URC-L-1870

UNIVERSAL

REMOTE 8in1

……………………………………………………………………………………………………

Contents

Introduction -----------------------------------------------------------------------------------3

Battery Installation ------------------------------------------------------------------------4

Function Keys -----------------------------------------------------------------------------------5

Set up Your Remote Control

Set-up by Brand and Code -------------------------------------------------------------------------------6

Set-up by Auto Search -----------------------------------------------------------------------------------6

Learn Function

A. Learn a Command--------------------------------------------------------------------------------------------8

B. Delete a Command-------------------------------------------------------------------------------------------9

C. Delete All Commands in a Device-----------------------------------------------------------------------10

D. Delete All Commands---------------------------------------------------------------------------------------11

Other Set-up

A. Set up Clock ----------------------------------------------------------------------------------------------- 11

B. Volume lock ------------------------------------------------------------------------------------------------ 12

C. Device lock ------------------------------------------------------------------------------------------------- 13

D. Background Adjust --------------------------------------------------------------------------------------- 14

E. Contrast Adjust--------------------------------------------------------------------------------------------- 15

F. All off function----------------------------------------------------------------------------------------------- 15

G. Show view--------------------------------------------------------------------------------------------------- 15

H. Macro function---------------------------------------------------------------------------------------------- 15

I. Delete Macro function------------------------------------------------------------------------------------ 17

J. Device Alternation----------------------------------------------------------------------------------------- 17

Clear All -----------------------------------------------------------------------------------------------18

Need Help? ------------------------------------------------------------------------------------------19

Device Brand Code List

TV ------------------------------------------------------------------------------------------------------

VCR ------------------------------------------------------------------------------------------------------

CBL/SAT ------------------------------------------------------------------------------------------------------

CD -------------------------------------------------------------------------------------------------------

DVD ------------------------------------------------------------------------------------------------------

TAPE -------------------------------------------------------------------------------------------------------

TUNER -------------------------------------------------------------------------------------------------------

AUX ------------------------------------------------------------------------------------------------------

……………………………………………………………………………………………………

Introduction

Thank you for purchasing the URC20-F15DL universal remote control. It has 8

direct device buttons with LCD screen and features the largest infrared code library on

the European market. Based on our (patent pending) creative design, it has the easiest

and fastest way to “set up directly” by brand name and code no. through the LCD

screen even without the manual book.

The URC20-F15DL universal remote control covers almost all brands of

Televisions (TV), DVD-players (DVD), DVR-players (DVD), DVB (CBL/SAT), (digital)

Satellite receivers (CBL/SAT), Cable box (CBL/SAT), Video Recorders (VCR), Tuner

receivers (TUNER), Tape receivers (TAPE), CD-players (CD), Audio amplifiers (AMP)

and other Audio (AUX). It can operate all main functions of your devices.

You can also use “Auto Search” to scan the code library in case of you can’t find

your device brand in the list.

Besides, URC20-F15 can “learn” a new code from an original remote control to

supplement the codes in case of code shortage.

“Show View” function scans all channels for you to have a program quick view.

“All off” function can switch off all your devices with one button.

“Macro” function makes several sequent operations with one button for your home

theater

“Volume lock” can fix VOL+/VOL- button to control only the amplifier for your home

theater.

“Device lock” can prevent the device from being reset until you unlock it.

URC20-F15 has backlight for LCD screen and separate device backlight to show you

the currently working device.

“Low battery indication” reminds you when needed to replace the batteries.

“Device Alternation” allows you to set up any device to AUX. E.g. you can set up a

TV code to AUX and then you will have 2 TV device keys.

All the set up data will be stored in “back up memory” permanently, you don’t need to

be worry about data loss when you replace battery.

The F15DL also has “real time clock” to show your time and AM or PM.

All above mentioned functions show you the URC20-F15D is a advanced, very

powerful LCD universal remote control. Please read this user manual carefully prior to

using you new LCD remote control.

Code Assignment

Bank for Device Initial code Total of codes

TV TV 042 372

VCR VCR 115 170

CBL/SAT Satellite, Cable, DVB 045 323

DVD DVD, DVR 006 127

CD CD 098 120

TUNER TUNER 075 103

TAPE TAPE 083 133

AUX AMP, LD 030 178

……………………………………………………………………………………………………

Battery Installation

This remote control needs 2 AAA batteries to work with. Fresh Alkaline batteries are

strongly recommended. To install the batteries:

1. Turn the remote over, and lift the battery cover off.

2. Insert the batteries, matching the batteries to the (+) and (-) marks inside the

battery compartment.

3. Slide the battery cover back into place.

Notice 1. Whenever the batteries needed replacement, the LCD remote will indicate this on the

screen with a message. Please replace the new batteries now.

2. All data you have set up into the unit will be stored in memory even you take off the

batteries, but you may need to set the clock again.

Security- and disposal references for batteries:

- Batteries are not included in the delivery!

- Keep children away from batteries. If batteries are being swallowed accidentally,

consult a doctor immediately!

- Never bypass batteries.

- Please pay attention to the right polarity (+) and (-) of the batteries! Always

replace both batteries at once; do not use old and new batteries together or

batteries of different types at the same time.

- Do not open batteries, deform or recharge them!

- There is a risk of injury, in case of leaking batteries!

- Do not throw batteries into the fire.

- Danger of exploding is existent.

- Take exhausted batteries out of the device immediately.

- Take the batteries out of the device, if you do not use it for a long period of time.

With reference to environmental protection:

Packing materials are raw materials and can be used again.

Keep packing materials separate. For more information about recycling contact your local

administration.

Old devices do not belong in the domestic refuse!

Dispose of old devices responsibly, and contribute to environmental protection.

Your local administration will inform you about collecting points and opening times.

Old batteries do not belong in the domestic refuse!

Dispose of old batteries accordingly and contribute to environmental protection.

Your local administration will inform you about collecting points and opening times.

Maintenance

Protect the remote control from dirt. Do not use solvents or other aggressive detergents.

Clean the case with a damp cloth and dry it well afterwards.

Note:

In case of leaking batteries, wipe the battery compartment with a cloth. Do not insert

new batteries straightaway.

……………………………………………………………………………………………………

Function Keys

For you start to set up the remote control

or show you the status in LCD

The number keys operate the

same as on your original

remote control, and maybe also

used for entering device codes

when set up.

Let you select the device you

want to control.

Works like the Menu or OSD (on-

screen display)

or Memory key on your original remote control

Turns the device on or off.

Control the volume like the Volume

Up and Down on your original remote

control.

Works like the UP,DOWN,LEFT,RIGHT

OK key on your ori

ginal remote control for

menu function. But during set up mode they

are used for cursor, confirm and exit to

program your remote control only.

Works like the Channel Up and Down

keys on your original remote control.

Mute the sound

Let you make sequent o

perations for you home

theater.

Works like the TV/Video key on

your original TV remote, select

the input for TV.

Works like the Enter

on your

original remote.

For TV Fastext.

Television video, TV and text

mixed, Teletext mode, Page

hold

REW (fast reverse), PLAY

(operate your DVD,CD ect.),

FFWD (fast forward), REC

(Record), Stop

(Terminate your

operation), PAUSE (Pause the

function and standby)

Scans all channel for your

program quick view.

Switches off all your devices

with one button only.

Learnin

g function to import

instructions from other remote

control

Ends the entry

……………………………………………………………………………………………………

Direct Set Up (by Brand and Code)

This revolutionary method lets you directly choose the brand and code in LCD screen,

simply set up your remote control even without manual book.

1.Turn on the device (e.g. your television set) you would like to operate. If it is a VCR,

please insert a tape.

2.Press and hold the key on your remote control. Then press (simultaneously)

a desired device keys (e.g. )

3.Then release them, the brand will be displayed on the screen.

4.Press the or key to select the brand of your device (e.g. your TV

brand: Philips)

5.Check the function of the keys. If none of the keys of your new remote control can

work, or most of the keys work improperly, please try other code by the or

key to choose, until all basic functions operated properly.

6.If you are satisfied with the code, just press the key to save it. LCD shows

“SUCCESS” and then finishes the set up.

SET+TV

i f s a t i s f i e d , p r e s s O K

Remark:

1. To terminate set up, please press .any device (e.g. ) key or key.

2. You must point your remote control to the device that you want to control when

you test the keys.

3. , only used to program your new remote control

during set up. You can’t control your device as normal menu function at this

moment until you finish set up.

4. If the device is locked, you must first unlock the device then set up.

Set-up by Auto Search

In case of the set-up by Brand and Code failed or you can’t find the brand name in

your remote control screen, you may use the Auto Search to find the correct code to

operate your device.

1. Turn on the device (e.g. television) you would like to operate. If it is a VCR,

please insert a tape.

T V

10:45 A M

P H I L I P S

001

ACCENT

023

SUCCESS

P H I L I P S

016

T V 0 1 6

1 1 : 4 5 A M

……………………………………………………………………………………………………

2. Press the key on your new remote control for more than 3 seconds. Then

release it.

3. Press the or keys to select to “CODE SET UP” in LCD menu,

and press the key.

4. The screen shows “DEV SEARCH” in the LCD menu, press the key to

confirm. Then press your desired device key (e.g. key) and then press

the key to start the Auto Search (you must point your remote control to

your device during the search).

5. See if the device reacts or not, once the device reacts, press any key to stop the

search.

6. Test if most of keys work good or not. If most keys work not good enough,

please repeat step 4~5.

7. If you satisfy the reactive code, please press the key to save it and LCD

shows “SUCCESS” then show “DEV SEARCH”. You can press device key (e.g.

) again to finish set up or use or to select other set up.

SET 3S

DVD

Press any key to stop the search check function

s, if satisfied, press OK

Remark:

1. In case of you did not stop the search on time when device being reacted, you may

press the or key to search back to find the passed code.

2. The keys of , are only used to set-up your new remote control

during the Auto Search, you can’t control your device for menu function at the

moment until you finished set up.

T V 0 1 0

1 1 : 4 5 A M

C O D E S E T U P D E V S E A R C H

T V 0 1 0 DVD 014

D V D 0 1 3

D V D 0 3 5

SUCCESS

……………………………………………………………………………………………………

3. When remote control searches through all codes, the remote control will stop at the

beginning code of the search.

4. If the device is locked, you must first unlock the device then set up.

Learn

The function is used to supplement the preprogrammed code list. The standard

code list may provide most of functions needed, but you can add a small number of

additional functions on your URC20-F15D. Or you can add a new code from a new

original remote control which is shortage in the code list.

In learn mode, you must prepare a another original remote control where you will take

codes from and add into your URC20-F15DL.

You can select “LEARN KEY” to learn commands, or “DELETE KEY” to delete learnt

commands, or choose “DELETE DEV” to delete all learnt commands under a

device,or “DELETE ALL” to delete all learnt commands in the remote control.

Learn a Command

1 Press a device key (e.g. key) where you want to learn into.

2 Press and hold the key for more than 3 seconds, and then release it.

3 Scroll or key to “LEARNING”, then press the key.

4 Scroll or key to “LEARN KEY”, then press the key. The LCD

shows “SELECT KEY”.

