Urbanista 2033202 Bluetooth sports earphones User Manual 15 2033202 UserMan
Urbanista AB Bluetooth sports earphones 15 2033202 UserMan
15_2033202 UserMan
Boston
Bluetooth sports earphones
Boston_broschyr_90x105.indd 1 31/03/15 20:36
FCC ID: 2AEN52033202
YOU ARE AN URBANISTA!
ank you for your purchase of Urbanista Boston
Bluetooth earphones.
Urbanista is a tribute to people living modern urban
lives. Products are developed to allow an active and
mobile lifestyle. Boston is designed to resist rain
and sweat, but should not be dipped into water.
Keep in mind to put the silicon lid on the micro USB
connection, to better withstand water (IPX5).
To start Boston, press the logo button for 5 seconds.
Boston will start and go into synch mode. e small
blue light will show continuous frequent blinking.
Volume control
hands free.
Bluetooth unit.
USB port
LED
Boston_broschyr_90x105.indd 2 31/03/15 20:36
Now you can switch on the Bluetooth on your phone
or computer and search for ”Urbanista Boston”. Once
you connect the two devices you can start using
Boston for listening to music or making phone calls.
e blue light will blink 3 times and then pause.
Functions
Volume Click shortly on + or – buttons
Forward Press and hold the + button
Backward Press and hold – button.
Answer Click logo button at incoming calls
Hang up Click logo button
On/Off Press and hold the logo button 5 sec.
e playing time is around 4 hours. e charging time
is around 1-2 hours, depending on the energy source.
e blue light is on when charging and turns off when
the battery is full. e Bluetooth distance is about 10
meters, without obstacles between the two devices.
To charge the batteries of Boston, connect the
complimentary cable A to the micro USB connection
and the USB to an energy source such as a computer.
Boston_broschyr_90x105.indd 3 31/03/15 20:36
GoFit silicon wings come in three sizes. To get the
most out of your workout it’s important that you
choose the right size. To switch ear-buds, pull it off to
the side without damaging the latch that secures it in
the earphone and gently slip the other over using the
same motion in reverse.
e smallest of the three ear-buds, without the GoFit
wing, can be a good choice when you’re not working
out and want to be more discreet.
Clean the headphones gently with a cloth. e ear
buds can be rinsed with soap under running water.
Make sure that the ear-buds are dry before you put
them back on.
If you need instructions in additional languages, visit us at:
Stereo Kopfhörer. 1 Jahr Gewährleistung. Anleitung und Informationen können
unter folgendem Link abgerufen werden:
Auriculares Garantía limitada de un año. Pueden encontrar el modo de empleo
y información técnica aquí:
Casque audio. Garantie limitée d’un an. Retrouvez les conseils d’utilisation et
les informations techniques ici:
http://us.urbanista.com/pages/translations
Boston_broschyr_90x105.indd 4 31/03/15 20:36
1. Boston, GoFit
3. Do not push the latch!
2. Pull & remove gently
4. Put on in reverse order
Boston_broschyr_90x105.indd 5 31/03/15 20:36
All Urbanista headphones are designed and manufactured with your high
expectations and best customer experience in mind.
We are devoted in providing the best quality and modern technology, how-
ever, as most people realize, electronic products sometimes do have technical
difficulties, and sometimes it is due to a manufacturing defect. is is why we
offer a one (1) full year replacement warranty, from purchase date, against
manufacturer defects on each headphone we sell.
URBANISTA ONE YEAR LIMITED WARRANTY
Urbanista AB hereby warrants that, under normal use, this product will be free
from defects in materials and workmanship for a period of one (1) year from
the date of original retail purchase. e replacement warranty is valid only if
the original proof of purchase issued to the purchaser, specifying the date of
purchase, is presented with the product to be replaced.
How does it work? If you believe this product is defective within the warranty
period, carefully repack the unit and return the product to your authorized
dealer, with the original proof of purchase. Your authorized dealer will replace
the product in the case a defect in manufacture or workmanship is identified.
In Case your authorized dealer does not have the corresponding product or
color in stock, Urbanista AB will promptly provide you with a new product.
is limited replacement warranty does not apply in cases of abuse or misuse
of the product, use contrary to Urbanista AB instructions, ordinary wear and
tear, incorrect connection, force majeure or unauthorized repair. Any lawsuit
for breach of this limited warranty shall be commenced, if at all, within one (1)
year of the date that the claim accrues.
Urbanista AB shall not be liable for special, indirect, incidental or consequential
damages resulting from the use or inability to use this product, regardless of
the legal theory on which the claim is based.
is warranty gives you specific legal rights, and you may have other rights,
which vary from country to country. is warranty does not restrict the rights
of the consumer mandated under applicable laws.
Boston_broschyr_90x105.indd 6 31/03/15 20:36
is product shall not be treated as household waste. Instead it shall be handed
over to the applicable collection point for the recycling of electrical and elec-
tronic equipment. is product was produced after April 1 2015.
e limited Premium replacement warranty is valid only if the original proof of
purchase issued to the purchaser, specifying the date of purchase, is presented
with the product to be replaced.
IMPORTANT SAFETY INSTRUCTIONS
Warnings
• Contains small parts which may be a choking hazard. Not suitable for children
under age three.
• Set a low volume setting before using the headphones.
• Long-term exposure to loud music or sounds may cause hearing damage. It
is best to avoid high volume levels when using these headphones, especially
for extended periods.
• Do not use these headphones when operating a motor vehicle, a bicycle,
machinery or where your inability to hear outside sounds may present a danger
to you or others.
Cautions
• Using these headphones limits your ability to hear noises around you, regard-
less of listening volume. Please use caution when using these headphones.
• Do not drop, sit on, or allow the headphones to be immersed in water.
• e pads that accompany these headphones may deteriorate over time.
Please make sure to use suitable pads on the headphones at all times.
For any questions or concerns contact
info@urbanista.com
For warranty and safety instructions in other languages:
Vous trouvez les réstrictions de sécurité et d’autres informations ici:
Usted encontrará las restricciones de seguridad y otra información aquí:
http://us.urbanista.com/pages/translations
Boston_broschyr_90x105.indd 7 31/03/15 20:36
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Urbanista AB, Runebergsgatan 6, 114 29 Stockholm, Sweden
Phone: +46 8 30 38 20. E-mail: info@urbanista.com
www.urbanista.com
Boston_broschyr_90x105.indd 8 31/03/15 20:36
