Manual

-1-

Content

1 General Information.....................................................................................................................................................3

1.1 Profile............................................................................................................................................................................... 3

1.2 Safety warning and Attentions ......................................................................................................................................... 4

2 Your phone ....................................................................................................................................................................7

2.1 Phone overview................................................................................................................................................................ 7

2.2 Functions of Keys............................................................................................................................................................. 7

2.3 Functions of icons ............................................................................................................................................................ 7

3 Getting started ..............................................................................................................................................................8

3.1 Installing the SIM Card and the Battery........................................................................................................................... 8

3.2 Charging the Battery ........................................................................................................................................................ 9

3.3 Linking to the Networks and devices..............................................................................................................................11

3.4 Using the touch screen ................................................................................................................................................... 12

3.5 Using the onscreen keypad............................................................................................................................................. 13

3.6 Dialing Calls................................................................................................................................................................... 14

4 Using the Menus .........................................................................................................................................................15

-2-

4.1 Application Manager...................................................................................................................................................... 15

4.2 Browser .......................................................................................................................................................................... 15

4.3 Calculator....................................................................................................................................................................... 18

4.4 Calendar ......................................................................................................................................................................... 18

4.5 Call History .................................................................................................................................................................... 19

4.6 Camera ........................................................................................................................................................................... 19

4.7 Chrome........................................................................................................................................................................... 20

4.8 Clock .............................................................................................................................................................................. 20

4.9 Downloads...................................................................................................................................................................... 20

4.10 Email............................................................................................................................................................................ 20

4.11 Facebook ...................................................................................................................................................................... 21

4.12 File Explorer ................................................................................................................................................................ 21

4.13 FM Radio ..................................................................................................................................................................... 21

4.14 Gallery.......................................................................................................................................................................... 22

4.15 Messaging .................................................................................................................................................................... 22

4.16 Music............................................................................................................................................................................ 22

4.17 Note.............................................................................................................................................................................. 24

4.18 People........................................................................................................................................................................... 24

-3-

4.19 Phone............................................................................................................................................................................ 25

4.20 Search........................................................................................................................................................................... 25

4.21 Settings......................................................................................................................................................................... 25

4.22 SIM Toolkit.................................................................................................................................................................. 27

4.23 Sound Recorder............................................................................................................................................................ 28

4.24 Tasks manager.............................................................................................................................................................. 28

4.25 Video player................................................................................................................................................................. 28

4.26 WeChat......................................................................................................................................................................... 28

4.27 Whatsapp...................................................................................................................................................................... 28

5 Appendix .....................................................................................................................................................................29

1 General Information

1.1 Profile

Please read this pamphlet carefully in order to make your phone in perfect condition.

Our company may change this mobile phone without prior written notice and reserves the final right to

interpret the performance of this mobile phone.

Due to different software and network operators, display on your phone may be different, refer to your

-4-

phone for details.

1.2 Safety warning and Attentions

Safety warning

 ROAD SAFETY COMES FIRST

Do not use a hand-held phone while driving. Use hands-free fittings when calls are unavoidable while

driving. In some countries, dialing or receiving calls while driving is illegal!

 SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft. Using a mobile phone in flight is illegal and risky.

Please make sure that your mobile phone is powered off in flight.

 SWITCH OFF BEFORE ENTERING RISKY AREAS

Strictly observe the relevant laws, codes, and regulations on the use of mobile phones in risky areas.

Turn off your mobile phone before entering a place susceptible to explosion, such as an oil station, oil tank,

chemical plant or a place where a blasting process is under way.

 OBSERVE ALL SPECIAL REGULATIONS

Follow any special regulations in force in any area such as hospitals and always switch off your phone

whenever it is forbidden to use it or, when it may cause interference or danger. Properly use your mobile

phone near medical apparatuses, such as pacemakers, hearing aids and some other electronic medical devices,

as it may cause interference to such apparatuses.

 INTERFERENCE

The conversation quality of any mobile phone may be affected by radio interference. An antenna is built

inside the mobile phone and located below the microphone. Do not touch the antenna area during a

-5-

conversation, lest that the conversation quality deteriorate.

 QUALIFIED SERVICE

Only qualified personnel may install or repair phone equipment. Installing or repairing the mobile phone

on your own may bring great danger and violates the warranty rules.