5 Select a (target) key where you want to learn into (e.g. Power key). The LCD

shows “WAITING”, it is waiting for your source IR signal. (If you don’t send a IR

signal in 30s, LCD will show “FAILED” and then show “SELECT KEY” again.).

6 Point the transmitter of the original (source) remote control to the receiver

window of URC20-F15DL by approximately 30mm apart. Refer to below

drawing.

7 Press and hold a source key (e.g. Power key) from the original remote control

until the LCD display “S U C C E S S ”. If LCD shows “F A I L E D ”, please repeat

steps 4-6.

8. Repeat steps 4-6 to learn more other keys.

S E T 3 S

Press a target key e.g. ³Power

T V 0 1 0

1 1 : 4 5

C O D E S E T U P L E A R N I N G

WAITTTING

L E A R N K E Y S E L E C T K E Y

……………………………………………………………………………………………………

Press a source key from original remote, e.g. ³Power´

Remark:

1. A selected target key can be multi learnt from different sources keys,

URC20-F15D will store the final learnt signal only.

2. All usual function keys can be learnt except ALL OFF, Show View and Macro etc..

3. Some code form may not be learn by this remote control.

4. You can learn about 100 keys totally for 8 device key.

5. You may press any device key (e.g. key) to finish the learn operation. But

you can’t quit when LCD shows “WAITING” until it’s ended.

Delete a Command

If you like to delete a learnt command, you can follow the steps as below:

1. Press the device key (e.g. key) where you like to delete command from.

2. Press and hold the key for more than 3 seconds, and then release it.

3. Scroll or key to “LEARNING”, then press the key and the LCD

shows “LEARN KEY”.

4. Scroll or key to “DELETE KEY ” and then press the key.

5. Press the key on URC20-F15DL that you want to delete, the LCD shows “SURE

DELET” and then press the key to confirm, the LCD will show “SUCCESS”.

6. Repeat step 4 to delete other key if you want.

7. Press a device key (e.g. key) to quit the delete operation when all desired

commands are deleted.

S E T 3 S

SUCCESS

C O D E S E T U PT V 0 1 0

1 1 : 4 5

L E A R N I N G

Target Key Source Key

Original Remote ControlReceiver window

……………………………………………………………………………………………………

Select a key you want to delete d delete next key

Delete All Command in a Device

If you want to delete all learnt commands in a device with one operation in stead of

deleting every key one by one, please follow the below steps:

1. Press a device key (e.g. key) where you want to delete commands.

2. Press and hold the key for more than 3 seconds, and then release it.

3. Scroll or key to “LEARNING”, then press the key and the LCD

display

“LEARN KEY”.

4. Scroll or key to “DELETE DEV” and then press the key. The LCD

shows “SELECT DEV”

5. You select the device key (e.g. key) want to delete.

6. The LCD shows “SURE DELET” , press the key to confirm, the LCD shows

“SUCCESS”, then shows“SELECT DEV”.

7. Repeat step 4-5 to delete commands for other device key.

8. Press to quit current operation.

S E T 3 S

Device key

L E A R N K E Y S E L E C T K E Y

D E L E T E K E Y

SURE DELET S U C C E S S

C O D E S E T U PT V 0 1 0

1 1 : 4 5

L E A R N I N G

L E A R N K E Y S E L E C T D V E

D E L E T E D E V

S U C C E S SSURE DELET S E L E C T D V E

……………………………………………………………………………………………………

Remark: sometimes it may take maximum about 3 minutes for delete all commands in

one device. So if the commands are not many, suggest you delete commands one by

one.

D. Delete All Learnt Commands

If you want to delete all learnt commands in your remote control, please follow the

below steps:

1. Press and hold the key for more than 3 seconds, then release it.

2. Scroll or key to “LEARNING”, then press the key, LCD shows

“LEARN KEY”.

3. Scroll or key to “DELETE ALL” , then press the key.

4.The LCD shows “SURE DELET” , then press the key again,LCD shows

“SUCCESS” to finish the deletion.

S E T 3 S

Other Set Up

A. Set up Clock

You can set up the clock on your URC20-F15DL remote control on it’s LCD screen as

below:

1 Press and hold the key for more than 3 seconds, then release it.

2 Press the or key to select the “CONFIGURE” menu, and then

press the key.

3 Press the or key to select the “TIME SETUP” menu, and then

press the key.

C O D E S E T U P

T V 0 1 0

1 1 : 4 5

L E A R N I N G

D E L E T E A L LL E A R N K E Y

S U C C E S SSURE DELET T V 0 1 0

1 1 : 4 5

……………………………………………………………………………………………………

4 Press the or key to move the cursor to select hour or minute or AM/PM, then

press the number key to set hour and minute, and press the or key to

select AM or PM.

5 Press the key to save the setting and LCD display “SUCCESS” exit to current

setup state, if you enter errors the LCD screen shows³ERROR”. You can press any

device(e.g. ) key to finish set up or press key return to the last state.

SET 3S

B. Volume Lock

This function makes you very convenient when you only use one device to adjust

volume. For example, you may use your amplifier as your main volume control, then

you can use this function to fix the volume and mute key to , no matter which

device you use (even you use TV, DVD, VCR etc), the volume and mute key on

remote control still control the volume and mute of your amplifier.

1. Press and hold the key for more than 3 seconds, and then release it.

2. Press the or key to select the “CONFIGURE”, and then press the

key.

3. Press the or key to select the “VOL LOCK”, and then press the

key.

4. Press the device key to select the device you want to fix, such as .

5. Press the or key to change to “ON” or “OFF” mode.

6. Press the key to save the setting and LCD display “SUCCESS” then “VOL

T V

10:45 A M

C O D E S E T U P CONFIGURE

T I M E

1 1 4 5 A M

T I M E S E T U P T I M E

0 1 4 5 A M

S U C C E S ST I M E

02 30 P M

T I M E S E T U P

……………………………………………………………………………………………………

LOCK” to current setup state, You can press any device key (e.g. ) to finish set up

or press the key to last state, or you can use or to select other set

up.

S E T 3 S

AMP

Remark: You can only lock one device for volume and mute of your new remote control.

The locked device will be unlocked when you lock on the other device automatically.

C Device Lock

You can use Device lock function to fix current device code and this device code can’t

be changed by a new set up such as brand and code set up or auto search. You can

set it to the “OFF” to quit from this function.

1 Press and hold the “ “key for more than 3 seconds, then release it.

2 Press the or key to select the “CONFIG URE”, then press the

key.

3 Press the or key to select the “DEV LOCK”, then press the

key.

4 Press the device key to select the device that you want to fix, such as .

5 Press the or key to change to the “ON” or “OFF” mode.

6Press the key to save the setting and LCD display “SUCCESS” then “DEV

LOCK”, exit to current setup state. You can press any device key (e.g. ) to

finish the set up or press the key to last state, or you can use or

to select other set up.

C O D E S E T U P

T V 0 1 0

1 1 : 4 5

CONFIGURE

V O L L O C KT I M E S E T U P T V O N

A M P O F F A M P O F F SUCCESS

……………………………………………………………………………………………………

S E T 3 S

Remark:

You can fix all more than one device code and these device codes can’t be

changed by neither Auto Search nor Brand Code Set up.

D. Background Light

If the background light is on, the background light will be lighted up for a while after you

press any key.

1 Press and hold the key for more than 3 seconds, and then release it.

2 Press the or key to select the “CONFIGURE”, and then press

the key.

3 Press the or key to select the “LIGHT ”, and then press the

key.

4 Press the or key to change to the “ON” or “OFF” mode.

5 Press the key to save setting and LCD shows SUCCESS then “LIGHT” exit

to current setup state. You can press any device key to finish set up or press the

key to last state, or you can use or to select other set up.

E. Contrast Adjust

If you are not satisfied the LCD screen contrast of your remote control, you can use

below steps to change it.

1 Press and hold the key for more than 3 seconds, then release it.

2 Press the or key to select the “CONFIG URE”, then press the

key.

3 Press the or key to select the “CONTRAST”, then press the

C O D E S E T U P

T V 0 1 0

1 1 : 4 5

CONFIGURE

D E V L O C KT I M E S E T U P T V O F F

T V O N SUCCESS

……………………………………………………………………………………………………

key.

4 Press the or key to adjust contrast level, then press the key until you

satisfied.

5Press the key to save the setting and the LCD shows SUCCESS then

“CONTRAST” exit to current setup state. You can press any device key to finish

set up or press the key to last state, or you can use or to

select other set up.

F. ALL OFF

You can turn off or turn on all devices by one button only and sometimes it’s

convenient .

Press and hold the key about 1second and then release it. The remote control

will send out each power signal for each device key to turn on (or turn off) your

appliance one by one. Meanwhile the device key on remote control flashes to tell you

which power signal is been sending.

Remark: The remote control must be pointed to device that you like to control until the

operation finished.

G. Show View

Show view function scans all TV or CAB/SAT channels for your quick view.

1. Press the device key to select the device (such as ) that you want to operate.

2. Press and hold the SHOWVIEW key about 1 second. When the device’s LED

flashes and it goes into Show View mode. The remote control automatically scans

all channels for a brief view.

Remark: 1. The remote control must be pointed at the device until Show View

operation finished.

2. If you want to exit the show view mode, please press any key during

operation.

H. Macro

Macro function lets you make sequent operation for your home theater. URC20-F15D

can has total 3 Macro operations.

Press and hold the MACRO key and key (or 2, 3 key) simultaneously, then

release them, the remote control will send out a sequent IR commands that you

programmed before. Meanwhile the device LED will flash to tell you which button

command is sending.

……………………………………………………………………………………………………

You can set up a Macro operation by following steps:

1. Press and hold the key for more than 3 seconds, and then release it.

2. Press the or key to select “MACRO”, and then press the key.

3. Press the or key to select the “MACR O1” (or Macro2 or Macro3),

then press the key.

4. The screen shows “SET UP ”, and then press the key.

5. LCD shows “SELECT KEY”, then you can select the device and function key for a

sequent operation that you like.

e.g.: TV+POWER+MUTE+AV, +DVD+PLAY, +VCR+RECORD, etc. That means you want to

turn on the TV and shut off it¶s sound, switch TV input to AV port, at the same time DVD starts

to play, VCR begins to record

6.Press the key to save the setting, LCD shows “SUCCESS” then exit to current

setup state,

7.You can press any device key to finish set up or press the key to last state and

use or to select other set up.

SET 3S

Input sequent operation, then press OK

Remark:

1. A new Macro set up will erase and cover the last programmed Macro.

2.You can set up to maximum 10 commands in a Macro.

3. During operating Macro, be sure point your remote control to your appliance until

finish this operation.

4..Be sure all the keys included in MACRO can send out signals, otherwise even if

you programmed these keys inside the MACRO, it still can’t work properly when

you operate this function. You can check those keys by pressing them to see the

relative Device buttons flash or not before you set up into MACRO.

5. Be sure the device must have relative conditions when you operate MACRO

function. For example the disc must be put in the DVD player and a video tape

must be put in the VCR when you like to play the DVD or make a record by your

VCR by Macro operation.

