Owners Manual
OVERVIEW
The T01 universal remote control works
exclusively with the set-top box supplied
by your cable operator. This remote
control operates all of the features and
functions of the set-top box and is pro-
grammable to operate the Volume and
Power of your TV or audio device.
INSTALLING BATTERIES
1. Pull back the remote control’s
battery cover and remove it.
2. Insert the two (2) supplied AA bat-
teries according to the + and
-
marks
in the battery case.
3. Push the battery cover back into
place.
4. Test the unit by pressing the Power
key.
5. If the batteries are inserted correctly,
the green light blinks.
NOTE: When batteries need replacement, the
remote control stops operating. Replace the
old batteries with new AA batteries.
T01
Universal Remote Control
PAIRING T01 REMOTE
To fully enjoy all of the features and functions of
the T01 remote and set-top box you must put
the remote control in the RF mode by using the
following pairing process.
1.
Press both oval buttons on the front of the
set-top box for 3 seconds.
2. Point the T01 remote at the set-top box
and press the MENU key on the remote
for 3 seconds to complete the pairing
process.
3.
Once the pairing process is completed,
press the OK/SELECT (OFN) key on the
remote to clear the on-screen display.
PROGRAMMING TV CONTROL
The T01 remote also contains a universal TV
library and can be programmed to operate the
Power and Volume control of your TV.
1.
Turn on the TV you want to control.
2. Press and hold
the Del key until the green
light under the Power key blinks twice.
3. See setup codes for TVs to find the brand
name of the TV you want to control. Enter
the first 5-digit code for your brand of
TV. If performed correctly, the green light
under the Power key blinks twice.
NOTE: If the green light emits one long
blink, repeat steps 2 and 3, entering the
same code.
4. Aim the remote at the TV and press the
Power key. If the TV turns off you have
found the correct code. If the TV does
not respond, repeat steps 2-4 trying each
code listed for your brand of TV. If none
of the codes work, see "SEARCHING FOR A
DEVICE CODE".
TV Code:
PROGRAMMING AUDIO CONTROL
The T01 remote also contains a universal audio
library and can be programmed to operate
the power and volume controls of your audio
device such as an Amplifier.
1.
Turn on the audio device you want to con-
trol.
2. Press and hold
the Del key until the
green light under the Power key blinks
twice.
3. See setup Codes for Audio Devices, find
the brand name of the audio device you
want to control. Enter the first 5-digit
code for your brand of audio device. If
performed correctly, the green light under
the Power key blinks twice.
4. Aim the remote at the audio device and
press the Power key. If the audio device
turns off you have found the correct code.
If the audio device does not respond
repeat steps 2-4, trying each code listed
for your brand of audio device. If none of
the codes work, see "SEARCHING FOR A
DEVICE CODE".
Audio Code:
SEARCHING FOR A DEVICE CODE
If the Brand of your TV or audio device is not
listed in the code list, try searching for your
code.
1. Turn on your TV or audio device.
2.
Press and hold
the Del key until the green
light under the Power key blinks twice.
3. Press 9 - 9 - 1. The green light under the
Power key will blink twice.
4. Press 1 to search for a TV, or press 3 to
search for an audio device.
5. While pointing the remote control at
the device, press and release the Cursor
Up key until the device turns off. (You
may need to press Cursor Up numerous
times).
NOTE: In the search mode, the remote
control sends IR codes from its library to
the target device.
6. Press OK/SELECT (OFN) to lock in the
code.
CHECKING THE CODES
If you have set up the remote control using the
“
SEARCHING FOR A DEVICE CODE”
procedure,
you may need to find out which 5-digit code
is operating your TV or audio device. Perform
the following steps after setting up your TV
or audio device to find out which 5-digit code
operates your TV or audio device.
1. Press and hold
the Del key until the green
light under the Power key blinks twice.
2. Press 9 - 9 - 0 - 1 to find the TV
code or
9 - 9 - 0 - 3 to find the audio code. The
green light under the Power key blinks
twice.