 ACCESSORIES AND BATTERIES

Use only approved accessories and batteries.

 USE SENSIBLY

Use only in a normal and proper manner.

 EMERGENCY CALLS

Ensure the phone is switched on and in service, enter the emergency number, e.g. 112, then press the

Dial key. Give your location and state your situation briefly. Do not end the call until told to do so.

Note: Just like all other mobile phones, this mobile phone does not necessarily support all the features

described in this manual due to network or radio transmission problems. Some networks even do not support

the emergency call service. Therefore, do not rely solely on the mobile phone for critical communications

such as first aid. Please consult the local network operator.

Precautions

This mobile phone is well designed with fine art. Please exercise special care when using it. The

following suggestions will help your mobile phone survive the warranty period and extend its service life:

 Keep the mobile phone and all its fittings beyond children's reach.

 Keep the mobile phone dry. Keep away from rain, moisture, liquid or other substances that may corrode

electronic circuits.

-6-

 Do not use or store the mobile phone in dusty places, lest that active parts of the mobile phone be damaged.

 Do not store the mobile phone in a high-temperature place. High temperature will shorten the life of

electronic circuits and damage the battery and some plastic parts.

 Do not store the mobile phone in a chilly place. Otherwise, moistures will be formed inside the mobile

phone to damage electronic circuits when the mobile phone is moved to a constant temperature place.

 Do not throw, knock or shock the mobile phone, as that will destroy the internal circuits and high-precision

components of the mobile phone.

-7-

2 Your phone

2.1 Phone overview

2.2 Functions of Keys

The mobile phone provides the following keys:

 Power key

Power key situates at the right side of the phone. While using the phone, you can press this key to lock

screen; if you press and hold this key, a phone-options dialog would pop out. Here, you can select to

adjust the profile mode, power off, reboot or turn on/off airplane mode.

 Volume key

Volume key situates at the right side of the phone. You can press it to adjust ringer volume.

2.3 Functions of icons

 Menu icon

-8-

Touch this icon to access options of a selected function;

 Home icon

Touch it to open home screen. If you’re viewing the left or right extended Home screen, touch it can

enter the home screen.

 Back icon

Touch this icon to return to the previous screen;

3 Getting started

3.1 Installing the SIM Card and the Battery

A SIM card carries useful information, including your mobile phone number, PIN (Personal Identification

Number), PIN2, PUK (PIN Unlocking Key), PUK2 (PIN2 Unlocking Key), IMSI (International Mobile

Subscriber Identity), network information, contacts data, and short messages data.

Note:

After powering off your mobile phone, wait for a few seconds before removing or inserting a SIM card.

Exercise caution when operating a SIM card, as friction or bending will damage the SIM card.

Properly keep the mobile phone and its fittings such as the SIM cards beyond children's reach.

Installation

 Hold the power key for a while and select power off to power off the mobile phone.

-9-

 Take the back cover away.

 Insert the SIM Card into the SIM Card slot lightly with the corner cutting of the card aligning to the

notch of the slot and the gold plate of the card facing download, till the SIM Card cannot be further

pushed in.

 With the metallic contacts of the battery facing the metallic contacts in the battery slot, install the

battery.

Note:

The SD card is a miniature object. Keep it out of the reach of children for fear that children swallow it!

3.2 Charging the Battery

 Your mobile phone can monitor and display the battery state.

 Normally the remaining energy of the battery is indicated by the battery level icon at the upper right

corner of the display screen.

 When the battery energy is insufficient, the mobile phone prompts "Battery low".

Using a travel adapter:

 Install the battery into the mobile phone before charging the battery.

 Connect the adapter of the travel charger with the charging slot in the mobile phone. Ensure that the

adapter is fully inserted.

 Insert the plug of the travel charger to an appropriate power outlet.

 During the charging, the battery level grids in the battery icon keep flickering till the battery is fully

charged.

 The battery icon does no longer flicker when the charging process ends.

-10-

Note:

Ensure that the plug of the charger, the plug of the earphone, and the plug of the USB cable are inserted

in the right direction. Inserting them in a wrong direction may cause charging failure or other problems.

Before the charging, ensure that the standard voltage and frequency of the local mains supply match the

rated voltage and power of the travel charger.

