Uniform UIC680FG Contactless Smart Card Reader Module User Manual

Uniform Industrial Corp. Contactless Smart Card Reader Module User Manual

User Manual

UIC680FG Specification 2016/9/26
UIC680FG Contactless Smart Card Reader Specification
The contactless smart card reader module UIC680FG is mainly to support the contactless payment systems.
The small footprint size of the module makes it easily to integrate to the current transaction system such as
Point-of-Sale terminal, kiosk, and vending machine station as the part of the system. The module
communicates with a host computer or terminal using a standard RS-232, USB or TTL interface.
FEATURES
Small footprint PCB with antenna board
Supports ISO 14443 & ISO 18092 standard
Supports American Express® ExpressPay, MasterCard® PayPassTM (Contactless MagStripe and M/Chip), Visa®
PayWave (MSD and qVSDC), and Discover Network Zip Contactless Payments applications,
Encrypted card data output (optional)
The direct coupling antenna
RS232 and USB 2.0 by use of corresponding cables
AGENCY APPROVAL
Specifications for FCC Class B, CE Class B, BSMI
EMVCo CLL1, Visa, Paypass, AMEX, Discover
SPECIFICATIONS
Communication Standard RS232 signal level
Compatible with USB 2.0 specification
Power Requirements 5V DC ± 5%
Power Consumption 330mA in idle mode; 430mA in operating mode
Operating Temperature -10 to 50ɗ
Operating Humidity 10 to 85% (non condensing)
Dimension 104mm(L)x72mm(W)x17.5mm(H)
PIN ASSIGNMENT
Interface J5 Pin Assignment
DB9
Signal Direction PCB-J5
Signal
5 GND 1 GND
2 RxD Serial data to host 2 TXD1 Out
3 TxD Serial data from host 3 RXD1 In
4 VCC
USB data 5 USB D-
USB data 6 USB D+
Shield 7 Shield
Changes or modifications are not expressly approved by the manufacturer could void the user's
authority to operate the equipment.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX FCC ID:
TFJUIC680FG ". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19
statement has to also be available on the label: This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device
must accept any interference received, including interference that may cause undesired operation.
This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of
the end product which integrates this module.
