Contents

User Manual 2

Quick Start Guide
Follow these instructions to set up your Gini Learning Keyboard™.
(TV not included.)
1
Introduction
Thank you for buying the Gini Learning Keyboard™. The Gini Learning
Keyboard™ includes songs and games based on the Gini Method created
by renowned pianist Giovanni Marradi. This system uses a simplified
notation to make reading music easier to learn so that children can
quickly begin mastering songs and exploring musical concepts. The basis
for the system are the Gini Avatars—letters, numbers, and avatars which
represent each key on the piano. Different colors represent different
octaves to allow children to quickly identify where on the keyboard they
should focus their attention.
You may want to start your child in Standalone Mode, where our
innovative in-key light system not only shows the notes that a child should
play for a song, but also shows which note is coming up so that children
have time to prepare and position their hands properly to play a song.
Once children gain confidence by playing a few of the included songs,
they can begin to explore the TV-connected content by unlocking games
in the Adventure Story. These games focus on specific skills and musical
concepts that will help your child learn to play piano and to explore the
wonderful world of music.
Gini Learning Keyboard™ TV Mode Quick Reference
Game Curriculum
Gini
Notation
Gini
Value
Gini
Beat Fingering Chords
Launch the Fireworks ●
Rockin' Aliens ○ ●
Rescue that Rocket ○ ● ○
Alien Dance Party ○ ●
Green Thumb Gardening ●
Giant Music Player ● ○ ○ ○
Jetpack Journey ● ○ ○
Meteor Catch ● ○
Jam Session ●
Play a Song ● ○ ○ ○ ○
● Main Curriculum ○ Secondary Curriculum
Parent Tip #1
While the games and practice activities are all meant to be played by the child on
their own, music is a complex concept. They will learn quicker and more easily if
you help them along by modeling the activities for them.
2
3
Product Features
21
20
19 321 6 8 1094 5 7 11 17 18161312 1514
1 Power Button
2 Power Indicator / Connection Indicator (Keyboard)
3 Standalone / TV Mode Switch
4 Volume Knob
5 Mode Button (Free Play / Listen / Practice)
6 Avatars / Letters Button
7 5 Rhythm Buttons (Pop / Rock / R&B / Jazz / Latin)
8 6 Instrument Buttons (Piano / Marimba / Strings / Flute / Synthesizer / Steel Drum)
9 Metronome Button
10 D-Pad (8-Directional)
11 Exit Button
12 Record indicator
13 Help Button
14 Record Button (Red Button)
15 Play Button (Green Button)
16 Smart Wheel
17 Stop Button (Enter Button)
18 Keyboard
19 DC Jack
20 Microphone Jack (Microphone not Included)
21 Headphone Jack
Gini Learning Keyboard™
4
Standalone Mode
In Standalone Mode, the Gini Learning Keyboard™ includes a variety of
different features that allow children to explore musical concepts and
learn to play the piano.
Modes of playing
In Free Play, there are a variety of instrument sounds and rhythms children
can use to create their own music. There's also a record feature that
allows children to make a short recording of a song they've composed.
Additional recording space is found in TV Mode.
In Listen, children can hear each of the 20 bundled songs in order to
learn the melody and get a sense for how each song should be played.
The avatars or letters can light up in this mode in order to show children
which keys are being played throughout a song.
In Practice, an innovative LED light system shows children what keys to
press to play the song. To improve the ability to learn, these LED lights do
not just light up at the moment they should be played, but rather travel
down the appropriate key to indicate that key is coming, allowing children
to anticipate notes and get their hands ready to play in plenty of time.
Parent Tip #2
Set aside a specific amount of time each week for practice. Children need the
repetition to learn musical concepts, but they also need repetition to gain the finger
strength and dexterity necessary to perform.
TV Mode
TV Mode allows children to explore music and learn piano skills through
a series of interactive games and activities. The Adventure Story brings
children from the basics of identifying different keys on the piano to
playing basic one-hand songs to playing music with both hands and
how to play chords. As children complete games, they become available
in Quick Play on the TV so children can improve their skills and master
the available games.
Additionally, the Play a Song and Jam Session sections of TV Mode
allow children to explore a variety of songs and even record their own
music. Look for the sections of TV Mode that your child enjoys best and
encourage them to revisit these sections as they improve their skills.
Going back to replay songs and games is an excellent way to enhance
learning, improve skills, build confidence, and foster an appreciation of
music. All of these are necessary for a child to truly learn piano.
Parent Tip #3
Some skills will come easier to your child while others will be true challenges.
Encourage them to replay the easy games to gain confidence and skill while
replaying the difficult games to see how much their skills have grown.