Optimizing battery life

You can extend your battery’s life between charges by turning off features that you don’t need. You can

also monitor how applications and system resources consume battery power.

To guarantee the optimal performance of your battery, please stick to the following rules:

 Turn off radios that you aren’t using. If you aren’t using Wi-Fi, Bluetooth, or GPRS, use the Setting

application to turn them off.

 Turn down screen brightness and set a shorter screen timeout.

 If you don’t need them, turn off automatic syncing for Gmail, Calendar, Contacts, and other

applications.

Note: On the Home screen, press Menu icon and touch Settings > More>Battery. The Battery Use screen

lists the applications that have been using the battery, from greatest to least battery use. The top of the screen

displays the time since you were last connected to a charger or, if you’re currently connected to one, how

long you were running on battery power before you connected to a charger. Then each application or service

that used battery power during that time is displayed, in order of the amount of power they used. Touch an

application in the Battery Use screen to learn details about its power consumption. Different applications

offer different kinds of information.

-11-

3.3 Linking to the Networks and devices

Your phone can connect to a variety of networks and devices, including mobile networks for voice and

data transmission, Wi-Fi data networks, and Bluetooth devices, such as headsets. You can also connect your

phone to a computer, to transfer files from your phone’s SD card and share your phone’s mobile data

connection via USB.

Connecting to mobile networks

When you assemble your phone with a SIM card, your phone is configured to use your provider’s

mobile networks for voice calls and for transmitting data.

Connecting to Wi-Fi networks

Wi-Fi is a wireless networking technology that can provide Internet access at distances of up to 100

meters, depending on the Wi-Fi router and your surroundings.

Touch Settings>Network > Wi-Fi. Check Wi-Fi to turn it on. The phone scans for available Wi-Fi

networks and displays the names of those it finds. Secured networks are indicated with a Lock icon.

Note: If the phone finds a network that you connected to previously, it connects to it.

Touch a network to connect to it. If the network is open, you are prompted to confirm that you want to

connect to that network by touching Connect. If the network is secured, you’re prompted to enter a password

or other credentials.

Connecting to Bluetooth devices

Bluetooth is a short-range wireless communications technology that devices can use to exchange

information over a distance of about 8 meters. The most common Bluetooth devices are headphones for

-12-

making calls or listening to music, hands-free kits for cars, and other portable devices, including laptops and

cell phones.

Touch Settings> Network > Bluetooth. Check Bluetooth to turn it on.

You must pair your phone with a device before you can connect to it. Once you pair your phone with a

device, they stay paired unless you unpair them.

Your phone scans for and displays the IDs of all available Bluetooth devices in range. If the device you

want to pair with isn’t in the list, make it discoverable.

Connecting to a computer via USB

You can connect your phone to a computer with a USB cable, to transfer music, pictures, and other files

between your phone’s SD card and the computer.

3.4 Using the touch screen

 Touch-screen tips

 Touch

To act on items on the screen, such as application and settings icons, to type letters and symbols using

the onscreen keyboard, or to press onscreen buttons, you simply touch them with your finger.

 Touch & hold

Touch & hold an item on the screen by touching it and not lifting your finger until an action occurs. For

example, to open a menu for customizing the Home screen, you touch an empty area on the Home screen

until the menu opens.

 Drag

-13-

Touch & hold an item for a moment and then, without lifting your finger, move your finger on the

screen until you reach the target position.

 Swipe or slide

To swipe or slide, you quickly move your finger across the surface of the screen, without pausing when

you first touch it (so you don’t drag an item instead). For example, you slide the screen up or down to scroll a

list.

 Lock screen

When Screen lock in Security setting is enabled, press Power key to lock the handset. This helps to

prevent accidental touching of keys and as well as power saving. When Sleep function in Display setting is

enabled, after the handset device has been idle for preset period, the screen will be locked automatically to

save power.

 Unlock screen

Press Power key to switch on the handset device. The lock screen appears. Touch and slide right to

unlock screen, and the screen being locked last time will show.

3.5 Using the onscreen keypad

You enter text using the onscreen keyboard. Some applications open the keyboard automatically. In others,

you touch a text field where you want to enter text to open the keyboard. You can also enter text by speaking

instead of by typing.