T V 0 1 0

1 1 : 4 5 A M

MACRO

CODE SET UP

S E T U P

MACRO1 S E L E C T K E Y

SUCCESS

……………………………………………………………………………………………………

I. Delete Macro

1. Press and hold the key for more than 3 seconds, then release it.

2. Press the or key to select the “MACRO”, then press the key.

3. Press the or key to select the “MACRO1”, then press the key.

LCD shows “SET UP”

4. Press the or key to select the “DELETE ”, and then press the

key.

5.LCD shows “SURE DELETE”, Press the key to confirm to delete and the LCD

display shows “SUCCESS” then goes back to the last state.

6.You can press any device key to finish the delete operation or press the key to

last state, and use or to select other set up.

SET 3S

J. Device Alternation

URC20-F15D has a flexible device definition for key. If you want operate second

VCR (or second TV, SAT/CBL, CD... etc.), you can set up it’s code to AUX device key

for a device alteration (CODE SHIFT). Just follow the steps below:

1. Press and hold the key for more than 3 seconds, then release it. Press the

or keys to select to “CODE SETUP”, and press the key.

2. The LCD screen shows the “DEV SEARCH”, Press the or keys to

select “CODE SHIFT”, and press the key. Then you press device key (e.g.

VCR key) for your desired operation device, then press . And then enter the code

M A C R O

T V 0 1 0

1 1 : 4 5 A M

C O D E S E T U P

M A C R O 1 S E T U P D E L E T E

SURE DELET SUCCESS

……………………………………………………………………………………………………

number, e.g.005 (you can find them in the BRAND CODE LIST at the attachment of

this manual book) of the device brand by number button.

3. Please press the key to save it and exit, LCD shows “SUCCESS”. then return

to current setup.

4. Now you can press key to check, it must be set up to VCR code 005. You can

press any device key to finish Device Alternation or press the key to last state,

and use or to select other set up.

SET 3S

VCR

Input the code no. 005

Clear All

Erase all the setting up data, and go back to the factory default settings.

1. Press and hold the key for more than 3 seconds, and then release it.

2. Press the or key to select the “CONFIG URE”, and then press

the key.

3. Press the or key to select the “CLEAR ALL”, and then press the

key and LCD shows SURE CLEAR.

4. Then press the key to clear all settings and go back to original factory

default settings.

T V 0 1 0

1 1 : 4 5 A M

D E V S E A R C HC O D E S E T U P

C O D E S H I F T V C R 0 1 8

T V 0 1 0

SUCCESS

VCR 005

1 1 : 4 5 A M

VCR 018

1 1 :4 5 A M

……………………………………………………………………………………………………

Service and warranties:

Your new 8-in-1 remote control is pre-programmed and can handle all important

functions of your device. In case of technical inquiries or information concerning our

product or its use, our service team is at your service, to help you through a free phone

hotline or via email.

Service Address:

SP European Service & Distribution Centre

Londonerstraße 11

D- 48455 Gildehaus

Service times: Monday to Friday from 9.00 to 18.00

Phone: 00- 800 / 77 77 88 99 (free)

E-Mail: Service@SupportPlus.org

Note: Please don’t send us your device to our address without an explicit calling of our

service team. The sender is responsible for any costs and the risk of unrequested

submissions.

Need Help?

If you have questions about your remote control, just call our free-phone help line!

Before you call, please read the manual carefully. However, please make a note of your

device in the table below and tell it to our operators when you make a call.

Date of purchase: / / /

Day month year

Device Brand Model

number

Model number of

original remote

Code

VCR

CBL/SAT

DVD

TUNER

TAPE

AUX

……………………………………………………………………………………………………

Device Brand Code List

Brand TV

Accent 023

Acme 004,010,313

Acura 010,309

ADA 015

ADC 002,006

Admiral 001,002,003,020,050,054,109,187,196,197,234,308

Adyson 004,186,210,213,296

Agashi 185,187,212,214,296

Agazi 003,308

Agb 124

Agef 234

Aiko 004,005,010,023,296,309

Aim 023

Aiwa 088,213,318,339

Akai 007,009,010,011,012,023,052,062,069,070,071,134,142,170,185,221,296,309,31

4,317,340

AKI 185

Akiba 012,023,101,212

Akito 023,026

Akura 003,012,016,023,072,101,185,191,212,308

Alba 309,317,326

Albe 004,010,012,023,028,029,054,063,069,087,163,170,184,185,187,195,198,215,21

7,296

Albiral 038,185,207

Alcyon 209

Alkos 165

Allorgan 021,027,195,212,219

Allstar 023,052

Amplivision 004,198,207,214,228

Amstrad 003,010,012,014,023,031,069,070,072,075,109,124,226,308,309,317,341

Anam 010,066,110,309

Anglo 010,309

Anitech 003,010,016,023,044,110,183,184,209,224,231,308,309

Ansonic 010,015,023,198,275,309

Arcam 296

Arcam delta 004

Arc en ciel 046,127,140,204,207

Aristona 016,023,052,170,195

A.R.Systems 023

……………………………………………………………………………………………………

Arthur

Martin

159

Art-tech 212

ASA 001,017,018,019,050,111,234

Asberg 023,044,052,182,187,195,209

Astra 010,309

Astro sound 207,212

Asuka 003,004,012,101,212,214,218,296,308

Atlantic 004,021,022,023,052,170,182,197,296

Atori 010,309

Audiosonic 004,010,012,021,023,052,140,170,198,309

Audioton 004,182,198,231,233

Ausind 044,209,212

Autovox 001,003,004,021,044,058,102,126,209,234,308

AWA 023,296

Baird 140,185,186,200,232

Bang&olufsen 001,234

Barcom 210

Basic line 010,012,023,052,101,184,186,212,309

Bastide 004

Baur 023,077,119,133,142,170

Bazin 183,185,201,217

Beijin 263

Beknteknik 228

Beko 008,023,035,084,198,214,228,311,342

Beon 023,052,170

Best 114,115,198

Bestar 023,052,116,198,228,321

Binatone 004

Black

diamond

326

Black star 130

Blacktron 101,212

Blackway 101,212

Blaupunkt 009,113,120,136,179

Blausonic 207

Blue sky 012,023,101,212,228

Blue star 101,121

Bondstec 130

Boots 004,026

Boston 208,218

BPL 023,096,101,121

Brandt 037,046,047,127,128,140,204

Brinkmann 023

Brion vega 001,023,052,058,170,208,234,343

……………………………………………………………………………………………………

Bristol 208

Britannia 004,296

Bruns 001,008,040,227,234

BSR 027,132,197,210,212,215

BTC 012

Bush 010,012,020,023,025,026,028,029,033,052,063,069,101,116,121,132,133,140,16

8,170,172,309,317,320,321,326

California 195

Capsonic 003,214,308

Carad 023

Carena 023,212,214

Carrefour 028

Cascade 010,023,309

Casio 023,201

Cathay 023,052,170

CCE 023

Centrum 325,326

Centurion 023,052,170

Century 001,191,234

CGE 044,054,130,132,187,198,204,209

CGM 226,233

Changhong 241,242,245,246,247,248,264,278,279,288

CIE 196,212,226

Cihan 214

Cimline 010,029,212,213,309

City 010,309

Clarivox 038,040,170

Clatronic 003,004,010,012,023,031,044,052,084,130,185,198,209,212,214,308,309

Cofadel 204

Colombia 228

Colombus 182

Concorde 010,309

Condor 004,022,023,052,084,101,182,184,187,198,211,296

Conrowa 265

Contec 004,010,028,030,031,211,212,217,296,309

Cont.ediso 204

Continental

edison

037,046,047,112,127,140

Cosmel 010,309

Crezar 182,226

Crosley 001,044,130,132,209,234

Crown 010,023,044,052,054,084,096,115,122,170,198,209,228,309,371

Cs electronics 004,012,130,296

CTC 130

CTC clatronic 015,187,198,207,210,212,226

……………………………………………………………………………………………………

Cybercom 308,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,32

6,327,328,329,330,331,332,333,334,335,336,337,338

Cybermaxx 308,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,32

6,327,328,329,330,331,332,333,334,335,336,337,338

Cybertron 012

Cytron 308,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,32

6,327,328,329,330,331,332,333,334,335,336,337,338

Daewoo 004,010,023,052,059,095,116,196,296,309,321,345

Dainichi 012,212,296

Dansai 003,023,052,170,212,296,308

Dantax 035,149,162,198,213,326

Datronic 196,211

Datsura 096,122

Dawa 023,195

Dayton 010,309

Daytron 023,196

Deawoo 023

Decca 004,011,023,026,031,052,124,170

Decca(uk) 229

De graaf 007,020,034

Deitron 023

Denko 185,214

Denver 211,212

Desmet 023,052,170,182

Diamant 023

Digiline 023,213

Digital 212

Dixi 010,023,040,052,170,309

Domland 219

Domoh 182

Drean 023

DTS 010,309

Dual

004,023,090,126,127,132,140,161,185,195,197,207,211,219,308,309,310,311,31

2,313,314,315,316,317,318,319,320,321,322,323,324,325,326,327,328,329,330,

332,333,334,335,338

Dual-Tec 004,010,132,197,309

Dumont 001,004,015,018,019,234

Dux 023,170,195

Dynatron 023,052,170

Elbe 023,038,109,158,180,198,275

Elcit 001,234

Electa 121

Electro Tech 010,309

Elekta 101

Elektronska 207

……………………………………………………………………………………………………

ELG 023

Elin 004,017,019,023,052,170,181,186,197,233,296

Elite 012,022,023,052,179,184,197

Elman 015,132 ,207,213

Elsay 184,229

Elta 010,296,309

Emerson 001,023,101,128,142,234

Emperor 101

Engel 207,227

Erres 016,023,052,170

ESC 023

Estel 207

Etron 010,023,309

Eurocom 207,212

Euro-Feel 003,308

Euroline 089,170

Euroman 023,185,196,198,212,214,296

Euromann 003,004,052,115,308

Europa 023,228

Europhon 004,015,023,026,052,073,124,132,207,226

Eurotronic 228

Expert 021,186,188,197

Exquisit 023

Fenner 010,116,184,191,195,212,309,321

Ferguson 036,037,038,051,053,082,112,128,164,170,232

Fidelis 182,211

Fidelity 004,020,023,069,097,296,317

Filsai 217

Finlandia 007,020,111,129,181,186,200

Finlux 001,004,011,015,017,018,019,023,044,052,064,111,124,132,158,168,170,181,20