3. To view the code for the first digit, press
1 once. Wait 3 seconds and count the
number of times the green light blinks
(e.g., 3 blinks =3) and write down the
number in the left most TV or audio
code boxes (at end of this section).
NOTE: If a code digit is “0”, the green
light under the Power key will not blink.
4. Repeat step 3 four more times for the
remaining digits. Use 2 for the second
digit, 3 for the third digit, 4 for the fourth
digit and 5 for the fifth digit. Finish writ-
ing down the code in the TV or audio
code boxes below.
TV Code:
Audio Code
:
ADDITIONAL INFORMATION
The T01 remote control does not have any user
serviceable parts. Opening the case, except for
the battery cover, may cause permanent dam-
age to your remote control.
No part of this publication may be reproduced,
transmitted, transcribed, stored in any retrieval
system, or translated to any language, in any
form or by any means, electronic, mechanical,
magnetic, optical, manual, or otherwise, with-
out the prior written permission of Universal
Electronics, Inc.
All trademarks and service marks appearing
herein are the properties of their respective
owners. Copyright © 2011 Universal Electronics
Inc.
M4167_Rev 1.2 2-1-11
SETUP CODES FOR TVS
A-Mark 10003
Abex 10032
Accurian 11803
Action 10873
Admiral 10093, 10463, 10179
Advent 10761, 10783, 10815, 10817, 10842, 11933,
Adventura 10046
Aiko 10092
Aiwa 10032, 10701, 11914
Akai 11675, 10060, 10702, 10030, 10765,10098,
10672, 11207, 11385, 11676, 11688, 11689,
11692, 11935
Albatron 10700, 10843
Ambassador 10177
America Action 10180
Anam 10180, 10004, 10009, 10008
Anam National 10161
AOC 10030, 10003, 00019, 10052, 10137, 10185,
11089, 11365, 11590, 12014, 12087
Anam National 10161
AOC 10030, 10003, 00019, 10052, 10137, 10185,
11089, 11365, 11590, 12014, 12087
Aomni 11623
Apex Digital 10748, 10879, 10765, 10890, 11217, 11991,
12397
Archer 10003
Astar 11531, 11738
Audiovox 10451, 10180, 10092, 10003, 10802, 10846,
10875, 11284, 11766, 11769, 11803, 11868,
11951, 11952, 12513
Aurora Systems 10801
Aventura 10171
Axion 10171
Belcor 10019
Bell & Howell 10154, 10016
BenQ 11032, 11315
Bradford 10180
Brillian 11007
Brockwood 10019
Broksonic 10236, 10463, 10003, 10426, 11905, 11911,
11929, 11935
Bydesign 11309
C&M 10700
Cadia 11283
Candle 10030, 10046, 10056, 10186
Carnivale 10030
Carver 10054, 10170
Casio 10611, 11205
CCE 10217, 10329
Celebrity 10000
Celera 10765
Changhong 10765
Cinego 11986
Citizen 10060, 10030, 10092, 10046, 10056, 10186,
10280, 10561, 11669, 11671, 11672, 11935
Claritone 10185
Clarion 10180
Classic 11984
Coby 11538, 12017, 12306, 12314, 12315, 12326,
12338, 12340, 12344, 12345, 12347, 12348,
12351, 12560
Commercial Solut. 10047
Compaq 10749
Concerto 10056
Contec 10180
Craig 10180
Crosley 10000, 10054
Crown 10180, 10039
CTX 10700
Curtis 11200, 11326, 12352, 12466
CXC 10180
Cyberhome 10794
Cytron 11326
