Universal Electronics R37023B TIVO Creek Android Voice Remote 2018 User Manual
Universal Electronics Inc TIVO Creek Android Voice Remote 2018
User Manual
MUG7023E_A1
Programming the TV PWR Key
1. Turn on the device (TV or audio device).
2. Refer to the code list and note the rst code
listed for your brand.
3. Simultaneously press the TiVo and TV PWR
keys for three seconds. The feedback LED will
turn on and stay on.
4. Using the numeric keys, enter the rst ode for
your brand. The activity LED will blink 3 times
and turn o.
5. Point the remote at your TV or audio device
and press the TV PWR key to see if it responds.
6. If the device does not turn o, repeat steps 2-5
using the next code listed for your brand.
7. For a TV, point the RCU at the TV and press the
INPUT, VOL and MUTE keys.
8. If the TV Input or volume does not change,
repeat steps 2-7, selecting the next code
listed for your brand.
9. When the TV responds to keypresses as
expected, setup is complete.
Programming the INPUT Key
1. Turn on the device (TV or audio device).
2. Refer to the code list and note the rst code
listed for your brand.
3. Simultaneously press the TiVo and INPUT
keys for three seconds until the feedback
LED stays lit.
4. Using the numeric keys, enter the rst ode
for your brand. The activity LED will blink
3 times and turn o.
5. Point the remote at the device and press
the Input key.
6. If the TV does not display the name of a signal
source, repeat steps 2-5, selecting the next
code listed for your brand.
Programming the VOL and MUTE Keys
1. Turn on the TV or audio device.
2. Refer to the code list and note the rst code
listed for your brand.
3. Simultaneously press the TiVo and Mute keys
for three seconds. The feedback LED will turn
on and stay on.
4. Using the numeric keys, enter the rst ode for
your brand. The activity LED will blink 3 times
and turn o.
5. Point the RCU at the device and test each of
the VOL keys.
6. If the volume does not increase, decrease and
mute, repeat steps 2-5, selecting the next
code listed for your brand.
7. If the volume controls all functions as
expected, setup is complete.
Setup Codes For Audio - Amplier (A)
Anthem 2254, 2252
Anthem Statement 2254, 2252
Arcam 2006
Cambridge Audio 2212
Carver 2000
Classé 2009, 2010, 2015
Clatronic 2015
Denon 2014, 2215, 2012
Durabrand 2005
Emotiva 2008, 2019, 2020, 2021, 2022
Halcro 2011
Harman/Kardon 2002, 2016
Left Coast 2002
Left Coast Products 2002
Lexicon 2004
Linn 2000
Magnavox 2000
Marantz 2013, 2000, 2002, 2007
Memorex 2005
NAD 2003
New Acoustic Dim. 2003
NuForce 2018
Onkyo 2256
Optimus 2001
Parasound 2011
PeachtreeAudio 2214
Philips 2000, 2002
Pioneer 2001
Polk Audio 2253, 2000, 2002
RCA 2001
Regent 2005
Rotel 2255
Sony 2017
Yamaha 2213, 2216
Setup Codes For Audio - Accessory (M)
Acoustic Audio 2236, 2265