 To enter text

Touch a text field, and the onscreen keyboard opens. Some applications open the keyboard automatically.

In others, you touch a text field where you want to enter text to open the keyboard.

-14-

 Touch the keys on the keyboard to type.

The characters you’ve entered appear in the text field, with suggestions for the word you are typing

below.

 Use the Delete icon to erase characters to the left of the cursor.

After finishing typing, touch Back icon to close the keyboard.

3.6 Dialing Calls

 Dialing a call to a number in the contacts

Touch the Phone icon or the phone application icon on the Home screen, then select the Contacts tab.

Swipe or slide upward/downward to pick out the target contact. Then you can touch the dial icon to originate

a call.

 Dialing a call to a number in call log

Touch the Phone icon or the phone application icon on the Home screen, then select the call log tab.

Swipe or slide upward/downward to pick out and touch the target contact. Then you can originate a call.

 Answering incoming calls

Touch the Answer icon to answer an incoming call.

Touch the End icon to end the current conversation.

To reject an incoming call, touch the Decline icon.

 Managing multiple calls

If you accept a new call when you’re already on a call, you can touch the Answer icon to answer the

current calls.

-15-

4 Using the Menus

4.1 Application Manager

You can manage your application through this function.

4.2 Browser

You can use Browser to view web pages and search for information on the web.

When you open Browser, your home page opens. The web address (URL) of the current page is

displayed at the top of the window.

To go to a webpage or search the web

Touch the URL box at the top of the Browser screen. Enter the address (URL) of a webpage. Or enter

terms you want to search for. As you enter text, your web search engine makes suggestions of web pages and

queries.

To refresh the current page

Touch Menu icon and an option interface appears, then you can touch Refresh to update the current web

page.

-16-

To zoom in or out on a webpage

Slide your finger slightly on the screen to reveal the Zoom control. Touch the plus or minus side of the

Zoom control to zoom in or out.

To find text on a webpage

Touch Menu icon and touch More > Find on page. Enter the text you’re looking for. As you type, the

first word with matching characters is highlighted on the screen, and subsequent matches are boxed. Touch

the left or right arrow to scroll to and highlight the previous or next matching word.

Copy text from webpage

Open a webpage and scroll to the beginning of the text you want to copy, touch Menu icon and touch

More > Select text. Use your finger to drag across the text you want to copy. Touch the text you selected and

the text would be copied to the clipboard.

Navigate among webpage

You can open links on a webpage, navigate back and forward, and review your browsing history, just as

in any web browser.

To open a link: Touch a link to open it. Links that you touch are highlighted in orange until the webpage

they refer to opens in the window.

To go back and forward among the pages you’ve opened: Press back key or touch menu icon> forward.

To view your Browser history: As you browse the web, Browser keeps track of the pages you visit, to

help you find your way back later. Touch the icon which situates at the right of the URL box, then touch

History tab, and then you can view your browser history. Select Most visited tab and you can view a list of

most visited webpage.

-17-

Working with multiple browser windows

You can open up to several Browser windows at once and switch among them.

To open a new Browser window, touch menu icon >new window; New windows open with your home

page.

To switch Browser windows, touch menu icon > windows. Here, all your open windows are listed.

You can select one of them as per your need.

To close a Browser window, touch menu icon > windows. Here, all your open windows are listed.

You can touch the close icon at the right side of each open window to close it.

Downloading files

You can download files and even applications from webpage. The files that you download are stored on

your SD card.

To download a file, Different webpage offer different mechanisms for downloading pictures, documents,

applications, and other files. Touch & hold an image or a link to a file or to another webpage. In the menu

that opens, touch Save. If the file is in a format supported by an application on the phone, it is downloaded to

your SD card. Touch menu icon and then touch More>downloads, here, you can find a list of downloaded

files. If you want to delete a file, just touch the indication box which situates at the left of the downloaded file,

and an option box will pop out, here, you can select delete to delete an unnecessary file.

Working with bookmarks

Open a webpage to bookmark, touch menu icon> Bookmarks, here, you can view bookmarks displayed

in thumbnail style.

Touch & hold a bookmark, an option box will pop out. There, you can perform the following operations

-18-

on bookmarks: Open, open in new window, Edit bookmark, Add shortcut to Home, Share link, copy link

URL, Delete bookmark and set the current bookmark as homepage.

