Preface
About This Manual
Thank you for purchasing the unitech product.
This manual explains how to install, operate and maintain our product.
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical
means, such as photocopying, recording, or information storage and retrieval systems, without
permission in writing from the manufacturer. The material in this manual is subject to change without
notice.
Regulatory Compliance Statements
FCC Warning Statement
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference with radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference with radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
–Consult the dealer or an experienced radio/TV technician for help.
1. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
2. This device complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. To maintain compliance with FCC RF exposure requirements, avoid direct contact to
the transmitting antenna during transmitting.
3. Any changes or modifications (including the antennas) made to this device that are not expressly
approved by the manufacturer may void the user’s authority to operate the equipment.
Unitech Group
5
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
FCC Label Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
RF Radiation Exposure Statement
For body contact during operation, this device has been tested and meets FCC RF exposure guidelines
when used with an accessory that contains no metal and that positions the handset a minimum of 20
cm from the body.
Use of other accessories may not ensure compliance with FCC RF exposure guidelines.
Canadian Compliance Statement
This Class B Digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numerique de la classe B respecte les exigences du Reglement sur le material broilleur du
Canada.
European Conformity Statement
unitech Electronics co., Ltd herewith declares that the unitech product is in compliance with the
essential requirements and all other provisions of the R&TTE 1999/5/EC directive, the EMC 2004/108/EC
directive and the Low Voltage 2006/95/EC directive.
The declaration of conformity is available for download at:
https://portal.unitech.eu/public/Safetyregulatorystatement
RoHS Statement
This device conforms to RoHS (Restriction Of Hazardous
Substances) European Union regulations that set maximum
concentration limits on hazardous materials used in electrical
and electronic equipment.
Waste electrical and electronic equipment (WEEE)
Unitech Group
6
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
unitech has set up a policy and process to meet the EU
directive 2002/96/EC and update 2003/108/EC concerning
electronic waste disposal.
For more detailed information of the electronic waste disposal
of the products you have purchased from unitech directly or
via unitech’s resellers, you shall either contact your local
supplier or visit us at :
https://portal.unitech.eu/public/WEEE
Taiwan NCC Warning Statement
低功率電波輻射性電機管理辦法
第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更
頻率、加大功率或變更原設計之特性及功能。
第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應
立即停用，並改善至無干擾時方得繼續使用。
低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備
之干擾。
Laser Information
The unitech product is certified in the U.S. to conform to the requirements of DHHS/CDRH 21CFR
Subchapter J and to the requirements of IEC 825-1. Class II and Class 2 products are not considered to
be hazardous. The unitech product contains internally a Visible Laser Diode (VLD) whose emissions do
not exceed the maximum limits as set forth in the above regulations. The scanner is designed so that
there is no human access to harmful laser light during normal operation, user maintenance or
prescribed service operations.
The laser safety warning label required by the DHHS/IEC for the unitech product’s optional laser
scanner module is located on the memory compartment cover, on the back of the unit.
* Laser information only applies to the products with laser components.
CAUTION! Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous laser light. Use of optical instruments with the scanner,
including binoculars, microscopes, and magnifying glasses, with will increase eye damage.
Unitech Group
7
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
This does not include eyeglasses worn by the user.
LED Information
The unitech product contains LED indicator(s) or LED ring whose luminance is not harmful to human
eyes during normal operation, user maintenance or prescribed service operations.
*LED information only applies to the products with LED components.
Battery Notice
1. To guarantee optimal performance, it is recommended that rechargeable batteries be replaced
every year, or after 500 charging cycles are completed. It is normal for the battery to balloon or
expand after one year or 500 cycles. Although it does not cause damage, it cannot be used again
and must be disposed of according to the location's safe battery disposal procedures.
2. If a battery performance decreases more than 20%, the battery is at the end of its life cycle. Stop
use and ensure the battery is disposed of properly.
3. The length of time that a battery lasts depends on the battery type and how the device is used.
Conserve the battery life by doing the following:
Avoid fully uncharging the battery because this places additional strain on it. Several partial
uncharges with frequent charges are better than a fully uncharged battery. Charging a
partially charged battery does not cause harm to the unit.
Keep the battery cool. Avoid hot vehicles. For prolonged storage, keep the
battery at a 40% charge level.
Do not leave the battery uncharged and unused for an extended period of time, the battery
will wear out and the longevity of the battery will be at least half of one with frequent
charges.
