BluetoothCarChargerBC33



I.ProductIntroduction

TheProductisaBluetoothhands‐freecarchargerandMP3player,

Usetheprofessionalhigh‐performanceBluetoothchipset,built‐in

MP3/WMAdecoder,supportU‐diskmusicplayandA2DP.Automode

switchbetweencallingandA2DPtofreethehandforsafetydriving.

Meanwhile,itcanchargethemobilephone,detectanddisplaythecar

batteryvoltagewhichbringstheintelligentexperiencetouser.

II.ProductDiagram

1.LedDisplaywindow  

2．Multifunctionalbutton;(shortpressforplay/pause,answer/hangup

call,longpress2storejectcall,doubleclickforredial,longpress8stoerase

thehistoryofBTpairinglist)

3．Mic

4．USB1,U‐DISK+5V/1Achargingport; 

5．USB2,QC3.0chargingport(3.6V‐6.5V/3A,6.5‐9V/1.5A,9V‐12V/1A)

6．ShortpressforNext;longpressforV+andfastspeedFM+(inFMmode)

7.FMkey,shortpresstoentermodeswitchbetweenBT/USB,longpressto

enterFMmode

8.shortpressforprev.,longpressforV‐andfastspeedFM‐(inFMmode)

9.powercontact



III.ProductCharacteristics

1．Echocancellationandnoisecontrol(CVC)tech.

2．Bluetoothanswering,hangingup,rejecting,redialingfunctions

3．SupportBluetoothstereomusicplaying

4．Supportdigitaltubedisplay;

5．Supportcarbatteryvoltagedetection;

6．SupportU‐Disk(1G‐32GMax)

7．SupportMP3/WMAformatmusicplay

8．FullFMfrequency87.5‐108MHz;

9．Automaticpower‐offmemoryfunction;

10．USB1supportU‐Diskplayand5V/1Aoutputforphonecharging

11．USB2supportQC3.0fastcharging;

12．Supportphonevoicenavigationviacaraudio

IV.OperationInstruction

4.1FMadjustment

4.1.1longpressFMkeytoenterFMmodeafterthisunitplugin,theLED

flashdisplay,thenlongpress</>forfastFM+/FM‐,Shortpressfor

FM+/FM‐.



4.2BTmode

4.2.1.Afterpluggingintheunit,LEDwilldisplaythecarbatteryvoltage

andFMfrequency;openthecarradioandtunetheFMfrequencysame

withtheunit.

4.2.2.EnablethephoneBT,search”carkit”,clicktopair,thereisanvoice

promptafterpairingsuccessfully

4.2.3.OpenthephoneplayertorealizethemusicplayviaA2DP,short

pressmultifunctionalbuttontoplay/pause;shortpress</>fornext/prev.

song;longpress</>forV+/V‐

4.2.4.Shortpressmultifunctionalbuttontoanswer/hangup,doubleclick



forredial;longpressthemultifunctionalbuttontoswitchtheprivate

answering.OnthestatusoftheBTstandby,longpressmultifunctional

button8stoerasethehistoryofBTparinglist.

Note:Onlythelastphonenumbercanberedialed.



4.3U‐Disk

4.3.1.PlugtheU‐diskintotheUSB1port,Itcanautoplaytheinside

MP3/WMAformatmusics.Shortpressmultifunctionalbuttonto

play/pause;longpress</>forV+/V‐,shortpress</>fornext/prev.Song.



4.4modeswitch

4.4.1.WhenU‐Disk/BTmodeisstandbyatthesametime,shortpressFM

keytoswitch.

Note:thereisanvoicepromptwhenexternaldeviceplugin.

Carbatteryvoltagedetection:Theunitwillautodetectanddisplaythe

voltageofcarbatterafterpoweron.Thevoltagedisplayrangeis11V‐27V,

itwillshowHHHifthevoltageexceedstherange,error±1,pleasecheck

thecarbatteryifHHHdisplayedinordertoavoidcarstartingproblem.



Chargingrecognition:pleaseconnectthemobilephonetotheUSB2,

makesurethemobilephoneisQC3.0complied,otherwisetheunitcharge

thephonenormallywithoutquickcharge.Thisunitsupports

QC3.0/QC2.0/FCP/PE/PE2.0/APPLE/Samsung/BC1.2chargingprotocols.



V.tec hspecifications

Ratedworkingvoltage12V~24V

Limitworkingvoltage8‐32V

USB1output5V/1A+U‐Disk

USB2outputQC3.0

MusicformatMP3/WMA

U‐diskcapacity1G‐32G

Workingtemperature<60℃

Batteryvoltagedisplay

accuracy

Error±1V

SNR>60dB

Degreeofdistortion<0.1%

Frequencyresponse20Hz‐15Khz

LeftandRightChannel>60dB

BluetoothversionVersion4.2+EDR

Bluetoothsound

processing

A2DP(AdvanceAudioDistribution

Profile)function

Bluetoothtransmission

distance

Barrier‐freewithin10M

Effectivedistanceof

Bluetoothmicrophone

0.5‐2M

FMfrequency87.5‐108MHz

FMTransmission

distance

2M

VI.Notice

1.Thisdevicehasdualchargingportsformobilephonecharging

2.Althoughthetransmissionpowerofthisproductisrelatively

strong,bettertoskiptheFrequencywithstrongsignalinlocaltoget

abettersoundquality

3.Duetothedifferencefromeachphone,therewillbesome

differenceduringBluetoothconnection.

4.Bluetoothhastobemanuallyreconnectedforsomephones

withoutautoconnectionwhenpoweriscutoff.

5.Thisproductiscompatiblewithmorethan95%phonesonthe

marketbutsomearestillincompatible.Pleasepayattentiontoit

whenpurchasingourproduct.

6．Donotenlargetheradiovolumetoomuch,soasnottoincrease

backnoiseofthesound.

7．Donotusethisproductinadustyandhumidenvironmentwith

extremelyhighandlowtemperatures.

8.Donotdroptheproducttoavoidsurfacedamageorbreakdown.

9.WhenplayingU‐disk/A2DPmusic,ItwillautoswitchtoBluetooth

modewhenthereiscalling;aftertalkingfinished,autoreturnto

U‐diskmode/A2DPtocontinuethemusicplay.



VII.Packaging

1.Maindevice2.UserManual



V1.0