9,225,234,314,315

First Line 004,010,023,027,052,063,130,183,296,309

Fisher 001,004,007,019,028,030,040,041,084,132,195,198,200,211,227,234

Flint 023,052,149,183,184,187,196,214

Formenti 001,002,004,022,044,126,132,134,170,182,209,234,296

Fortress 001,002,234

Fraba 023,198

France

Concept

184

Friac 023

Frontech 003,010,020,050,069,119,130,183,184,191,213,308,309,317

Fujitsu 011,021,197,207,212

Funai 003,027,211,212,308,346

Galaxi 023,054,084

Galaxis 023,198

……………………………………………………………………………………………………

Galeria 196

Galway 184

GBC 010,028,132,226,233,309

GCM 195,212

GEC 004,011,023,042,050,052,124,133,142,170

GEC(UK) 186,224,229,231

Geloso 010,020,132,231,309

General

Technic

010,309

Genexxa 012,023,050,052,212

Germanvox 226

Goldhand 231,296

Goldstar 004,010,013,020,023,052,085,094,130,132,170,172,198,206,210,223,296,309,32

6,344

Goodmans 003,010,011,023,028,029,052,069,094,112,116,128,154,170,206,230,308,309,31

7,321,326

Gorenje 084,115,198

GPM 012,210,212

Gradiente 023

Graetz 050,142,143,188

Granada 004,007,011,020,023,028,032,041,044,052,055,065,124,128,129,134,135,139,17

0,209

Grandin 010,012,023,101,121,170,184,309

Gronic 180,191,212

Grundig 009,018,023,044,092,102,117,118,136,137,185,209,347

GTT 187,211

H-150a 276

Haaz 338

Halifax 003,004,296,308

Hampton 004,183,226,296

Hanseatic 004,008,010,022,023,027,028,052,074,096,101,119,132,142,170,198,234,275,30

Hantarex 010,023,124,309

Hantor 023

Harwood 023,186,326

Hauppauge 023

HCM 003,004,010,023,075,101,121,200,211,226,308,309

Hemmermann 183,201

Hifivox 140,204

Higashi 185

Highline 023

Hinari 007,010,012,023,028,044,052,138,170,200,212,213,227,230,309,326

Hisawa 012,101,121,149,212

……………………………………………………………………………………………………

Hitachi 004,011,017,020,023,024,028,034,042,045,046,047,048,049,050,086,119,124,13

2,133,139,140,141,142,143,145,186,224,257,258,280,313,348

Hitsu 185,212

Horizont 306,307

Hornyphon 023,052

Hoshai 012,212,233

Huanyu 004,116,296,321

Hygashi 004,296

Hyper 004,010,130,132,226,233,296,309

Hypson 003,004,023,052,101,121,170,212,214,308

Iberia 023

Ibervisao 188,207

Ibico 196

ICE 003,004,010,012,023,052,069,187,210,212,296,308,309,317

ICES 296

Imperial 023,044,050,052,054,084,130,132,187,198,209

Indesit 025,102

Indiana 023,052,170

Ingelen 050,188

Ingersol 010,309

Inno Hit 004,010,011,012,023,052,094,124,170,206,209,211,222,309

Innovation 003,010,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,308,30

9,314,316,317,318,319,320,321,322,324,325,326,327,328,329

Interbuy 010,110,130,309

Interfunk 001,016,023,050,052,130,140,142,170,198,234

Internal 023

Intersound 182

Intervision 003,004,015,023,101,110,198,308

Irradio 010,012,023,052,069,170,206,209,212,309,317

Iskra 183,231

Isukai 012,023,101,212

ITC 004,132,184,204,233

ITE 207

ITL 196

ITS 012,023,052,069,101,121,212,296,317

ITT 010,050,062,133,134,135,142,143,144,188,220,309,314,349

ITV 023,309,326

JEC 165

Jet Point 199

JVC 028,052,069,082,189,317,350

Kaisui 004,010,012,023,121,212,296,309

Kamosonic 004

Kamp 004,296

Kapsch 021,050,188,197,200

Karcher 004,010,017,023,038,101,170,198,309

……………………………………………………………………………………………………

Kasai 212

Kendo 015,020,023,029,109,180,183,186,196,197,198,207,213

Kennedy 021,132,182,197,231

Kennex 182,226,233

Kerion 182,212

Kingsley 004,296

Kitt 212

Kneissel 023,175,180,182,196,198,212,275

Kolster 023,052,191,210,214

Konka 012,023,185,238,242,243,244,248,249,254,255,260,261,285,287,289,303,313

Kontact 204

Korpel 023,052,170

Korting 001,022,198,234

Kosmos 023

Kotron 226

Koyoda 010,309

Kronne 180

KTV 004,210

Kuba 186,195

Kuro 096,122,200

Kyoto 038,217

Lavis 211

Lenco 010,023,226,233,309

Lenoir 004,010,196,199,208,211,309

Lesa 130,191

Leyco 003,011,023,027,052,170,214,308

LG 004,010,013,020,023,052,085,089,094,130,132,150,170,172,198,206,210,223,29

6,309,326

Liesenk 170

Liesenkotter 023,179,195

Life 003,010,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,308,30

9,314,316,317,318,319,320,321,322,324,325,326,327,328,329

Lifetec

003,010,023,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,21

1,214,308,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,3

25,326,327,328,329,330,331,332,333,334,335,336,337,338

Loewe 023,098,099,198,234,275,351

Loewe Opta 001,052,170,190

Logik 031

Luma 020,021,023,052,142,170,186,197

Lumatron 020,021,023,052,142,170,308

Lux May 023,052

Luxor 004,020,048,078,094,102,133,139,142,147,206,313

Madison 023,182,212

Magnadyne 001,015,124,130,132,170,191,234

Magnafon 004,015,044,073,124,181,182,183,195,207,209,296

……………………………………………………………………………………………………

Magnavox 023

Magnum 003,010,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,308,30

9,314,316,317,318,319,320,321,322,324,325,326,327,328,329

Mandor 003,308

Manesth 003,004,022,023,029,052,170,182,184,188,213,308

Manhattan 023

Marantz 023,052,170,187,195

Marech 182

Marelli 001,234

Mark 023,052,170,296

Marshall 212

Matsui 004,005,010,011,014,020,023,026,027,028,029,031,052,063,069,092,124,148,14

9,165,170,174,213,215,309,317

Matsushita 066

Mcmichael 042

Mediascreen 214

Mediator 016,023,052,170,195

Medion 003,010,023,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,21

1,308,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,3

26,327,328,329,330,331,332,333,334,335,336,337,338

M-Electronic 004,010,017,019,037,050,052,069,110,111,116,140,170,309,317,321

Melectronic 023,296

Memorex 010,309

Memphis 010,011,114,309

Mercury 023

Metz 001,076,081,136,152,153,218,234

Micromaxx 003,010,023,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,30

8,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,326,3

27,328,329,330,331,332,333,334,335,336,337,338

Microstar 003,010,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,308,30

9,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,326,327,3

28,329,330,331,332,333,334,335,336,337,338

Minerva 018,102,136,185,209

Minoka 023,052

Mitsubishi 001,023,028,031,052,055,056,061,099,102,136,171,192,234,276,278,279,280,32

6,352

Mivar 004,044,074,094,124,193,198,206,209,275,290,291,292,293,294,295

Morgans 023

Motion 044,209

MTC 133,198

Multi System 170

Multitec 023

Multitech 004,010,015,020,023,028,044,046,130,132,170,198,207,212,233,296,309

Murphy 004,019,134,296

NAD 142

……………………………………………………………………………………………………

Nagoya 207

Naiko 023

Nakimura 023

Naonis 020,109

National 065,102,194,284

NEC 023,028,057,331

Neckermann 001,004,009,020,023,052,084,119,133,170,198

NEI 023,052,069,114,170,183,199,212,317

Nesco 130

Neufunk 023

Newmar 182,183,207

Newtech 010,023,052,309

New World 012

Nicamagic 004,296

Nikkai 003,004,011,012,023,052,114,165,170,186,205,211,212,296,308

Nikkei 226,233

Noblex 023,184,199,200

Nobliko 004,015,018,044,209,296

Nogamatic 140,204

Nokia 050,062,064,133,134,135,142,143,144,188,220,314,315,353

Nordic 212,213

Nordmende 023,025,037,046,047,050,052,058,112,127,128,140,204,354

Nordvision 170

Nordway 217

Nortek 233

Novatronic 023,183,187,212,226

Oceanic 050,142,143

Oceanic(F) 188,220

Octan 195

Okano 023,084,187,198,233

Onceas 004,196,211

Onwa 070,196,212

Opera 023

Orbit 023,052

Orion 010,014,022,023,027,029,031,052,063,076,100,124,143,148,160,170,172,213,30

9,326,355

Orline 023

Ormond 172,326

Orsowe 207

Osaki 003,004,005,011,012,023,075,166,308

Osio 023

OSO 012

Osume 011,030

Otto Versand 002,004,009,022,023,028,052,077,112,119,121,122,132,133,140,142,170

Pael 004,181,185,296

……………………………………………………………………………………………………

Palladium 004,013,023,084,198

Palsonic 023

Panama 003,004,010,023,166,296,308,309

Panasonic 023,050,065,066,067,068,102,125,142,143,152,153,194,266,286,316,356

Panavision 023

Panda 267

Pathe Cinema 004,022,038,074,132,182,207,211,228,275,296

Pathe Marconi 038,046,047,127,140,204

Pausa 010,309

PCM 211

Perdio 005,011,022,023,182,207,213

Perfekt 023

Philarmonic 185

Philco 001,023,044,054,130,132,187,198,209,234

Philharmonic 004,166

Philips 001,004,016,023,039,042,044,052,089,090,112,116,132,142,156,170,195,219,23

4,321,323,357

Phoenix 001,023,052,170,182,195,198,234,296

Phonola 001,016,023,052,170,195,219,234,296

Pioneer 037,050,052,140,146,170,198,216,358

Pionier 198

Plantron 003,023,052,308

Polar 305

Poppy 010,211,309

Prandoni-Prin

020,124,142,182,197,207,209,212

Precision 004,166

Prima 010,050,309

Prinz 048,186,195,217,230,313

PRO2 308,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,32

6,327,328,329,330,331,332,333,334,335,336,337,338

Profex 010,044,142,309

Profilo 172,326

Profi-Tronic 023,052

Proline 011,016,023,052,063,184,213,214

Prosonic 023,043,108,162,170,172,198,296,311,320,326

Protech 003,004,010,015,023,052,114,130,132,133,166,170,308,309

Provision 023,170,326

Pye 016,023,052,069,170,195,234,317

Pygmy 208

Pymi 010,309

Quasar 130

Quelle 003,004,017,018,019,023,027,031,052,077,130,132,136,142,151,170,206,308,32

Questa 028

……………………………………………………………………………………………………

Radialva 023

Radiola 016,023,039,052,170,195

Radiomarelli 001,023,124,130,191

Radionette 017,019,181,188

Radio Shack 023

Radioton 185,211

Radiotone 008,023,052,198

Raduga 307

Rank 018,028

RBM 018

Rc 259

RCA 032

Recor 023

Record 307

Rectiligne 023

Rediffusion 142

Redstar 023

Reflex 023

Revox 023,052,170,190,198

REX 003,020,021,050,109,158,197,308

RFT 001,008,040,198,227,234,275

R-Line 023,052,170

Rm-d 268

Roadstar 003,010,012,023,226,233,308,309,359

Robotron 001,227,234

Royal Lux 198

RTF 001

Rubin 304,306,307

Saba 001,037,046,047,050,059,112,124,127,128,140,142,143,204,360

Saccs 038

Sadec 212

Sadko 307

Sagem 101,184

Saisho 003,004,010,014,029,031,124,183,213,215,308,309

Saito 207

Salora 020,048,050,094,096,108,109,119,122,129,132,133,135,139,142,186,206,313,31