4. Protect battery life by not over or under charging the battery.
5. Please do not leave battery unused for long time without charging it. Despite unitech’s safety
precautions, the battery pack may begin to change shape. If so, stop using it immediately. Please
check to see if you are using a proper power adapter to charge the battery or contact your service
provider for service.
6. If you cannot charge the battery after it has been idle for an extended period of time and it begins
to heat up, please do not try to charge it. It may not be functional anymore.
7. Please only use the original battery from unitech. Using a third party battery can damage our
products. Please note that when such damage occurs, it is not covered by unitech’s warranty
policy.
Unitech Group
8
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
CAUTION!
RISK OF EXPLOSION IF BATTERY IS REPLACED
INCORRECTLY.
DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
如果更換不正確之電池行事會有爆炸的風險
請依製造商說明書處理用過之電池
如果更换不正确之电池行事会有爆炸的风险
请依制造商说明书处理用过之电池
Battery charge notice
It is important to consider temperature when the battery pack is charging. Charging is most efficient at
normal room temperature or in a slightly cooler environment. It is essential that batteries are charged
within the stated range of 0°C to 40°C. Charging batteries outside of the specified range could damage
the batteries and shorten their life cycle.
CAUTION! Do not charge batteries at a temperature lower than 0°C. This will make the batteries
unstable and dangerous. Please use a battery temperature detecting device for a charger
to ensure a safe charging temperature range.
CAUTION! To ensure the unit working properly, please keep all connectors away from the
contaminants staying inside of them such as dust, grease, mud, and water. The negligence
may cause the unit with no communication, short circuited, and overheated and so on.
CAUTION! If the connector is damaged, please ensure the connector is being
fully repaired before use the unit to avoid causing short circuited.
Storage and safety notice
Although charged batteries may be left unused for several months, their capacity may be depleted due
to build up of internal resistance. If this happens, they will require recharging prior to use. Batteries
may be stored at temperatures between -20°C to 60°C, however they may deplete more rapidly at
higher temperatures. It is recommended to store batteries at room temperature.
* The message above only applies to the usage of the removable batteries.
For the products with non-removable batteries / without batteries, please refer to the specification of each
product.
Unitech Group
9
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Product Operation and Storage Notice
The unitech product has applicable operation and storage temperature conditions. Please follow the
limitation of suggested temperature conditions to avoid failure, damage or malfunction.
*For applicable temperature conditions, please refer to the specification of each product.
Adapter Notice
1. Please do not leave the power adapter in the socket when it is not connected to your unitech
product for charging.
2. Please remove the power adapter when the battery is fully recharged.
3. The bundled power adapter that comes with your unitech product is not meant to be used
outdoors. An adapter exposed to water or rain, or a very humid environment can cause damage to
both the adapter and the product.
4. Please only use the bundled power adapter or same specification of adapter to charge your
unitech product. Using the wrong power adapter can damage your unitech product.
* The message above only applies to the product connected to the adapter.
For the products without using the adapters, please refer to the specification of each product.
Hearing Damage Warning
Zx.3 Warning
The warning shall be placed on the equipment, or on the packaging, or in the instruction manual and
shall consist of the following:
- the symbol of Figure 1 with a minimum height of 5 mm; and
- the following wording, or similar :
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Alternatively, the entire warning may be given through the equipment display during use, when the
user is asked to acknowledge activation of the higher level.
Unitech Group
10
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Warranty Policy
The following items covered under the unitech Limited Warranty are free from defects during normal
use:
The warranty period is varied from each country. Please consult with your supplier or unitech local
office for actual length of warranty period to your purchased product.
Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or
neglect, or if any parts are improperly installed or replaced by the user.
Unitech Group
11
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Chapter 1
Getting Started
MT390S and Elfin System
This manual includes the introduction of MT390S, the installation and other supporting information for
the users.
Elfin system is a kind of Smart Home system, and MT390S is the Public Door Terminal and/or the Family
Door Terminal in the Elfin System. MT390S is designed for the TASHI related vertical markets; TASHI
stands for Telephony, Access, Security, Home Automation and Intercom.
The following diagram has presented the architecture of the Elfin system; it includes MT390S and other
related devices:
For the user manuals on the Elfin System, “Elfin Household User Manual” and “Elfin Custodian User
Manual”, please refer to the Appendix B, “World Support” and contact regional services
representatives.