Altec Lansing 2023, 2262, 2035
Apex Digital 2231
Audio Solutions 2051
Audioengine 2229
AudioSource 2059
Aura 2227
B & W 2073, 2029, 2069
BÖHM 2226
Bose 2228, 2058, 2057, 2259
Boston Acoustics 2055
Bowers & Wilkins 2073, 2029, 2069
Coby 2219
Curtis 2068
Denitive Technology 2232, 2053, 2220
Denon 2032, 2078, 2079
Durabrand 2024
Dynavox 2041
Dynex 2070
Enclave Audio 2263
Energy 2066
Energy Sistem 2066
Focal 2077
Haier 2047
Harman/Kardon 2062, 2048
iLive 2039
Inkel 2260
Insignia 2070
Integra 2076
Jamo 2066
JBL 2062, 2050
JVC 2036
Klipsch 2066, 2267, 2223, 2224
Lenoxx 2024
LG 2040, 2221
Logitech 2217
Magnavox 2042
Martin Logan 2049, 2225
Monoprice 2233
Onkyo 2075, 2076, 2044
Orbitsound 2261
Panasonic 2043, 2045, 2063
Paradigm 2234, 2049, 2235, 2264
Philips 2072, 2042, 2034
Pinnacle Speakers 2064, 2060
Pioneer 2071
Polk Audio 2046
Procient 2054
Pyle 2230
RCA 2074, 2257
Samsung 2033
Sanyo 2222
Scandyna 2028
Sharp 2061, 2037
Sherwood 2258, 2260
Sonos 2067
Sony 2056, 2218
SpeakerCraft 2054
Toshiba 2052
TruAudio 2266
VIZIO 2030
Yamaha 2031, 2025, 2038
ZVOX 2026, 2065, 2027
Setup Codes For Audio - Receiver (R)
Adcom 2089
Aiwa 2082, 2120, 2084, 2086
Alco 2107
Altec Lansing 2164
AMC 2092
Anam 2116
Apex Digital 2125, 2096, 2109
Arcam 2094, 2086
Audiotronic 2094
Audiovox 2107, 2181
Axess 2248
Axiim 2280
Bose 2133, 2118, 2209
Cambridge Audio 2277
Carver 2086, 2127, 2082, 2094
Coby 2170, 2168, 2190
Craig 2279, 2250
Denon 2173, 2104, 2205, 2160,
2273, 2147, 2110, 2172,
2274, 2093
Durabrand 2186
Dynex 2179
Emotiva 2207, 2251
Epworth 2082, 2120, 2084, 2086
Fisher 2127
Garrard 2088
Gateway 2114, 2113
GE 2195
General Electric 2195
GPX 2189
Harman/Kardon 2145, 2081, 2198, 2199, 2086
Hitachi 2127
Inkel 2183, 2276
Insignia 2143, 2091, 2157, 2123,
2271, 2174, 2177, 2188,
2276, 2278, 2092, 2162, 2163
Integra 2128, 2269, 2083
JBL 2145, 2198, 2081
JVC 2122, 2080, 2105, 2150,
2111, 2175
Kenwood 2115, 2121, 2102, 2101
KLH 2107
Klipsch 2182
Koss 2112
LG 2167, 2144, 2148, 2101,
2131, 2151, 2202
Linn 2086
Liquid Video 2112
Logitech 2153
Magnavox 2086, 2129, 2094, 2187
Marantz 2100, 2086, 2247, 2140,
2094, 2238, 2129, 2200,
2249, 2205
McIntosh 2100
Micromega 2094
Myryad 2094
NAD 2268
Nakamichi 2102
New Acoustic Dim. 2268
NexxTech 2123
Norcent 2123
Onkyo 2128, 2083, 2269
Optimus 2090, 2127
Oritron 2112
Outlaw 2270, 2210
Panasonic 2178, 2119, 2204, 2169,
2211, 2196, 2139, 2203,
2161, 2185, 2244, 2180, 2122
Philco 2107, 2129
Philips 2154, 2149, 2272, 2086,
2129, 2097, 2241, 2094, 2191
Pioneer 2134, 2106, 2090
Polk Audio 2100, 2086, 2146
Primare 2242
Proscan 2095
Pyle 2246
RCA 2195, 2137, 2165, 2107,
2095, 2193, 2116, 2152,
2192, 2194, 2090, 2127, 2181
Rio 2131
Samsung 2130, 2171, 2176, 2141
Sansui 2086
Sanyo 2127
Sharp 2208
Sherbourn 2207
Sherwood 2092, 2114, 2183, 2132, 2113,
2135, 2276, 2278
Sherwood Newcastle 2114