4,320,361

Sambers 015,044,073,124,181,207,209,211

Samsung 003,004,010,011,023,031,052,084,091,094,105,106,161,166,170,173,198,199,20

6,296,308,309,362

Sandra 004,296

Sandra

Color

195,231

Sansui 023,052,183,196,212

Sanwa 188

……………………………………………………………………………………………………

Sanyo 004,007,011,017,019,023,028,030,031,032,040,041,044,074,096,128,132,135,16

1,198,200,244,252,275,278,296,363

Save 023

SBR 016,023,042,170

Schaub

Lorenz

050,142,143,188,220

Schneider 004,012,023,039,052,069,072,126,130,132,140,161,170,317,329,372

Schneider

France

195,212,219

Scott 182

SEG 003,004,015,023,028,040,044,089,130,132,170,296,308,326

SEI 023,201,234

SEI-synudyne 001,014,015,027,050,076,124

Seleco 020,021,028,050,109,132,158,197,364

Sencora 010,309

Senday 182

Sentra 165,205,212

Serino 184,212

Sharp 002,006,028,030,060,202,243,365

Shivaki 195,196

Shiwan 212

Shorai 027,212

Siam 023

Siarem 001,015,124,132,180,191,234

Sicatel 038,207

Siemens 009,023,030,136,179,366

Siera 023

Sierra 016,052

Siesta 161,198

Silva 023,211,212,224,296

Silver 028

Singer 001,015,023,130,132,180,188,191,204,211,234,338

Sinudyne 001,014,015,023,027,029,076,132,170,201

Skantic 050,139,147

Skyworth 239,271,272,273,301,338

Sogera 022

Sokol 306,307

Solavox 050,093,188

song 251,269,283

Soniko 214,217,233

Sonitron 007,135,198

Sonneclair 023

Sonoko 003,004,010,023,052,101,170,211,212,214,308,309

Sonolor 007,050,188

Sontec 023,052,161,170,196,198,210,220

……………………………………………………………………………………………………

Sony 010,011,028,030,031,077,107,128,131,166,203,237,302,309,367

Soundcolor 211,212,214,215

Soundmaster 226

Sound&Vision 012,015

Soundwave 023,052,170

Standard 004,010,012,022,023,052,166,182,183,191,196,309

Starlight 170

Starline 228

Starlite 023,212

Starlux 196,226

Stenway 101,121,185,212

Stern 020,021,050,197

STM 221

Strato 023

Sunic Line 182

Sunkai 010,023,027,063,183,211,212,213,309

Sunstar 023

Sunwood 010,023,052,309

Superla 004,296

Supertech 023,119,212,226,233,296

Supertone 185,207

Supra 010,184,214,309

Susumu 012

Sutron 010,309

Sydney 004,166,296

Sysline 170

Sytong 212,296

Taisho 207,213

Tamashi 212

Tandberg 081,158

Tandy 002,004,011,012,049,050,166

Tashiko 004,020,028,042,057,129,166,296

Tatung 004,011,023,026,052,124,166,170,229

TCL 196,240,241,250,253,274,277,297,298,299,300

TCM 003,010,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,308,30

9,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,326,327,3

28,329,330,331,332,333,334,335,336,337,338

Teac 023

Teak 190

TEC 004,010,049,130,132,166,309

Tech Line 023

Technema 182

Technics 066,194

Technisat 040

Tecnema 022

……………………………………………………………………………………………………

Teinelsa 182,207

Teknant 211

Teleavia 037,046,112,127,140,204

Telecor 023

Telefunken 023,036,037,051,052,053,079,080,102,103,112,127,128,140,164,204,368

Telefusion 023

Telegazi 023

Telemeister 022,023

Teleopta 226

Telesonic 023

Telestar 023

Teletech 010,023,089,114,130,170,309

Teleton 004,021,081,119,133,166,197

Televideon 022,182,296

Tempest 023

Tennesee 233

Tensai 010,012,019,022,023,027,052,184,185,207,211,213,217,325

Tenson 182

Tesla 180,207

Tesmet 052

Tetran 182,197

Tevion 003,010,023,062,068,069,088,104,108,112,116,155,157,169,172,176,177,178,30

8,309,310,311,312,313,314,315,316,317,318,319,320,321,322,323,324,325,326,3

27,328,329,330,331,332,333,334,335,336,337,338

Texet 004,166

Thomson 004,023,037,046,047,051,052,053,059,102,103,112,127,128,140,164,167,204,33

1,369

Thorn 011,019,023,036,038,055,082,112,128,142,165,170,232

Tokai 011,023,052,183,184,210,212,226

Tokyo 004,296

Tomashi 101,121,212

Top Vision 210

Toshiba 018,028,083,165,205,245,270,279,281,370

Towada 050,132

Trans

Continens

023

Transonic 023

Transtec 296

Trevi 199,226,233

Trident 166

Triumph 014,023,083,124,181,211,226

Tsoshi 212

Uher 021,022,023,044,050,052,181,184,190,195,197,198,209

Ultravox 001,004,015,023,130,132,134,182,183,186,191,201,234,296

Unic Line 023,182,183,212

……………………………………………………………………………………………………

Unic Radio 180,188,228

Uniden 212

United 023,089,170,326

United

Satellite

228

Universum 003,017,019,023,052,084,103,111,115,123,130,132,170,198,206,209,308,314

