REMOTE USER GUIDE

Safety Instructions

You must keep safety in mind while using this device. Keep

these and any other instructions for future reference.

Observe Warnings: Carefully follow all warnings on the device

and in the operating instructions.

Heat: Do NOT place the device near heat sources such as

radiators, stoves, heat registers, or other appliances that

produce heat.

Care and Use

Cleaning: Do NOT use liquid, abrasive, solvent, or aerosol

cleaners. Use a damp cloth for cleaning.

When Not in Use: Remove the batteries if this device is to be

left unattended or unused for a long period of time.

Refer servicing to qualied personnel when a

solid object or liquid has fallen onto or into the

device.

Do NOT attempt to service this device. Refer all

servicing to qualied personnel. Opening covers

other than the battery cover will void the warranty.

Publishing Information

The information in this User Guide may change without notice.

Revisions may be issued to tell you about such changes.

Send comments or questions about this User Guide to

techpubs@echostar.com or

Technical Publications, EchoStar Technologies L.L.C,

90 Inverness Circle East, Englewood, Colorado 80112.

Document Number: 206231

Printed in

DISH is a registered trademark of DISH Network L.L.C.

All product names, trade names, or corporate names

mentioned in this User Guide are acknowledged to be the

proprietary property of the registered owners.

Insert the Batteries

Push the tab toward

the top of the remote to

release the battery door

latch and then lift the

battery door from the

remote.

Insert 2 AA batteries,

making sure to match

the plus (+) ends with

the plus markings on the

battery case.

Replace the remote

battery cover.

REMOTE

ANTENNA

SYSTEM

INFO

SYS INFO

Pairing Remote to the

Hopper® or Joey® Receiver

Verify the antenna

is installed on the back

of your Hopper receiver.

Joey receivers have an

internal antenna.

Turn your receiver

and TV on, and press

SYSTEM INFO on the

front panel.

Conrm that you

see the System

Info screen.

Press and release the

SAT button on your

remote (on the side of

the remote). Wait until

you hear a tone and see

the remote listed on the

screen. After pairing,

you should hear a series

of ascending tones.

Conrm that your

remote operates your

receiver by pressing

remote buttons. If this is

not working, go back to

step 4.

For the remote to work with either a Hopper® or

Joey® receiver, it must be paired. Use the following

procedure to pair the remote.

Joey:

Hopper:

Arrow/Select

Buttons

Channel up/

down, navigate

through menus,

and select a

desired option

SAT/TV/AUX

Mode indicator lights

up when sending

signals in that mode

For the remote to work with either a Hopper® or

Joey® receiver, it must be paired. Use the following

procedure to pair the remote.

Channel up/

down, navigate

through menus,

and select a

desired option

Skip Forward/

Forward

Press to skip

forward

10 seconds in a

program. Press

and hold to

forward through

the program

Skip Back/

Back

Press to skip

back

10 seconds

in a program.

Press and hold

to reverse the

program

Back/Live TV

Return to

previous menu.

Press and hold to

return to viewing

live TV

Pause/Play

Pauses or plays

a live or recorded

program

SAT Mode

To use the features described in this section, make sure

you are in SAT mode by pressing the SAT Mode button.

Note: Some features may not be available depending on

your receiver model.

Power & TV Power

Left button turns the

receiver on/off

Right button turns the

TV on/off

Vol and Mute

Buttons

Control TV volume

Programming

required

Recall

Return to

previously viewed

channel(s)

Number Buttons

Enter a channel

number or navigate

through menus

and program guide

Home

Access

receiver

features and

settings

Options

Opens

contextual

options menu

for each

screen

Apps

Displays the

Apps menu

DVR

Displays list

of recorded

programs

Info/Help

Retrieve info

on programs

and set a timer.

Press and hold

for contextual

help

Guide

Display current

and future

satellite program

listings

Search for

programs

SAT Mode, continued

To use the features described in this section, make sure

you are in SAT mode by pressing the SAT Mode button.

Note: Some features may not be available depending on

your receiver model.

