USER MANUAL
BLUETOOTH PHONE CONNECTOR BT-PSCN
Using a mobile phone by the car driver while driving is not allowed in some countries. One of the
possible solutions is to use a handsfree audiosystem for controlling an inserted and connected mobile
phone.
Such a handsfree audiosystem with steeringwheel-buttons, microphones and loudspeakers and/or
speechrecognition has been developed for easy covering all information and communication needs of
the car users, e.g. listening to radiobroadcasts or calling to a telephone partner.
The central part of the system, the so-called “Head-Unit”, is mounted in the car dash-board as the basic
control unit for information and communication. Via the integrated display and keys it informs and
enables the user to select a radiostation or to use the mobile phone.
Adapters, so-called cradles, adapt selected mobile phones from the market mechanically and electrically
for easy use in conjunction with the control base (head-unit) via a fixed interface plug.
The cradle is attached directly to the Bluetooth Phone Connector (BT-PSCN) by this interface plug-in
connector on top of the BT-PSCN. The cradle adapts audio communication and data communication
signals to the BT-PSCN. These signal informations will be transferred between BT-PSCN and head-unit
via a wireless Bluetooth link.
Additionally the interface plug on the BT-PSCN has mechanically implemented a coax-plug with no
electrical connection to the BT-PSCN circuits. The coax-plug is connected to the external roof antenna
via a separated coax-cable.
BT-Antenna
Head
Unit
Roof-Antenna
BT-PSC/mobile phone
Datatransmission
via Bluetooth
BT-PSCN will be assembled during the car manufacturing process. Installation will be done by specialized
personnel of the car-manufacturer only.
BT-PSCN is not intended to be assembled by the end-user.
Therefore “usage” of BT-PSCN will be described in the user manual of the car-informationsystem as part
of that system.
Installation and operation is described in a separate Operational Description document.
_______________________________________________________________________________________________________________ Seite 1
peiker acustic GmbH & Co. KG, Max-Planck-Straße 32, D-61381 Friedrichsdorf, Amtsgericht Bad Homburg HRA 1897
phG: peiker Verwaltungs GmbH, Vorsitzender der Geschäftsführung: Andreas Peiker, Geschäftsführer: Stephan Graf von der Schulenburg, Amtsgericht Bad Homburg 1369
Vorsitzender des Aufsichtsrates: Prof. Dr. Agilolf Lamperstorfer Ein Unternehmen der peiker Firmengruppe
_______________________________________________________________________________________________________________ Seite 2
peiker acustic GmbH & Co. KG, Max-Planck-Straße 32, D-61381 Friedrichsdorf, Amtsgericht Bad Homburg HRA 1897
phG: peiker Verwaltungs GmbH, Vorsitzender der Geschäftsführung: Andreas Peiker, Geschäftsführer: Stephan Graf von der Schulenburg, Amtsgericht Bad Homburg 1369
Vorsitzender des Aufsichtsrates: Prof. Dr. Agilolf Lamperstorfer Ein Unternehmen der peiker Firmengruppe
Conformity to CE directives: CE 0681
Conformity to FCC-Rules:
The following passages will be inserted in the vehicle’s user manual at the appropriate positions where
radio based components are described:
This device FCC-ID: QWY-BT-PSC-N
IC: 6588A-BTPSCN
RF exposure:
Statement according FCC part 2.1091:
This equipment complies with FCC RF radiation exposure limits set for an uncontrolled environment as
per section 2.1091 of the FCC rules
USA only:
Statement according to FCC part 15.19:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Statement according to FCC part 15.21:
Modifications to this device not expressly approved by this company could void the user’s authority to
operate the equipment.
Statement according to FCC part 15.105:
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the user manual, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
Statement according to FCC part 15.27:
With this device will no additional special accessories be shipped or marketed. This equipment BTPSC
has to be assembled by professional installing personnel of the vehicle manufacturer.
It is the responsibility of the installer to install the equipment in that way that the resulting system
complies with the regulations.
Canada only:
Statement according to RSS-210:
This device complies with RSS-210 of Industry Canada. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Modifications to this device not expressly approved by this company could void the user’s authority to
operate the equipment.