4.3 Calculator

You can use this Calculator to solve simple arithmetic problems or use its advanced operators to solve

more complex equations.

Enter numbers and arithmetic operators on the basic screen; Drag the basic screen to the left to open the

advanced screen; Touch Del to delete the last number or operator you entered. Touch & hold Del to delete

everything in the display.

In the calculator screen, you can touch menu icon to access advanced panel.

4.4 Calendar

You can open Calendar to view events you’ve created.

Touch the Calendar icon in the main menu interface. Events from each account you’ve added to your

phone and configured to synchronize calendars are displayed in Calendar.

Creating an event

You can use Calendar on your phone to create events. In any calendar view, touch menu icon > new

event to open a event details screen for a new event.

Enter a name, time, and optional additional details about the event. You can touch plus icon to add more

reminders. In the Guests field, you can enter the email addresses of everyone you want to invite to the event.

Separate multiple addresses with commas ( , ). If the people to whom you send invitations use Google

Calendar, they’ll receive an invitation in Calendar and by email. You can touch menu icon and touch Show

-19-

extra options to add details about the event. Scroll to the bottom of the Event details screen and touch Done.

The event is added to your calendar.

Synchronizing and displaying calendars

When you add a Google Account or Microsoft Exchange ActiveSync account to your phone that

includes a calendar service, and you configure that account to synchronize calendar events to the phone, the

events from that calendar are added and kept up to date in Calendar on the phone.

In calendar screen, touch menu icon and touch Calendars to display > Calendars, here, you can set

whether calendars are stored on the phone or visible. The Calendars screen displays all the calendars you’ve

added or subscribed to for each account that is configured to synchronize events to your phone, organized by

account. Touch the name of an account to show or hide its calendars on your phone. An icon to the right of

each calendar indicates whether its events are synchronized in the phone and whether they are visible in

Calendar.

Change Calendar settings

You can change the following settings for how Calendar displays event and how it notifies you of

upcoming events. Open a Calendar view, touch menu icon and touch settings.

4.5 Call History

Through this function, you can view a list of all calls,including missed calls, Outgoing call and

Incoming calls.

4.6 Camera

Touch the Camera icon in the main menu interface or on the home screen, camera opens in Landscape

mode, ready to take a picture. In this mode, you can touch the camera icon to take a photo, touch photo icon

-20-

and slide right to switch between camera and video mode.

Note: you can also touch menu icon to pop out an option box. There, you can switch to camcorder mode.

4.7 Chrome

This is a Browser. You can view the Browser to use it.

4.8 Clock

Touch the Clock icon on the Home screen or in the main menu interface. You can set an alarm by

modifying an existing alarm or by adding a new one. You also can use word time，Timer and Stopwatch.

4.9 Downloads

Through this function, you can view a list of files and applications which you downloaded from the

webpage.

4.10 Email

You use the Email application to read and send email. There are many email address to choose

Touch email icon to access it. If the Email account has not been set up, you can set up an Email account

in a few steps.

 Account setup

Enter an Email address and the account’s password.

 Account settings

 Set inbox checking frequency.

 Set Send email from this account by default.

 Set Notify me when email arrives.

-21-

 Set Synchronize contacts, calendar or Email from this account.

 Set Automatically download attachments when connected to Wi-Fi.

 Compose and sending Email

To compose and send an Email:

1. Touch the create icon to compose a new Email.

2. Enter Email address(es) for intended recipient(s).

3. Touch Menu → Attach file to attach a file.

4. Touch Menu → Add Cc/Bcc to add copy or blind copy this Email to other contacts.

5. After completing the Email, Touch send icon to send the Email. Touch folder icon to check the

account status. For each Email account there are five default folders, i.e., Inbox, Drafts, Outbox, Send and

Trash folders. To view sent Emails, open Sent folder and tap refresh icon.

4.11 Facebook

You can use the facebook through this access after connecting to the network.

4.12 File Explorer

The phone supports the SD card. You can use the File Explorer to conveniently manage various

directories and files on the SD card or in the phone.

4.13 FM Radio

Please plug in the compatible earphone to the device and then turn on the radio. The earphone cable can

be used as FM Antenna. Please adjust appropriate volume when listening to the radio. Continue to use higher

volume is harmful for your ear.

