TS890 Simple Manual 2013-6-14
TS890 SERIES Transaction Terminal
(Support Paypass, Paywave, J/speedy, express pay, D-PAS)
Thank you for purchasing the TS890 series products.
The contactless & Signature Pad TS890 is to support the mag-stripe card ,
EMV / ISO 7816 card and contactless payment systems . The small footprint
size of the device makes it easily to integrate to the current transaction system
such as Point-of-Sale terminal as the part of the system. The device
communicates with bank host by Modem , Ethernet or GPRS. Allow to connect
peripherals by RS232 or USB.
FEATURES
Build-in thermal printer
Support mag-stripe , ICC , contactless transaction
Support quad-band GPRS communication
Support Modem and Ethernet
TS890 Specifications
Processor 32 bits high performance processor
Memory System Flash 8/16Mb , SDRAM 16Mbb .
LCD Display 128 x 64 pixels Graphical Display with LED Backlight
SAM 3 SAM Card Slots (support 5V and 3.3V SAM) (option)
Contactless Build-in contactless module (option) , supported ISO
14443 13.56Mhz contactless card .
RTC Battery backup real time clock
Communication Provided RS232/USB Ports for peripherals connection
Provideed standard USB Port to connect PC/Terminal
Modem/Ethernet/GPRS
Dimensions (L)199 x (W) 94 x (H) 75mm
Power Requirements 9VDC 5A
Operation Environment
Temperature 0 °C to +50 °C; Humidity 5% to 90%
![](/img.php?id=2004069&img=bg2.png)
TS890 Simple Manual 2013-6-14
AGENCY APPROVAL
● Specifications for FCC Class B
Changes or modifications are not expressly approved by the manufacturer could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/ TV technician for help.
You are cautioned that any change or modifications to the equipment not expressly approve by
the party responsible for compliance could void your authority to operate such equipment.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
![](/img.php?id=2004069&img=bg3.png)
TS890 Simple Manual 2013-6-14
Interface RJ11 Pin Assignment ( RS232 )
The 9.0V power comes from external 9V@5A adaptor , the 5.0V power comes from
internal regulator .
Pin Assignment
PIN 232 A 232 B
1 GND GND
2 CTS GND
3 Rx Rx
4 RTS 5.0V .
5 Tx Tx
6 9.0V 9.0V