Daewoo 10145, 10451, 10092, 11661, 10019, 10066,
10067, 10091, 10672, 11909
Daytron 10019
Dell 11264, 11080, 11178
Delta 11369
Denon 10145, 10511
Diamond Vision 11996
Digistar 11565
Digital Lifestyles 11765, 11822
Disney 11665, 12152
Cytron 11326
Daewoo 10145, 10451, 10092, 11661, 10019, 10066,
10067, 10091, 10672, 11909
Daytron 10019
Dell 11264, 11080, 11178
Delta 11369
Denon 10145, 10511
Diamond Vision 11996
Digistar 11565
Digital Lifestyles 11765, 11822
Disney 11665, 12152
Dumont 10017, 10019
Durabrand 10463, 10180, 10178, 10171, 11034, 10003,
11665
Dwin 10747
Dynex 12049, 11463
Eiki 10735
Electroband 10000, 10185
Electrograph 11755, 11623
Electrohome 10463, 10381, 10409, 11570, 11670, 11672
Element 11687, 12183
Emerson 11864, 11394, 10154, 10451,10236,10462,
10180, 10178, 10171, 11661, 11905, 11909,
11911, 11913, 11929, 11944,11963, 12167,
10282, 10280, 10183, 10182, 10181, 10179,
10177, 10158, 10039, 10038, 10019, 10002
Emprex 11422, 11765
Encross 10876, 11474
Envision 10030, 10813, 11365, 12014, 12087
Epson 11122, 11290
Erae 11222
ESA 10171, 11944, 11963
Fisher 10154, 10159
Fujitsu 10179, 10186, 12008
Funai 10000, 10180, 10171, 10179, 11904, 11963
Futuretech 10180
Gateway 11755, 11001, 11756
GE 10047, 10051, 10451,10178, 10021, 10027,
10029,10055, 10135, 10279,10282,10747,
11907, 11919, 11922, 12359
GFM 10171, 11665, 11963, 12167
Gibralter 10017, 10030, 10019
Go Video 10886, 11823, 11831
GoldStar 10178, 10030, 10002,10019, 11032, 10039,
10056, 10409, 11926
Goodmans 10360
GPX 10360
Gradiente 10392
Grunpy 10180, 10179
H & B 11366
Haier 11034, 10768, 11009, 11570, 11748
Hallmark 10178
Hanns.G 11783
Hannspree 11348, 11745, 11783
Harley Davidson 10043, 10179, 11904
Harman/Kardon 10054
Harvard 10180, 10068
Hewlett Packard 11494, 11088, 11089, 11101
Hewlett Packard 11494, 11088, 11089, 11101
Hisense 10748, 11314, 11660, 12089
Hitachi 10279, 10227, 10217, 10173, 10151, 10097,
10096, 10095, 10056, 10043, 10038, 10036,
10032, 10016
HP 11494, 11088, 11089, 11101
Hyundai 10849,11219, 11294
Hyundai 10849, 11219, 11294
I-Inc 11746
iLo 11394, 11286, 11603, 11665, 11684, 11990
Infinity 10054
Insignia 12049, 11423, 10463, 10171, 11204, 11326,
11385, 11517, 11660, 11892, 11963, 12002,
12417
Inteq 10017
iRIS 12189
IX 10877
Janeil 10046
JBL 10054
JCB 10000
JCM 12189, 12256
Jensen 10761, 10050, 10817, 11299, 11326, 11933
JVC 10463, 10053, 10036, 10069, 10160, 10169,
10182, 10731,
Kamp 10216
Kawasho 10158, 10216, 10308
Kaypani 10052
KDS 11687
KEC 10180
Kenwood 10030, 10019
KLH 10765, 10767
Kloss 10024, 10046
Knoll Systems 10781
KMDS 12278
Konka 10632, 10638, 10707, 11385, 11831, 11939
Kost 11262, 11483
Kreisen 10876, 11474
KTV 10180, 10030, 10039, 10183, 10185, 10217,
10280
LG 11423, 10017, 11265, 10178, 10442, 10700,
10856, 11178, 11530, 11637, 11934
LiteOn 10088
Lloyd’s 11904
Loewe 10136
Logik 10016
Luce 10837, 11031
Luxman 10056