Univox 023,038,188,191,195,207,234

Uranya 182,191,211

Utax 211

Vanguard 186,212

Venus 262

Vestel 023,050,052,170,183,199,319,325,326

Vexa 010,023,170,212,231,309

Victor 028,052,066

Video Logic 185

Videologique 004,012,296

Videosat 130

Video System 023,052

Videotechnic 296

Videoton 184,217

Vidion 196

Visiola 004,180,296

Vision 022,023,052,182

Visorex 097

Vistar 049,188

Vityaz 306,307

Vortec 023,052,170

Voxson 001,020,023,044,050,052,109,189,197,208,209,234

Walkie 197

Waltham 004,023,038,049,139,166,217

Watson 022,023,052,170

Watt Radio 004,015,038,132,187,201,210,231,296

Wega 001,023,028,234

Wellfund 233

Weltblick 023,052,170,182

Weston 132

Wharfedale 023

White 182

White

Westinghouse

004,015,022,023,044,170,182,296

Windstar 101

Xoceco 235,236,242,260

Xrypton 023,182

Yamishi 023,101,184,212

Yokan 023

……………………………………………………………………………………………………

Yoko 003,004,010,012,023,052,166,170,183,198,212,224,296,308,309

Yorx 012,185,196

Zanussi 020,021,109,197

Zoppas 197

7el 256

Others 282

VCR

Brand VCR

Adelsound 098

Adyson 099

Aiwa 001,002,003,004,017,100,101,102,103,104,105,106,165,166

Akai 003,005,006,007,008,009,019,063,102,105,113,121,145,146

Akiba 041,099

Akitan 107

Akura 003,013,041,099,102

Alba 004,014,015,016,017,019,041,099,101,103,104,105,107,108,109,110,

111,113,165,166

Allorgan 073,145,169

Allstar 114,115

Ambassador 019

Amstrad 002,022,023,099,101,108,116,117

Anitech 041,099,114

Anitsch 091

Ansonic 098

Aristona 115

ASA 025,026,086,106,115

Asuka 002,025,026,041,099,101,106,115,118

Audiosonic 108

Audioton 019

AWA 106,108,119,120

Baird 002,003,005,014,027,028,045,101,102,107,108,121,122,123

Basic line 004,014,019,041,099,103,108,165

Baur 026,032

Bestar 014,019,108

Black Panther 108

Black panther line 014

Blaupunkt 026,029,030,031,032,039,071,115,125,126,127,128,129,130,167

Blue sky 099,103,104,105,106

Bondstec 019,099

Brandt 066,067,102,131,132,133,134

Brinkmann 103,104

Brion vega 033,135

Broksonic 042

……………………………………………………………………………………………………

Bush 004,014,015,016,017,041,052,099,101,103,104,105,107,108,109,110,

113,136,165,166

Canon 137

Carena 103,115

Carrefour 138

Casio 101

Cathay 108

Catron 019

CGE 002,003,101,102

CGM 089

Cimline 004,041,099,103,165

Clatronic 019,099

Combitech 017,105,166

Condor 014,019,107,108

Crown 014,019,041,099,108,114

Cybercom 165,166,167,168,169,170

Cybermaxx 165,166,167,168,169,170

Cytron 165,166,167,168,169,170

Daewoo 014,019,034,040,079,103,105,108,138,170

Dansai 041,099,107,108

Dantax 165

Daytron 014,108

Decca 002,003,026,101,102,104,115,142,143

De graaf 026,035,115,122,139,140,141,147

Deitron 108

Denko 099

Diamant 106

Domland 103

Dual 003,026,101,102,108,115,165,166,167,169,170

Dumont 002,026,035,045,101,115,122,144

Elbe 062,108,118

Elcatech 099

Elin 021,145

Elsay 099

Elta 041,099,107,108

Emerson 053,099,138

ESC 014,019,108,145

Etzuko 041,099

Europhon 019

Fenner 019

Ferguson 003,028,039,043,046,057,067,101,102,108,123,133,134,146

Fidelity 002,099,101,116,145

Finlandia 026,035,045,101,115,122,139,140,147

Finlux 002,003,005,026,035,045,050,061,101,115,122,144,147

……………………………………………………………………………………………………

First Line 004,025,034,035,041,061,099,103,104,106,108,120,136,138,147,148,

165

Fisher 019,044,045,118,122,141,149,150

Flint 004,103,165

Formenti-Pheonix 026

Frontech 019,114

Fujitsu 002,101

Funai 002,101

Galaxi 101

Galaxy 002

GBC 019,041

GEC 026,115

Geloso 041

General 019

General Technic 004,017,038,073,104,165,166,167,169

Genexxa 122

Goldhand 041,099

Goldstar 002,025,101,106

Goodmans 002,014,019,021,025,028,041,047,048,099,101,103,104,106,108,115,

129,136,145,151,152

Gradiente 142

Graetz 003,033,045,102,122,135,145

Granada 010,026,029,035,039,045,049,101,106,115,122,127,140,141,145,147

Grandin 002,014,019,025,041,099,101,103,106,108

Grundig 026,029,032,039,041,050,051,052,054,084,104,115,127,128,129,133,

153,154,155

Haaz 165

Hanimex 105,107

Hanseatic 025,026,103,106,108,115

Harwood 099

HCM 041,052,099,114

Hinari 004,017,041,052,053,098,099,102,103,105,108,114,136,148,152,156,

165,166

Hisawa 004,103,105,165

Hitachi 002,003,026,035,037,098,101,102,115,129,139,144,145,147

Hornyphon 115

Hypson 004,041,099,103,105,108,165

Impego 019

Imperial 002,101,145

Ingersoll 098,103,145

Inno Hit 014,019,021,026,041,099,108,114,145

Innovation 004,017,038,073,165,166,167,169

Interbuy 025,106

Interfunk 026,045,099,115,122

Internal 108

……………………………………………………………………………………………………

International 108

Intervision 002,101,103,104,106,107,108

Irradio 025,041,099,106,115

ITT 003,005,033,045,055,056,102,121,122,135,141,145,157

ITT/Nokia 082,084,085,088,089,090,092,140

ITV 014,019,025,106,108

JVC 003,056,057,058,059,060,102,132,142,143,157

Kaisui 041,099

Karcher 026,108

Kendo 004,005,006,014,019,034,063,099,103,104,106,113,121,146,165

Kenwood 003,102,118

Kimari 149

Kneissel 103,104,105,106

Korpel 041,099

Kuba 149

Kuwa 029

Kyoto 099

Lenco 014

Leyco 041,099,148

LG 002,025,101,106,108

Lifetec 004,017,038,073,103,104,165,166,167,168,169,170

Loewe 031,036,098,106,115,126,127,144,158,159,167

Loewe Opta 025,026,039

Logik 021,041,098,099,103,121,145

Luma 093

Lumatron 014,108

Luxor 005,045,047,061,099,120,121,122,141,149,151

Magnasonic 045

Magnavox 115,129

Manesth 034,041,099,103,115,138

Marantz 026,039,047,062,103,107,115,118,127,151,160

Mark 019,108

Marquant 114

Matsui 004,017,025,053,064,098,101,103,104,105,106,107,111,117,145,148,

156,165,166

Mediator 026,115

Medion 004,017,038,073,103,104,105,165,166,167,168,169,170

Melectronic 002,101,106,118

Memorex 002,010,025,044,045,101,106,122,140,141,149

Memphis 041,099

Metz 029,030,031,032,039,084,115,125,126,127,128,153,158,159,161,167

Micormay 104

Micromaxx 004,017,038,073,103,165,166,167,168,169,170

Microstar 004,017,038,073,165,166,167,168,169,170

Migros 002,101

……………………………………………………………………………………………………

Minerva 032,039,128

Mitsubishi 002,026,057,061,115,119,120,143,162

Multitech 002,019,026,041,099,101,114,122

Murphy 002,101

NAD 096,122

National 029,031,126,167

NEC 003,057,062,102,106,118,122,143

Neckermann 003,026,033,053,102,115,127,135,156

NEI 026

Nesco 041,099,101,105

Neufunk 103

Nikkai 019,065,099,108

Nobliko 083,097

Nokia 003,005,010,021,033,045,055,102,108,113,115,121,122,135,140,141,

145,147

Nordmende 003,056,057,066,067,102,131,133,134,143,148,157

Oceanic 002,003,010,101,102,115,121,122,140,141

Okano 004,063,099,103,104,108,113,114,165

Orion 004,015,017,048,053,064,098,103,104,105,107,109,110,148,152,156,

165,166

Orson 002,101

Osaki 002,025,041,099,101,106

Osume 136

Otake 109,110

Otto Versand 026,032,115

Palladium 003,025,039,041,063,098,099,102,103,106,113,127,145

Palsonic 099,101

Panasonic 029,030,031,038,076,125,158,159,161,167

Pathe Cinema 064,098,120

Pathe Marconi 003,102

Penney 062

Pentax 035

Perdio 002,101,103

Philco 062

Philips 012,026,039,054,056,077,115,127,129,160

Phonola 026,115

Pioneer 026,057,115,143,147

Portland 014,019,107,108

Prinz 002,101,148

PRO2 165,166,167,168,169,170

Profex 041,114

Profi-Tronic 115,145

Proline 002,052,101,133,134,136

Prosco 108

Prosonic 101,103,107,108,165

……………………………………………………………………………………………………

Protech 115

Provision 108

Pye 026,115

Quartz 045

Quelle 002,026,027,032,033,039,045,053,115,127,135,156

Radialva 099,106,115,140

Radiola 026,115

Rank 102

RCA 094

REX 003,056,102,157

RFT 019,026,099,129

Roadstar 014,021,025,041,099,106,108,145

Royal 099,114

Saba 003,046,056,066,067,081,102,108,131,132,133,134,151,157

Saisho 004,017,041,053,064,098,103,104,111,148,156,165,166

Salora 005,045,055,061,120,121,122,141

Samsung 021,073,074,145,163,169

Samurai 019

Sansui 003,013,057,099,102,104,114,121,143

Sanwa 098

Sanyo 027,044,045,122,140,141,143,149

Saville 017,105,107,108,145,166

SBR 026,115

Scan Sonic 145

Schaub Lorenz 002,003,005,033,045,101,102,113,121,122,135

Schneider 002,004,014,019,025,026,034,041,099,101,106,108,115,145,165

Seaway 108

SEG 021,041,099,108,114,119,145

SEI sinudyne 026,098,115

Seleco 003,019,102,106,142,157

Semivox 103,138

Sentra 019,099,136

Sentron 041

Setron 099

Sharp 010,011,047,106,140,151

Shintom 041,045,099,122

Shivaki 025,106

Shorai 098,148

Siemens 025,032,039,045,050,106,115,122,127,128,150,155,160

Siera 115

Silva 025,106

Silver 108

Sinudyne 026,098,115

Solavox 019

Sonitron 149

……………………………………………………………………………………………………

Sonneclair 099

Sonoko 014,108

Sonolor 010,140

Sontec 025,106

Sony 018,020,024,070,071,072,075,078,112,121,124,130,161,164

Soundwave 103,106

Ssangyong 099

Standard 014,108

Starlite 106,122

Stern 108

Strong 013

Sunkai 004,103,104,108,165

Sunstar 002,101

Suntronic 002,101

Sunwood 041,099

Supra 106,145

Symphonic 099,101

Taisho 004,098,103,148,165

Tandberg 032,053,108

Tashiko 002,010,101,106,115,140,145

Tatung 002,003,026,101,102,103,104,115,120,140,146

TCM 004,017,038,073,165,166,167,168,169,170

Teac 100,101,102,106,108,115

TEC 019,099,107,108

Technics 029,031,167

Technisat 103,104

Teleavia 003,102,131

Telefunken 003,056,057,058,066,067,068,069,080,081,102,108,131,133,134,157

Telemeister 095

Teletech 099,101,108,114

Tempest 019

Tenosal 041,099

Tensai 002,025,041,098,099,101,106,114

Tevion 004,017,038,073,103,104,165,166,167,168,169,170

Thomson 003,012,056,057,058,067,080,081,102,132,133,134,157

Thorn 003,045,064,102,106,122

Tivo Hdd 012,078

TMK 087

Tokai 025,041,099,102,106,122

Tokiwa 099

Tonsai 041

Topline 104

Toshiba 003,026,034,056,061,102,115,120,129,138,157,170

Towada 041,099,114

Towika 041

……………………………………………………………………………………………………

Trakton 019

Triumph 053,156

TVA 019

Uher 025,033,106,135,145

Ultravox 033,107,108,135

Unitech 021,145

United Quick Star 014,107,108

Universum 002,005,009,022,025,026,032,039,054,101,103,104,106,114,115,116,

121,127,128,129,145

Vector 062