5
6
22 Power Button
23 Power Indicator / Connection Indicator (TV Console)
24 DC Jack
25 Micro-USB Port
26 HDMI Out Port
27 Back up Battery
28 microSD Card Slot (microSD Card Not Included)
Parent Tip #4
Correct fingering and hand position are very important to playing at tempo. Watch
your child play and see if they are using the suggested fingering and hand position.
If not, gently guide them to improve their hand position and to use multiple fingers
to press keys.
2223
24 25 26
28
27
TV Console
Downloadable Content
Additional Downloadable Content is available for purchase via the
Downloaded Songs section of the Gini Learning Keyboard™ Menu.
Downloadable content includes additional Songs to learn, Keyboard
Games, and Additional Content. Learn and explore even more with these
exciting expansions.
Downloaded Songs - Downloadable songs include classic kids and
piano songs as well as hit songs from some of today's hottest artists.
Play downloaded songs in four different games across multiple levels of
difficulty. This will help your child learn the notes of the song and allow
them to practice playing it in a fun way.
Keyboard Games - Build finger strength and dexterity with these
keyboard-based games. A variety of formats give children the opportunity
to practice musical concepts within games. Keep learning fresh with fun,
engaging keyboard games.
Additional Content - Find a selection of additional games and other
content, such as music, educational games, videos, and more. Explore
the downloaded content to maximize the fun in your Gini Learning
Keyboard™.
Keyboard Games and Additional Content can be found by pressing the Red
Button to go to the next page of the Home screen.
7
8
Connecting the TV Console to a TV
1. Turn off your television set.
2. Plug the end of the HDMI cable nearest to the Ferrite Core into the HDMI
Out port located on the back of the TV Console, and then connect the
other end to the HDMI In port on the television.
3. Insert the Power Adapter Jack into the TV Console, and then plug the
Power Adapter into a power outlet.
4. Turn on the television, and then set the proper HDMI input.
5. Press and hold the Power Button on the TV Console until the green
light comes on.
6. To turn the TV Console off, press the Power Button again. The green
light will turn off.
Light
Ferrite core
HDMI In
Port
Power
Adapter Jack
HDMI
Out
TV Console
Power Button
Power Adapter
Powering the Keyboard
Battery Installation (For 4 “D” Batteries)
1. Open the battery compartment located under the keyboard.
2. Insert 4 “D” cell batteries, following the diagram inside the battery
compartment.
3. Replace the battery cover
Power Adapter
There is a single Power Adapter included in the package. It works with
both the TV Console and the keyboard. If you would prefer to not run the
keyboard on battery power during TV Mode, additional power adapters
are available separately. Insert the Power Adapter Jack into the keyboard,
and then plug the Power Adapter into a power outlet.
Wirelessly Connecting the Keyboard to the TV Console
1. Press the keyboard's Power Button to turn on the controller. Toggle
the keyboard into TV Mode.
2. Once a wireless connection between the keyboard and the TV Console
is established, a sound effect indicating connection will be heard.
3. When finished, press the keyboard's Power Button to turn it off.
Note: If the unit repeatedly powers down or disconnects, we suggest
changing to new batteries. The Green light of the Power Button will
flash several times and power down when the unit's battery level is low.
9
Power Adaptor Jack
Connecting the Console to Wi-Fi
To adjust the console's Wi-Fi connection:
1. Select the Green Button in the Profile Selection menu to access Parental
Controls directly, or select the Green Button within the console desktop
area and then select the Parental Controls icon.
2. In the Parental Controls menu, select Wi-Fi Settings.
3. Make sure Wi-Fi is on. The television will list the available networks.
Select the network that you would like to connect to, and enter a
password if needed. When the connection is set up, select the check
mark at the top of the screen to return to the Parental Controls menu.
Note: Gini Learning KeyboardTM supports 802.11 b/g/n wireless
standards.
10
Select this switch
to turn on Wi-Fi.
Setting up the Gini Learning KeyboardTM
Follow these steps to set up your Gini Learning Keyboard™ before the
first use:
1. Set up a Wi-Fi Internet connection.
2. Your Gini Learning Keyboard™ console may require a firmware update
before use. If this is the case, follow the instructions on screen to
download and install the firmware update.
3. Once installation is completed the console will restart, and you will
prompted to register your Gini Learning Keyboard™. Complete the
necessary steps to register your console.
4. Don't forget to set a parental control passcode when you're done to
prevent your child from accessing the console settings.
11
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks
or registered trademarks of HDMI Licensing LLC in the United States and other countries.
All Gini Music Method™ content ©2016 by Giovanni Intellectual Property, Inc.
© 2016 VTech. All Rights Reserved. Printed in China. 91-003271-000