Input

Swaps the

tuner

Press this

button for

SAT Mode

SAT LED

lights up

TV Mode

To use the features described in this section, make sure you

are in TV mode by pressing the TV Mode button. Remote

programming is required. Note: The remote has Limited

Mode enabled, which means only the Volume, Mute, and TV

Power buttons work in TV Mode (see Enabling or Disabling

Limited Mode on page 18). Note: Some features may not be

available depending on your TV model.

Mute

Turn TV

volume on

or off

Input

Switch between TV

inputs (available only

for certain makes

and models of TVs)

Channel Up/

Down

Channel up/

down on the

Volume

Control TV

volume

Press this button

for TV Mode

Power & TV Power

Left button turns the

receiver on/off

Right button turns the

TV on/off

TV Menu

Access menu

features

available on

some TVs

Up/Down

Arrow Button

Channel up/

down on the

Select Button

Select a

program or

Number

Buttons

Enter a channel

number

DVR Functions

• Displays a list of recorded programs.

• Plays a live or recorded program.

• Pauses a live or recorded program.

• Press SKIP BACK to skip back about

10 seconds in a program. Press and

hold SKIP BACK to reverse the program

four times as fast as normal play. Press

BACK twice to reverse at 15 times normal

speed, three times to reverse at 60 times

normal speed, and four times to reverse

at 300 times normal speed. The on-

screen bar shows how far you’ve gone.

For a live program, you can only reverse

back to the last channel change or back

one hour, whichever occurs rst.

• Press SKIP FWD to skip ahead about

30 seconds in the program. Press and

hold SKIP FWD (Forward) to fast-forward

through the program four times normal

speed. Press FWD twice to forward at

15 times normal speed, three times to

forward at 60 times normal speed, and

four times to forward at 300 times normal

speed. The on-screen bar shows how

far you’ve gone. Of course, you cannot

forward a live program that has not been

broadcast yet.

DVR Functions, continued

• Press PAUSE and then press and hold

SKIP BACK to reverse the program in

slow motion at 1/4 the speed of normal

play. Press BACK again to reverse at

normal speed.

• Press PAUSE and then press and hold

SKIP FWD to forward the program

in slow motion at 1/15 the speed

of normal play. Press FWD twice

to forward at 1/4 as fast as normal

play. Press FWD three times to play

the program. Of course, you cannot

forward a live program that has not

been broadcast yet.

Buttons In Guide Display Scroll in Lists

Move 3 hours back By 1 screen

upward

Move 3 hours ahead By 1 screen

downward

24 hours back To beginning of list

24 hours ahead To end of list

Using Remote Button

Shortcuts

In addition to their normal functions, some buttons

on your remote control have special shortcut

functions. These shortcuts are enabled while

navigating the on-screen Electronic Program Guide

(EPG) or viewing the scrollable list of events.

Programming Remote to

Control Another Device

There are three ways that you can program your

DISH remote to control another device, such as a

TV, DVD, Blu-ray Disc™ (BD) Player, VCR, audio

receiver, or amplier:

• Scanning the Remote Database

(see page 10)

• Entering a Code (see page 13)

• Learning Codes (see page 15)

Use Scanning the Remote Database if you do

not know the device code. The receiver scans the

database of codes for the particular device and tries

each code. When you nd one that works, you save

that code.

Use Entering a Code when you know the device

code.

Use Learning Codes when either your device is not

listed under Lookup or when you have scanned the

database and none of the codes worked.

Typically, the TV mode button is programmed to a

TV and the AUX button to a DVD, BD, VCR, audio

receiver, or amplier. However, each of the Mode

buttons are programmable to whatever device you

select.

Each of these procedures is discussed in the

following pages.

Lookup Code

continued on next page

Programming Remote to Control

Another Device, continued

Scanning the Remote Database

Turn the device and

receiver on.

Press HOME and select

the Settings tile. From the

Settings screen, select

Remote Manager.

Select the TV Code or

AUX Code option on the

Remote Manager settings

screen. If programming in

TV Code, continue to

step 4. If programming in

AUX Mode, continue with

this step.

For programming in

AUX Mode only:

Scroll the Aux Device:

list to select and highlight

your device type. Select

Next.

Select the Lookup Code

option.

Scan the remote database to nd codes for another

device, such as a TV, DVD, BD, or VCR.