-22-

4.14 Gallery

Both pictures and videos taken by camera or stored in SD card can be scanned through this function.

4.15 Messaging

You can use Messaging to exchange text messages (SMS) and multimedia messages (MMS) with your

friends on their mobile phones.

 Sending a message

1. Touch message icon on the home screen and touch New message icon to edit a new message.

2. Enter a contact’s name or call number in the To field. As the information is entered, all matching

contacts appear. Touch a suggested contact or multiple contacts as message recipient(s).

3. Touch Enter message to compose your message. Touch to select a message template.

4. After completing the message, touch Send icon which beside template icon to send your message.

 Message template

Message templates can save your time in editing message with similar format. To create a message

template:

1. Touch message icon on the home screen and touch application item to enter message settings.

2. Touch Message template to create or edit a message template.

4.16 Music

Music plays audio files that are stored on your phone’s SD card, so before you open Music, you must

copy audio files from your computer onto the SD card. Music supports a wide variety of audio file formats,

so it can play music that you purchase from online stores, music that you copy from your CD collection, and

-23-

so on.

To open Music and view your music library

Touch the Music icon in the main menu interface or on the Home screen.

When you copy music to your SD card, Music searches the card for music files and builds a catalog of

your music, based on information about each file that is stored in the file itself. This can take from a few

seconds to several minutes, depending on how many files you have copied onto the SD card. When the

catalog is complete, the Music library screen opens, with tabs that you can touch to view your music library

organized by Artists, Albums, Songs or Playlists.

Note: If the phone power off owing to low battery while you were downloading music via USB cable, the

phone would prompt ‘ SD card error’ when you power on the phone. Repower on the phone for about 5 times,

the same prompt would occur. Under this circumstance, you should repower on the phone until it prompts

‘SD card error. Format?’. Please select format to format your SD card to ensure the phone runs properly.

Any sudden suspend during downloading music via USB cable may result in great damage to your SD

card.

Play music

You can listen to music by using the phone’s built-in speaker, through a wired headset, or through a

wireless Bluetooth stereo headset.

Touch a song in your library to listen to it. The Playback screen opens and the song you touched starts to

play. The Playback screen contains several icons that you can touch to control the playback of songs. On the

right-top of playback screen, you can find three function icons. You can touch them to open the current

playlist, shuffle the current playlist or repeat the current playlist / repeat the current track (touch twice). Three

function icons which situates just above the process bar can be used to control the playing process of the

-24-

music application. Their functions can be defined as the following: switch to last song (touch) /rewind (touch

& hold), play/pause and switch to next song (touch)/ fast forward (touch & hold)

To delete a song from the SD card

You can delete music from the storage card. Touch & hold a song in a library list. In the menu that opens,

touch Delete.

4.17 Note

You can create new note through this function.

4.18 People

In the contacts screen, touch menu icon and you can perform the following operations:

Contacts to display: you can select the contacts on different group to display.

Import/export: you can import/export the contacts form SIM card or storage; you can also share the

visible contacts.

Accounts: you can sync with your account.

Settings: you can set the display options in this interface.

Send contacts by sms/mms: you can share your visible contacts via sms/mms.

Batch delete: Select this function, then you can mark the target contacts. To delete all contacts, you just

need to touch all at the top of contacts screen. Last, touch OK and confirm to delete contacts.

There are four icons on the bottom of the screen,touch it to switch.

Groups : You can assign contacts to several caller groups.

Favorites:You can add contacts you communicated with most frequently to favorites.

Note: Factory data reset enables you to erases all of your personal data from internal phone storage,

-25-

including all messages and contacts information stored in phone memory.

More option: Through this function, you can perform following operations: show contacts,

import/export, fast dial and account.

4.19 Phone

Touch the Phone icon on the Home screen or in main menu interface. Expand the dial pad which

situate center bottom of interface. Touch left bottom of interface there are four tabs are listed at the top

of the screen and you can dial the call log number. You can also view all contacts in your phone and

SIM card.

Note: During a conversation, you can’t originate a new call by open the dial-pad, enter number

and press dial key. If you press dial key, the current conversation would hold.

4.20 Search

The Search function enables you to open a search box for searching your phone and the web.

4.21 Settings

The Settings application contains most of the tools for customizing and configuring your phone.