Victor 057,058,142,143

Video 062

Videon 004,017,038,073,165,166,167,169

Watson 105,115

Weltblick 025,106

White 085,086

White Westinghouse 033,085,086,135

Xenon 093

Yamishi 041,099,107,108

Yokan 041

Yoko 019,021,025,041,106,145

ZX 103

SAT

Brand SAT

AGS 249

Akai 003,125,242

Akena 249

Alba 003,004,005,006,007,008,009,102,133

Aldes 007,010,011

Allantide 015

Allsat 012,014,055,125,242

Allsonic 010,029,309

Alpha 242,249

Ampere 024

Amstrad 017,018,019,021,023,154

Andover cablevision 258

Ankaro 010,029,243,244,309

Anttron 004,009,014,247

Apollo 004

Arcon 017,024,025,027,056,243

Armstrong 021,242

Asat 125,242

AST 036

……………………………………………………………………………………………………

Astacom 249,250

Aston 164

Astra 003,021,030,031,032,033,034,093,284

Astro 009,011,029,040,041,042,241,247,309

Astrx 288

Athena 249

Audioton 009,055,247

Aura 034

Axiel 249

Axis 017,029,033,050,309

Barcom 025,243

Best 025,029,309

Blaupunkt 040,241

Boca 021,093,246

Brain wave 044

Brandt 136,137,138,145,316

Broadcast 043

Brunor 126

BT 249,250

BT cable 260

BT satellite 003,022,145

Bush 005,006,012,045,102,133

Cabletime 261,262,263,264

Cambridge 003,046

Camundosat 047

Canal+ 140,174,222

Canal Satellite 245

Century 279

Channel master 007

Chaparral 098

Chess 318

Citycom 005,052,253

Clark 247

Clatronic 044

Clemens kamphus 015,083

Clyde cablevision 265

CNT 011

Colombia 249

Columbus 069

Commander 244

Commlink 010

Comtech 050,051

Condor 029,309

Connexions 039,047,048

Conrad 246,

……………………………………………………………………………………………………

Contec 050,052,246

Cosat 055

Crown 021

Cryptovision 266

Cybercom 306,307,308,309,310,311,312,313,314,315,316,317,318,319,320,321

Cybermaxx 306,307,308,309,310,311,312,313,314,315,316,317,318,319,320,321

Cytron 306,307,308,309,310,311,312,313,314,315,316,317,318,319,320,321

Daeryung 039

Dansat 012,014

DDC 007

Decca 053

Delega 007

DEW 050

Diamond 054

Discovery 249

Diseqc 250

Disk Express 243

Diskxpress 025,048

Distrisat 242

Ditristrad 055

DNT 039,125,242

Dong Woo 092

Drake 056,128

Dual 306,307,308,309,311,312,313,316,317,318,319,320,321

Dynasat 031

Echostar 026,039,057,058,060,073,149,150,151,156,249,318

EEC 015

Einhell 004,010,015,019,021

Elekta 011

Elta 004,008,029,055,125,242,309

Emanon 004

Emme Esse 029,031,045,083,309

Ep Sat 005

Eurodec 062,063

Europa 022,242,244,246

Eurosat 021

Eurosky 021,029,031,309

Eurospace 061

Eurostar 008,021,080

Exator 003,004,009,247

Fenner 249

Ferguson 005,012,014,045,062,064,065,066

Fidelity 017,019

Filmnet Cablecrypt 267

Filmnet Comcrypt 267

……………………………………………………………………………………………………

Finlandia 005

Finlux 003,005,030,067,072,079

Finnsat 050,062

Force 148

Fortec Star 285,286

Fracarro 133,249

France Satellite/Tv 069

Freecom 004,068

FTE 022,024,051,087,246

Fuba 004,025,029,032,039,040,069,072,122,125,241,243,309

Galaxi 025,243

Galaxis 010,029,033,050,055,070,076,152,153,309,317

Gardiner 253

GEC 265

GMI 021

Goldbox 245,322

Goldbox-D+ 222,233

Goldstar 068

Gooding 075

Goodmans 005,074

Granada 030

Grothusen 004,068

Grundig 005,009,040,045,075,077,086,124,154,235,241,251,252

G-Sat 014,015

Hanseatic 095,312

Hantor 004,019,044,092

Hanuri 011

Harting Und Helling 015

HEDY 277

Heliocom 024

High Performance 082

Hinari 007,008,014

Hirschmann 015,039,040,078,079,080,083,122,129,178,179,180,181,241,250

Hisawa 044

Hitachi 005,045,115

Houston 055,244,249

Humax 152,192,193,234,281

Huth 010,013,021,043,044,050,055,083,244,246

Imperial 102,133

Innovation 029,085,095,153,156,157,309,311,312,313,317,318,319,320,321

Intertronic 021

Intervision 055

Italtel-Stream 223,224

ITT/Nokia 005,030,045,048,079,115,122

Jerrold 257,270

……………………………………………………………………………………………………

Johansson 044

Jok 250

Jsr 055

JVC 003,075,236

Kathrein 015,040,042,052,087,088,089,090,098,125,177,241,242,247,249,253,

254

Kosmos 068,083,087,088

KR 009,247

Kreiselmeyer 040,241

Kyostar 004,247

Lasat 011,029,091,092,093,136,137,138,309,316

Lenco 004,022,068,094,244

Leng 044

Lennox 055

Lexus 242

Leyco 003

LG 068

Life 137,153,317

Lifesat 029,085,095,137,153,156,157,306,307,308,309,310,311,312,313,314,

315,316,317,318,319,320,321

Lifetec 029,085,095,137,153,156,157,306,307,308,309,310,311,312,313,314,

315,316,317,318,319,320,321

Lion 015,061

Lorenzen 244

Lorraine 068

Lupus 029,309

Luxor 019,030,115,122

Macab 062

Manata 249,250

Manhattan 005,011,045,055,249,250

Marantz 125,242

Mascom 011,088

Maspro 005,045,064,075,098,129,235,241,251

Matsui 003,075,145,235,241,250

Mb 095,312

Mediabox 245

Mediamarkt 021

Mediasat 033,245

Medion 029,085,095,137,153,156,157,214,215,216,217,218,219,306,307,308,

309,310,311,312,313,314,315,316,317,318,319,320,321

Mega 125,242

Melectronic 253

Metronic 004,009,010,171,247,253

Metz 040,241

Micro 247

……………………………………………………………………………………………………

Micromaxx 029,085,095,137,153,156,157,306,307,308,309,310,311,312,313,314,

315,316,317,318,319,320,321

Microstar 029,085,095,137,153,156,157,306,307,308,309,310,311,312,313,314,

315,316,317,318,319,320,321

Micro Technology 015,034,061

Mimtech 096

Minerva 040,075,235

Mitsubishi 005,040,145

Mitsumi 093

Morgans 021,093,097,125,242,246

Movie Time 269

Multichoice 172

Multistar 087,092

Multitec 318,319

Muratto 038,068

Navex 044

NEC 100,101

Network 014

Neuhaus 033,055,071,244,246

Nextwave 016,155

Nikko 021

Nimbus 096

Nokia 005,030,045,048,079,110,111,122,134,135,194,195,196,197,198,199,

200,201,202,203,204,222,223,227,230,236,280,292

Nordmende 004,005,007,011,062,065,123

Novis 044

OAK 271

Oceanic 015,054,061

Octagon 004,008,009,050,244,247

Okano 021,083,087,236,237,238,239

Ondigital 186,229,230

Optex 052,055

Orbit 015,036

Orbitech 004,103,246

Origo 105

Osat 009

Otto Versand 040

Oxford 003,249

Pace 005,012,014,040,045,064,074,099,107,112,130,154,186,189,191,195,

204,205,206,207,208,209,210,211,212,213

Pacific 054

Packsat 250

Palcom 007,032,069,071

Palladium 021,075,077,235

Paltec 032

……………………………………………………………………………………………………

Panasonic 005,045,154,183

Panda 005,012,241

Patriot 249,

Patriot Worldsat 003,249,250

Philips 005,014,028,035,037,045,049,059,075,086,099,104,121,124,125,132,

169,170,222,224,225,235,237,238,241,242,243,244,245,246,247,248,

249,250,251,252,253,254,311

Phoenix 014,050,074

Phonotrend 010,055,083

Pioneer 245,272,273,275

Pk Sat 015

Polsat 173

Polytron 052

Predki 044

Preisner 246

Premiere 055,140,245

Priesner 021

PRO2 306,307,308,309,310,311,312,313,314,315,316,317,318,319,320,321

Profi 094

Profile 249

Promax 005

Prosat 006,007,010,102,133

Protek 015,054

Proton 015

Provision 011

Ptt Telecom 047

Pye 235,

Quadral 007,010,029,246,249,250,309

Quelle 019,040

Quiero 173

Radiola 125,242

Radix 039

Rainbow 009,247

RE 096

Rediffusion 101

Redpoint 033

Redstar 029,309

Remoshack 296

Revox 096

RFT 010,103,125,242,244

Ruefach 094

Saba 006,011,014,045,061,064,065,120,127,133,136,142,143,144,146,250

Sabre 005

Sagem 062

Sakura 050,074

……………………………………………………………………………………………………

Salora 030,100,101,107,274

Samsung 004,027,078,272

Sat 007,017,036,038

Satbox 276

Satcom 043,095,106,312

Satec 014,045

Satford 043

Satmaster 043

Satpartner 004,009,011,044,068,083,247

Schäcke 247

Schneider 049,248,250,252,254,309,313,317,318,319,320

Schwaiger 013,014,052,054,089,095,137,144,146,147,152,155,157,168,246,306,

312,316,317,319

Scientific Atlanta Sts 255,256,268

Seemann 003,021,033,039

SEG 004,008,029,034,044,095,119,309,312

Seleco 055

Siemens 040,241

Silva 068

Skardin 033

Sky 154,182,190,191,220,221,278,282,283,323

Sky Digital 154

Skymaster 010,095,148,156,158,159,160,161,162,293,294,295,297,298,299,300,

301,302,303,304,305,312,315,318,319

Skymax 015,125,242

Skyvision 055

Sony 020,154

SR 021,065,093

Starion 034

Starland 156,318

Starring 044

Star Trak 004

Stella 047

Strong 004,009,029,048,051,081,133,222,228,247,289,309

Sumida 021

Sun/Moon/Star 184

Sunstar 021,093,107

Tandberg 062

Tandy 009

Tantec 005,045,064,069,071

Tatung 053,105

TCM 029,085,095,137,153,156,157,306,307,308,309,310,311,312,313,314,

315,316,317,318,319,320,321

Techniland 043

Technisat 039,071,103,108,109,126,242

……………………………………………………………………………………………………

Teco 021,093

Telanor 007

Telasat 095,312

Tele+1 222,228,267

Teleciel 247

Telecom 047

Telefunken 004,045,131,136,137,138,145,250,316

Teleka 009,021,027,039,088,247,251

Telemaster 011

Telemax 091

Telesat 095,312

Telestar 071

Televes 005,185,187,188

Telewire 055

Tevion 029,085,095,137,153,156,157,218,219,306,307,308,309,310,311,312,

313,314,315,316,317,318,319,320,321

Thomson 005,065,084,131,139,145,173,245,249,250

Thorens 054

Thorn 005,012,014,045,064,066

Tioko 052

Tokai 242

Tonna 005,043,055,249

Toshiba 239

TPS 141,175

Triad 015,036,038,068,113

Triasat 072

Triax 040,071,136,242

Tristar 051

Tudi 259

Uniden 114,287

Unisat 021,050,242

Unitor 025,044,243

Universum 040,067,075,079,235,241

Variosat 241

Variostat 040

Vector 015,061

Ventana 125,242

Via Digital 135,139,231,232

Visiosat 044,055,156,163,164,165,166,167,318

Viva 244

Vortec 004,027,078

VTech 253

V-Tech 036,038,104,115

Way 291

Wela 246

……………………………………………………………………………………………………

Westminster Cable 260

Wevasat 005,015

Wewa 005

Winer 290

Winersat 044

Wisi 005,036,038,039,040,113,116,117,118,241,246

Wittenberg 017

Wolsey 082

Woorisat 011

Xsat 176,249

Zehnder 011,029,038,087,089,119,243,253,309

Zeta Technology 242

Zodiac 009,247

Brand CD

Adcom 006

Aiwa 007,008,009,098

Akai 010,011,012,013

Alba 014

Arcam 083

Asuka 015

Audiosonic 015

Bestar 016

BSR 017

Bush 018

California audio lab 019

Carrera 020

Classic 119

Condor 017

Crown 021

Cybercom 103,104,105,106,107,108,109,110,111,112,113,114,115,116,117,118,119

,120

Cybermaxx 103,104,105,106,107,108,109,110,111,112,113,114,115,116,117,118,119

,120