Sonic Blue 2131
Sony 2117, 2124, 2142, 2158, 2184,
2084, 2166, 2206, 2201, 2239
Stereophonics 2090
Sunre 2159, 2102
Teac 2088, 2107, 2098
Technics 2119
Thorens 2094
Toshiba 2126
Venturer 2107, 2181
Victor 2080
Wards 2084, 2086
Yamaha 2155, 2085, 2245, 2099, 2138,
2087, 2197, 2243, 2275, 2108,
2103, 2136, 2156
Zenith 2101, 2144, 2131, 2148
Setup Codes For Television (T)
3M 1019
888 1360
Accurian 1174
Acer 1083, 1357, 1359, 1378
ad notam 1385
Admiral 1012
Advent 1022, 1005, 1030, 1120
Anity 1330, 1311, 1329
Aftron 1050
Aiwa 1089
Akai 1145, 1016, 1149, 1061, 1081,
1093, 1150, 1189, 1223, 1023
America Action 1008
Anam 1008
Anhua 1008
AOC 1124, 1090, 1204, 1210, 1243,
1262, 1125, 1328
Aomni 1131
Apex Digital 1242, 1023, 1021, 1062, 1199,
1049
Ario 1242
Astar 1155, 1114
Asus 1297
Atvio 1318, 1323, 1050, 1317, 1320
Atyme 1271
Audiovox 1180, 1118, 1193, 1182, 1244,
1039, 1068, 1008, 1029, 1167,
1170, 1190, 1283, 1011, 1174,
1254
Aumark 1002
Auria 1204, 1413, 1210
Aventura 1007
Avera 1242, 1206
Avol 1299, 1269, 1285
Awa 1250
Axess 1313
Axion 1190, 1194, 1206
B & O 1130
Bang & Olufsen 1130
Bell & Howell 1089
BenQ 1308, 1078, 1117, 1052,
1412, 1327
Blu:sens 1269
Blue Light 1321
Bosch 1282
Boxlight 1019, 1020, 1026
Bradford 1008
Brillian 1051
Broksonic 1012, 1189, 1185, 1184, 1191
Byd:sign 1076
Calypso 1413
Canon 1137
Casio 1280, 1060
Celera 1023
Champion 1089
Changhong 1023
Cinego 1197
Cineon 1344
Citizen 1141, 1143, 1144, 1002, 1189
Clarion 1008
Claris 1333
Coby 1305, 1229, 1226, 1235,
1228, 1236, 1133, 1233,
1231, 1234, 1316, 1115,
1237, 1238, 1307, 1205,
1259, 1319
Commercial Solutions 1103
Contec 1008
Contex 1355
Cornea 1326
Craig 1008, 1302
Crosley 1014
Crown 1008
Curtis 1276, 1311, 1249, 1337,
1239, 1242, 1343, 1353,
1199, 1317, 1080, 1077,
1258, 1289, 1292, 1299,
1314, 1330
Curtis Mathes 1002, 1011, 1016, 1140,
1105, 1086, 1089, 1136,
1195, 1252
CXC 1008
Cytron 1080
Daewoo 1140, 1014, 1011, 1089, 1264
Daytek 1404
Dell 1097, 1066, 1054
Denon 1136
Diamond Vision 1200, 1201
Digistar 1119
Digital Lifestyles 1166
Digital Projection Inc. 1160
Digitrex 1363
Disney 1184, 1094, 1293, 1201
Dream Vision 1074
Dukane 1019, 1020, 1095, 1105
Dumont 1000
Durabrand 1012, 1007, 1094, 1120,
1008, 1053
Dynex 1206, 1012
Eiki 1248, 1137, 1261, 1412, 1026
Electric Mirror 1373
Electrograph 1131, 1161
Federal Communication Commission
Interference Statement:
This equipment has been tested and found to
comply with the limits for a class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide a reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiated radio
frequency energy and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet or a circuit
dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
In order to maintain compliance with FCC regulations,
shielded cables must be used with this equipment.