【Network】

You can use Wireless & Network settings to manage your SIM card, configure and manage

connections to networks and devices by using Wi-Fi. You also can set Bluetooth, data usage, airplane

mode, Default SMS app, tethering & portable hotspot , VPN and mobile networks in this interface.

【My device】

-26-

 Audio profiles

There are four profiles: General, Silent, Vibration and Outdoor. You can set the profiles according to

different conditions.

 Display

You can set Brightness, Wallpaper, Auto-rotate screen, Sleep, Daydream, Font size and Font in this

interface.

 Time Switch Machine

You should set a certain time, when the time arrive, the phone would power on/off automatically.

 Language & input

Use the Language & Keyboard settings to select the language for the text on your phone and for

configuring the input method.

 Date & time

You can use Date & Time settings to set your preferences for how dates are displayed. You can also use

these settings to set your own time and time zone, rather than obtaining the current time from the network,

etc.

【PERSONAL】

 Add account

You should add account first before using this function.

 Security

You can set the parameters about security through this function.

 Location

You can turn on/off location and select High accuracy, Battery saving or Device only through this function.

-27-

 Factory data reset

You can backup your data and reset your phone in this interface.

【More】

 Storage

Use the Storage settings to monitor the used and available space on your phone and on your SD card and

to manage your SD card.

 Battery

You can view your battery status, battery level and battery use in this interface.

 Apps

You can use the Applications settings to view details about the applications installed on your phone, to

manage their data and force them to stop, to view and control currently running services, and to view the

storage used by applications, etc.

 Printing

You can connect to printer and print something you need through this function.

 Accessibility

You use the Accessibility settings to configure any accessibility plug-ins you have installed on your

phone.

 About phone

This function enables you to view some phone related information.

4.22 SIM Toolkit

STK service is the tool kit of SIM card. This phone supports the service function .The specific items are

-28-

depended by SIM card and network. Service menu will be auto added to the phone menu when supported by

network and SIM card.

4.23 Sound Recorder

Use this function to record audio files. Two function icons at the bottom of the Recorder screen are

corresponding to start recording and review record file.

4.24 Tasks manager

You can manager the tasks running in you phone through this function. You also can view and manager

the apps in your phone and SD card.

4.25 Video player

With Videos, you can play video clips in your device (for example, the video you captured by the

camera) or video files stored in compatible SD card (if inserted).

<Tips>

If there are available video files in the device, for example, you captured some video files by camera, the

amount of these video files will be displayed in bracket at right of Movie.

4.26 WeChat

This is a app to chat whit others after connecting to the network,if you want to use it, please log in it

first.

4.27 Whatsapp

You can use Whatsapp through this function.

-29-

5 Appendix

Appendix 1：Troubleshooting

If you find exceptions when operating the mobile phone, restore the factory settings and then refer to the

following table to solve the problem. If the problem persists, contact the distributor or service provider.

Fault Cause Solution

The SIM card

is damaged. Contact your network service provider

The SIM card

is not in

position.

Check the SIM card

SIM

card

error The metal

face of the

SIM card is

polluted.

Clean the SIM card with a clean cloth

-30-

Signals are

obstructed.

For instance,

radio waves

cannot be

effectively

transmitted

nearby a high

building or in

a basement.

Move to a place where signals can be effectively transmitted

Poor received

signal quality

Line

congestions

occur when

you use the

mobile phone

in high-traffic

hours

Avoid using the mobile phone in high-traffic hours

-31-

The mobile

phone cannot

be powered on

The battery

energy is

exhausted.

Charge the battery

Calls cannot be

dialed

Call barring is

activated Cancel call barring

The mobile

phone cannot

connect the

network

The SIM card

is invalid Contact your network service provider

-32-

The mobile

phone is not

in a service

area of the

GSM network

Move to the network operator's service area

The signal is

weak Move to a place where the signal quality is high

The charging

voltage does

not match the

voltage range

indicated on

the charger

Ensure the charging voltage matches the voltage range

indicated on the charger

An improper

charger is

used

Use the charger specially designed for the mobile phone

The battery

cannot be

charged

Poor contact Ensure the charger plug is in good contact with the mobile

phone



6FCCStatement



ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,

pursuanttopart15ofFCCRules.Theselimitsaredesignedtoprovidereasonableprotection

againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgeneratesandcan

radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,

maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat

interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful

interferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipment

offandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe

followingmeasures:‐‐Reorientorrelocatethereceivingantenna.‐‐Increasetheseparation

