Emergency/Weather Channel
There are 7 NOAA channel frequencies available and
these frequencies are common between the US and
Canada.You need to know what frequency is being
transmitted in your location.
1) Press and hold WX/ALERT. appears.
2) When the unit receives a warning signal, it beeps
for 5 seconds. and channel indicator flash.
3) To turn off Weather Alert, press and hold
WX/ALERT. disappears.
• When Weather Alert is activated, the highest
priority is given to this function. It checks the
weather alert signals every 7 seconds. When the
unit finds a warning signal, it switches to the
warning receive mode automatically.
• Weather Alert is activated even if Beep Tone is
turned off.
NOAA Weather Radio Frequency List
Channel 1 162.550 MHz Channel 5 162.450 MHz
Channel 2 162.400 MHz Channel 6 162.500 MHz
Channel 3 162.475 MHz Channel 7 162.525 MHz
Channel 4 162.425 MHz
• The radio retains the keylock status even when you
cycle power.
Automatic Power Save Feature
Your radio has a unique circuit designed to
dramatically extend the life of the batteries. If there is
no transmission nor an incoming call within 3 seconds,
your radio switches to the Power Save mode. The
radio is still able to receive transmissions in this mode.
LCD Backlight
The LCD Backlight automatically turns on when any
key (except for PTT and Power boost) is pressed.
The LCD remains lit for 10 seconds before turning off.
UT042ZH_GMR2875-2CK_0722_1002.indd 2UT042ZH_GMR2875-2CK_0722_1002.indd 2 7/22/2009 10:09:46 AM7/22/2009 10:09:46 AM
