User’s manual
(Canada version)
DM251/DM251-102
Wireless Monitoring System
with Safe & Sound®
Digital Audio Monitor
Congratulations
on purchasing your new VTech product. Before
using this product, please read
Important safety instructions.
For support, shopping, and everything new at
VTech, visit our website at
www.vtechcanada.com.
What’s in the box Overview
Baby unit overview
f
a
g
h
b
c
d
e
i
j
k
1POWER indicator
On when the baby unit is turned on.
Off when the baby unit is off.
•
•
2PAGE
Press to start or stop paging the
parent unit.
•
3
Press to play a lullaby at the baby unit.
Press again to play the next lullaby.
•
•
4
-
Press to decrease the speaker volume.•
5+
Press to increase the speaker volume.•
6
Press to power on the baby unit.
Press and hold to power off.
•
•
7
Press to play or stop the lullaby.•
8Microphone
9Power jack
10 Speaker
11 Temperature sensor
Parent unit overview
g
l
ah
j
k
b
c
d
e
i
f
n
m
1TALK
Press and hold to talk to the baby unit.•
2 On/off indicator
On when the parent unit is turned on.
Flashes when the link between the
parent unit and the baby unit is lost.
Off when the parent unit is off.
•
•
•
3 Battery level indicator
On when the battery is charging.
Flashes when the battery is low and
needs charging.
Off when the battery is not charging.
•
•
•
4
Press to power on the parent unit.
Press and hold to power off.
•
•
5
Press to decrease the speaker volume.
While in a menu, press to scroll down.
•
•
6
Press to increase the speaker volume.
While in a menu, press to scroll up.
•
•
7Visual sound indicator
The visual sound indicator has two
functions. One is to show the sound level
detected by the baby unit. The other
one is to show the volume level during
speaker volume setting.
Sound level detected by the baby unit
One to three green
lights indicate a moderate sound level
detected by the baby unit.
Additional red
lights indicate a higher sound level
detected by the baby unit (e.g. baby
crying loudly).
Speaker volume level
One to three green
lights indicate Level 1 to Level 3 of the
speaker volume setting.
Additional red
lights indicate Level 4 to Level 5 of the
speaker volume setting.
•
•
•
•
8LCD panel
9MENU/SELECT
Press to enter the menu.
While in a menu, press to choose an
item, or save a setting.
•
•
10
While in a menu, press to return to the
main menu or idle screen.
•
11 Microphone
12 Speaker
13 Power jack
14 Battery compartment cover
Open/closed sensor overview
P
P
P
P
P
P
P
P
P
P
P
P
1Latch button
Press to open the battery compartment
case.
•
2Back cover
3Pair button
Press and hold to pair to the baby unit.•
4LED light
Flashes when the sensor is pairing to
the baby unit.
•
5Battery compartment case
Parent unit display icons
Connection status
or display when strong signal
strength is detected between the
baby unit and the parent unit.
or display when weak signal
strength is detected between the
baby unit and the parent unit.
flashes when the link between the
baby unit and the parent unit is lost.
•
•
•
Battery status
animates when the
battery is charging.
displays solid when the battery is
fully charged.
displays when the battery is low
and needs charging.
•
•
•
Lullaby
Displays when the baby unit is
playing lullaby.
•
Sound alert
Displays when sound alert is turned
on.
Flashes when the baby unit detects
loud sound while sound alert is on.
•
•
Vibration
Displays when vibration is turned on.
Flashes when the parent unit vibrates.
•
•
High temperature alert
Displays when the temperature