LXI 10047, 10054, 10154, 10156, 10178, 10148,
10747
MAG 11678
Magnasonic 11713, 11913
Magnavox 11454, 11866, 11755, 10054, 10051, 10030,
10171, 10706,11944, 11963, 11931, 11913,
11904, 11990, 12372, 11525, 12597, 11365,
11198, 10802, 10386, 10230, 10187, 10186,
10179, 10096, 10036, 10028, 10024, 10020
Magnin 11907
Majestic 10016
Marantz 11454, 10054, 10030, 10704, 11714, 12447
Matsushita 10250
Maxent 11755, 11597, 11714, 11757
MB Quart 11868
Megatron 10178, 10145, 10003
Memorex 10154, 10463, 10150, 10178, 10016, 10179,
10877, 11570, 11665, 11670, 11892, 11911,
11920, 11924, 11926
MGA 10150, 10178, 10030, 10019, 10155, 11907
Micro 11436
Midland 10047, 10017, 10051, 10032, 10039, 10135,
10747
Mintek 11603, 11990
Minutz 10021
Mitsubish 11250, 10093, 10150, 10178, 10014, 10019,
10036, 10098, 10155, 10331, 10592, 11797
Monivision 10700, 10843
Motorola 10093
MTC 10060, 10030, 10019,10056, 10091, 10185,
10216
Multitech 10180, 10217
NAD 10156, 10178, 10056
Nakamichi 11493
Naxa 11998
NEC 10030, 10019, 10036, 10056, 10170, 10704,
11797, 12026
NetTV 11755
Nexus Electronics 12183
Nikko 10178, 10030, 10092
Niko 11581
Noblex 10430
Norcent 10748, 10824, 11089, 11365, 11590, 11591
Norwood Micro 11286, 11296
Noshi 10018
NTC 10092
NuVision 11657
Olevia 11610, 11144, 11240
Onwa 10180
Optimus 10250, 10154, 10166, 11913, 11924
Optoma 10887, 11348
Optonica 10093, 10165
Orion 10236, 10463, 11463, 10179, 11905, 11911,
11929
Panasonic 11480, 10250, 11457, 10051, 10161, 10162,
10226, 11291,11919, 11924, 11947, 11969
Park 12104
PDI 11474
Petters 11523
Philco 11394, 10054, 10030, 10171,10019, 10020,
10024, 10028, 10096, 10179, 10187, 10381,
11665, 11963
Philips 11454, 11394, 11866, 10054,10690, 11483,
11744, 12372, 12597
Pilot 10030, 10019, 10039
Pioneer 11457, 10166, 10038, 10172
Planar 11496
Polaroid 11523, 10765, 12120, 12117, 12063, 12002,
11991, 11962, 11769, 11767, 11766, 11762,
11687, 11565, 11538, 11385, 11341, 11328,
11327, 11326, 11316, 11314,11286, 11276,
11262, 10865 11314, 11286,11276, 11262,
10865, 11385
Portland 10451, 10092, 11661, 10019, 10039
Prism 10051
Proscan 10047, 10030, 10466, 10747, 11922, 12147,
12183, 12256
Proton 10178, 10003, 10031, 10052,10466
Protron 11320, 11323
Proview 11687
Pulsar 10017, 10019
Pvision 11222
Pyle 11200
Quasar 10250, 10051, 10165, 10219,11291, 11919,
11924, 11969
RCA 12434, 10047, 10051, 10093, 11661, 12932,
12746, 12002, 11958, 11953, 11922, 11919,
11907, 10747, 10278, 10254, 10135, 10090,
10038, 10029, 10019, 10018
Realistic 10154, 10180, 10178, 10030,10019, 10032,
10039, 10056, 10165
RevolutionHD 11623
Rhapsody 10183, 10185, 10216
Runco 10017, 10030, 10612
Sampo 11755, 10030, 10032, 10039, 10052, 10100,
10110, 11597
Samsung 12051, 10060, 10702, 10178, 10030, 11959,
11060, 10814, 10766, 10587, 10482, 10427,
10329, 10217, 10056, 10039, 10032, 10019
Samsux 10039
Sansui 10463, 10171, 10165, 10173, 11670, 11892,