MT390S has delicate design and is suitable to be installed in the household and community as the
public door terminal and/or the family door terminal.
Unitech Group
12
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Chapter 2
Basic Operation
Package and Interface Overview
Please make sure the following contents are in the MT390S box. If anything appears missing or
damaged, please contact the TASHI representatives.
MT390S
Relay Cable (3 pins)
Communication Cable (8 pins)
QRG Paper Note
Screw (1 pcs in a bag)
Note: The on-wall kit and the on-wall kit with shielding roof are the options.
Unitech Group
13
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Outlook:
The appearance is graceful and meets the IP Code 65; refer to Appendix A, “System Specifications” for
the details.
MT390S with on-wall kit, shielding roof:
MT390S with on-wall kit:
Front Side:
It consists of five main parts; the speaker, the camera, the LED, the doorbell and the RFID area.
攝相模組
摄相头
Camera
門鈴
門鈴
Door Bell
RFID 區
RFID 區
RFID Area
喇叭
喇叭
Speaker
Speaker
LED
Doorbell
RFID Area
Camera
Unitech Group
14
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Rear Side:
There are two terminal blocks; one is the Terminal Block (1X8), the other is the Terminal Block (1X3).
The pin definition/functionality, refer to the section of “Terminal Block”.
Terminal Block
Terminal Block (1X8) Pin Assignment:
This is the Terminal Block (1X8); the color and the function have been depicted respectively.
Pin
Wire Color
Description
1
Blue
RS485-
2
Green
RS485+
3
Yellow
DI-2
4
Orange
DI-1
5
Purple
Wiegand_D1
6
Gray
Wiegand_D0
7
Black
GND
8
Red
12V
Terminal
Block (1X8)
Slot
Terminal Block (1X3) Slot
Ethernet Port
Pin 1
Pin 8
Unitech Group
15
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
In the condition of “DI-1 connects to Hi (5V)” and “DI-2 connects to ground (0)”, DI (Input)
will be High when be activated; otherwise DI will be Low.
Relay Pin Assignment:
This is the Terminal Block (1X3); the function has been presented.
Pin
Name
Wire Color
Description
1
C
Black
Relay 1 Common
2
NC
White
Relay 1 Normal Close
3
NO
Red
Relay 1 Normal Open
Pin 1
Pin 3
Unitech Group
16
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Chapter 3
Installation
Process
Please follow the process to install the MT390S.
1. Fit the on-wall kit in the direction as shown onto the wall by two bolts, there are two kinds of on-wall
kit; the outside on-wall kit, the on-wall kit.
Due to the outside on-wall kit has the upper cover; it is higher than the on-wall kit. Please refer to the
section of “Altitude” for the suggested altitude when installing the outside on-wall kit/on-wall kit.
Condition 1: On-wall kit with shielding roof
Condition 2: On-wall kit
Hook
Hook
Unitech Group
17
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
2. Connect the Ethernet, the Communication Cable (8 pins) and the Relay Cable (3 pins).
3. Fit MT390S onto the outside on-wall kit/on-wall kit by aligning the hooks (the outside on-wall
kit/on-wall kit) to the mounting holes (the rear side of MT390S), and then lift MT390S vertically
upwards and push to the end.
4. Tighten the screw as shown below. Using other kinds of screw will result in unrecoverable damage
and void the warranty.
Altitude
Due to the wide-range camera is used in the MT390S (the horizontal angle is 91° and the vertical angle
is 47°), the altitude of the installation should be considered carefully.
Condition 1: Outside on-wall kit
It is suggested that the distance between the top of the outside on-wall kit and the ground is about
174cm.
Communication Cable
(8 pins)
Mounting Hole
Relay Cable (3 pins)
Ethernet
Unitech Group
18
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Condition 2: On-wall kit
It is suggested that the distance between the top of MT390S and the ground is about 171cm.
Please make sure the ground is flat, take the height difference into consideration if it is not the flat
surface.
In front of camera with 50cm, the coverage of length of users would be from 143cm to 187cm; it might
need to be modified by the on-site situation.