Operation with non-approved equipment or
unshielded cables is likely to result in interference
to radio and TV reception. The user is cautioned that
changes and modications made to the equipment
without approval of manufacturer could void the
user’s authority to operate this equipment.
Industry Canada Statement:
This device complies with RSS-210 of the Industry
Canada Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
www.urcsupport.com
© Copyright Universal Electronics 2018
MUG7023E_A1
UEI PROPRIETARY AND CONFIDENTIAL –
ALL MATERIAL © 2018 UEI
Electrohome 1012, 1144, 1120, 1142
Electron 1249, 1276
Elektra 1000, 1140
Element 1309, 1148, 1219, 1279, 1340,
1183, 1397, 1224
Elite 1335, 1105
ELMO 1137
Emerson 1179, 1094, 1012, 1007, 1196,
1008, 1186, 1183, 1315, 1185,
1140, 1219, 1272, 1011, 1201,
1089, 1309
Emprex 1101, 1166
Encross 1106
Envision 1124, 1090, 1210, 1033, 1204,
1262
Epson 1331, 1071, 1092, 1036, 1055,
1256
Epworth 1089
EQD 1204, 1210
EQD Auria 1204, 1210
ESA 1016, 1007, 1094, 1196, 1186
eTec 1242
Faroudja 1074
Favi 1299
Fisher 1089
Fluid 1279, 1340
Fujitsu 1042, 1031, 1015
Funai 1179, 1007, 1094, 1008, 1186,
1196
Furrion 1296, 1356
Futuretech 1008
Gateway 1161, 1162
GE 1011, 1103, 1086, 1001, 1023
General Electric 1011, 1103, 1086, 1001, 1023
GFM 1007, 1094, 1196, 1183, 1179,
1180
Gibralter 1000
Go Video 1176, 1093, 1177, 1002
GPX 1349, 1348, 1267, 1300, 1365,
1273
Grundig 1015
Grunpy 1008
Haier 1227, 1159, 1387, 1299, 1225,
1025, 1382, 1251, 1053, 1264,
1120, 1239, 1291
Hannspree 1087, 1157
Harvard 1008
Helios 1044
Hello Kitty 1011, 1272
Hewlett Packard 1135, 1286
Hidear 1334
Hightong 1210, 1175, 1173
Himitsu 1008
Hisense 1219, 1410, 1399, 1139, 1211,
1077, 1021, 1387, 1299
Hitachi 1136, 1019, 1027, 1085, 1121,
1387, 1299, 1105, 1394
Hiteker 1285
HP 1135, 1286
Hyundai 1301, 1041, 1063, 1072, 1410
I-Inc 1158
iLo 1094, 1146, 1198, 1128, 1012,
1070
Mitsui 1324, 1361, 1318, 1320,
1322, 1323, 1325
MTC 1002
Multitech 1008
NAD 1006, 1045
Naoki 1116, 1240
Naxa 1356, 1212, 1269, 1289,
1299, 1302
NEC 1403, 1172, 1095, 1151,
1017, 1402, 1406, 1225, 1222
NetTV 1161
New Acoustic Dim. 1006, 1045
Nextar 1352
Nexus 1118, 1219
Nexus Electronics 1219
Nikko 1000, 1086, 1006, 1089
Niko 1123, 1157
Norcent 1090, 1124, 1035, 1126,
1021, 1125, 1157
Norwood Micro 1070, 1073
NuVision 1218, 1138, 1242
oCOSMO 1338
Ölevia 1129, 1064, 1057
Onwa 1008
Optimus 1105, 1188, 1186, 1187,