11904, 11911, 11929, 11935
Sanyo 10054, 10154, 10036, 10088, 10107, 10146,
10159, 10232, 10484, 10798, 11907
Sceptre 10878, 11217, 11360, 11599, 12337
Scimitsu 10019
Scotch 10178
Scott 10236, 10180, 10178, 10019, 10179, 10309
11711
Sharp 10093, 10039, 10153, 10157, 10165, 10281,
10386, 10491
Sharper Image 11950
Sheng Chia 10093
Shogun 10019
Signet 10800, 10844, 11262
Simpson 10186, 10187
Skyworth 11799
Solarism 11220
Sole 11031, 11366, 11377, 11483, 11530, 11623,
12076
Sony 10810, 10000, 10011, 10080, 11400, 11685,
11904, 11925
Soundesign 10180, 10178, 10179, 10186
Sova 11320, 11952
Soyo 11746, 11826, 11828, 11830, 11831
Spectricon 10003, 10137
Spectroniq 11687
Squareview 10171
SSS 10180, 10019
Starlite 10180
Studio Experience 10843
SunBrite 11420, 11435, 12337
Superscan 10093, 10864, 01944
Signature 10054, 10016
Signet 10800, 10844, 11262
Simpson 10186, 10187
Skyworth 11799
Solarism 11220
Sole 11031, 11366, 11377, 11483, 11530, 11623,
12076
Sony 10810, 10000, 10011, 10080, 11400, 11685,
11904, 11925
Soundesign 10180, 10178, 10179, 10186
Sova 11320, 11952
Soyo 11746, 11826, 11828, 11830, 11831
Spectricon 10003, 10137
Spectroniq 11687
Squareview 10171
SSS 10180, 10019
Starlite 10180
Studio Experience 10843
SunBrite 11420, 11435, 12337
Superscan 10093, 10864, 01944
Supre-Macy 10046
Supreme 10000
SVA 10748, 10587, 10768, 10865,10871, 10872,
11963
Sylvania 11864, 11394, 10054, 10030, 10171, 11963,
11944, 11931, 11913, 11665, 11314, 10587,
10381, 10187, 10096, 10065, 10028, 10024,
10020
Symphonic 10180, 10171, 11904, 11913
Syntax 11610, 11144, 11240
Tandy 10093, 10218
Tatung 10003, 11101, 11286, 11287, 11288, 11361,
11503, 11756
Technics 10250, 10051
Technol Ace 10179
Techview 10847, 12004
Techwood 10051, 10003, 10056
Teknika 10054, 10180, 10150, 10060, 10092, 10016,
10019, 10039, 10056, 10179, 10186, 10312
Telefunken 10702, 10056
Tera 10031
Thomas 11904
Thomson 10209, 10625
TMK 10178, 10056, 10177
TNCi 10017
Toshiba 10156, 10154, 11265, 10060, 10003, 10036,
10149, 11343, 11369, 11935, 11945, 11959,
12006
Tosonic 10185
Totevision 10039
Trical 10157
TruTech 11665, 11723, 12066
TVS 10463
Ultra 10391, 11323
Universal 10027
US Logic 11286
Vector Research 10030
Venturer 11865
VEOS 11007
Victor 10053
Video Concepts 10098
Vidikron 10054
Vidtech 10178, 10019, 10036
Viewsonic 11755, 10797, 10857, 10864, 10885, 11330,
11365, 11578, 11627, 11742, 12014, 12087
Viking 10046, 10312
Viore 11207, 11684, 11811, 12104, 12087
Visart 11336
Vizio 11758, 10864, 10885, 11756
Waycon 10156
Westinghouse 10451, 10885, 10889,10890, 11217, 11282,
11577, 12293
White Westinghouse 10463, 11661, 11909
WinBook 11381, 11503
Wyse 11365
Yamaha 10030, 10019, 10797
Zenith 11423, 10000, 10047, 10017, 10463, 11265,
10178, 10030, 10145, 10092, 11661, 10160,
11365, 10016, 11904, 11909, 11911, 11929
Zonda 10003
SETUP CODES FOR AUDIO
ADC 30531
Aiwa 30158, 30189, 30121, 31089, 31388, 31641