betweentheequipmentandreceiver.‐‐Connecttheequipmentintoanoutletonacircuit

differentfromthattowhichthereceiverisconnected.‐‐Consultthedealeroranexperienced

radio/TVtechnicianforhelp.ThisdevicecomplieswithPart15ofFCCRules.Operationis

subjecttothefollowingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and

(2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause

undesiredoperation.Note:ThemanufacturerisnotresponsibleforanyradioorTV

interferencecausedbyunauthorizedmodificationstothisequipment.suchmodificationscould

voidtheuser’sauthoritytooperatethisequipment.AnyChangesormodificationsnot

expresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser'sauthorityto

operatetheequipment.



33



7SARStatement



ThisPhonemeetsthegovernment'srequirementsforexposuretoradiowaves.Theguidelines

arebasedonstandardsthatweredevelopedbyindependentscientificorganizationsthrough

periodicandthoroughevaluationofscientificstudies.Thestandardsincludeasubstantialsafety

margindesignedtoassurethesafetyofallpersonsregardlessofageorhealth.FCCRFExposure

InformationandStatementTheSARlimitofUSA(FCC)is1.6W/kgaveragedoveronegramof

tissue.Devicetypes:V351(FCCID:P46‐V351)hasalsobeentestedagainstthisSARlimit.SAR

informationonthisandotherpadcanbeviewedon‐lineathttp://www.fcc.gov/oet/ea/fccid/.

PleaseusethedeviceFCCIDnumberforsearch.Thisdevicewastestedfortypicalbodyworn

mode5mm&Hotspotmode10mmfromthebody.TomaintaincompliancewithFCCRFexposure

requirements,useaccessoriesthatmaintaina10mmseparationdistancebetweentheuser's

bodies.Theuseofbeltclips,holstersandsimilaraccessoriesshouldnotcontainmetallic

componentsinitsassembly.Theuseofaccessoriesthatdonotsatisfytheserequirementsmay

notcomplywithFCCRFexposurerequirements,andshouldbeavoided.



34

-35-

FCC Hearing-Ai d Compatibility (HAC)

The (V351) has been tested for hearing aid compatibility. This device has an M3 and T3 rating. When some

wireless devices are used near some hearing devices such as hearing aids and implants, users may detect a

buzzing or humming noise. Some hearing devices are more immune than others to this interference noise.

Wireless devices may also vary in the amount of interference they generate.

The ratings for compatibility of digital wireless devices with hearing aids are described in the American

National Standards Institute (ANSI) C63.19 standard:

M-Rating: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference with

hearing devices than phone that are not labeled. M4 is the better/higher of the two ratings.( V351) is rated

M4.

T-Rating: Phones rated T3 or T4 meet FCC requirements and are likely be more usable with hearing devices’

telecoil than unrated phones. T4 is the better/higher of the two ratings.

(V351) is rated T3.

The more immune the hearing aid device is, the less likely one is to experience interference noise from the

wireless phone. Hearing aid devices may also be rated. Adding the rating of the hearing aid and the phone

would determine probable usability:

1. Any combined rating equal to or greater than six offers the best use.

2. Any combined rating equal to five is considered normal use.

The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If

your hearing device happens to be vulnerable to interference, you may not be able to use this device

successfully. Trying out this device with your hearing device is the best way to evaluate it for your personal

-36-

needs.This device has been tested and rated for use with hearing aids for some of the wireless technologies

that it utilizes. However, there may be some newer wireless technologies used in this phone that havenot been

tested yet for use with hearing aids. It is important to try the different features of this phone thoroughly and in

different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise.

Consult your service provider or the manufacturer of this phone for information non hearing aid

compatibility.

For information about hearing aids and digital wireless phones

FCC Hearing Aid Compatibility and Volume Control:

http://www.fcc.gov/cgb/dro/hearing.html

Unimax Communications V351 Mobile phone User Manual

Unimax Communications Mobile phone

Contents

Manual

Navigation menu

Namespaces

Views

Navigation