1013, 1089
Optique 1220
Optoma 1364, 1282, 1409
Orion 1012, 1185, 1191, 1184, 1215
Panasonic 1107, 1001, 1013, 1075,
1188, 1192, 1187, 1099,
1002, 1005, 1006, 1071,
1086, 1089, 1136
Pantel 1376, 1374, 1375
PARK 1212
PDI 1106
Peerless 1408
Peerless-AV 1408
Penney 1002, 1086, 1001, 1006
Philco 1007, 1094, 1196
Philips 1181, 1104, 1315, 1370,
1263, 1266, 1260, 1000,
1007, 1405, 1198, 1090,
1094, 1108
Pioneer 1105, 1045, 1095, 1294
Planar 1105, 1046, 1124, 1327
Polaroid 1112, 1170, 1068, 1115,
1093, 1148, 1168, 1353,
1023, 1199, 1081, 1165,
1299, 1044, 1077, 1119,
1167, 1208, 1214, 1070,
1079, 1080, 1202, 1216,
1246, 1285
Portland 1140, 1011
Prima 1206, 1022, 1159, 1005, 1030
Prism 1001
Projectiondesign 1160
Proscan 1311, 1299, 1330, 1219,
1224, 1296, 1317, 1355,
1337, 1345, 1391, 1353,
1390, 1343, 1384, 1103,
1086, 1217, 1363, 1392,
1398, 1271, 1340, 1356
InFocus 1306, 1409, 1020, 1026, 1222
Initial 1198, 1128
Insignia 1206, 1134, 1118, 1080,
1184, 1202, 1059, 1102,
1110, 1007, 1012, 1093,
1139, 1196, 1245, 1372
Inteq 1000
iRIS 1220
iSymphony 1299, 1285, 1284
IX 1046
JC Penney 1002, 1086, 1001, 1006
JCM 1220, 1224
Jensen 1080, 1291, 1005, 1022,
1030, 1255
JVC 1171, 1230, 1215, 1120,
1142, 1013, 1015, 1012, 1184
jWin 1299
KC 1362
KDS 1148
KEC 1008
Kenmore 1309
Kingston 1295
KLH 1023
Knoll Systems 1306
Kolin 1064
Konka 1093
Kost 1108
Kreisen 1106
KTV 1008
Lasonic 1290
LeEco 1380, 1383
Legend 1242, 1239, 1159, 1227
Lexus 1318, 1320, 1323
LG 1102, 1286, 1387, 1067,
1351, 1169, 1277, 1000, 1010
Lloyd’s 1299
LodgingStar 1288
LXI 1089, 1000, 1006, 1086
MAG 1148
Magnasonic 1186
Magnavox 1315, 1104, 1370, 1260,
1186, 1196, 1018, 1198,
1058, 1007, 1090, 1001,
1029, 1161, 1181
Marantz 1095, 1247, 1017, 1104
Matsushita 1001, 1013
Maxent 1161, 1163
MB Quart 1182
Megatron 1136
Memorex 1120, 1398, 1012, 1185,
1191, 1142, 1184, 1094,
1148, 1206, 1293, 1002,
1005, 1046, 1089, 1143,
1187, 1188, 1270
MGA 1005
MicroTEK 1344
Midland 1000, 1001
Mintek 1128, 1198
Misakae 1007
Misakai 1007
Mitsubishi 1065, 1287, 1005, 1172,
1369, 1308
Prosonic 1212
Proview 1148
Pulsar 1000
Pyle 1221, 1265, 1339
Pyle Home 1221
QuantumFX 1313, 1232
Quasar 1001, 1188, 1363, 1187,
1299, 1338, 1013
Qumi 1026, 1412, 1091
RadioShack 1008, 1089
RCA 1271, 1246, 1311, 1299,
1330, 1296, 1278, 1391,
1337, 1355, 1411, 1086,
1103, 1219, 1317, 1343,
1276, 1381, 1386, 1390,
1105, 1288, 1353, 1023,