Akai 31512
Altec Lansing 32595, 32597
AMC 31077
Amphion Media 31563, 31615
AMW 31563, 31615
Anam 31609, 31074
Apex Digital 31257, 31430, 31774
Arcam 31189, 30189
Audiologic 31646
Audiotronic 31189
Audiovox 31390
B & K 30820
Bose 31229, 30639, 31253, 31841, 31933
Cambridge Sound 31370
Carver 31189, 30189, 30042, 30121, 31089
Casio 30195
Coby 31389, 32127
Criterion 31420
Curtis 30797, 31389
Daewoo 31250
Denon 32857, 31360, 30176, 31142, 32279
Dynex 32971
Fisher 30042, 31409, 31801
Garrard 30463
GE 31379
Go Video 31532
GPX 32604
Harman/Kardon 30110, 30189, 30891, 31306, 32443
Hitachi 31273, 31801
Insignia 31030, 31077, 31652, 31751, 31893, 32126,
32169, 32175, 32472, 32929, 32966
Integra 31805, 30135, 31298
iSymphony 32018, 32258, 32442
JBL 30110, 31306
Jensen 30797
JVC 30074, 30531, 31374, 31495, 31676
Kenwood 31313, 30042, 30077, 30186
KLH 31390, 31412, 31428
Klipsch 31443
Koss 31497
Lasonic 31798
Lenoxx 31437
Lexicon 31076
LG 31293, 31524, 32676
Linn 30189
Liquid Video 31497
Magnavox 31189, 31269, 30189, 30195, 30391, 30531,
31089, 31514
Marantz 31189, 31269, 30039, 30189, 31089, 31289
Marantz 31189, 31269, 30039, 30189, 31089, 31289
McIntosh 31289
Mitsubishi 31393
NAD 31743
Nakamichi 31313, 30097, 31555, 31642
NexxTech 31751
Norcent 31389, 31751
Onkyo 31805, 30135, 31298, 31531, 32451
FCC COMPLIANCE
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and if not used in accordance with
the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harm-
ful interference to radio or television reception, the user is
encouraged or try to correct the interference by one or more
of the following measures:
• Increase or decrease the separation between the equipment
and receiver.
• Consult the dealer or an experienced remote control/TV
technician for help.
This equipment has been verified to comply with the limits
for a Class B computing device, pursuant to FCC Rules. The
user is cautioned that changes and modifications made to the
equipment without the approval of manufacturer could void
the user's authority to operate this equipment.
FCC AUTHORIZATION LABEL
FCC ID: MG3-4167
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2 This device must accept any interference received, includ-
ing interference that may cause undesired operation.
RCA 31023, 31609, 31254, 30346, 30531, 31074,
31390, 31459, 31511, 32041, 32611
Samsung 31868
Sansui 30189, 30346, 31089
Sanyo 31251, 31469, 31801
Sharp 30186
Sherwood 31077, 31423, 31517, 31653, 32169
Sony 31622, 30158, 31131, 31382, 31503, 31558,
31658, 31722, 31758, 32216, 32475
Soundesign 30670
Stereophonics 31023
Sunfire 31313
Sylvania 30797
Teac 30463, 31074, 31390, 31528, 32261
Technics 31308, 31518, 30039, 31633
Thorens 31189
Toshiba 31572
Vivid 31635
Vizio 31517
Yamaha 32061, 30176, 30186, 30376, 31176, 31276,
31331, 31375, 31476, 32455, 32467, 32471
Yorx 30195
Zenith 30857, 31293, 31524, 31652
