Wireless Motion Sensor User's Manual
Product Name : Wireless Motion Sensor
Model No : SMT-230
Input Power: 4.5V DC(Battery) / 5V/1A(Power Adaptor)
Features Description:
1. The use of Infrared Motion Detection of sensor detector, it self cannot transmits light
wave of the infrared.
2. The use of three UM-3 AA 1.5V alkaline batteries，battery power is insufficient to inform
the host will automatically operate a very low power, the battery can be used for more
than one years.
3. Easy link, when install at the first time to press the set button on the side of product
Joining with Gateway、Panel Coordinator or Route.
4. Can use the WPW-220 (Wireless Power Controller) do so with even control, For
example: Corridor night auxiliary lighting.。
5. When the device is connected to the power supply, it will automatically cut off the
battery power.
6. This device must be compatible with Gateway using, if beyond the effective reception
distance will not be used.
Outline Dimensions:
Installation Hints:
1. First use UM-3 AA 1.5V alkaline batteries into SMT-230 (Wireless Motion Sensor) battery
holder, and check the battery positive and negative polarity marked is correct.
2. The SMT-230 (Wireless Motion Sensor) by pressing the SET button at the side, and then
press the Gateway、Panel Coordinator or Route at the bottom of the SET button, Wait for 1
second to 15 seconds. If green LED indicator light flash and long light that means linking
success. If green LED indicator light flash and red LED long light that means fail.
3. The SMT-230 (Wireless Motion Sensor) placed on the need to detect the channel next to，
need to pay attention to the Wireless Motion Sensor detector window, do not be put into
place where the sun, and not on where the ambient temperature is too high.
4. Can use the SMT-230 (Wireless Motion Sensor) signals through the Panel Coordinator, on
the Wireless Power Controller do so even control. Join to link with Gateway, please
reference user manual of Wireless Panel Coordinator).
Troubleshooting:
1. Problem: When link with Gateway、Panel Coordinator or Route, there is no display of
green LED indicator light flash and long light for SMT-230 (Wireless Motion Sensor to
flash two or three times.
Solution: a. Need to make sure the battery is good there is electricity, the installation
of the battery positive and negative direction is correct.
b. May be not press set button, need to link with Gateway、Panel
Coordinator or Router again.
c. If the above handles are invalid, please contact with agency.
2. Problem: Unable to link with Gateway、Panel Coordinator or Router.
Solution: a. It needs to confirm the distance between SMT-230(Wireless Motion Sensor)
and Gateway、Panel Coordinator or Route. Wireless connects in
non-camouflage straight line effective range 10 meters. May pull closer
between booth's distance tests to have a look first, whether to have the
improvement segment condition
Specification: :
UIS/Wireless Motion Sensor
Model No. SMT-230
Electrical Specification
Transmit Frequency 2.4GHz ISM band, IEEE802.15.4: 2405 ~
2480MHz
Detection Mode Passive Infrared
Operation Range Up to 200 meters (LOS)
AC Adapter
Input : AC 100 ~ 240V , 47 ~ 63Hz at
0.19A MAX
Output : DC 5V/1A 5W MAX
Battery Type AA Alkaline battery x 3
Battery Life up to 3 year
Sensor Detection Range 8 M 25°C, Angle 110,
LED Indicator Red
Environmental Requirement
Operating Temperature 0°C to 40°C
Storage Temperature -10°C to 55°C
Humidity 90% RH Max., Non-Condensing
Mechanical Specification
Dimension (WxHxD, mm) 86.3*53.1*71mm
Weight (w/o Battery) 78g
Notice : The changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements,
the antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter. No change to the antenna or the
device is permitted. Any change to the antenna or the device could result in the device
exceeding the RF exposure requirements and void user’s authority to operate the
device.