1140, 1194, 1195, 1345,
1093, 1182, 1185, 1202,
1342, 1356, 1396, 1001,
1004, 1142, 1336
Realistic 1008, 1089
RevolutionHD 1131
Runco 1105, 1095, 1000
Sampo 1161
Samsung 1207, 1016, 1350, 1002,
1346, 1195, 1371, 1024,
1257, 1013, 1034
Sansui 1012, 1184, 1142, 1185,
1189, 1355, 1191, 1098,
1389, 1007, 1309
Sanyo 1056, 1089, 1028, 1137,
1248, 1206, 1107, 1003, 1118
Sceptre 1338, 1232, 1225, 1062,
1088, 1127, 1047, 1253
Scott 1152, 1008
Sears 1089, 1006, 1007, 1051
Seiki 1345, 1309, 1279, 1310, 1299
Seiko Epson 1331, 1071, 1092, 1036,
1055, 1256
Seleco 1074
Sens 1159, 1180
Seura 1365
Sharp 1241, 1410, 1387, 1261,
1399, 1243, 1335, 1395, 1219
Sherwood 1096, 1281
Sigmac 1304, 1302
Silo 1400, 1332, 1338, 1304, 1362
Silo Digital 1400, 1332, 1338, 1304, 1362
SIM2 Multimedia 1074
SkyVue 1407, 1241
Skyworth 1210, 1175, 1173
Smart 1347
Solé 1108, 1131, 1393
Sony 1032, 1009, 1038, 1147
Soundesign 1008
Soyo 1177, 1158, 1111, 1093, 1178
Spectroniq 1148
Speler 1358, 1354
Squareview 1007
SSS 1008
Starlite 1008
SunBriteTV 1232, 1100, 1129
Superscan 1043, 1007
Supersonic 1313, 1289, 1212, 1379,
1314, 1273, 1291, 1336
SVA 1021, 1044, 1025, 1196
Sylvania 1179, 1007, 1094, 1196,
1186, 1183, 1077, 1296,
1311, 1355
Symphonic 1007, 1186, 1094, 1196, 1008
Syntax 1129, 1064, 1057
Taki 1116
Tatung 1070, 1252, 1162
TCL 1246, 1387
Technicolor 1311
Technics 1001, 1000, 1086, 1013
Techview 1040, 1203
Techwood 1001
Teknika 1008, 1002, 1005
Telefunken 1016
TNCi 1000
Tosaki 1116, 1240, 1093
Toshiba 1113, 1006, 1189, 1037,
1195, 1151, 1084, 1013,
1002, 1020, 1067, 1091,
1274, 1089
TruTech 1094, 1154, 1209
TVS 1012
Upstar 1362, 1388, 1338
US Logic 1070
Venturer 1182, 1180
VEOS 1051
Vidao 1242
Vidikron 1095, 1105
Viewsonic 1204, 1327, 1132, 1366,
1210, 1019, 1161, 1043,
1026, 1082, 1206, 1275,
1027, 1090, 1109, 1286,
1048, 1105, 1118, 1122,
1156, 1213, 1409, 1157
Viore 1299, 1239, 1285, 1212,
1252, 1284, 1146, 1061,
1377, 1289
VisionQuest 1148, 1289, 1298, 1155, 1176
Vivitek 1026, 1412, 1091
VIZIO 1164, 1268, 1162, 1043, 1048
Vuon 1301
W Box 1398
W Box Technologies 1398
Wards 1000, 1006, 1001, 1086,
1002, 1008, 1045, 1089
Waycon 1006
Westinghouse 1153, 1312, 1299, 1048,
1225, 1284, 1303, 1049,
1069, 1242, 1341, 1401,
1011, 1012, 1062
White Westinghouse 1140, 1012, 1186
WinBook 1091
Wyse 1090
Xoceco 1206, 1022, 1159, 1005, 1030
Yamaha 1027
Zenith 1000, 1067, 1185, 1102,
1136, 1140, 1012, 1090