Yes

K-L

Sort by

I-J

M-N

O-Q

R-S

RCS

Brand

RadioShack

Realistic

Reoc

RevolutionHD

Programming Remote to Control

Another Device, continued

Scroll the Sort By: (or

Aux Device:) list to

position the selected

option within the blue

highlight bar.

Highlight device’s name

in the Brand: list and

select Next.

Note: If the brand is not

listed, see Entering a

Code on page 13. The

available device codes

and the code ready to be

tested displays for the

selected brand.

Select Yes to test the

remote with the device.

Press the Mode button

for the device you are

setting up.

Press POWER to turn

off your device. If device

turns off, continue with

step 10.

If it does not turn off,

press to switch

modes. Select No on

screen and repeat

steps 6 through 9 for the

next code.

Scanning the Remote Database,

continued

Programming Remote to Control

Another Device, continued

Save

Yes

Programming Remote to Control

Another Device, continued

Scanning the Remote Database,

continued

Using the remote, turn

the device on and try

some other remote

buttons to make sure

they work. When

nished, press

to switch modes.

If the code worked for

other buttons, select Yes

and continue to step 11.

If the code did not work,

select No and repeat

steps 6 through 10 for

the next code for the

brand of your device.

On the Remote Manager

screen, conrm that the

device’s brand name is in

parentheses after a four-

digit code. Select Save.

Enter Code

Programming Remote to Control

Another Device, continued

Turn the device and

receiver on.

Press HOME and select

the Settings tile. From the

Settings screen, select

Remote Manager.

Select the TV Code or

AUX Code option on

the Remote Manager

settings screen.

If programming in TV

Code, continue to step 4.

If programming in AUX

Code, continue with

this step.

For programming in

AUX Mode only:

Scroll the Aux Device:

list to select and highlight

your device type. Select

Next.

Select Enter Code.

Entering a Code

If you know a device’s code, you can enter the code

directly.

Programming Remote to Control

Another Device, continued

Yes

XXXX

1 2 3

4 5 6

7 8 9

CLEAR

* 0 #

Entering a Code, continued

Using the on-screen keypad,

enter the four-digit code for

your device. Select Next.

Note: The three-digit device

codes used by other DISH

remote controls cannot be

used.

Select Yes to save the code.

Conrm that the code you

entered appears for the

programmed device (TV

or AUX) on the Remote

Manager settings screen.

Press the Mode button

for the device you are

programming (TV or AUX).

Press POWER. If device

does not turn off, press

to switch modes. Try

entering the code again. If

device turns off, continue to

step 10.

Using the remote, turn the

device back on and try some

other remote buttons to see

if they work.

Repeat steps 1 through 10

until you have the best code

for controlling your device.

Programming Remote to Control

Another Device, continued

Learn

Learning Style

Add learned commands to existing code

Blank Slate-This will erase all previous commands

Start Learning

Using the on-screen keypad,

enter the four-digit code for

your device. Select Next.

Note: The three-digit device

codes used by other DISH

remote controls cannot be

used.

Select Yes to save the code.

Conrm that the code you

entered appears for the

programmed device (TV

or AUX) on the Remote

Manager settings screen.

Press the Mode button

for the device you are

programming (TV or AUX).

Press POWER. If device

does not turn off, press

to switch modes. Try

entering the code again. If

device turns off, continue to

step 10.

Using the remote, turn the

device back on and try some

other remote buttons to see

if they work.

Repeat steps 1 through 10

until you have the best code

for controlling your device.

Programming Remote to Control

Another Device, continued

Learning Codes

Turn the device and

receiver on.

Press MENU and select

the Settings tile. From the

Settings screen, select

Remote Manager.

Select the TV Code or AUX

Code option on the Remote

Manager settings screen,

depending on the device

that you want the remote to

learn from.

Select Learn.

Select Learning Style.

Select Add learned

commands to existing

code if you want to

program specic buttons.

Select Blank Slate—This

will erase all previous

commands if you want to

program most of the remote

codes into your 40.0 remote.

Select Start Learning.

Another way to program codes from one remote to

another is the Learning Codes procedure.

Programming Remote to Control

Another Device, continued

Follow the instructions given

on the screen.

When nished, press

any Mode button to save

commands and exit this

screen. To cancel without

saving, do not press any

button on either remote for

at least 20 seconds.