Cytron 103,104,105,106,107,108,109,110,111,112,113,114,115,116,117,118,119

,120

Denon 022,023

Dual 015,024,103,104,105,107,108,109,110,111,112,113,114,115,116,117,118

Elta 105,108,113

Emerson 006,016,025

Fisher 026,027

Genexxa 016,025,028,029,030,031,032,033,034,107

Goldstar 020

……………………………………………………………………………………………………

Goodmans 025,035,036

Grundig 037,083

Harmon Kardon 010,038,039,040

Hitachi 006,024,041,042,043

Innovation 081,089,090,091,092,093,094,109,110,111,112,113,114,115

Intersound 015

JVC 044

Kenwood 026,029,045,046,047,100

Kodak 005

LG 020

Lifetec 081,089,090,091,092,093,094,103,104,105,106,107,108,109,110,111,11

2,113,114,115,116,117,118,119,120

Linn 083

Luxman 048,049

Magnum 081,089,090,091,092,093,094,109,110,111,112,113,114,115

Marantz 051,052,083

Matsui 051,053,083

Mcintosh 054,055

Medion 081,089,090,091,092,093,094,103,104,105,106,107,108,109,110,111,11

2,113,114,115,116,117,118,119,120

M-Electronic 050

Memorex 006,016,025,031,034

Meridian 083

Micromaxx 081,089,090,091,092,093,094,103,104,105,106,107,108,109,110,111,11

2,113,114,115,116,117,118,119,120

Micromega 083

Microstar 081,089,090,091,092,093,094,103,104,105,106,107,108,109,110,111,11

2,113,114,115,116,117,118,119,120

Mission 083

NAD 028,049,084,085,086,087

Naim 083

Nakamichi 056,057

Onkyo 002,058,059,060,061

Panasonic 018,019,062

Philips 003,063,064,082,083

Philips Cd-I 064

Philips Cd-V 002

Pioneer 030,034,099

PRO2 103,104,105,106,107,108,109,110,111,112,113,114,115,116,117,118,119

,120

Proton 083

Quad 083

Realistic 006,016,031,032,107

Roadstar 050,063,065

Rotel 083

……………………………………………………………………………………………………

Saba 024

SAE 083

Samsung 102

Sansui 003,025,066,067,068,083

Schneider 001,017,083

Scott 016,025

Sharp 029,069,070,071

Siemens 072

Signature 010

Singer 118

Sony 028,073,074,075,088,095,096,097

Sunwood 015

Tandberg 083

TCM 081,089,090,091,092,093,094,103,104,105,106,107,108,109,110,111,11

2,113,114,115,116,117,118,119,120

Technics 019,062,077,101

Telefunken 024

Tevion 081,089,090,091,092,093,094,103,104,105,106,107,108,109,110,111,11

2,113,114,115,116,117,118,119,120

Thomson 004,024

Toshiba 049,078,079

Universum 083

Vector Research 020

Victor 044

Welltech 107,108,112

Yamaha 069,076,080

Yorx 065

DVD

Brand DVD DVR

Akai 010,034,064

AMW 091

Arena 120 120

BBK 075,076,077,078,079,080,081,082,083,084,085

Brandt 118

Bush 097

CMI 120 120

Crown 118

Cybercom 102,103,104,105,106,107,108,109,110,111,112,113,114,115,

116,117,118,119,120,121,122,123,124

120

CyberHome 042,068

Cybermaxx 102,103,104,105,106,107,108,109,110,111,112,113,114,115,

116,117,118,119,120,121,122,123,124

120

Cytron 102,103,104,105,106,107,108,109,110,111,112,113,114,115,

116,117,118,119,120,121,122,123,124

120

……………………………………………………………………………………………………

Daewoo 070,091

Denon 005,036,058

DIK 114

Dual 102,103,104,105,107,108,109,110,111,112,113,114,115,116,

117,118,119,120

120

ECG 095

Ferguson 118

Golden Sphere 108

Goodmans 118

Go-Video 105

Gradiente 118

Grundig 011

GVG 096

Haaz 108,109

Harman/Kardon 050

H&B 110

Himage 094

Hitachi 009,025,030,043,063,127 127

HTY 086

Innovation 012,013,014,114,116,117,118

JVC 002,032,066

Kendo 114,120 120

Kenwood 005,028,058

Koss 118

Labwave 023,048

Lasonic 067,108

LG 016

Life 012,013,014,116,117,118

Lifetec 012,013,014,102,103,104,105,106,107,108,109,110,111,112,

113,114,115,116,117,118,119,120,121,122,123,124

120

Limit 108

Linn 035

Loewe 011,039

Magnavox 056,089,125,126

Marantz 003,038

Matsui 118

Maxim 091

Medion 012,013,014,041,102,103,104,105,106,107,108,109,110,111,

112,113,114,115,116,117,118,119,120,121,122,123,124

120

Metz 009,024

Mico 087,088

Micromaxx 012,013,014,102,103,104,105,106,107,108,109,110,111,112,

113,114,115,116,117,118,119,120,121,122,123,124

120

Microstar 012,013,014,102,103,104,105,106,107,108,109,110,111,112,

113,114,115,116,117,118,119,120,121,122,123,124

120

……………………………………………………………………………………………………

Mitsubishi 007

Mustek 069,071,072

NAD 027

Noname 045

Norcent 093

Nortek 091

Onkyo 015,029,065

Optimus 059

Oritron 118

Pacific 114

Panasonic 005,006,017,022,036,051,054,055,058

Panda 090

Philco 053

Philips 003,011,039,040,047,052,125,126 125,126

Pioneer 009,024,026,059,062

Prism 104

PRO2 102,103,104,105,106,107,108,109,110,111,112,113,114,115,

116,117,118,119,120,121,122,123,124

120

Proline 118

RCA 057,073

Reoc 108

RTL 120 120

Saba 118

Sampo 108

Samsung 008,030,063,105

Sanyo 092

Schneider 014,113,114,118

SEG 108

Sharp 012,013,116

Sherwood 044

Siltex 076

Skymaster 098,099,100,101

Sony 004,031,046,060

Strong 091

SVA 074

Sylvania 106

TCM 012,013,014,102,103,104,105,106,107,108,109,110,111,112,

113,114,115,116,117,118,119,120,121,122,123,124

120

Teac 108

Technics 005,036,037,058

Tevion 012,013,014,102,103,104,105,106,107,108,109,110,111,112,

113,114,115,116,117,118,119,120,121,122,123,124

120

Thomson 001,033

Toshiba 003,049

Xenius 115,118

……………………………………………………………………………………………………

Yamaha 005,036,058,061,125,126 125,126

Others 018,019,020,021

TAPE

Brand TAPE

Aiwa 008,009,010,126,127

Akai 015,079,089,099,100,110

Amstrad 082

Aswo 017

Braun 036

Bush 003

Daewoo 073

Denon 002,006,007,045,058,132

Diora 065,066

Dual 016,101,102

Fischer 059,060,071,129

Goldstar 128

Goodmanns 001

Goodmans 033

Grundig 017,021,026

Harman Kardon 057,092

Hitachi 045,081

ITT 084,085

JVC 011,028,029,123,124

Kenwood 014,083,098,101,102,116,121,122

Linn 054

Luxman 042,043,050,097

Marantz 017,053,088

NAD 069,070

Nakamichi 093

Nokia 086

Okano 113,114

Onkyo 012,013,022,067,068

Palladium 109

Panasonic 048,094,095

Philips 017,026,087

Pioneer 019,020,078,104,106,107,108

Radmor 053

Revox 027

Revox/Studer 017

Samsung 049,051,052,062,063

Sany 071

Sanyo 072,096,103

Schneider 017,032,033,034,035,038,039,040,044,084,085,112,128

Sharp 005,030,116

……………………………………………………………………………………………………

Sherwood 056,074,075,076,077

Siemens 015,017,046,047,111,112,115,117,118,119,120,128

Sony 031,091,105,130,131,133

T+A 037,125

T+A Elektroakustik 125

Technics 004,055,064,094

Thomson 018

Universum 034,041,052,061,112,115

Yamaha 023,024,025,080,090

TUNER

Brand TUNER

Aiwa 006,007,048

Akai 026,077,089

Amstrad 081,093,097,098

Ash 053

Aswo 056

Bush 042

Daewoo 087

Denon 001,002,031,052,074,100

Diora 090

Dual 011,025

Fischer 063

Goldstar 004

Goodmanns 077

Goodmans 042

Grundig 056,058

Harman Kardon 084

Hitachi 031,082

ITT 030

JVC 044,073,076

Kenwood 025,066,068,071,075

Linn 101

Luxman 067,103

Marantz 056

Minowa 039

Mission 018

NAD 088

Nakamichi 049

Nokia 040

Noname 042

Okano 079,092

Onkyo 055,069

Palladium 080

Panasonic 001,061

……………………………………………………………………………………………………

Philips 056

Pioneer 010,013,014,065

Radmor 057

Revox 016

Revox/Studer 056

Rotel 008

Samsung 009,041,078,094,102

Sanyo 022,062

Schneider 004,018,020,021,023,024,028,029,030,032,033,034,037,038,039,042,070,

072,080,089,092,093,098

Sharp 003,075

Sherwood 043,085,086

Siemens 004,018,036,037,047,056,077,087,092,095,099

Sinotec 024

Sinotec(Pepsi-Dose) 024

Sony 019,046,050,051

Supertech 042

T+A 035,054

T+A Elektroakustik 054

Technics 017,059,060,091

Thomson 012

Uher 005

Universum 033,077,092,096,102

Yamaha 015,027,045,064,083

AUX OTHER

Brand AMP LD/OTHER

ADT 161

Aiwa 028,128,129

Akai 018,112,121

Amplifier 158

Amstrad 014,034,077,086,145

Arion 162

ASH 027

Aswo 043

Audio Comb1 040

Braun 104

Bush 032,116

CD Photo 039

CDR 041

CD Video 038

Cybercom 169,170,171 173,174,175,176,177,178

Cybermaxx 169,170,171 173,174,175,176,177,178

Cytron 169,170,171 173,174,175,176,177,178

Daewoo 022

……………………………………………………………………………………………………

Denon 020,080,098,131,139 001(LD)

Diora 081

Disco Vision 003(LD)

DMT 161

Dual 062,124,169,170 173,174,175,176

Elta 176

Fischer 021,085,134

Goldstar 029

Gold Vision 166,167

Goodmanns 015,018,032

Grundig 043,142,148 005(LD),043,044,046

Harman Kardon 091

HDT 159

Hitachi 098 003(LD)

ITT 073

JBL 068,118

JVC 067,146,150

Kenwood 023,062,156 062

Lifetec 169,170,171 173,174,175,176,177,178

Linn 043,148 043

Luxman 099,100,149,152

Magnavox 046

Marantz 043,148,153 043,044,046

Medion 034,169,170,171 173,174,175,176,177,178

Meridian 148 043

Micromaxx 169,170,171 173,174,175,176,177,178

Microstar 169,170,171 173,174,175,176,177,178

Minowa 013

Mission 155

Mitsubishi 005(LD)

NAD 048 005(LD),047,048,049,050

Naim 043

Nakamichi 069

Niam 148

Nokia 072

Noname 032

Okano 016,017

Onkyo 024,125

Palladium 033,090,133

Palladium/Okano 143

Panasonic 136,138,141

Philips 043,101,140,148,153,154 004(LD),006(LD),043,044,045,046

Pioneer 011,119,148 003(LD),005(LD),043,055

PRO2 169,170,171 173,174,175,176,177,178

Quad 148 043

……………………………………………………………………………………………………

Radiola 006(LD)

Radiotone 087

Radix 160

Radmor 140,153,154

Revox 089,120

Revox/Studer 101,153,154

Rotel 126,127

Saba 151

Samsung 010,074,083,092 065

Sansui 044,046

Sanyo 134,157

Schneider 012,013,016,019,026,029,032,033,034,

035,043,073,075,086,088,096,105,106,

107,108,109,110,111,113,114,115,143,

144,145,147

Sharp 132,156

Sherwood 071,078,079

Siemens 016,018,019,022,026,029,031,034,043,

075,093,094,095,142

Sinotec 035

Sinotec(Pepsi-Dose) 035

Sony 036,117,133 002(LD),007(LD),008(LD),051,

052,053,056,057,058,059,060,061,

168

Supertech 032

T+A 025,103

T+A Elektroakustik 025

TCM 169,170,171,172 173,174,175,176,177,178

Techmate 163

Technics 082,097,135,138 063

Techsan 164,165

Telefunken 005(LD)

Tensai 102

Tevion 169,170,171 173,174,175,176,177,178

Thomson 123 064

Thorn 009(LD)

Uher 130

Universum 010,016,018,084,107

Video CD 037

Welltech 173,178

Yamaha 030,070,076,122 042,054,066

Others 137

Universal Remote Control Urc L 1870 Users Manual ManualsLib Makes It Easy To Find Manuals Online!

Navigation menu

Versions of this User Manual:

Views

Navigation