Schematic Diagram:
Physical Appearance
The diagram of physical appearance for MT390S: Unit: mm
Outside on-wall kit
Height = about 174 cm
Distance = 50 cm
On-wall kit
Height = about 171 cm
Unitech Group
19
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Chapter 4
Document Version Record
Version Record
V1.0 Initial Version
V1.1 Modify the title of the cover page
Remove some statements in the section of “Regulatory Compliance Statements”
Unitech Group
20
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Appendix A
System Specifications
This table contains the system specifications for MT390S:
Processor
CPU
ITE IT9079(400MHz)+IT9917(200MHz)
Memory
SDRAM
64MB (DDR2, 16 bits)
Flash
16MB (NOR TYPE Flash, 4 bits)
OS
Open RTOS, based on FreeRTOS V7.5.3
Key
Top Side
1 key for doorbell with 2 color LED
Red for power off / off line / alarm set for RFID
Green for power on (keep flashing) / on line
(constant green) / RFID signal (one flash)
Bottom Side
WIFI WPS Button: HW WPS function input
Reset Button: HW warm start function
Interface
USB Host
Just for firmware update OS
MicroSD Connector
Support MicroSD memory card
Terminal Block (1X8)
Refer to page 6
Terminal Block (1X3)
Refer to page 6
RJ45
Ethernet 10/100M bps PHY with POE function
Audio
Speaker
8 ohm/2W output
Support for over 85 dB at 10cm distance from top
side when push doorbell
Microphone
One MIC design
Directivity => Omni-direcyivitional
Sensitivity => -42dB (@1K Hz)
Unitech Group
21
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Enclosure
Weight
200g
Dimension
154.50mm(L) X 96.00mm(W) X 20.00mm(H)
Environmental
Operating Temperature
-10° to 50° C
Storage Temperature
-20° to 60° C
Charging Temperature
0° to 40° C
Humidity
95% non-condensing
Vibration and Shock
Protection
Tested to MIL-STD-810F, 514.4 process II
Loose Cargo Test
With package
RF Module
Wireless LAN Module
Module Name: WM-8188E
IEEE 802.11 b/g/n
Using USB interface connected to CPU
RFID/HF Module
Module Name: Egm-nfc-s68
Support ISO-15693
Support ISO-14443A (EasyCard) / 14443B
Support NFC
RFID/LF EM module
Module Name: RF10-10
Support ISO-11784
Support ISO-11785
RF Antenna &
Performance
Wireless LAN
One antenna design, support b/g/n; antenna passive
> 40%
RFID/HF
PCB Antenna; Using HF Mirfare S50 card, 4.0cm ≧
Reading distance ≧ 3.0cm
RFID/LF
Coil Antenna; Using LF EM card, 3.0cm ≧Reading
distance ≧ 2.6cm
Certification
Complies with FCC class B, CE , BSMI , NCC, CCC waived, C-Tick
Camera
1M camera: 606563G / PIXELPIUS PO3100K; landscape type
Data Formats
Bayer color filter pattern
4:2:2 YUV data sequence
Maximum Frame Rate
60fps, 1280x720 YCbCr @ 74.25MHz
60fps, 1280x720 Bayer @ 74.25MHz
Unitech Group
22
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Storage
Micro SD, support up to 32GB
IP Requirement
IEC/EN 60529 Standard
IP rating is IP65, front panel
Power
DC Power 12V
From terminal block
POE
13W, from RJ45 connector
ESD
Contact
8KV
Air
12KV
Unitech Group
23
TASHI Smartech Co., Ltd. Unitech Group
3F., No. 188, Baoqiao Rd., Xindian Dist., New Taipei City 231,Taiwan, R.O.C.
Tel: +886-2-8912-1268 Fax: +886-2-2911-3918 TASHI Website: www.tashi.ute.com
Appendix B
Worldwide Support
At Unitech, we have a professional support team to answer your questions or any related technical
issues. If the equipment problem occurs, you may contact our regional services representatives to get
the quick response. We have seven regional services centers, and choose your region to get our quick
support and their contact information can be found in our websites provided as below.
Region
Website
TASHI Smartech
http://www.tashi.ute.com
Global Operation Center
http://www.ute.com
Unitech Taiwan
http://tw.ute.com
Unitech Asia Pacific & Middle
http://apac.ute.com
http://india.ute.com
Unitech China
http://cn.ute.com
Unitech Japan
http://jp.ute.com
Unitech America
http://us.ute.com
http://can.ute.com
Unitech Europe
http://eu.ute.com
In addition, you could contact TASHI Smartech by TASHI@tashi.ute.com