Learning Codes, continued

Programming Remote to Control

Another Device, continued

Programming Remote to Control

Another Device, continued Displaying Device Code

To identify the device code that your remote control

is using, complete the following steps:

Press HOME, select Settings

tile, and then select Remote

Manager. The Home screen

for your current remote

control displays.

If you used the Look Up

option, the brand name

of the device is listed in

parentheses after the code.

If you entered the device

code, the code displays with

Unknown in parentheses

after it.

Remember that the type of

device controlled in AUX

mode may be a DVD/BD

player, a VCR, an audio

receiver, accessory, amplier,

or a second TV. If you

entered the device code, the

code displays with Unknown

in parentheses after it.

Record the stored device

code in the Reference Table

on the inside back cover of

this Guide (see page 31).

Limited Mode

Save

Limited Mode

Enabled

Disabled

Limited Mode

Enabled

Disabled

Enabling or Disabling

Limited Mode

Limited Mode locks out all the device mode

operations except for the device’s Power, Mute, and

Volume. This prevents you from accidentally tuning

away from satellite programming. The following steps

describe how to enable Limited Mode on the remote

and how to disable Limited Mode.

Note: Limited Mode is only used with TV mode.

Press HOME, select

Settings tile, and then

select Remote Manager.

Select the Limited Mode

option.

Use the arrow button to

highlight Enabled and then

select it.

To take the remote out of

Limited Mode, highlight

Disabled instead of

Enabled.

Select Save.

LOCATE

REMOTE

LOCATE

REMOTE

Locating a Lost Remote

Activate your receiver’s front

panel controls and touch

LOCATE REMOTE.

If the missing remote control

is paired to this receiver and

within range, there should

be a series of tones you

can hear and ashing lights

you can see to help you nd

the remote. It can take up

to 30 seconds for the tones

to begin. Press any button

on the remote to turn off the

LOCATE REMOTE tones

after nding it.

If you do not hear any tones

after pressing LOCATE

REMOTE, press the

SYSTEM INFO button on

the front panel. The System

Info screen lists the paired

remote(s). If the remote

control you want to nd is

not listed, it is not paired to

the receiver and LOCATE

REMOTE is not an option.

If the remote control you

want to nd is out of RF

range, LOCATE REMOTE

is not an option.

If you are unable to nd the remote, try this feature

for locating it.

Joey:

Hopper:

REMOTE

ANTENNA

REMOTE

ANTENNA

Avoiding RF Interference

Because your remote control uses UHF-2G

(2.4 GHz ISM band) radio frequencies (RF), you

might experience interference from other devices

transmitting nearby. The instructions in this section

describe how to avoid such conicts.

Ensure the UHF-2G remote

antenna is connected to the correct

input on the Hopper receiver’s back

panel and is not touching anything.

Tighten only by hand.

Vary the tilt angle of the Hopper

receiver’s remote antenna, locating

the antenna’s tip away from any

other electronic equipment or metal

surfaces, even if separated by

wooden shelving.

Move the receiver to a different

location. Place it on as high a

surface as possible, above all other

equipment in your entertainment

center.

Use the optionally available special

extension cable to connect the

remote antenna to the Hopper

receiver and place it away from

other equipment.

Move any nearby antenna or radio

equipment away from the Hopper

and/or the Joey receiver. Do not

place an over-the-air antenna, WiFi,

Bluetooth®, or ZigBee® devices on

or near the receivers.

Adjusting the Antenna

The Hopper receiver communicates with its remote

control(s) through an UHF-2G antenna connected to

the Remote Antenna input on it’s back panel.

Note: This remote antenna can only be used with

UHF-2G capable receivers.

Save

Volume

Control Volume for

AUX

Ensure the UHF-2G remote

antenna is connected to the correct

input on the Hopper receiver’s back

panel and is not touching anything.

Tighten only by hand.

Vary the tilt angle of the Hopper

receiver’s remote antenna, locating

the antenna’s tip away from any

other electronic equipment or metal

surfaces, even if separated by

wooden shelving.

Move the receiver to a different

location. Place it on as high a

surface as possible, above all other

equipment in your entertainment

center.

Use the optionally available special

extension cable to connect the

remote antenna to the Hopper

receiver and place it away from

other equipment.

