VSON TECHNOLOGY V850 Integrative Mini Presenter User Manual v850 User s Manual
Vson Technology Co.,Ltd. Integrative Mini Presenter v850 User s Manual
User Manual
0
Integrative Mini Presenter
User's Manual
Be sure to carefully read this user’s
manual first for the proper use of the
Integrative Mini Presenter and keep it for future reference.
1
Table of Contents
Introduction..................................................................... 2
I. Operation system......................................................... 2
II. Functions.................................................................... 3
III. Battery installation ..................................................... 3
IV. Technical parameters................................................. 4
V. Safety Measures......................................................... 5
2
Instruction
It is a great tool for PowerPoint presentations! With it, you don't
need to stand beside your computer or have an additional
person click the slide for you!
Features:
1. Easy carry
The transmitter and receiver are integrated into one unit to
easy carry!
2. Easily control the pace of your presentation
Advanced radio frequency (RF) technology that works
through walls and control distance up to 15-meters / 50-feet
away, so you never have to stand at beside of your computer.
I. Operation System
Windows 98,Se,Me,2000,XP, Mac OS, Linux
II. Functions:
3
A) Function table:
Page Up
Page Down
Play PowerPoint
Blank Screen ( For PowerPoint play only )
Laser Pointer
III. Battery installation
● The remote is powered by 1x CR2032 battery.
● Push and remove the battery compartment cover.
● Insert 1x CR2032 battery into the battery holder.
● Battery positive (+) is up and negative (-) is down.
● Put the battery compartment cover back into position.
Note
1. Do not insert battery into the device in the wrong
direction.
2. Do not leave bad or exhausted battery in the device
3. If you do not use the device for a long period of time,
remove the battery to avoid possible damage from
battery corrosion.
√×
4
4. If the device does not function correctly or if the
operating range becomes reduced, try to replace the
battery with new one.
IV. Technical parameters
Transmitter
RF Frequency 433.92Mhz
RF Output Power 0dBm
Control distance Up to 15 meters
Battery 1 x CR2032
Working voltage 3V
Sleep current 1uA
Dimension 13.7cmx3.3cmx0.7cm
Weight 15g (No battery)
V. Safety Measures
z To avoid possible eye damage, never point the presenter
at people especially their faces, or look directly into the
presenter’s laser beam.
z Avoid pointing the presenter’s laser beam at a mirror or
other highly reflective surface.
z Keep the presenter away from children.
z Never view the presenter’s laser beam using telescopic
devices, such as a microscope or binoculars.
z Any attempt to disassemble, adjust or repair the
5
presenter may result in exposure to laser light or other
safety hazards.
Warning:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance will void the user’s authority to
operate the equipment. Any change to the equipment will void FCC grant.
This equipment has been tested and found to comply with the limits
for a Class B digital device,pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
The equipment compliance with FCC radiation exposure limit set forth for
uncontrolled Environment