Move any nearby antenna or radio

equipment away from the Hopper

and/or the Joey receiver. Do not

place an over-the-air antenna, WiFi,

Bluetooth®, or ZigBee® devices on

or near the receivers.

Control Amplier Volume

When the remote is set up to operate your TV, the

MUTE and VOLUME buttons adjust your TV volume

when in SAT mode. When the remote is also set up

to operate a remote-controllable audio receiver or

amplier (usually in AUX Mode), use these steps to

program the remote to control the amplier’s volume.

Press HOME, select

Settings tile, and then

select Remote Manager.

Select Volume.

Under Control Volume for,

highlight the AUX option.

Select Save.

Makesuretheremotecontrolstheamplier’s

volume in other modes:

Press SAT.

Press the plus (+) and minus

(-) sides of the VOLUME

button.

Your tuner/amplier’s volume

changes, and the AUX mode

button lights.

Save

Volume

Control Volume for

AUX

Control TV Volume

Use this procedure to change from having the remote

adjust the volume of an audio receiver or amplier to

having the remote adjust the TV’s volume. When the

remote control is set up to operate your TV, the MUTE

and VOLUME buttons adjust your TV volume when in

SAT mode.

Press HOME, select

Settings tile, and then

select Remote Manager.

Select Volume.

Under Control Volume for,

highlight the TV option.

Select Save.

MakesuretheremotecontrolstheTV’s

volume in other modes:

Press SAT.

Press the plus (+) and minus

(-) sides of the VOLUME

button.

Your TV’s volume changes,

and the TV mode button

lights.

Use this procedure to change from having the remote

adjust the volume of an audio receiver or amplier to

having the remote adjust the TV’s volume. When the

remote control is set up to operate your TV, the MUTE

and VOLUME buttons adjust your TV volume when in

SAT mode.

Troubleshooting

Use this information if you have a problem using

the remote. To solve a particular problem, do the

following:

• Find the information that relates to the problem

you are experiencing. Try the suggested solution

for that problem.

• Make sure your remote control has fresh

batteries. If you see the Remote Battery Low

warning on your TV screen, it is time to change

the batteries. Follow the instructions on page 1.

• Make sure you have a direct line of sight between

the remote and the receiver.

• Visit www.mydish.com/support.

When you press a button on the remote control,

the equipment doesn’t do what you expect.

What to do: Press the correct mode button to set the

remote to the mode for the device you want to control:

SAT for your receiver, TV for your TV, or AUX for your

auxiliary equipment such as a DVD, BD, or VCR.

Point the remote control directly at the TV, with no

objects blocking the signal path. The remote control

uses IR signals to control the devices. IR signals

travel less than 40 feet and cannot go through walls

or other solid objects.

If the batteries are missing or dead, replace them

with new AA-size batteries. If the remote has new

batteries, check whether you put them in correctly.

If you didn’t, take them out and put them in the right

way.

Set up the remote to control all the devices you want

to use with the remote. See Programming Remote to

Control Another Device on page 9.

Troubleshooting, continued

Your remote control does not work well when

controlling the receiver.

What to do: Move your receiver to different

locations. For best results, place the receiver as

high as possible, above all other equipment in your

entertainment center.

Your remote control does not work well when

controlling a TV or AUX device.

What to do: There may be IR interference from

objects near the receiver. Make sure there is a direct

line of sight between the remote and the device.

Your remote control seems to have stopped

working.

What to do: Press one or more buttons on the

remote to wake the remote control. The remote

control may have gone to sleep to reduce battery

drain. If your remote is still unresponsive, take out

the batteries and press any button for three seconds,

then reinsert the batteries.

Your picture is snowy (or black or blue).

What to do: Make sure your TV is tuned to the

correct channel. You may have accidentally changed

the channel on your TV. Check the Reference Table

on page 31 to see what channel your TV is tuned to.

When you press the remote control MUTE or

VOLUME button, nothing happens.

What to do: Program the remote to control your TV.

See Programming Remote to Control Another Device

on page 9. If you are trying to control TV volume, but

the remote is set up to control a tuner or amplier in

AUX mode, then see Control TV Volume on page 22.

The receiver does things even though you haven’t

pressed any remote control buttons.

What to do: Check the System Info screen to

view a list of remotes paired to your receiver. Un-

pair the unwanted remote controls from this screen.

See Avoiding RF Interference on page 20 for more

information.

Troubleshooting, continued

Your remote control isn’t working.

What to do: Make sure the remote control is in the

correct mode (SAT, TV, or AUX).

Change the batteries as described on page 1.

Your UHF-2G remote control does not work well

from far away.

What to do: Make sure the UHF antenna is

connected to the receiver and not touching anything

else.

Vary the angle of the receiver’s UHF antenna.

Locate the UHF antenna tip away from other

electronics equipment or metal surfaces, even if

separated by wooden shelving.

Move the receiver to different locations. For best

results, place the receiver as high as possible,

above all other equipment in your entertainment

center.

Move any nearby off-air antenna away from the UHF

remote antenna. Do not place an off-air antenna on

your receiver.

Your PIP (Picture-In-Picture) is not working.

What to do: The PIP feature works only when

viewing with the Hopper receiver. To access PIP,

press Options on your remote.

Limited Warranty

This Limited Warranty is a legal document. Keep it in a

safe place. Remember to keep your Sales Receipt for

warranty service. We will consider any items you return

without a copy of the Proof of Purchase to be out of

warranty.

This warranty extends only to the original user (“you,” “your”) of the DISH

remote control and is limited to the purchase price of the remote control. DISH

Network L.L.C. and its afliated companies (“we,” “our,” “us”) warrant this

remote control against defects in materials or workmanship as follows.

For one year from the original date of purchase, if we nd the remote control

is defective subject to the limits of this warranty, we will replace the remote at

no charge for parts or labor. We warrant any such work done against defects

in materials or workmanship for the remaining part of the original warranty

period.

This warranty does not cover installation of the DISH Network System;

consumer instruction; physical set up or adjustment of any consumer

electronic equipment; remote control batteries; signal reception problems;

loss of use of the equipment; unused programming charges due to equipment

malfunction; cosmetic damage; damage due to lightning, electrical or

telephone line surges, re, ood, or other acts of Nature; accident; misuse;

abuse; repair or alteration by other than our factory service; negligence;

commercial or institutional use; improper or neglected maintenance;

equipment sold AS IS or WITH ALL FAULTS; equipment removal or

reinstallation; shipping damage if the equipment was not packed and shipped

in the manner we prescribe; nor equipment purchased, serviced, or operated

outside the contiguous United States of America.

REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR

EXCLUSIVE REMEDY. WE SHALL NOT BE HELD LIABLE FOR ANY

INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY

EXPRESSED OR IMPLIED WARRANTY ON THIS DEVICE, NOR FOR ANY

INCIDENTAL OR CONSEQUENTIAL DAMAGE RESULTING FROM THE USE

OF, OR INABILITY TO USE, THIS DEVICE. SOME STATES MAY LIMIT OR

EXCLUDE THE FOREGOING LIMITATION, SO THE ABOVE EXCLUSION

OR LIMITATION MAY NOT APPLY TO YOU. EXCEPT TO THE EXTENT

PROHIBITED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES

SHALL OUR LIABILITY, IF ANY, EXCEED THE PURCHASE PRICE PAID

FOR THIS DEVICE. ANY IMPLIED WARRANTY OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE ON THIS DEVICE IS

LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. SOME

STATES DO NOT ALLOW LIMITATIONS ON HOW LONG A STATUTORY

OR IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT

APPLY TO YOU. WE RESERVE THE RIGHT TO REFUSE TO HONOR THIS

WARRANTY IF WE DETERMINE ANY OF THE ABOVE EXCEPTIONS TO

HAVE CAUSED THIS DEVICE NOT TO HAVE PERFORMED PROPERLY.

THIS WARRANTY SHALL BE VOID IF ANY FACTORY-APPLIED

IDENTIFICATION MARK, INCLUDING BUT NOT LIMITED TO SERIAL OR

CONDITIONAL ACCESS NUMBERS, HAS BEEN ALTERED OR REMOVED.

THIS WARRANTY SHALL ALSO BE VOID IF THE DEVICE HAS BEEN

OPENED BY AN UNAUTHORIZED PERSON (with the exception of opening

the battery cover).
